Hamilton Bed
NOTES:
• 2-person assembly
REQUIRED TOOLS:
Adjustable Wrench
ASSEMBLY INSTRUCTIONS
1.
Hold Headboard upright while attaching one side
rail to the headboard using (2) Spring Washers, (2)
Flat Washers, (2) 5/16"-18 x 1" Button Head Hex
Drive Screws and Allen Wrench. Repeat on other
side.
Headboard
STEP 1
Side Rail
INCLUDED TOOLS + HARDWARE:
5/16"-18 x 1"
Button Head Hex Drive
Screws (x8)
5/16"-18
Hex Nut (x6)
5/16"
Spring Washer (x14)
2.
Attach Footboard using (2) Spring Washers, (2)
Flat Washers, (2) 5/16"-18 x 1" Button Head Hex
Drive Screws and Allen Wrench. Repeat on other
side.
schoolhouse.com
1
5/16"-18 x 3/4"
Button Head Hex Drive
Screws (x4) twin, (x6) king, queen
5/16"
Flat Washer (x14)
Allen Wrench (x1)
STEP 2
Footboard
