HQUA
Instruction Manual
For Spa Light
HQUA-PN02DC

Section 1 Safety Information

Electrical Safety
Negligence to these instructions may result in serious injury or death.
Always disconnect the power to the spa light at the circuit breaker before
servicing the light. Failure to do so could result in death or serious injury due to
the electrical shock.
Grounding Plug
• This product use
12V-15V AC
as the power source, which must be grounded and
protected by a ground-fault circuit interrupter (GFCI) to reduce the risk of electrical shock.
Contact a qualified electrician if you cannot verify that the receptacle is protected by a
GFCI.
• Do not use an appliance leakage current interrupter (ALCI) in place of a GFCI since the
ALCI will not protect people.
Electric Shock

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HQUA-PN02DC and is the answer not in the manual?

Questions and answers

Related Manuals for HQUA HQUA-PN02DC

Summary of Contents for HQUA HQUA-PN02DC

  • Page 1: Section 1 Safety Information

    HQUA Instruction Manual For Spa Light HQUA-PN02DC Section 1 Safety Information Electrical Safety Negligence to these instructions may result in serious injury or death. Always disconnect the power to the spa light at the circuit breaker before servicing the light. Failure to do so could result in death or serious injury due to the electrical shock.

  • Page 2: Section 2 General Information

    Section 2 General Information HQUA-PN02DC is a dimmable and color changing pool/spa LED light, which is easy to install and safe to use. Fit for 6 inches standard small wet niche. Replace the old fixture with this LED light.
  • Page 3 need higher voltage input depending on the length of the cords. 0-30’ electric cord only needs 12V AC input. 30-60’ needs 13V AC input. 60’-100’ needs 14V AC input.100’ needs 15 AC input. The voltage on the LED board would be 12V DC, which is not harmful for human body at all.
  • Page 4 2.2 Specification Item White Color Wattage Volts Dimmable Name Luminous flux Changing PN02DC 12V-15V AC 1250lm 2.3 Installation Precaution Keep people out of the spa pool when you operate the installation. Always turn off the main electrical switch or circuit breaker. 1.
  • Page 5 Brown to R Half Yellow Half Green to G Blue to B Black to W Grey to V+ Figure 3. 5. Roll remain electric cords around the LED light assembly, put it into the wet niche. Screw on the face ring to secure the light assembly into the niche. Figure 4. Figure 4.
  • Page 6 Figure 5. The Instruction of the Control Modes: Mode Mode White GREEN 3-Colors Jump Change Blue 7-Colors Jump Change Yellow 3-Colors Flashing Purple 7-Colors Flashing Cyan Black In Mode 1-7 : “+” and “–“ control the brightness In Mode 8-11: “+” and “–“ control the changing speed When there is no operation about 30 secs, the controller will fall into sleep to save power.
  • Page 7 The Converter/Receiver M4-3A and Remote Controller M4 are already paired. If you find the connection is failed. You might need to reset the connection: 1. Press the pair button for over 5 seconds. It would delete the pair. 2. Click the pair button for a short time, the operating indicator would keep working, click any button on the remote controller M4.

  • Page 8: Section 3 Troubleshooting

    The LED pool light does not light Check the connection part in step Loose Connection. up at the beginning. The LED pool light is Contact HQUA for more help. damaged somehow. The power cord is Check the wiring connection first loose.

  • Page 9: Section 4 After-Sales Service

    Should you need any support, or have any questions about the system, please contact our Technical Support team via hqua.tech@gmail.com we will be glad to assist you. We sincerely hope that you enjoy the benefits of bright and safe pool/spa illumination with HQUA inground swimming pool/spa light.
  • Page 10 HQUA warrants that the LED spa light is free from defects of material and workmanship for a period of 2 years from the date of purchase. During this period, HQUA will repair or replace, at its option, any defective parts covered by the warranty. Please return the defective part to your dealer for claim.

  • Page 11: Part Number List

    Part Number List Part Number Description PN02DCL RGBW Led Light Assembly 15W,12V AC/DC PN01CS M4-3A Control System PN01CS01 M4 Remote Controller PN01CS02 M4-3A Control Receiver PN02CS03 Waterproof Junction Box for M4-3A Receiver PN01DCC 5C×22 AWG,100’ Weatherproof Electric Cord Accessories PN1001 #10-24 x 1-1/4 in.
