  • Page 1 ROHO ® Hybrid ELITE™ Cushion SUPPLIER: This manual must be given to the user of this product. USER: Before using this product, read instructions and save for future reference.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTENDED USE PRODUCT SPECIFICATIONS CAUTIONS PARTS DETAIL PLACEMENT AND ADJUSTMENT INSTRUCTIONS COVER AND CUSHION INSERT REMOVAL COVER AND CUSHION INSERT REPLACEMENT CLEANING AND DISINFECTING PRODUCT 6 - 7 TROUBLESHOOTING RETURN POLICY DISPOSAL LIMITED WARRANTY SPANISH FRENCH ROHO, Inc. has a policy of continual product improvement and reserves the right to amend specifications presented in this manual. ROHO Cushioning Products are manufactured by ROHO, Inc., ® 100 North Florida Avenue, Belleville, Illinois 62221-5429, www.therohogroup.com. U.S.A.: 1-800-851-3449, Fax 1-888-551-3449 Outside the U.S.A.: 1-618-277-9150, Fax 1-618-277-6518 Email: cs@therohogroup.com © ROHO, Inc., 2009 The following are trademarks and registered trademarks of ROHO, Inc.: ROHO , DRY FLOATATION ® ® shape fitting technology , and Hybrid ELITE™. ® Velcro is a registered trademark of Velcro Industries B.V. ®...
  • Page 3: Intended Use

    PRODUCT SPECIFICATIONS: MATERIALS: The contoured foam base is comprised of water resistant polyethylene closed cell foam. The cushion insert is made of neoprene rubber with nickel plated brass inflation valve(s). The cover top layers and side materials are flame resistant polyester. Bottom and valve opening reinforcements are polyester reinforced PVC. Comfort foam inside the cover is polyurethane. The ROHO Hybrid ELITE Cushion with cover complies with EN 1021-1 and EN 1021-2 flammability requirements. SIZING SPECIFICATIONS: Assembled Cushion Smallest Width Smallest Depth Largest Width Largest Depth 13.5 in. 14.25 in. 23.5 in. 20.25 in. (34.5 cm) (36.0 cm) (59.5 cm) (51.5 cm) Average product height is 4 in. (10.0 cm). Average product weight based on a 17.75 in. x 18.5 in. (45.0 cm x 47.0 cm) cushion is 3.5 lbs. (1.5 kg). NOTE: All measurements are approximate. For specific cushion sizes, contact ROHO Customer Service at 1-800-851-3449 toll free in the U.S.A. Outside the U.S.A., contact your country’s ROHO International distributor. For a current list of ROHO International distributors, visit our website at www.therohogroup.com, contact ROHO International at 1-618-277-9150 or email us at cs@therohogroup.com.
  • Page 4: Cautions

    • OVER-INFLATION: DO NOT use an over-inflated cushion insert. Doing so will not allow user to sink into the cushion insert and will reduce or eliminate the cushion’s benefits, increasing risk to the skin and other soft tissue. • CUSHION AND COVER ORIENTATION: Product must be used with the provided cover, air cells facing up, contoured foam area in the front portion of the chair and the cushion insert in the back portion of the chair. If the cover is not used correctly or if the cover is the wrong size, it may reduce or eliminate the cushion’s benefits and could increase risk to the skin and other soft tissue. • PRODUCT USE: DO NOT use the ROHO Hybrid ELITE Cushion in conjunction with any other seat cushioning products except as indicated in Intended Use section. DO NOT use the components of the ROHO Hybrid ELITE Cushion separately. DO NOT use the components of the ROHO Hybrid ELITE in conjunction with any other seat cushioning products. • DO NOT use cushion as a water flotation device (e.g. a life preserver). • DO NOT use any pump, cover or repair kit other than those provided by ROHO, Inc. Doing so may damage the cushion insert and void product’s warranty. • OBSTRUCTIONS: DO NOT place any obstructions between the user and the cushion or the cushion insert and the contoured foam. Doing so will reduce product effectiveness.
  • Page 5: Parts Detail

    ® to help secure cushion in chair. Additional Velcro tabs included if needed. B. Cushion Insert: Individual interconnected air cells. Velcro on bottom to help secure to contoured foam base. C. Inflation Tube: Used to transfer air to and from the cushion insert. Some models may have two inflation tubes. D. Inflation Valve: Used to open and close the cushion insert’s airway. Some models may have two inflation valves. E. Contoured Foam Base: Enhances stability and helps to position pelvis and thighs. Velcro on top to help secure cushion insert. F. Operations Manual: Instructions on adjustment, care, warranty and other important information about cushion. G. Repair Kit: Patch kit for minor repairs of the cushion insert. H. Hand Pump: Used to inflate cushion. I. Product Registration Card: Used to register product. Complete card and mail to ROHO, Inc. or register online at www.therohogroup.com.
  • Page 6: Placement And Adjustment Instructions

