Download
Share
Print this page
Wolf M Series Design Manual
  1. Manuals
  2. Brands
  3. Wolf Manuals
  4. Oven
  5. M Series
  6. Design manual

Wolf M Series Design Manual

Hide thumbs Also See for M Series:

Advertisement

Quick Links

Download this manual
D E S I G N G U I D E
IC B R E V I SE D 1 / 2 01 7

Advertisement

loading
Need help?

Need help?

Do you have a question about the M Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wolf M Series

Summary of Contents for Wolf M Series

  • Page 1 D E S I G N G U I D E IC B R E V I SE D 1 / 2 01 7...
  • Page 2 T A B L E O F C O N T E N T S B U I L T- I N O V E N S M I C R O W A V E O V E N S W A R M I N G D R A W E R S C O O K T O P S | M O D U L E S C O F F E E S Y S T E M S | C U P W A R M I N G D R A W E R S...
  • Page 3 There is more usable space inside for deliciousness on a grand scale. M series ovens can be installed in a standard or flush inset application. ICBSO30TM/S/TH ICBDO30TM/S/TH...
  • Page 4 M S ER IE S O VE NS M Series Built-In Ovens TR ANSIT IO N AL SIN G L E O V E N 46 mm 51 mm 36 mm CONDUIT CHANNEL 759 mm 584 mm BEHIND FRAME OPEN OVEN DOOR...
  • Page 5 M S ER IE S O VE NS M Series Built-In Ovens PRO F ES SIO NA L S IN G L E O V E N 46 mm 51 mm 36 mm CONDUIT CHANNEL 759 mm 584 mm BEHIND FRAME...
  • Page 6 M S ER IE S O VE NS M Series Built-In Ovens CONTEMP O R ARY SIN G L E O V E N— STA IN L E S S ST EEL 46 mm 36 mm CONDUIT CHANNEL 759 mm...
  • Page 7 M S ER IE S O VE NS M Series Built-In Ovens CONTEMP O R ARY SIN G L E O V E N— B L AC K G LA SS 46 mm 51 mm 36 mm CONDUIT CHANNEL 759 mm...
  • Page 8 M S ER IE S O VE NS Planning Information The M series oven can be installed in a standard or flush E L EC TR IC AL inset application. If a cooktop is being installed above an Installation must comply with all applicable electrical codes oven, a minimum of 6 mm is required between units.
  • Page 9 M S ER IE S O VE NS M Series Single Oven S TAND AR D INSTAL L AT ION 591 mm OPENING DEPTH TOP VIEW 699 mm OPENING HEIGHT OPENING WIDTH SIDE VIEW FRONT VIEW NOTE: Location of electrical supply within opening may require additional cabinet depth.
  • Page 10 M S ER IE S O VE NS M Series Double Oven S TAND AR D INSTAL L AT ION 591 mm OPENING DEPTH TOP VIEW 1267 mm OPENING HEIGHT OPENING WIDTH 432 mm TYPICAL SIDE VIEW FRONT VIEW NOTE: Location of electrical supply within opening may require additional cabinet depth.
  • Page 11 M S ER IE S O VE NS M Series Single Oven FLUS H IN SE T IN STAL L AT I O N 22 mm 610 mm FLUSH INSET 25 mm DEPTH FINISHED CLEATS* TOP VIEW FLUSH INSET WIDTH***...
  • Page 12 M S ER IE S O VE NS M Series Double Oven FLUS H IN SE T IN STAL L AT I O N 22 mm 610 mm FLUSH INSET 25 mm DEPTH FINISHED CLEATS* TOP VIEW FLUSH INSET WIDTH***...
  • Page 13 MODE TIMER TIME modes, with Wolf’s innovative dual convection in single ovens and in the upper unit of double ovens. Wolf E series ovens are crafted of stainless steel. Tubular handles have ICBSO2418TE/S/TH ICBSO24TE/S/TH been updated to match the rest of the new Wolf cooking appliance offering, providing a more cohesive look.
  • Page 14 E SER IES O VEN S 60 cm E Series Ovens MODE L IC B SO 24 18T E / S / T H TR A NS I TI O NA L S I N GLE OV EN 22 mm 538 mm WATER LIGHT...
