BayRS Version 13.10
Document Change
Notice
BayRS Version 13.10
Site Manager Software Version 7.10
BCC Version 4.10
Part No. 300020-C Rev. 00
November 1998

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BayRS and is the answer not in the manual?

Questions and answers

Related Manuals for Bay Networks BayRS

Summary of Contents for Bay Networks BayRS

  • Page 1 BayRS Version 13.10 Document Change Notice BayRS Version 13.10 Site Manager Software Version 7.10 BCC Version 4.10 Part No. 300020-C Rev. 00 November 1998...

  • Page 2: Restricted Rights Legend

    ACE, AFN, AN, BCN, BLN, BN, BNX, CN, FRE, LN, PPX, and Bay Networks are registered trademarks and Advanced Remote Node, ANH, ARN, ASN, BayRS, BaySecure, BayStack, BayStream, BCC, BCNX, BLNX,, FN, IP AutoLearn, SN, SPEX, Switch Node, System 5000, and the Bay Networks logo are trademarks of Bay Networks, Inc.
  • Page 3 Software is first shipped to Licensee. If any item of Software fails to so function during its warranty period, as the sole remedy Bay Networks will at its discretion provide a suitable fix, patch, or workaround for the problem that may be included in a future Software release.
  • Page 4 7. Term and termination. This license is effective until terminated; however, all of the restrictions with respect to Bay Networks’ copyright in the Software and user manuals will cease being effective at the date of expiration of the Bay Networks copyright; those restrictions relating to use and disclosure of Bay Networks’ confidential information shall continue in effect.

  • Page 5: Table Of Contents

    Preface Text Conventions ... xi Acronyms ...xiii Bay Networks Technical Publications ...xiii How to Get Help ...xiv Document Change Notice Configuring L2TP Services ... 4 Overview of the Name Server Addresses Feature ... 4 Specifying the Origin of the Name Server Address ... 6 Configuring the NSA Feature for L2TP ...
  • Page 6 Monitoring EIA Signals ... 57 Configuring and Managing Routers with Site Manager ... 58 Configuring and Monitoring Syslog Using the BCC ... 58 Upgrading Routers to BayRS Version 13.xx ... 89 Boot and Diagnostic PROM Upgrades for Version 13.10 ... 89 300020-C Rev. 00...
  • Page 7 Figure 1. Specifying Server-Assigned NSAs in the Dial-Up Networking TCP/IP Settings Window ... 5 Figure 2. Network with Name Server Address Origin Parameter Set to Local ... 8 Figure 3. Network with Name Server Address Origin Parameter Set to RADIUS ... 9 Figure 4.
  • Page 9 Table 1. Version 13.10/7.10 Documentation ... 1 Table 2. Syslog Parameters (box or stack > syslog) ... 86 Table 3. Parameters of log-host (box or stack > syslog > log-host) ... 86 Table 4. Parameters of filter (box or stack > syslog > log-host > filter) ... 87 Table 5.

  • Page 11: Preface

    This guide describes changes to router software and hardware documentation since BayRS Version 13.10, identifies new and revised manuals since Version 13.00, and lists those manuals that we have not revised and which are affected by sections in this document change notice.
  • Page 12 braces ({}) brackets ([ ]) ellipsis points (. . . ) italic text screen text Indicate required elements in syntax descriptions where there is more than one option. You must choose only one of the options. Do not type the braces when entering the command.

  • Page 13: Acronyms

    You can now print Bay Networks technical manuals and release notes free, directly from the Internet. Go to support.baynetworks.com/library/tpubs/. Find the Bay Networks specific category and model or version for your hardware or software product. 300020-C Rev. 00 Shows menu paths.

  • Page 14: How To Get Help

    Using Adobe Acrobat Reader, you can open the manuals and release notes, search for the sections you need, and print them on most standard printers. You can download Acrobat Reader free from the Adobe Systems Web site, www.adobe.com. You can purchase Bay Networks documentation sets, CDs, and selected technical publications through the Bay Networks Collateral Catalog.

  • Page 15: Document Change Notice

    Table 1 lists the manuals included in the Version 13.10/7.10 release and those manuals affected by sections in this document. Table 1. Document Title BCC Quick Reference Cable Guide Configuring and Managing Routers with Site Manager Configuring and Troubleshooting Bay Dial VPN Networks Configuring AppleTalk Services Configuring APPN Services...
  • Page 16 Table 1. Document Title Configuring Dial Services Configuring DLSw Services Configuring Ethernet, FDDI, and Token Ring Services Configuring Frame Relay Services Configuring IP Security Services Configuring Interface and Router Redundancy Configuring IP Multicasting and Multimedia Services Configuring IP Services Configuring IP Utilities Configuring IPv6 Services Configuring IPX Services Configuring L2TP Services...
  • Page 17 Configuring XNS Services Connecting ASN Routers to a Network Managing Routers Using the HTTP Server Quick-Starting Routers Troubleshooting Routers Upgrading Routers to BayRS Version 13.xx Using Technician Interface Scripts Using Technician Interface Software Using the Bay Command Console Writing Technician Interface Scripts 300020-C Rev.