    ROHO HYBRID ELITE PLACEMENT AND ADJUSTMENT INSTRUCTIONS: NOTE: Cover not shown for demonstration purposes only. Product must be used with provided cover. STEP 1: Place ROHO Hybrid ELITE STEP 2: Turn valve counterclockwise STEP 3: Pinch the pump’s nozzle Cushion in wheelchair seat so the to open. Slide the pump’s rubber and turn valve clockwise to close. user will be properly supported and nozzle over a valve and inflate the Remove pump. immersed when in their normal sitting cushion insert until it begins to position. Use the directional patch on slightly arch upward. (Repeat steps 2 and 3 for the right side of the cover as a guide. remaining valve on dual valve cushion inserts.)
  • Page 7: Cover And Cushion Insert Removal

    COVER AND CUSHION INSERT REMOVAL: To Remove The Cover: 1. Unzip the zipper. 2. Carefully push the inflation valve(s) back through the valve opening(s) in the cover. 3. Gently remove contoured foam base and cushion insert from cover. To Remove the Cushion Insert: 1. Gently remove the inflation tube(s) from the groove(s) in the contoured foam base. 2. Extract the inflation tube(s) from the corresponding hole in the foam base corner by gently pushing and pulling until the entire tube, including the valve, is out. 3. Peel the cushion insert away from the foam base and separate the Velcro strips. COVER AND CUSHION INSERT REPLACEMENT: To Replace the Cushion Insert: 1. Place the cushion insert, cell side up, in the cutout section of the contoured foam base with the BACK of the cushion insert facing the BACK of the foam base. Refer to directional labels. 2. Line up the Velcro strips on the bottom of the cushion insert and top of the foam base then press firmly to secure. 3. Insert the inflation valve(s) into the corresponding hole on the back corner of the foam base and carefully push the inflation tube(s) through until the valve(s) protrude on the side.
  • Page 8: Troubleshooting

    To Disinfect the Cushion Insert: Repeat cleaning instructions using a germicidal that meets infection control needs (ROHO, Inc. suggests a disinfectant with tuberculocidal properties). A solution of 1/2 cup liquid household bleach per quart of warm water (125 ml bleach to 1 liter of warm water) can also be used. Keep the clean cushion insert wet with bleach solution for 10 minutes. Rinse and dry per cleaning instructions. NOTE: Most germicidal disinfectants are safe for use with the cushion insert if used following the disinfectant manufacturer’s dilution directions. To Sterilize the Cushion Insert: ROHO, Inc. highly discourages sterilization methods using temperatures greater than 200°F / 93°C. High temperatures accelerate aging and may cause damage to the cushion insert. If institution protocol demands sterilization, open the valves and use the lowest temperature possible for the shortest time possible. Gas sterilization is preferable to steam autoclave, but neither is recommended. If steam autoclaving, make sure all valves are open. NOTE: DO NOT use oil-based lotions, lanolin, or phenolic-based disinfectants on cushion insert. Doing so may compromise the integrity of the neoprene. To Clean the Contoured Foam Base Surface: Wipe lightly with a damp cloth. DO NOT use soap. DO NOT submerge in water. Wipe off with a clean cloth. Let completely air dry before reassembly. NOTE: Disinfectants are not effective on porous surfaces such as foam. If the foam becomes soiled or contaminated, DO NOT use with multiple users. Replacement foam parts may be purchased. Replace with ROHO foam parts only.
  • Page 9: Return Policy

    RETURN POLICY: All products returned must be new and unused, require prior authorization from ROHO, Inc. and are subject to a restocking charge. Before returning product, contact our Customer Service Department at 1-800-851-3449 toll free in the U.S.A. Outside the U.S.A., contact your country’s ROHO International distributor. For a current list of ROHO International distributors, visit our website at www.therohogroup.com, contact ROHO International at 1-618-277-9150 or email us at cs@therohogroup.com. DISPOSAL: When properly used and disposed, there are no known environmental hazards associated with the components of the ROHO Hybrid ELITE Cushion. Dispose of the product and/or components in accordance with the applicable regulations in your jurisdiction. DO NOT INCINERATE. LIMITED WARRANTY: What is covered? ROHO, Inc. covers any defects in materials or workmanship of the product. For how long? 24 months from the date the product was originally purchased, with the exception of the cover, which has a 6-month Limited Warranty. What is not covered? A product that has been misused, damaged by an accident, or damaged from "an act of Nature", e.g., flood, tornado, earthquake, fire. Any substitutions of supplied hardware or modification to the product will void the warranty. What the customer must do.
  • Page 10: Spanish

    A P R OD U CT S UPPORTED BY: A L L I A N C E 100 North Florida Avenue Belleville, IL 62221-5429 U.S.A. www.therohogroup.com cs@therohogroup.com U.S.A.: 1-800-851-3449 Fax 1-888-551-3449 Outside the U.S.A.: 1-618-277-9150 Fax 1-618-277-6518 T20192 11/09...