  • Page 15 E SER IES O VEN S 76 cm E Series Ovens TR ANSIT IO N AL SIN G L E O V E N 25 mm 76 mm CONDUIT CHANNEL 718 mm 759 mm 603 mm BEHIND FRAME OPEN OVEN DOOR TR ANSIT IO N AL DO U B L E O VE N 25 mm 76 mm...
  • Page 16 E SER IES O VEN S 76 cm E Series Ovens PRO F ES SIO NA L S IN G L E O V E N 25 mm 76 mm CONDUIT CHANNEL 718 mm 759 mm 603 mm BEHIND FRAME OPEN OVEN DOOR PRO F ES SIO NA L DO U BL E O V E N 25 mm...
  • Page 17 E SER IES O VEN S 76 cm E Series Ovens CONTEMP O R ARY SIN G L E O V E N 32 mm 76 mm CONDUIT CHANNEL 718 mm 759 mm 603 mm BEHIND FRAME OPEN OVEN DOOR CONTEMP O R ARY DO U B L E O VE N 32 mm 76 mm...
  • Page 18 E SER IES O VEN S Planning Information The E series oven can be installed in a standard or flush E L EC TR IC AL inset application. If a cooktop is being installed above an Installation must comply with all applicable electrical codes oven, a minimum of 6 mm is required between units.
  • Page 19 E SER IES O VEN S 60 cm E Series Oven S TAND AR D INSTAL L AT ION 572 mm OPENING DEPTH TOP VIEW OPENING HEIGHT 562 mm OPENING WIDTH SIDE VIEW FRONT VIEW NOTE: Electrical supply must be located in adjacent cabinet within .9 m of opening. O PE N ING H EIGHT Model ICBSO2418TE/S/TH 449 mm...
  • Page 20 E SER IES O VEN S 76 cm E Series Single Oven S TAND AR D INSTAL L AT ION 610 mm OPENING DEPTH TOP VIEW 692 mm 724 mm OPENING HEIGHT OPENING WIDTH SIDE VIEW FRONT VIEW NOTE: Location of electrical supply within opening may require additional cabinet depth. Dashed line represents profile of unit.
  • Page 21 E SER IES O VEN S 76 cm E Series Double Oven S TAND AR D INSTAL L AT ION 610 mm OPENING DEPTH TOP VIEW 1264 mm 724 mm OPENING HEIGHT OPENING WIDTH 432 mm TYPICAL SIDE VIEW FRONT VIEW NOTE: Location of electrical supply within opening may require additional cabinet depth.
  • Page 22 E SER IES O VEN S 60 cm E Series Oven FLUS H IN SE T IN STAL L AT I O N 584 mm FLUSH INSET 22 mm DEPTH FINISHED CLEATS* TOP VIEW 13 mm FLUSH INSET HEIGHT** 24 mm 6 mm 610 mm FLUSH INSET WIDTH**...
  • Page 23 E SER IES O VEN S 76 cm E Series Single Oven FLUS H IN SE T IN STAL L AT I O N 25 mm 635 mm FLUSH INSET 32 mm DEPTH FINISHED CLEATS* TOP VIEW 772 mm FLUSH INSET WIDTH*** 19 mm 721 mm FLUSH INSET...
  • Page 24 E SER IES O VEN S 76 cm E Series Double Oven FLUS H IN SE T IN STAL L AT I O N 25 mm 635 mm FLUSH INSET 32 mm DEPTH FINISHED CLEATS* TOP VIEW 772 mm FLUSH INSET WIDTH*** 19 mm 1292 mm FLUSH INSET...
  • Page 25 Wolf convection steam oven—with more control. Two P ROFESSION AL widths and three distinct styles compliment the look of Wolf ovens, ranges and cooktops. Convection steam ovens can be installed in a standard or flush inset application.
  • Page 26 CONVECT IO N STE AM O VE NS Convection Steam Ovens TR ANSIT IO N AL 22 mm 538 mm 546 mm WIDTH BEHIND FRAME OPEN OVEN DOOR W ID T H 60 cm Model 597 mm 76 cm Model 759 mm PRO F ES SIO NA L 22 mm...
  • Page 27 CONVECT IO N STE AM O VE NS Planning Information The convection steam oven can be installed in a standard E L E C TR I C A L or flush inset application. The electrical supply for the oven Installation must comply with all applicable electrical codes must be located in an adjacent cabinet.
  • Page 28 CONVECT IO N STE AM O VE NS Convection Steam Oven S TAND AR D INSTAL L AT ION 548 mm OPENING DEPTH TOP VIEW 449 mm OPENING HEIGHT OPENING WIDTH SIDE VIEW FRONT VIEW NOTE: Both 60 cm and 76 cm models require the same opening dimensions. Electrical supply must be located in adjacent cabinet within .9 m of opening.