  • Page 18: Configuring L2Tp Services

    Configuring L2TP Services The following sections are amendments to Configuring L2TP Services. Overview of the Name Server Addresses Feature Bay Networks Server Addresses,” for Layer 2 Tunneling Protocol (L2TP) connections. This name server address (NSA) feature enables a remote host dialing in to a Bay Networks router acting as an L2TP network server (LNS) to obtain NSAs from either the LNS or a RADIUS server.

  • Page 19: Figure 1. Specifying Server-Assigned Nsas In The Dial-Up Networking Tcp/Ip Settings Window

    Figure 1. When users specify that they want to use server-assigned NSAs, they should not enter primary and secondary domain name server (DNS) and WINS name server addresses (also called NetBIOS name server addresses or NBNS addresses). Instead, when a user dials in, the LNS or RADIUS server automatically assigns name server addresses for the connection.

  • Page 20: Specifying The Origin Of The Name Server Address

    Specifying the Origin of the Name Server Address When you configure the NSA feature on the router, you must use Site Manager to set the Name Server Address Origin parameter to one of three values: Disable, Local, or RADIUS. The following sections describe each of these options. Disable If you leave the Name Server Address Origin parameter at its default of Disable, the NSA feature is disabled for the LNS configured on this router slot.
  • Page 21 • The RADIUS server must have entries in its database corresponding to incoming host user names. • The RADIUS server must support vendor specific attributes (VSA) and must have the following entries in its dictionary: ATTRIBUTE Annex-Primary-DNS-Server ATTRIBUTE Annex-Secondary-DNS-Server ATTRIBUTE Annex-Primary-NBNS-Server ATTRIBUTE Annex-Secondary-NBNS-Server Examples Name Server Address Origin Parameter Set to Local...

  • Page 22: Figure 2. Network With Name Server Address Origin Parameter Set To Local

    Remote host A Remote host B Remote host C Figure 2. Network with Name Server Address Origin Parameter Set to Local Name Server Address Origin Parameter Set to RADIUS Figure 3 shows a network with the following configuration: • Users at remote hosts Eng. host A, Eng. host B, Fin. host C, and Fin. host D have specified “Server assigned name server addresses”...

  • Page 23: Figure 3. Network With Name Server Address Origin Parameter Set To Radius

    When users at remote hosts Eng. host A and Eng. host B make dial-up connections to the corporate network, those connections use Eng. DNS1, Eng. DNS2, Eng. NBNS1, and Eng. NBNS2 as primary and secondary name servers. When users at remote hosts Fin. host A and Fin. host B make dial-up connections to the corporate network, those connections use Fin.

  • Page 24: Configuring The Nsa Feature For L2Tp

    Configuring the NSA Feature for L2TP To configure the NSA feature for L2TP, complete the following tasks: You do this 1. In the Configuration Manager window, choose Protocols. 2. Choose IP . 3. Choose L2TP . 4. Choose L2TP Configuration. 5.

  • Page 25: Checking Nsa Assignments

    Checking NSA Assignments To see which NSAs the LNS or RADIUS server assigned to a particular user, complete the following steps at the remote user’s PC: Choose Start > Run. The Run window opens Figure 4. t the Open: winipcfg The IP Configuration window opens 300020-C Rev.

  • Page 26: Figure 5. Ip Configuration Window

    Figure 5. Click on More Info. The More Info. IP Configuration window opens field lists the primary and secondary DNS server addresses assigned by the server. (Click on the Primary WINS Server and Secondary WINS Server fields list the primary and secondary NBNS addresses, if any.

  • Page 27: Figure 6. More Info. Ip Configuration Window

    Document Change Notice Figure 6. More Info. IP Configuration Window 300020-C Rev. 00...

  • Page 28: Name Server Addresses Parameter Descriptions

    Name Server Addresses Parameter Descriptions This section includes descriptions of the Site Manager parameters related to the NSA feature. This is the same information available by clicking on the Help button. Parameter: Name Server Address Origin Path: Configuration Manager > Protocols > IP > L2TP > L2TP Configuration Default: Disable Options: Disable Local...
  • Page 29 Parameter: Secondary DNS Address Path: Configuration Manager > Protocols > IP > L2TP > L2TP Configuration Default: None Options: Any valid IP address Function: If the Name Server Address Origin parameter is set to Local, the Secondary DNS Address parameter specifies the address of the secondary domain name server (DNS) that every remote host should use.

