PuK Combi
Installation guide
1
Top side
of surface
1.1
Bottom side
of surface
1.
Position the mold on the top side of the
1
surface.
1.
Draw the shape to indicate the position
2
of the PuK Combi.
|
Page 2
PuK Combi installation guide
1.2
157x81 mm
Included items
a
PuK Combi
Power
b
adapter
c
Mounting
set
Installation
d
mold
|
Page 1
PuK Combi installation guide
2
157x81 mm
Use the jigsaw and follow the drawn
lines to cut out the correct shape.
|
Page 3
PuK Combi installation guide
Required tools
(not included)
e
Jigsaw
Screw
f
driver
g
Pencil or
pen
Measuring
h
tool