  • Page 29 CONVECT IO N STE AM O VE NS Convection Steam Oven FLUS H IN SE T IN STAL L AT I O N 584 mm FLUSH INSET 25 mm DEPTH FINISHED CLEATS* TOP VIEW 8 mm 460 mm FLUSH INSET HEIGHT** 3 mm FLUSH INSET WIDTH**...
  • Page 30 New drop down T RAN SITION AL door microwaves feature a door that hinges at the bottom. Drop down door microwaves are designed to match Wolf transitional, professional and contemporary products. Microwave ovens can be installed in a standard or flush inset application.
  • Page 31 MI CR O WAVE O VE N S Drop Down Door Microwave Ovens TR ANSIT IO N AL 22 mm 538 mm 546 mm WIDTH BEHIND FRAME OPEN OVEN DOOR W ID T H 60 cm Model 597 mm 76 cm Model 759 mm PRO F ES SIO NA L 22 mm...
  • Page 32 MI CR O WAVE O VE N S Planning Information Electrical Installation must comply with all applicable electrical codes DRO P D O WN DO O R MIC RO WAVE and be properly grounded (earthed). The drop down door microwave oven can be installed in a standard or flush inset application.
  • Page 33 MI CR O WAVE O VE N S Drop Down Door Microwave Oven S TAND AR D INSTAL L AT ION 548 mm OPENING DEPTH TOP VIEW 449 mm OPENING HEIGHT OPENING WIDTH SIDE VIEW FRONT VIEW NOTE: Both 60 cm and 76 cm models require the same opening dimensions. Dashed line represents profile of unit.
  • Page 34 MI CR O WAVE O VE N S Drop Down Door Microwave Oven FLUS H IN SE T IN STAL L AT I O N 584 mm FLUSH INSET 25 mm DEPTH FINISHED CLEATS* TOP VIEW 8 mm 460 mm FLUSH INSET HEIGHT** 3 mm...
  • Page 35 You can adjust the M | E SERIES temperature, keeping moist foods moist and crisp foods crisp. Warming drawers are ideal for proofing dough. Drawer fronts are available to match the look of Wolf ovens and TRANSITIONAL PROFESSIONAL CONTEMPORARY sealed burner rangetops.
  • Page 36 Dimensions for the warming drawer remain the same, even though the drawer front may be wider to match a Wolf 91 cm oven or sealed burner rangetop. OPEN DRAWER...
  • Page 37 WA RMING DR AW E RS Planning Information The warming drawer must be installed with a Wolf drawer E L EC TR IC AL front, avail able through an authorized Wolf dealer. Specific Installation must comply with all applicable electrical codes installation instructions are included with the drawer front.
  • Page 38 WA RMING DR AW E RS Warming Drawer S TAND AR D INSTAL L AT ION 584 mm OPENING DEPTH TOP VIEW ANTI-TIP BLOCK 232 mm OPENING HEIGHT 727 mm OPENING WIDTH SIDE VIEW FRONT VIEW NOTE: Location of electrical supply within opening may require additional cabinet depth. English...
  • Page 39 *Will be visible and should be finished to match cabinetry. **Dimension provides minimum reveals. NOTE: Location of electrical supply within opening may require additional cabinet depth. DRAW ER FR ON T DEPTH (A ) M SERIES E SERIES Transitional | Professional 22 mm...
  • Page 40 I N D U C TI ON C OO K TOP S wasted heat. Induction cooking has been popular among T RAN SITION AL European chefs and homeowners for decades. Now Wolf leads the way in bringing this remarkable technology to North American kitchens. Its secret is magnetism. Electro- magnetic elements cause iron and magnetic stainless cook- ware to heat up instantly and with perfectly distributed heat.
