- Page 1 User’s manual – A S Demolition Hammer 1700W REBO Demolition Hammer 1700 W AR-HE-AB1700 Please follow all security measures in this user’s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
User’s manual – A S Demolition Hammer 1700W REBO Please read and save these instructions. Read through this user’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. -
Page 3: Recommendations
User’s manual – A S Demolition Hammer 1700W REBO Warning! Read the safety instructions carefully. Failure to follow the safety precautions could result in serious injury or damage. Keep the operating instructions in a safe place. Insulated housing (protection class II)! Take special care when using this article. -
Page 4: General Power Tool Safety Warnings
User’s manual – A S Demolition Hammer 1700W REBO specialized service can intervene in complete safety, by using origin parts and the manufacturer's drawings. General Power Tool Safety Warnings • Read all safety warnings and instructions. Failure to heed warnings and follow instructions may result in electric shock, fire and/or serious injury. -
Page 5: Power Tool Use And Care
User’s manual – A S Demolition Hammer 1700W REBO moving parts. • If there are devices for connecting dust extraction and collection facilities, please ensure that they are attached and used correctly. Using such devices can reduce dust-related hazards. Power tool use and care •... - Page 6 User’s manual – A S Demolition Hammer 1700W REBO protective hair covering to contain long hair. • Use safety glasses. Use a face or dust mask as well if the operation is dusty or if using in enclosed spaces. • Do not abuse the cord.
-
Page 7: Explosive View
User’s manual – A S Demolition Hammer 1700W REBO Explosive view... -
Page 8: Piece List
User’s manual – A S Demolition Hammer 1700W REBO Piece List Stop Lever Bearing Cover 6203 Pin 4X18 Hex.Socket Hd.Bolt M8 Block Blessing handle set 107MA Spring Case 23X28 Washer 8 Damping spring Φ10.5xΦ1.6x28x6 Spring17.2×1.59×26.5 Washer12.4*17.6*2.6 Damping plate Washer 18*12.1*1.5 Damping screw M8x43 Nylock Hex.Socket Hd.Bolt M10X35 Damping sleeve 107MA... -
Page 9: Description
User’s manual – A S Demolition Hammer 1700W REBO Washer 29.5X39.5X2 Description 1. On-Off switch 2. Auxiliary handle 3. Main handle 4. Locking bolt 5. Tool chuck 6. Inspection window/ Oil filter opening 7. Wrench 8. Lock knob of auxiliary handle Application Switching On/Off Plug the cord set into power socket. -
Page 10: Additional Handle
User’s manual – A S Demolition Hammer 1700W REBO • Pull out the locking bolt (4) again, turn it through 180° in the opposite direction and release • Check the lock by pulling the tool. Remove/replace the tool • Proceed in reverse order to mounting. •... -
Page 11: Technical Data
User’s manual – A S Demolition Hammer 1700W REBO Technical Data Model AR-HE-AB1700 Max impact rate [1/min.] 1900 Bpm Impact Energy [Joule] Vibration level [m/s²] 17.787 m/s² Motor V/Hz 230-240V/50 Hz Power consumption P1 (W) 1700W Protection Class Class II... -
Page 12: Disposal Instructions
User’s manual – A S Demolition Hammer 1700W REBO Disposal Instructions Disposal of the packaging • Please make reference to the guidelines and standards for appropriate disposal of the packaging valid in your region. In part, the package may consist of plastic bags - watch this respect, with special care to ensure that this is out of the reach of children. -
Page 13: Declaration Of Conformity Eu
Hereby declare that the product named below, seen its design and construction as well as according to our sales, has been complied with the relevant and basic health and safety EU-requirements. Name of the product: AREBOS Demolition Hammer 1700 W Article number: 4260627423996 Model number: AR-HE-AB1700 If this product is modified without our consent, this declaration loses its warranty.
