- Page 1 User’s manual – A S Multifunction tool 5in1 (Premium) REBO Multifunction tool 5 in 1 (Premium) AR-HE-MT51PT Please follow all security measures in this user’s manual to ensure a secure use. Thank you for trusting AREBOS.
-
Page 2: Table Of Contents
User’s manual – A S Multifunction tool 5in1 (Premium) REBO List of contents 1. Safety instructions ..........3 1.1 Explanation of the symbols ..........3 1.2 Safety rules ..............5 2. Parts list ..............6 3. Intended Use ............7 4. -
Page 3: Safety Instructions
User’s manual – A S Multifunction tool 5in1 (Premium) REBO Please read and safe these instructions. Read through this user’s manual carefully before using this product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. - Page 4 User’s manual – A S Multifunction tool 5in1 (Premium) REBO Warning! Wear protective gloves! Warning! Wear protective gloves! Warning! Wear protective clothing! Warning! Flammable material! Pay attention to flying stones! Pay attention to pedestrians! Do not touch the utility pole!
-
Page 5: Safety Rules
User’s manual – A S Multifunction tool 5in1 (Premium) REBO Please note the sound power level. 1.2 Safety rules • Read the instruction manual carefully before using the unit. This applies in particular to the safety instructions. Otherwise you may injure yourself or damage the device. •... -
Page 6: Parts List
User’s manual – A S Multifunction tool 5in1 (Premium) REBO complete check, please contact a specialist workshop. • Keep the machine away from fire or sparks. • Be careful when using the machine. There is a risk of kickback and recoil. 2. -
Page 7: Intended Use
User’s manual – A S Multifunction tool 5in1 (Premium) REBO 3. Intended Use • Motor brush (use the cutting knife): Cutting of light wood, strong weeds and undergrowth. • Lawn trimmer (use the thread bobbin with cutting thread): Cutting lawns, grass areas and light weeds. •... - Page 8 User’s manual – A S Multifunction tool 5in1 (Premium) REBO • Sometimes overloading will cause misfiring which is normal. If the misfire is audible under normal load, we recommend replacing the fuel. • Do not overfill the tank (see figure max. level). •...
-
Page 9: Assembly
User’s manual – A S Multifunction tool 5in1 (Premium) REBO Draining gasoline: • Make sure that no fuel or chain oil gets into the ground. Use a suitable surface. • Empty the tank only outdoors or in well-ventilated rooms. • Hold a drip tray under the fuel drain plug. - Page 10 User’s manual – A S Multifunction tool 5in1 (Premium) REBO • Place the cutting disc (golden) on the rotor blade as shown. Place the bell on the rotor blade. • Attention: Left-hand thread! Turn the nut to the left to tighten. Tighten the left-hand thread as shown using the supplied Allen key.
- Page 11 User’s manual – A S Multifunction tool 5in1 (Premium) REBO • Then screw the bobbin attachment to the left onto the thread, hexagon wrench can then be removed. In the next step, pull the fixing bolt to make the joint flexible. •...
- Page 12 User’s manual – A S Multifunction tool 5in1 (Premium) REBO • Insert the chain into the furrows of the saw blade and place the chain on the wheel from behind, making sure that the saw blade engages under the wheel at a slightly inclined angle. •...
- Page 13 User’s manual – A S Multifunction tool 5in1 (Premium) REBO • Place the red plastic housing over the saw blade as shown using the nut. • Changing the thread bobbin: Open the bobbin case by pressing in at the marked point and unscrewing the cover.
-
Page 14: Use Of Included Attachments & Cutting Tools
User’s manual – A S Multifunction tool 5in1 (Premium) REBO • Insert the spring in the middle again and place the nut washer on it. Adjust the threads as desired and allow them to protrude laterally through the openings provided. 6. -
Page 15: Mowing With Grass Trimmer
User’s manual – A S Multifunction tool 5in1 (Premium) REBO 6.2 Mowing with grass trimmer • Use the thread cassette to obtain a clean cut even on uneven edges, fence posts and trees. • Carefully guide the trimming thread towards an obstacle and cut with the thread tip around the obstacle. -
Page 16: Maintenance
User’s manual – A S Multifunction tool 5in1 (Premium) REBO 7. Maintenance 7.1 Regular inspections • Attention: Always wear protective gloves when working on and around cutting tools. When not in use, during transport or storage, always fit transport protection to all cutting tools. Always switch off the engine and remove the spark plug connector before carrying out maintenance or cleaning work. -
Page 17: Cleaning The Air Filter
User’s manual – A S Multifunction tool 5in1 (Premium) REBO • Replace the spark plug: every 100 hours or 1x a year (depending on which case occurs first) if the insulation body is damaged with strong electrode erosion for heavily soiled or oily electrodes 7.3 Cleaning the air filter •... -
Page 18: Troubleshooting
User’s manual – A S Multifunction tool 5in1 (Premium) REBO 8. Troubleshooting - Air filter dirty. - Clean/replace air filter. - Fuel filter blocked. - Clean or replace fuel filter. - Lack of fuel supply. - Fill it up. - Fuel line fault. - Check fuel line for kinks or damage. -
Page 19: Technical Data
- Adjusting the chain tension. work. Chain blunt. - Have the chain sharpened again or replace it. 9. Technical data Model AR-HE-MT51PT Tank capacity 900 ml Weight 27 lbs (12.4 kg) Fuel Petrol/Oil mixture 40:1 with 2-stroke oil Drive shaft... -
Page 20: Disposal Instruction
User’s manual – A S Multifunction tool 5in1 (Premium) REBO 10. Disposal instruction 10.1 Disposal of the packaging • Please make reference to the guidelines and standards for appropriate disposal of the packaging valid in your region. In part, the package may consist of plastic bags - watch this respect, with special care to ensure that this is not out of the reach of children. - Page 21 Hereby declare that the product named below, seen its design and construction as well as according to our sales, has been complied with the relevant and basic health and safety EU-requirements. Name of the product: Arebos Multifunction tool 5in1 (Premium) Art. Nr.: AR-HE-MT51PT Model Nr.: 4260627421107...
