Instructions – Parts List
Airless Spray Gun
Model 206408, Series H
3000 psi (21.0 MPa, 210 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001
Parts
306796G
7414A
