Summary of Contents for Onson J10C
- Page 1 尺寸：148*210mm 材质：128g铜版纸/骑马钉/黑色印刷 技术要求：印刷清晰，不得错印,露底，不得有污迹...
-
Page 3: Table Of Contents
Safety Instructions· ONSON IMPORTANT SAFETY INSTRUCTIONS READ ALL INSRUCTIONS BEFORE USING (THIS APPLIANCE) WARNING Directory Safety Instructions···································02 · ··········· Components of the product················04 Product Useage········································07 Product Maintenance····························11 Troubleshooting·····································12 Product Specification ···························15 SAVE THESE INSTRUCTIONS... -
Page 4: Components Of The Product
Components of the product 1.1 robot cleaner channel infrared collision sensor mechanical collision sensor ONSON start/ pause push button Bumper along wall in the left Along wall in the right direction infrared sensor direction infrared sensor Right infrared receiver sensor... - Page 5 1.2 other components of the product Remote control Module and time indication screen Charging dock Adapter Remote control Auto clean Recharging Direction and Start/pause time setting Clock setting Reservation to sweep Fixed time point sweep Sweeping along the side Dust box Rolling brush Filter sponge and high Random sweep...
-
Page 6: Product Useage
Product Useage Activate product Place robot onto the Charging Dock, making sure the metal charging contacts 2.1 quick start on the Charging Dock match up with those underneath the Robot. Connect the charging dock to the cable storage box at the bottom of the If successful you will hear a series of tones. - Page 7 Fixed point cleaning 2.3 Time and appointment are scheduled Fixed point sweep the fixed point sweep mode is selected. The cleaner concentrates on sweeping the partially local area by The cleaning time can be set on the cleaning time of the cleaner. The appointment timing function can be rotating outwardly in a spiral with a diameter of about 1m, and realized by the remote control.
-
Page 8: Product Maintenance
Product Maintenance Take the side brush. Clean the Clean roller brush. Remove the hair from 3.1Empty dust box side brush with a cloth brush. the roller brush with the provided cleaning Press the dust box Release button 2. Remove the cover of the dust box tool knife. -
Page 9: Troubleshooting
Remoter battery power load. Replace the new battery Email：customer@onson.shop and install correctly. Telephone：1-855-919-0908 Ensure that the power switch The power switch of the cleaner is not... -
Page 10: Product Specification
Product Type J10C Input 19 V 0.6 A Working voltage 14.4 V Rated power 28 W Battery type DC 14.4 V Li-ion 2600 mAh Dust box volume 0.5L Max cleaning time 20 mins Charging duration 300 - 360 mins...