  • Page 41 IN DUC TI O N CO OK T O PS Induction Cooktops 38 c m TR ANSI TI O NAL 6 0 c m T R AN SI TI O N AL 7 6 c m TR AN S I TIO N A L 600 mm 762 mm 381 mm...
  • Page 42 203 mm 2100 | 3000 boost recessed area surrounding the cooktop cut-out must be 76 cm C OOKTOP provided. Wolf downdraft systems cannot be used with 279 mm 2600 | 3150 boost contemporary induction cooktops. 203 mm...
  • Page 43 IN DUC TI O N CO OK T O PS 38 cm Induction Cooktop S TAND AR D INSTAL L AT ION 64 mm 64 mm COUNTERTOP CUT-OUT 914 mm FLOOR TO COUNTERTOP SIDE VIEW FRONT VIEW NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces, combustible materials cannot be located within this area.
  • Page 44 IN DUC TI O N CO OK T O PS 60 cm | 76 cm | 91 cm Induction Cooktop S TAND AR D INSTAL L AT ION 64 mm WIDTH 64 mm COUNTERTOP CUT-OUT 114 mm 89 mm 254 mm 914 mm FLOOR TO COUNTERTOP...
  • Page 45 IN DUC TI O N CO OK T O PS 60 cm | 76 cm | 91 cm Induction Cooktop FLUS H IN STA LLAT IO N 64 mm COUNTERTOP PROFILE 537 mm CUT-OUT WIDTH RECESS RECESS 8 mm 40 mm 64 mm COUNTERTOP CUT-OUT 114 mm...
  • Page 46 GAS CO O KT O P S Gas Cooktops Like their oven counterparts, the new generation of Wolf gas GA S C O OK TO P S cooktops features three new looks—transitional, profes- T RAN SITION AL sional and contemporary. New performance enhancements make delicious results even more of a certainty than ever.
  • Page 47 GAS CO O KT O P S Gas Cooktops 38 c m TR ANSI TI O NAL 7 6 c m T R AN SI TI O N A L 9 1 c m TR A N S I TI ON A L 762 mm 914 mm 102 mm...
  • Page 48 LP gas. Locate the electrical supply as shown in the illustration Wolf natural gas cooktops will function up to 3124 m in alti- on the following pages. A separate circuit, servicing only tude without adjustment and LP gas cooktops will function this appliance is required.
  • Page 49 GAS CO O KT O P S 38 cm Transitional Gas Cooktop S TAND AR D INSTAL L AT ION 64 mm 64 mm COUNTERTOP CUT-OUT SIDE VIEW FRONT VIEW NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces, combustible materials cannot be located within this area.
  • Page 50 GAS CO O KT O P S 76 cm | 91 cm Transitional | Professional Gas Cooktop S TAND AR D INSTAL L AT ION 64 mm WIDTH 64 mm COUNTERTOP CUT-OUT 102 mm 89 mm 254 mm SIDE VIEW FRONT VIEW NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces, combustible materials cannot be located within this area.
  • Page 51 GAS CO O KT O P S 91 cm Contemporary Gas Cooktop S TAND AR D INSTAL L AT ION 64 mm 889 mm CUT-OUT WIDTH COUNTERTOP CUT-OUT 4" 98 mm – 130 mm (102) 51 mm – 127 mm 32 mm DIAMETER SIDE VIEW...
  • Page 52 MODULE C OO KTO P S 91 cm Contemporary Gas Cooktop FLUS H IN STA LLAT IO N 64 mm COUNTERTOP PROFILE 889 mm 13 mm 533 mm CUT-OUT WIDTH 914 mm RECESS RECESS 2 mm COUNTERTOP CUT-OUT 4" 98 mm –...
  • Page 53 MODULE C OO KTO P S Module Cooktops Wolf 38 cm modules have been redesigned to match the M OD U L E C OO K TOPS updated lines of Sub-Zero and Wolf. Controls, grates and trim allow them to integrate perfectly with their larger coun- terparts and deliver equal performance.
  • Page 54 MODULE C OO KTO P S Module Cooktops S T EAMER GR I L L TE PPA N YA K I M U LTIFU N C TION 102 mm 127 mm 22 mm 22 mm DRAIN OUTLET English...
  • Page 55 MODULE C OO KTO P S Planning Information Wolf does not recommend the use of When multiple modules are installed side by side, refer to IMPORTANT NOTE: downdraft ventilation with the steamer or grill modules. the chart and illustration below for typical configurations.
