Summary of Contents for Olympus iSnap
- Page 2 INSTRUCTIONS Read this manual carefully before using your camera.
- Page 3 WARNING Indicates circumstances under which mishandling resulting from ignoring this symbol could result in personal injury or property damage. KEEP THE BATTERIES AWAY FROM FIRE. NEVER TRY TO DISASSEMBLE, RECHARGE, OR SHORT-CIRCUIT BATTERIES. KEEP THE BATTERY OUT OF THE REACH OF CHILDREN. IF A CHILD SWALLOWS A BATTERY, CONTACT A DOCTOR IMMEDIATELY.
- Page 4 THE CAMERA; IT CONTAINS A HIGH- VOLTAGE CIRCUIT. IF THE INTERNAL PARTS OF THE CAMERA ARE EXPOSED DUE TO DROPPING OR DAMAGE, REMOVE THE BATTERIES IMMEDIATELY TO PREVENT FURTHER USAGE. IN CASE OF MALFUNCTION, CONSULT YOUR NEAREST OLYMPUS DEALER OR OLYMPUS SERVICE CENTER.
-
Page 5: Table Of Contents
Names of parts ... 5 Cartridge ... Loading the battery ... 8 Loading the cartridge film ... 10 Taking pictures ... 11 Flash photography ... 12 Unloading the cartridge film ... 13 Care and storage ... 14 Specifications... 18... -
Page 6: Names Of Parts
NAMES OF PARTS Shutter release button Viewfinder AE light sensor* Red-eye reduction lamp Flash* Lens* Lens barrier switch Cartridge cover release *Do not soil as this can cause blurred pictures. Wipe clean with a soft cloth. - Page 7 Battery check lamp Flash ready lamp Viewfinder Exposure counter Strap eyelet Cartridge cover Mid-roll rewind button Battery compartment cover Battery compartment cover release Attach the strap as shown.
-
Page 8: Cartridge
CARTRIDGE IX240 Cartridge Film Visual Exposure Indicator • Only cartridges with the (unexposed) visual exposure indicator can be used with this camera. • When a cartridge with other than the visual exposure indicator is loaded, the camera will rewind the film and set the cartridge to (exposed). -
Page 9: Loading The Battery
LOADING THE BATTERY Use one 3V lithium battery (CR2). 1. Slide the battery compartment cover release and open the cover 2. Load the battery and align the ends correctly. 3. Slide the lens barrier switch turn the camera on. If the battery check lamp starts blinking replace the battery About 15 rolls of... - Page 10 Battery Handling • Observe the precautionary remarks written on the batteries. • When the camera is not used for an extended period of time, remove the battery. • Keep spare batteries on hand when going on a long trip or to a cold area. •...
-
Page 11: Loading The Cartridge Film
LOADING THE CARTRIDGE FILM Use unexposed negative-color IX240 cartridge film (ISO 100~400). 1. Make sure that is displayed on the camera's exposure counter. Turn the cartridge cover release open the cartridge cover 2. Insert a cartridge with the (unexposed) visual exposure indicator and close the cartridge cover .The film will automati-... -
Page 12: Taking Pictures
TAKING PICTURES 1. Slide the lens barrier switch turn the camera on. 2. Press the shutter release button halfway to make sure the flash ready lamp lights. •When the flash ready lamp blinking, the flash is being recharged and the shutter cannot be released. -
Page 13: Flash Photography
FLASH PHOTOGRAPHY Check the flash ready lamp. Blinking: The flash is recharging, and the shutter cannot be released. Lit: The flash is charged. Shooting is possible. Red-eye reduction lamp This lamp helps to reduce the red-eye effect with flash pictures. The red-eye reduction lamp lights when the shutter release button is pressed lightly. -
Page 14: Unloading The Cartridge Film
UNLOADING THE CARTRIDGE FILM 1. The film will be rewound automatically when the end of the roll is reached . Even when the film is rewound, the number in the exposure counter remains the same. 2. Wait until the motor stops. Ensure that the two lamps beside the viewfinder are blinking. -
Page 15: Care And Storage
CARE AND STORAGE 1. Do not leave the camera in any place exposed to excessive heat, humidity, or direct sunlight — for example, in a car or on the beach. 2. Do not expose the camera to formalin or naphthalene. 3. - Page 16 5. Do not leave the camera on or near a television, refrigerator, or other appliance with a magnetic field. 6. Do not expose the camera to dust or sand as this could cause serious damage. 7. Do not shake or shock the camera. •...
- Page 17 • When transporting the camera from a cold place to a warm place or in the event of a sudden temperature change, put the camera into a plastic bag. This allows the camera's temperature to change slowly. Once the camera has adjusted to the new temperature, you can remove it from the bag and use it.
- Page 18 • Avoid leaving the camera unused for long periods of time. This can cause mold to grow on the camera as well as other problems. Try to press the shutter release button and check the operation of the camera before use. •...
-
Page 19: Specifications
Type: Fixed-focus lens-shutter camera. Film format: IX240 cartridge film, Image size: 16.7 x 30.2 mm. Print type: C type only. Lens: Olympus lens, 24 mm F7, 3 elements in 3 groups. Shutter: Programmed electronic shutter (1/200 ~1/50 sec). Viewfinder: Albada viewfinder 0.33X magnification. - Page 20 Film loading: One-touch insertion, automatic loading (automatically advanced to first frame when cartridge cover is closed). Film advance: Automatic film winding. Film rewind: Automatic rewind at end of roll. Mid-roll rewind also possible. Flash: Built-in flash with red-eye reduction lamp. Flash is automatically activated in low- light conditions.
- Page 21 OLYMPUS OPTICAL CO.,LTD. San-Ei Building, 22-2, Nishi Shinjuku 1 -chome, Shinjuku-ku, Tokyo, Japan. Tel. 03-3340-2211 OLYMPUS AMERICA INC. Two Corporate Center Drive, Melville, NY 11747-3157, U.S.A. Tel. 1 -800 "O" CAMERA(622-6372) OLYMPUS OPTICAL CO. (EUROPA) GMBH. (Premises/Goods delivery) Wendenstrasse 14-18,20097 Hamburg, Germany. Tel. 040-237730 OLYMPUS SINGAPORE PTE.
- Page 22 A 0201 63239-400-OLY CS0443-...
