- Page 1 User’s Manual – A S Wall Chaser REBO Wall Chaser AR-HE-MF17000W Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
User’s Manual – A S Wall Chaser REBO List of contents 1. Safety Instructions ..........3 1.2 Intended use ..............4 1.3 General safety instructions for power tools ....4 1.3.1 Work area safety ............4 1.3.2 Electrical safety ............4 1.3.3 Personal safety ............ -
Page 3: Safety Instructions
User’s Manual – A S Wall Chaser REBO Please read and save these instructions. Read through this user’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/ or damage to product or property. -
Page 4: Intended Use
User’s Manual – A S Wall Chaser REBO 1.2 Intended use • The wall chaser (normative cut-off machine), in the following also referred to as device, in conjunction with an approved industrial dust extractor, is intended to cut or slit primarily mineral materials, e.g. -
Page 5: Power Tool Use And Care
User’s Manual – A S Wall Chaser REBO • Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. • Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. -
Page 6: Further Safety Instructions For Abrasive Cutting-Off Operations
User’s Manual – A S Wall Chaser REBO run out of balance, vibrate excessively and may cause loss of control. • Do not use damaged wheels. Before each use, inspect the wheels for chips and cracks. If power tool or wheel is dropped, inspect for damage or install an undamaged wheel. After inspecting and installing the wheel, position yourself and bystanders away from the plane of the rotating wheel and run the power tool at maximum no load speed for one minute. - Page 7 User’s Manual – A S Wall Chaser REBO cause loss of control or kickback. • Do not attach a saw chain, woodcarving blade, segmented diamond wheel with a peripheral gap greater than 10 mm or toothed saw blade. Such blades create frequent kickback and loss of control.
-
Page 8: Parts List
User’s Manual – A S Wall Chaser REBO 2. Parts List Description Description ON-/OFF-switch Switch lock Handle Spindle lock Dust extraction adapter Roller Union nut Reducer Protective cover Centring flange Adapter flange (with lefthand thread) Spacers Depth stop Face pin wrench Additional handle Chisel... -
Page 9: Installation
User’s Manual – A S Wall Chaser REBO Scope of Delivery • 1x Wall chaser • 2x Cutting discs (preinstalled) • 1x Face pin wrench 1x Reducer (for use with the extraction adapter and a size ∅ 32 mm vacuum hose) •... -
Page 10: Handling The Wall Chaser
User’s Manual – A S Wall Chaser REBO Tighten the adapter flange with the face pin wrench (15). When doing so, hold the spindle lock. NOTE: When setting a cutting width smaller than the maximum, you must use the spacers on the clamping collar side, as the clamping collar alone cannot secure the discs due to the thread length on the spindle (see. -
Page 11: Technical Specifications
User’s Manual – A S Wall Chaser REBO 6. Technical Specifications Model AR-HE-MF1700W Mains voltage 230 V∼ 50 Hz Power input 1350 W Rated no load speed 9000 rpm Disc ø 125 mm Mounting hole 22.2 mm Groove depth 0–30 mm Groove width 8–26 mm Thread... -
Page 12: Disposal Instruction
User’s Manual – A S Wall Chaser REBO 7. Disposal instruction 7.1 Disposal of the packaging • Please make reference to the guidelines and standards for appropriate disposal of the packaging valid in your region. In part, the package may consist of plastic bags - watch this respect, with special care to ensure that this is not out of the reach of children. - Page 13 Authorised representative for the technical documentation: Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
