Philex 27815V User Manual

Installation

Before installation make sure your TV is switched
off. Select a location on the back of your TV
within comfortable reach of both a powered
USB socket and the "Antenna In" coax socket.
1. Using the sticky pads provided attach the
back of the booster housing to the location
selected on the back of the TV.
2. Connect the booster output lead to the
"Antenna In" socket on your TV, and
connect the lead from your aerial into the
booster aerial in socket.
3. Plug the booster USB lead into a powered
USB socket on the back of your TV and
switch on your TV.
Your antenna's signal strength will now boosted by
20dB.
Please Note: Make sure the booster does not
cover any vents or connector ports on your TV.

Specifications

Booster
27815V
1
In Out Frequency
1 1 88-694MHz
www.philex.com
Suitable
for
FM/DAB Radio
TV Ch 21-48
Freeview