  • Page 56 EL EC TR IC MODULE S Electrical Supply 220-240 VAC, 50/60 Hz Wolf natural gas cooktops will function up to 3124 m in alti- Steamer 2700 W tude without adjustment and LP gas cooktops will function...
  • Page 57 MODULE C OO KTO P S Steamer Module S TAND AR D INSTAL L AT ION 64 mm 64 mm COUNTERTOP CUT-OUT DRAIN OUTLET SIDE VIEW FRONT VIEW NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces, combustible materials cannot be located within this area. wolfappliance.com...
  • Page 58 MODULE C OO KTO P S Grill | Teppanyaki Module S TAND AR D INSTAL L AT ION 64 mm 64 mm COUNTERTOP CUT-OUT SIDE VIEW FRONT VIEW NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces, combustible materials cannot be located within this area. English...
  • Page 59 MODULE C OO KTO P S Multifunction Module S TAND AR D INSTAL L AT ION 64 mm 64 mm COUNTERTOP CUT-OUT SIDE VIEW FRONT VIEW NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces, combustible materials cannot be located within this area. wolfappliance.com...
  • Page 60 Water temperature and brew strength are adjustable. Uses either whole-bean or ground coffee. The design pairs beautifully, either side- by-side or in a tower application, with other Wolf products such as the convection steam oven. Coffee systems can be ICBEC24/B ICBEC24/S installed in a standard or flush inset application.
  • Page 61 COF FE E SY ST EM S Coffee System DI MENS IO N S 22 mm 394 mm UNIT WIDTH BEHIND FRAME FULL EXTENSION W ID T H 60 cm Model 597 mm 76 cm Trim 759 mm wolfappliance.com...
  • Page 62 COF FE E SY ST EM S Planning Information The coffee system can be installed in a standard or flush E L EC TR IC AL inset application. All 76 cm trim options are based on model Installation must comply with all applicable electrical codes ICBEC24/B.
  • Page 63 COF FE E SY ST EM S Coffee System S TAND AR D INSTAL L AT ION 548 mm OPENING SLIDE DEPTH SUPPORT TOP VIEW 449 mm OPENING SLIDE HEIGHT SUPPORT OPENING WIDTH SIDE VIEW FRONT VIEW NOTE: 60 cm model and model with 76 cm trim require the same opening dimensions. Dashed line represents profile of unit.
  • Page 64 COF FE E SY ST EM S Coffee System FLUS H IN SE T IN STAL L AT I O N 584 mm SLIDE FLUSH SUPPORT INSET 25 mm DEPTH FINISHED CLEATS* TOP VIEW 8 mm 460 mm FLUSH INSET SLIDE HEIGHT** SUPPORT...
  • Page 65 D I M E N S I ON S stay hot longer. The temperature is adjustable. Two model options match the look of Wolf stainless and black coffee systems. Cup warming drawers can be installed in a stan- dard or flush inset application.
  • Page 66 CU P WA RMING DR AW E R Planning Information The cup warming drawer can be installed in a standard or E L EC TR IC AL flush inset application. Finish the edges of the opening. Installation must comply with all applicable electrical codes They may be visible when the drawer is open.
  • Page 67 CU P WA RMING DR AW E R Cup Warming Drawer S TAND AR D INSTAL L AT ION 572 mm OPENING DEPTH TOP VIEW ANTI-TIP BLOCK 140 mm OPENING HEIGHT 562 mm OPENING WIDTH SIDE VIEW FRONT VIEW NOTE: Dashed line represents profile of unit. wolfappliance.com...
  • Page 68 CU P WA RMING DR AW E R Cup Warming Drawer FLUS H IN SE T IN STAL L AT I O N 597 mm FLUSH INSET 25 mm DEPTH FINISHED CLEATS* TOP VIEW 3 mm ANTI-TIP BLOCK 146 mm 3 mm FLUSH INSET HEIGHT** 603 mm...
