Ultra-Aire SD12 Quick Start Manual

Ultra-Aire
Specification Data
Dehumidifier
Part Number:
Blower:
Power:
Supply Voltage:
Current Draw:
Transformer Protection:
Circuit Requirement:
Energy Factor:
Operating Range:
Sized For:
Minimum Performance:
Water Removal:
Sensible Cooling:
Efficiency:
Duct Connections:
Air Filter:
Efficiency:
Size:
Optional Air Filters:
Efficiency:
Size:
Efficiency:
Size:
Power Cord:
Internal Insulated Cabinet: Yes
Drain Connection:
Line Set Requirements:
Liquid Line:
Gas Line:
Dimensions: Unit With Collars
Width: 20 1/4"
Height: 21 3/4"
Length: 41 1/2"
Weight: 110 lbs.
Condenser
Part Number:
Power:
Supply Voltage:
Current Draw:
Minimum Circuit Ampacity: 20 Amps
Maximum Fuse / Breaker: 20 Amps
Refrigerant Type:
Refrigerant Amount:
Operating Range:
Dimensions:
Power Cord:
(800) 533-7533 | www.Ultra-Aire.com
SD12 Split Dehumidifier
™
4033175
406 CFM @ 0.0" WG
374 CFM @ 0.2" WG
348 CFM @ 0.4" WG
160 Watts @ 80°F and 60% RH
115 VAC – 1phase – 60 Hz
1.4 Amps
Push Button Reset (located near power cord)
15 Amps
3.1 L/kWh
49°F Min, 95°F Max (Inlet Air Temperature)
Up to 4,000 Square Feet
80°F and 60% RH 70°F and 60% RH
184 Pints/Day 150 Pints/Day
4,300 BTUs/Hour 5,100 BTUs/Hour
6.6 Pints/kWh 6.0 Pints/kWh
6" Round Inlet; 10" Round Inlet; 10" Oval Outlet
20 1/4"
MERV-13, Standard Pleat
90% ASHRAE Dust Spot
6" Diameter
16" x 20" x 2"
MERV-11, Standard Pleat
65% ASHRAE Dust Spot
10" Diameter
16" x 20" x 2"
MERV-14, Embossed Pleat (will need filter housing) 10" Diameter
95% ASHRAE Dust Spot
FRONT VIEW
20" x 24" x 4"
9', 115 VAC, Ground
3/4" Threaded Female NPT
50 Feet (maximum)
1/4"
3/8"
Unit Without Collars
20 1/4"
21 3/4"
37 3/4"
109 lbs.
4033192
1080 Watts @ 80°F and 60% RH
115 VAC – 1phase – 60 Hz
9.7 Amps
R410A
36 oz.
40°F Min, 115°F Max
10"W x 25.5"H x 33"L - 75 lbs.
Hard-Wired
YEAR
FULL WARRANTY
YEAR
FULL WARRANTY
Dehumidifier
20 1/4"
6" Diameter
10" Diameter
10" Diameter
41 1/2"
FRONT VIEW
37 3/4"
Condenser
Shipping
35"
44"

Optional Accessories

44"
225 lbs.
4028539
4028407
4039391
4037733
4037734
4021475
4027420
4027424
4025287
4024370
4029087
4028614
4036685
4023672
4026859
4020128
4020656
4024375
4026969
4022126
4028399
ID #51102120 ID #510XXX
4033170
41 1/2"
37 3/4"
20 1/4" 20 1/4"
6" Diameter
10" Diameter
10" Diameter
FRONT VIEW BACK VIEW
10"
SIDE VIEW FRONT VIEW
DEH 3000 Control
DEH 3000R Control (with remote)
MERV-13 Filter (16" x 20" x 2")
MERV-13 Filters 4-Pack
MERV-13 Filters 12-Pack
MERV-11 Filter (16" x 20" x 2")
MERV-11 Filters 4-Pack
MERV-11 Filters 12-Pack
MERV-14 Filter Housing
MERV-14 Filter (20" x 24" x 4")
MERV-14 Filters 3-Pack
Pump Kit
Hang Kit
6" Motorized Damper
6" Flex Duct 25'
6" Flex Insulated Duct 25'
6" Inlet Hood
10" Gravity Damper
10" Flex Duct 25'
10" Flex Insulated Duct 25'
10" Oval to Round Adapter
PATENTS:
D570,988
8,069,681
9,052,132
41 1/2"
37 3/4"
33"
