Summary of Contents for Steren LAM-010

  • Page 2 IMPORTANTE Antes de utilizar su nuevo Kit C Antes de utilizar su nueva Lámpara de emergencia por favor lea las siguientes recomendaciones • No use ni almacene este equipo en lugares donde existan goteras o salpicaduras de agua. Puede causar un mal funcionamiento o un choque eléctrico.
  • Page 3 CONTROLES 1.- Botón de prueba. 2.- Selector de intensidad. de una lámpara, dos lámparas o apagado (off). 3.- Indicador de batería (Battery) 4.- Indicador de carga (Charge) 5.- Agarradera. 6.- Cable de alimentación. ESPAÑOL-03...
  • Page 4 INSTALACIÓN Y FORMA DE USO 1.- Inserte el cable de alimentación de la lámpara en un tomacorriente casero. 2.- El indicador de carga se enciende. 3.- Para realizar una prueba de funcionamiento siga los siguientes pasos: Mueva el interruptor a la posición de UNA sóla lámpara y presione el botón de Prueba (Test), deberá...
  • Page 5 5.- Si desea apagar la lámpara manualmente solo mueva el interruptor de intensidada a la posición OFF. Antes de utilizar su nuevo Kit C Para que la lámpara se encienda automáticamente cuando suceda una falla eléctrica, deberá estar conectada permanentemente a un tomacorriente.
  • Page 6: Especificaciones

    ESPECIFICACIONES Entrada: 110/220V~ 50/60Hz 4W max Batería: 6V - - - 4Ah Duración: 6 Horas Dimensiones: 410 x 76 x 85mm Antes de utilizar su nuevo Kit C El diseño del producto y las especificaciones pueden cambiar sin previo aviso. ESPAÑOL-06...
  • Page 7: Póliza De Garantía

    1.- Para hacer efectiva la garantía, presente ésta póliza y el producto, en donde fue adquirido o en Electrónica Steren S.A. de C.V. 2.- Electrónica Steren S.A de C.V. se compromete a reparar el producto en caso de estar defectuoso sin ningún cargo al consumidor. Los gastos de transportación serán cubiertos por el proveedor.
  • Page 8 Biólogo MaximIno Martínez No. 3408 Int. 3 y 4, San Salvador Xochimanca, México, D.F. 02870, RFC: SPE941215H43 ELECTRONICA STEREN DEL CENTRO, S.A. DE C.V. Rep. del Salvador 20 A y B, Centro, 06000, México. D.F. RFC: ESC9610259N4 ELECTRONICA STEREN DE GUADALAJARA, S.A.
  • Page 10 IMPORTANT Antes de utilizar su nuevo Kit C Before using your new Fluorescent emergency lamp, please read the following recommendations. • Do not use or store the equipment near wet places. May cause malfunction or electrical shock. • Do not try to open the equipment, may cause malfunction and warranty repeal.
  • Page 11 CONTROLS 1.- Test button 2.- Intensity button one lamp, two lamp or off 3.- Battery LED 4.- Charge LED 5.- Holder. 6.- Power cord ENGLISH-03...
  • Page 12: Installation And Use

    INSTALLATION AND USE 1.- Plug the lamp’s power cord into an AC household outlet. 2.- The charge LED lights on. 3.- To make a test follow the next steps: Place the switch in the position of ONE lamp , then press Test button, only one lamp will be turn on.
  • Page 13 5.- If you want to turn off manually, move the switch to off position Antes de utilizar su nuevo Kit C If you want to turn the lamp on automatically during an electrical outage, plug the emergency lamp into an AC household outlet permanently.
  • Page 14: Specifications

    SPECIFICATIONS Input 110/220V~ 50/60Hz 4W Battery 6V - - - 4Ah Duration 6 hours Dimensions 16,1 x 2,9 x 3,3in Antes de utilizar su nuevo Kit C Product design and specifications subject to change without previous notice. ENGLISH-06...
  • Page 15: Warranty

    Part number: LAM-010 Brand: Steren WARRANTY This Steren product is warranted under normal usage against defects in workmanship and materials to the original purchaser for one year from the date of purchase. CONDITIONS 1.- This warranty card with all the required information, invoice or purchase ticket, product box or package, and product, must be presented when warranty service is required.
  • Page 16 RETAILER INFORMATION Name of the retailer Address Product Brand Part number Serial number Date of delivery In case your product fails or have questions, please contact your nearest dealer. If you are in Mexico, please give a call to our Call Center. Call Center 01 800 500 9000...