  • Page 69 Dual Fuel Ranges Discover a new world of cooking—the best of two worlds, C ON FI GU R ATIO N S actually—with a Wolf dual fuel range. Topside, gas cooking 7 6 cm RAN GE 12 2 c m RA NGE...
  • Page 70 DU AL F U EL RA N G E S 749 mm 749 mm 699 mm 699 mm 1419 mm 1419 mm Dual Fuel Ranges 1165 mm 1165 mm 1038 mm 1038 mm 76 c m RANG E 9 1 c m R AN GE 1 2 2 c m R AN GE 613 mm 613 mm...
  • Page 71 DU AL F U EL RA N G E S Dual Fuel Ranges BU RN ER RATING—kW SU RFAC E B URNE R Large Small FEATU RE NAT URAL Charbroiler Griddle French Top wolfappliance.com...
  • Page 72 ISO 7/1-14 female inlet fuel range. Refer to page 87 for pro ventilation. to the gas supply line. Wolf natural gas ranges will function up to 3124 m in altitude ELECTR ICA L without adjustment and LP gas ranges will function up to Installation must comply with all applicable electrical codes 2621 m.
  • Page 73 DU AL F U EL RA N G E S Dual Fuel Range IN STALL ATI ON 762 mm 914 mm TO BOTTOM OF VENTILATION HOOD OPENING WIDTH 937 mm TO COOKING SURFACE LOCATION OF GAS AND 254 mm ELECTRICAL EXTENDS ON FLOOR 83 mm 330 mm...
  • Page 74 Wolf sealed burner rangetops incorporate all the gas C O N FI G U R ATI ON S cooking features of a Wolf dual fuel range. Customize your 7 6 cm RA NG ET OP 91 c m RA NGE TOP...
  • Page 75 S EALE D B UR NE R R AN GE TO P S 724 mm 699 mm Sealed Burner Rangetops 445 mm 318 mm 76 c m RANG E T OP 613 mm 759 mm 664 mm 724 mm 699 mm 445 mm 318 mm 91 c m RANG E T OP...
  • Page 76 ISO 7/1-14 female inlet to the gas supply line. Wolf natural gas rangetops will function up to 3124 m in altitude without adjustment and LP gas ranges will function up to 2621 m. If the installation exceeds these elevations, contact an authorized Wolf dealer for a high altitude conver- sion kit.
  • Page 77 S EALE D B UR NE R R AN GE TO P S Sealed Burner Rangetop IN STALL ATI ON 762 mm 914 mm TO BOTTOM OF VENTILATION HOOD 191 mm OPENING OPENING WIDTH HEIGHT 610 mm PLATFORM PLATFORM PLATFORM TOP VIEW 406 mm ELECTRICAL...
  • Page 78 COO KT O P H O O DS Cooktop Ventilation Hoods The new generation of Wolf cooktop ventilation hoods C O OK TO P V EN TI L ATI ON H OO D S feature three new looks—black, stainless and glass.
  • Page 79 COO KT O P H O O DS Cooktop Ventilation Hoods WA LL HO O D S—BL A CK 298 mm 260 mm 740 mm 997 mm* 57 mm 489 mm WIDTH *1248 mm to 1505 mm with accessory flue extension. W ID T H ICBVW30B 762 mm...
  • Page 80 COO KT O P H O O DS Cooktop Ventilation Hoods WA LL HO O D S—STAIN L E S S 298 mm 260 mm 740 mm 997 mm* 559 mm WIDTH *1248 mm to 1505 mm with accessory flue extension. W ID T H ICBVW30S 762 mm...
  • Page 81 COO KT O P H O O DS Cooktop Ventilation Hoods WA LL HO O D S—G L AS S 298 mm 260 mm 740 mm 997 mm* 57 mm 489 mm WIDTH *1248 mm to 1505 mm with accessory flue extension. W ID T H ICBVW36G 914 mm...
  • Page 82 E L EC TR IC AL with Wolf induction, electric and gas cooktops and modules. Installation must comply with all applicable electrical codes For ranges and rangetops, a Wolf pro ventilation hood is and be properly grounded (earthed). recommended. For wall hoods, locate the electrical supply within the These hoods have a telescopic chimney flue.
