GEOHOME B118-14 Assembly Instructions Manual

MODEL : B118-14
REVISION : C
Component List
No Descriptions
A Side Panel (Left)
B Side Panel (Right)
C Left Leg (Front)
D Left Leg (Back)
E Right Leg (Front)
F Right Leg (Back)
G Top Horizontal
H Apron Panel
I Top Panel
J Back Panel
Top Drawer Front
K
L Top Drawer Side (Left)
Top Drawer Side (Right)
M
N Top Drawer Back
O Drawer Bottom Shelf
P Drawer Bottom support
Q Bottom Drawer Front
R Bottom Drawer Side (Left)
S Bottom Drawer Side (Right)
T Bottom Drawer Back
Hardware List
No Descriptions
1 Big Camlock Ø15 x 12mm
2 Small Camlock Ø12 x 10mm
3
Camlock Screw
4
Wooden Dowel 6mm x 30mm
5
PHCB Screw M4 x 16mm
6
PHCB Screw M4 x 32mm
7
Truss Head Screw M4 x 15mm
8 Handle
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS :
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast and
easy assembly.
I M P O R T A N T N O T E :
Qty
· Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
1
· Check to be sure that you have all parts and hardware.
· Remove all wrapping materials, including staples & packing straps before you start to assemble.
1
· Do not tighten all screws/bolts until all completely assembled.
1
· Keep all hardware parts out of reach of children !
1 · Tighten screws periodically ! With the use of this product bolts and screws may become loose over time !
· Don't attempt to modify parts !
1
1
2
2
1
I
1
1
1
1
J
1
4
4
A
3
3
3
3
Qty
24
12
36
H
48
D
18
20
8
4
C
F
B
G
Page 1 of 7
Item No : B118-14
Description : CHEST
N
E
L
O
T
R
O
M
K
P
S
Q
X 3
P
