Lenovo Tab M10 Gen3
Level 2 – Service and Repair Manual
Rear-Facing Camera Assembly
Description
TB328FU MB_4+64G&*21201-03315 CS
TB328 Rear camera_8M&*CL2640AA000496 CS
1.
Use fingers to place and secure the 1 Rear-
Facing Camera on the location as shown
2.
Use your fingers to place and secure the Rear-
Facing Camera FPC BtB Connector on the
Main board as shown.
Page 43 / 72
Reference #
10
7
Lenovo Confidential Restricted:
Do not share without consent from Lenovo
