GE MDS TransNET Quick Start Manual page 4

Operational Configuration
Table 3:
COMMAND DESCRIPTION
XRSSI [NONE, Minimum RSSI level required to preserve
-40...-120]
ZONE CLEAR Reset zone data statistics
Table 4: Operating Status
COMMAND DESCRIPTION
ADDR Network address
AMASK Alarm mask (response)
ASENSE Current sense of the alarm output.
BAUD Data communication parameters. Exam-
BUFF Data buffering mode: ON = seamless
CODE Security/encryption operational status.
"NONE" (Inactive), or "ACTIVE"
CTS CTS delay in milliseconds (0–255 ms)
CTSHOLD "Hold time" that CTS is present following
DEVICE Device behavior
Alternatives: DCE and CTS KEY
HOPTIME Hop-time value in milliseconds (ms).
LPMHOLD Time (0-1000 ms) provided to give an
MODE Current operating mode:
M = Master
MRSSI Minimum RSSI level required to preserve
OWM Owner's message or site name
OT Status (ON/OFF) of the 1-second delay
OWN Owner's name or system name
PORT Current data port (DATA connector) inter-
PWR Forward power-output setting in dBm
REPEAT The fixed downstream re-send count.
RETRY The maximum upstream re-send count
RSSI Received signal strength indicator (in
RTU RTU simulator's operational status
RXTOT The amount of time (in seconds) to wait
4
(Continued)
synchronization with a non-primary radio.
(Only meaningful when XPRI is not
NONE)
—
Display Only
ple: BAUD 9600 8N1
data, OFF = fast byte throughput
last character from DATA port.
RTU time to respond before the radio
goes to sleep.
R = Remote
X = Extension (Repeater)
synchronization with a Master radio for
Remotes in mobile service.
on delivery of RXD serial data.
face signaling mode: RS232 or RS485
for ARQ (Automatic Repeat Request)
operation.
dBm). Unavailable at Master unless
SETUP is enabled.
(ON/OFF)
before issuing a time-out alarm.
GE MDS TransNET Quick Start Guide
Table 4: Operating Status
COMMAND DESCRIPTION
SAF Store-and-forward mode status in this
unit. (ON/OFF)
SER Serial number of radio
SHOW CON Display virtual modem connection status
SHOW PWR RF output power.
Measured RF power in dBm.
SHOW SYNC Information on synchronization source
SKIP Frequency zones that are skipped
SLEEP Radio's Sleep Mode setting.
(At Remotes Only)
SREV Transceiver firmware revision level
STAT Current alarm status
TEMP Transceiver's internal temperature (°C)
UNIT Programmed unit address for
network-wide diagnostics
XADDR This unit's Extended address
XPRI Address of the primary Extended radio
unit (Extension).
XMAP Included Extended units in MODE X.
(Extensions and Remotes only).
XRSSI Minimum RSSI level required to preserve
synchronization with a non-primary radio.
(Only meaningful when XPRI is not
NONE)
Table 5: Diagnostic and Test Functions
COMMAND DESCRIPTION
KEY Enables the transmitter test.
(must be in Setup mode).
DKEY Turns off the transmitter test
(must be in Setup mode).
TX [xxxx] Set/display transmit test frequency
(must be in Setup mode).
RX [xxxx] Set/display receive test frequency.
(must be in Setup mode).
SETUP Enables Setup mode.
Times out after 10 minutes. Press "Q" to
quit.
ZONE DATA Zone data statistics
ZONE CLEAR Clears the Zone Data log
—
Display Only (Continued)
