Judy
NOTES:
Judy can be installed as a cabinet knob, drawer pull,
interior door knob, or as a hook at a non-stud or stud
location. Choose the appropriate installation option
below for your application.
REQUIRED TOOLS:
Electric Drill
Phillips Head Screwdriver
/
Drill Bit:
" for Installation Option A
3
16
/
" for Installation Option B
1
2
/
"for Installation Option C
1
16
INSTALLATION INSTRUCTIONS
OPTION A: CABINET KNOB, DRAWER PULL OR INTERIOR DOOR KNOB
Mark mounting location and drill through surface
1.
/
using
" Drill Bit
3
16
Select Machine Screw length based on material thick-
2.
ness of cabinet/drawer/door. Insert Machine Screw
through Lock Washer and into pre-drilled hole. Tight-
en using Phillips Head Screwdriver. Thread Judy
Mounting Plate onto Machine Screw.
Judy Mounting
Plate
INCLUDED HARDWARE:
#10-24 x 1" Machine
Screw (x1)
#10-24 x 2" Machine
Screw (x1)
#10 Split Lock
Washer (x1)
Thread Judy knob onto Judy mounting plate. Tighten
3.
by hand.
Knob
Split Lock
Washer
schoolhouse.com
1
#10-24 x 1
Screw (x1)
#6 x 2" Wood
Screw (x1)
Toggle Bolt with
#10-24 x 3" Machine
Screw (x1)
Judy
/
" Machine
3
4
