Uninterruptible Power System (UPS)
Technical Specifications
PART 1 GENERAL
1.1 SUMMARY
A. This specification describes a single phase, on-line, double conversion, solid state Uninter-
ruptible Power System utilizing Patented ECM Technology here after referred to as the UPS.
The UPS shall operate in conjunction with the existing electrical system to provide high quality
power conditioning, back-up power protection and distribution for Lighting loads and other
critical loads. T he system shall consist of a solid-state inverter, a temperature compensated
rectifier/battery charger, a 100% rated for continuous duty static switch, an internal maintenance
bypass switch, battery plant, status/control panel, and synchronizing circuitry. The enclosure is
a Nema 3R (outdoor) rain / weather resistant enclosure designed for outdoor environmental
conditions as described herein.
1.2 STANDARDS
A. The UPS shall meet the requirements of the following standards:
1. IEEE 587-1980/ANSI C62.41 1980 Standards for Surge Withstand
Ability
2. FCC rules and regulations of Part 15, Subpart J, Class A
3. Listed under UL 924, Standards for Lighting Inverter Equipment
4. NEMA PE 1 (National Electrical Manufacturers Association) -
Uninterruptible Power Systems
5. NEMA 250 (National Electrical Manufacturers Association) – Enclosures
for Electrical Equipment (1000 Volts Maximum)
6. NFPA 70 – National Electrical Code
7. ISO 1001
8. Occupational Safety & Health Administration (OSHA)
Title: Micro
01
Doc No.: 018-1000-02
Description: Emergency Lighting Inverter User's Manual
Phone :
Fax:
Rev: NR
Website:
Date: 07/26/2016
E-Mail:
1.877.DSPM.POWER
-
1.877.377.6769
909.930.3335
www.dspmanufacturing.com
techsupport@dspmanufacturing.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DSPM Power Lynx 1
Summary of Contents for DSPM Power Lynx 1
- Page 1 Power Lynx 1 Uninterruptible Power System (UPS) Technical Specifications PART 1 GENERAL 1.1 SUMMARY A. This specification describes a single phase, on-line, double conversion, solid state Uninter- ruptible Power System utilizing Patented ECM Technology here after referred to as the UPS.
- Page 2 All semiconductor devices shall be sealed. All relays shall be provided with dust covers. The manufacturer shall conduct inspections on incoming parts, modular assemblies and final products. Phone : 1.877.DSPM.POWER 1.877.377.6769 Title: Micro Fax: 909.930.3335 Doc No.: 018-1000-02...
-
Page 3: Environmental Requirements
(18) months from date of shipment from the manufacturer, whichever occurs first. B. Battery: The battery manufacturer’s warranty shall be passed through to the final customer and shall have a minimum period of one year, with 4 years prorated warranty. Phone : 1.877.DSPM.POWER 1.877.377.6769 Title: Micro Fax: 909.930.3335... -
Page 4: Product Specification
PART 2 PRODUCTS 2.1 ACCEPTABLE MANUFACTURERS/PRODUCT A. DSPM Power Lynx 1 Outdoor Emergency Lighting System B. Engineer permits substitutions, subject to meeting all the requirements of this specification and having written approval no less than 10 days prior to bid closing. - Page 5 (store in memory) any alarms and make available through the front panel LCD all information. The RS 232 / 485 will also make information available. The system will monitor all working parameters before, during and after testing. Phone : 1.877.DSPM.POWER 1.877.377.6769 Title: Micro Fax: 909.930.3335...
-
Page 6: Modes Of Operation
A. Rectifier / Battery Charger: Incoming AC power shall be converted to a regulated DC output voltage. The rectifier / battery charger shall provide high quality DC power to charge the bat- teries and power the inverter and shall have the following characteristics: Phone : 1.877.DSPM.POWER 1.877.377.6769 Title: Micro Fax: 909.930.3335... - Page 7 All operation and parameters are firmware controlled. The logic shall include a self-test and diagnostic circuitry such that a fault can be isolated down to the print- ed circuit assembly or plug-in power assembly level. Phone : 1.877.DSPM.POWER 1.877.377.6769 Title: Micro Fax: 909.930.3335...
-
Page 8: System Controls And Indicators
Load on battery f. Load on UPS g. Load on automatic bypass h. Low-battery warning i. General alarm j. Additional indications shall provide maintenance assistance Phone : 1.877.DSPM.POWER 1.877.377.6769 Title: Micro Fax: 909.930.3335 Doc No.: 018-1000-02 Rev: NR Website: www.dspmanufacturing.com... - Page 9 C. Ventilation and Heat Rejection: The UPS shall be designed for forced aircooling. Air inlets shall be provided from the front bottom of the UPS enclosure. Air exhaust shall be from the top or side portions of the unit. Phone : 1.877.DSPM.POWER 1.877.377.6769 Title: Micro Fax: 909.930.3335...
- Page 10 3.2 MAINTENANCE TRAINING A. The manufacturer shall make available to the customer various levels of training ranging from basic UPS operation to UPS maintenance. END OF SECTION Phone : 1.877.DSPM.POWER 1.877.377.6769 Title: Micro Fax: 909.930.3335 Doc No.: 018-1000-02...