  • Page 83 DOWNDR AF T SY ST E MS Downdraft Ventilation Downdraft Constructed of heavy duty stainless steel, the Wolf down- D I M E N S I ON S draft rises from the countertop to whisk away odor and smoke into stainless steel, mesh filters and can be low-...
  • Page 84 DOWNDR AF T SY ST E MS Planning Information Wolf downdrafts can be installed with most Wolf cook- E L E C TR I C A L tops, but are not compatible with contemporary induction Installation must comply with all applicable electrical codes cooktops and the grill, steamer and fryer modules.
  • Page 85 DOWNDR AF T SY ST E MS Downdraft IN STALL ATI ON W IT H COO K T O P DOWNDRAFT CUT-OUT WIDTH 68 mm 210 mm COOKTOP CUT-OUT TOP VIEW SIDE VIEW FRONT VIEW *152 mm back from countertop cut-out when internal blower is rear mounted. NOTE: Internal blower 152 mm round, side, rear or bottom discharge.
  • Page 86 DOWNDR AF T SY ST E MS Downdraft IN STALL ATI ON W IT H SE AL E D BU R NE R RA N GETO P DOWNDRAFT CUT-OUT WIDTH 68 mm 210 mm RANGETOP OPENING TOP VIEW 483 mm PLATFORM DEPTH SIDE VIEW SIDE VIEW...
  • Page 87 PRO VE N TI LATI ON Pro Ventilation Hoods Professional heritage shines through in Wolf professional- P R O H OO D S style ventilation. Exteriors are heavy-duty, welded stainless WAL L HOO DS steel, so finely hand-finished that they appear seamless.
  • Page 88 PRO VE N TI LATI ON Pro Hoods 61 c m DE EP WAL L H O O D 102 mm 610 mm WIDTH 69 c m DE EP WAL L H O O D 102 mm 686 mm WIDTH W ID T H 61 cm D EEP WA LL HOO D 76 cm, 91 cm, 107 cm, 122 cm, 152 cm...
  • Page 89 Electrical Supply 220-240V, 50Hz and remote blowers are available through an authorized 220V, 60Hz Wolf dealer. The blower will vary in size and is dictated by Service 1.9A the cooking unit, volume of air and length of the duct run.
  • Page 90 PRO VE N TI LATI ON Installation 61 c m | 6 9 cm D E E P WAL L HO O D S 762 mm 914 mm BOTTOM EDGE TO COUNTERTOP English...
  • Page 91 VE NTIL AT IO N S UG G E ST IO N S Blower Assemblies For Wolf ventilation hoods and downdrafts that do not Ventilation suggestions on the following pages provide Wolf include a blower assembly, an internal or remote blower...
  • Page 92 VE NTIL AT IO N S UG G E ST IO N S Wolf Product CMH MOD E L CO OKTOP H OOD D OWND RAFT PRO HO OD C OOK TOP | MODULE ICBCI152TF/S ICBCG152TF/S 1014 ICBSM15TF/S ICBGM15TF/S 1014...
  • Page 93 VE NTIL AT IO N S UG G E ST IO N S Wolf Ventilation Blower Options BL O W ER IN TE RNA L RE MOTE 1014 1528 1859 1528 2028 2535 CO OK TOP HOOD ICBVW30B ICBVW36B ICBVW45B ICBVI42B •...
  • Page 94 Sub-Zero, Sub-Zero & Design, Sub-Zero & Snowflake Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, Wolf, Wolf & Design, Wolf Gourmet, W & Design, red colored knobs, Cove, and Cove & Design, are registered trademarks and service marks of Sub-Zero Group, Inc. and its subsidiaries.
  • Page 95 Service will be provided during normal business hours. LIMITED THIRD THROUGH FIFTH YEAR WARRANTY For five years from the date of original installation, Wolf Appliance will repair or replace the following parts that prove to be defective in materials or workmanship: gas burners (excluding appearance), electric heating elements, blower motors (ventilation hoods), electronic control boards, magnetron tubes and induction generators.
  • Page 96 W O L FA P P L I A N C E . C O M...

This manual is also suitable for:

Icbso30tm/s/thIcbdo30tm/s/thIcbso30pm/s/phIcbdo30pm/s/phIcbso30cm/sIcbdo30cm/s ... Show all
