PRODUCT DESCRIPTION .............4 BEFORE PLACING AN ORDER ............5 You need to establish which version of Smart Relay is required ... 5 You need to establish what accessories are required ..... 5 Mains adaptors need to be planned and acquired ......5 You need to determine the installation location .......
Page 3
Backup battery................... 21 10.0 TECHNICAL DATA FOR SREL ...........22 11.0 SMART RELAY 2 .................23 11.1 Smart Relay 2 versions ..............23 11.2 Card reader versions in conjunction with srel2......24 12.0 DESCRIPTION OF THE SREL2 CONNECTIONS .......25 13.0 TECHNICAL DATA FOR SREL2 ..........26 14.0 PRODUCT DESCRIPTION ............28...
In the event of doubt, original German language version applies. Product Description The SimonsVoss Smart Relay is an electronic switch which can be activated with a SimonsVoss ID transponder. The authorisation for transponders which are permitted to operate Smart Relay can be configured using the SimonsVoss software. Smart Re-...
SMART RELAY SREL, SREL.ZK, SREL.ADV Before placing an order YOU NEED TO ESTABLISH WHICH VERSION OF SMART RELAY IS REQUIRED Smart Relay Basic version: Order code: SREL This relay provides a simple yes/no authorisation for a maximum of 8,184 different transponders.
SimonsVoss. YOU NEED TO DETERMINE THE INSTALLATION LOCATION The transponder transmission range for Smart Relay (read range) is a max. of 1.5 m, but may be reduced in metallic environments, particularly in magnetic fields or where there is aluminium.
INSTALLATION OF BACKUP BATTERY Backup Batterie nur einsetzen, wenn das Smart Relais mit Only use the backup battery if the Smart Relay is powered Netzteil betrieben wird, bei Betrieb mit SREL.BAT diese via a mains adapter. Do not use this battery if the Smart Relay is powered by SREL.BAT.
Installation Switch off the power supply (disconnect the plug or battery if necessary). Connect all cables to their designated terminals on the Smart Relay (see Ter- minal Assignment on the next page). It is essential to ensure the polarity is correct if you connect a DC mains adapter.
SMART RELAY SREL, SREL.ZK, SREL.ADV DESCRIPTIONS OF CONNECTIONS IN SREL, SREL.ZK AND SREL Name Symbol Description Mains adapter + / ~ Either positive pole when connected to a direct current (5 to 24 V DC) or one of the two alternating current connec-...
SMART RELAY SREL, SREL.ZK, SREL.ADV Programming and configuration If Smart Relay is selected as the lock type in the SimonsVoss software (LDB Version 1.40 or higher, or LSM 2.1 or higher), the following configuration options are avail- able:...
Pulse mode (default setting) is switched off and the pulse duration no longer plays a role. When flip flop mode is activated, Smart Relay changes its status from on to off or vice versa each time it is activated using a transponder. This mode is ideal for switching lights, machines and other systems on and off.
SimonsVoss transponders in third- party systems. Select this option on both the Smart Relay and the cylinder if you wish the Smart Re- lay to transmit transponder data to a third-party system and a remote opening com- mand to be sent from Smart Relay to a cylinder after clearance by the third-party sys- tem.
SMART RELAY SREL, SREL.ZK, SREL.ADV 7.7.1 SMART RELAY IN OMRON MODE Authorised? Access control system ternes Zutrittskontroll- oder External access control or time-and- iterfassungssystem attendance system Freischalt Rel Relay release Relay release + 5..12VDC Pull up resistances ll Up Widerstände...
SREL.ADV only Auto-detection If an external antenna is connected, this is the one which is used. Smart Relay switches off the internal antenna in such cases. If no external antenna is con- nected (standard case), Smart Relay functions with the internal antenna.
SMART RELAY SREL, SREL.ZK, SREL.ADV 7.7.7 INTERFACE For SREL.ADV only You can enter the type of card reader here which the Smart Relay is to simulate for operation as a serial interface. The following options are available: • Wiegand, 33 bit •...
Page 17
SMART RELAY SREL, SREL.ZK, SREL.ADV Evtl. Widerstand zur Poss. resistance to power Leistungsbegrenzun limitation. The V+ output Der Ausgang V+ lief supplies max. 10 mA at 3 V DC x. 10 mA bei 3VDC ntweder Buzzer oder L Either buzzer or LED...
Summary of diode signals DESCRIPTION OF FUNCTIONS In order to use a Smart Relay as a card reader in a third-party access control or time- and-attendance system, the hardware (cabling and signal emitter) and data formats must match those of the card reader precisely. This is the only way that the third-party system will be able to understand and evaluate data from SimonsVoss transponders.
SMART RELAY SREL, SREL.ZK, SREL.ADV WIEGAND INTERFACE (33 BIT AND 26 BIT) Externes Zutrittskontroll- oder External access control or timeand attendance-system Zeiterfassungssystem + 5..12VDC Pull Up Widerstände Pull up resistances Brown + / ~ White F2 F1 xterne Antenn External antenna...
SMART RELAY SREL, SREL.ZK, SREL.ADV KABA BENZING, SIEMENS, GANTNER LEGIC, PRIMION, ISGUS INTERFACE Externes Zutrittskontroll- oder External access control or timeand Zeiterfassungssystem attendance-system + 5..12VDC Pull Up Widerstände Pull up resistances Clock Data Brown + / ~ White F2 F1...
Maintenance BATTERY WARNING AND BATTERY REPLACEMENT WHEN THE BATTERY SREL.BAT IS USED A Smart Relay can emit a battery warning as follows when the battery capacity is de- pleted: SREL, SREL.ZK, SREL.ADV Inside LED flashes 8x each time a transponder is used and before the relay switches.
SMART RELAY SREL, SREL.ZK, SREL.ADV 10.0 Technical data for SREL Housing made of black plastic: dimen- sions l x w x h 72 x 57 x 25.5 mm Protection rating IP20, not tested for outside use Temperature When operating: -22ºC to 55ºC In storage: 0ºC to 40ºC...
SMART RELAY SREL, SREL.ZK, SREL.ADV 11.0 Smart Relay 2 11.1 SMART RELAY 2 VERSIONS SREL2.G2.W: The SREL2 is basically used with transponders, i.e. as purely "active" components. There is also the option of using a Compact Reader and operating the ®...
SMART RELAY SREL, SREL.ZK, SREL.ADV Use of the backup battery (CR1220 Sony) is described in Section 4.1. 11.2 CARD READER VERSIONS IN CONJUNCTION WITH SREL2 ® ® The SC components can be operated with Mifare Classic or Mifare DESFire SC.M.E.G2.W: Smart Card Mifare External (external card reader) G2 (Generation 2) W (white housing) A maximum of two external card readers (SC.M.E.G2.W) and one internal card...
LED / buzzer (external) Card reader line link SimonsVoss bus - card reader line link Open drain outputs up to max. 24 V DC / 0.5 A. Earth connection to power supply's negative pole. If a CLS (card loading signal) is featured, the SREL2 must be config-...
SMART RELAY SREL, SREL.ZK, SREL.ADV 13.0 Technical data for SREL2 Housing made of white plastic: dimen- sions l x w x h about 78 x 78 x 19 mm Semi-transparent base plate Protection rating See note in 11.0 Temperature When operating: -22ºC to 55ºC In storage: 0ºC to 40ºC...
− Specialist knowledge in access control systems, door mechanics, door approvals, electronic system installation and the use of SimonsVoss soft- ware is required when installing a SimonsVoss INPUT NODE. This is why only trained specialists may install this terminal. −...
