- Page 1 Instruction Manual Undermount Rangehood ORU52GLED ORU90GLED...
- Page 2 Thank you for purchasing an Omega appliance Tailored for the modern aesthetic and lifestyle of busy people, your new Omega Appliance will make a welcome addition to the family. Omega caters to style-savvy customers who look for balance between stunning form and clever function.
-
Page 3: Table Of Contents
The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. Due to continual product development, Omega reserves the right to alter specifications and appearances without notice. -
Page 4: Important Safety Warnings
CAUTION: Accessible parts may become hot when used with cooking appliances. Warning: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. Appliance Details ORU52GLED ORU90GLED Voltage Rating 220 – 240V ~50Hz Voltage Rating 220 –... -
Page 5: Installation Instructions
750mm. Cut a hole in the underside of the cabinet, with the dimensions being 500x275 (mm) for ORU52GLED and 880x275 (mm) for ORU90GLED. Ensure that there is a clearance of 35mm between the edges of the hole and the sides of the cupboard. -
Page 6: Operating Instructions
Installation Instructions Tips for Exhaust Duct Installation The following rules should be strictly followed to obtain optimal air extraction: • Keep the expansion pipe short and straight. • Do not reduce the diameter or restrict the expansion pipe. • When using the expansion pipe, always install the pipe pulled taut to minimize pressure loss. Not following these instructions will reduce the performance and increase noise levels of the rangehood. -
Page 7: Maintenance And Cleaning
Maintenance and Cleaning Note: Any electrical repairs to this appliance must conform to your local, state and federal laws. Please contact the service centre if in any doubt before undertaking any of the above. Always disconnect the unit from the power source before opening the unit. External surfaces are susceptible to scratches and abrasions, so please follow the cleaning instructions to ensure the best possible result is achieved without damage. -
Page 8: Replacing The Led Panels
Take out the LED panel and replace it. 3. Apply the reverse procedure to install the new LED panel. Ensure that you use an exact match for the original LED panel. ORU52GLED ORU90GLED • ILCOS D code: DSS-15/65-S-340/160 •... -
Page 9: Troubleshooting
Troubleshooting Fault Possible Cause Solution Fan switch turned off. Select a fan switch position. Light on, but motor Fan switch failed. Contact service center. does not work Motor failed. Contact service center. House fuses blown. Reset/Replace fuses. Light does not work; Mains power cable is loose or Refit mains power cable to power outlet. -
Page 10: Australian & New Zealand Product Warranty Statements Of Standard Warranty Conditions
The Damage which occurs during delivery or installation. product will be repaired or replaced at the option of Omega, and 10. Claims to product surface coating due to liquid or solid all costs of installation, removal, cartage, freight travelling spill-overs, accidental damage or damage caused from expenses and insurance are to be paid by the customer.
