Connecting the RangeMaster5 board into an existing RFID reader - to replace the sub-carrier filters, see figure1 below. The connections can be made by directly soldering wires to the RangeMaster5 board or by first adding single in line 1mm header pins (2.54mm spacing).
Page 3
Apply power to the board +3.3V. The RangeMaster5 board will immediately start to configure itself, after about 36ms this will be complete the board then puts itself into /Sleep standby mode”. Do not enter a Control word during this initial 36msec configuration period.
Page 4
RangeMaster5 Evaluation board – Quick start Guide Figure 2, Pictorial Pin description Hardware and Timings SPI like pin table/ interface. This table and figure 3 show the timings specification Pin type Description Symbol Description units name Input Slave select SSb falling to SCK rising...