  • Page 30: Cable Guide

    Cable Guide The following sections are amendments to the Cable Guide: • 50-Pin to V.28 Cable (Order No. AA0018023) • 15-Pin D-Sub to RS-232: Raise DTR (Order No. 7118) • 15-Pin D-Sub to RS-232: V.25bis (Order No. 7119) • 15-Pin D-Sub to V.35: V.25bis (Order No. 7120) •...

  • Page 31: 50-Pin To V.28 Cable (Order No. Aa0018023)

    50-Pin to V.28 Cable (Order No. AA0018023) Pin 1 Pin 26 50-position 0.8-mm plug (ground shield connected to internal shell) Industry Interface Type: V.28 (V.10) Bay Networks Termination Signal Frame Ground Send Data + Receive Data + Request to Send + Clear to Send + Data Set Ready + Signal Ground...

  • Page 32: 15-Pin D-Sub To Rs-232: Raise Dtr (Order No. 7118)

    15-Pin D-Sub to RS-232: Raise DTR (Order No. 7118) Pin 1 Pin 9 15-position D-sub plug with locking posts (ground shield connected to backshell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Signal Ground Transmitted Data Transmitter Signal Element Timing (DTE Source) Transmitter Signal Element Timing (DCE Source)

  • Page 33: 15-Pin D-Sub To Rs-232: V.25Bis (Order No. 7119)

    15-Pin D-Sub to RS-232: V.25bis (Order No. 7119) Pin 1 Pin 9 15-position D-sub plug with locking posts (ground shield connected to backshell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Signal Ground Transmitted Data Transmitter Signal Element Timing (DTE Source) Transmitter Signal Element Timing (DCE Source) Request to Send...

  • Page 34: 15-Pin D-Sub To V.35: V.25Bis (Order No. 7120)

    15-Pin D-Sub to V.35: V.25bis (Order No. 7120) Pin 1 Pin 9 15-position D-sub plug with locking posts (ground shield connected to backshell) Industry Interface Type: V.35 (V.10 and V.11) Bay Networks Termination Signal Signal Ground Send Data + Send Data - Serial Clock Transmit + Serial Clock Transmit - Request to Send +...

  • Page 35: 15-Pin D-Sub To V.35: Raise Dtr (Order No. 7121)

    15-Pin D-Sub to V.35: Raise DTR (Order No. 7121) Pin 1 Pin 9 15-position D-sub plug with locking posts (ground shield connected to backshell) Industry Interface Type: V.35 (V.10 and V.11) Bay Networks Termination Signal Signal Ground Send Data + Send Data - Serial Clock Transmit + Serial Clock Transmit -...

  • Page 36: 44-Pin D-Sub To V.35: Raise Dtr (Order No. 7137)

    44-Pin D-Sub to V.35: Raise DTR (Order No. 7137) Pin 1 Pin 16 Pin 31 44-position D-sub plug with screw locks (ground shield connected to backshell) Industry Interface Type: V.35 (V.10 and V.11) 15 ft (4.57 m) Pin 15 Pin 30 Pin 44 34-position V.35 plug with screw jack retainers (ground shield connected to backshell)
  • Page 37 Bay Networks Termination Signal Frame Ground Request to Send + Clear to Send + Data Set Ready + Data Terminal Ready + Data Carrier Detect + VTT + VTT - Signal Ground VST + VST - VRT + VRT - VRD + VRD - VSD +...

  • Page 38: 44-Pin D-Sub To Rs-232: Raise Dtr (Order No. 7138)

    44-Pin D-Sub to RS-232: Raise DTR (Order No. 7138) Pin 1 Pin 16 Pin 31 44-position D-sub plug with screw locks (ground shield connected to backshell) Industry Interface Type: RS-232-C 15 ft (4.57 m) Pin 1 Pin 15 Pin 30 Pin 14 Pin 44 25-position D-sub plug with screw locks...
  • Page 39 Bay Networks Termination Signal Frame Ground Send Data + Receive Data + Request to Send + Clear to Send + Data Set Ready + Signal Ground Data Terminal Ready + Data Carrier Detect + Send Timing + Receive Timing + Transmitter Signal Element Timing + 12 Internal Wire Connections Pin 7 >...

  • Page 40: 44-Pin To V.35M (Order No. 7159)

    44-Pin to V.35M (Order No. 7159) Pin 1 Pin 16 Pin 31 44-position D-sub plug with screw locks (ground shield connected to backshell) Industry Interface Type: V.35 (V.10 and V.11) 10 ft (3.05 m) Pin 15 Pin 30 Pin 44 34-position V.35 plug with screw jack retainers (ground shield connected to backshell) CAB0031B...
  • Page 41 Bay Networks Termination Signal Frame Ground Request to Send + Clear to Send + Data Set Ready + Data Terminal Ready + Data Carrier Detect + VTT + VTT - Signal Ground VST + VST - VRT + VRT - VRD + VRD - VSD +...

  • Page 42: Pass-Through: 15-Pin To Rs-232 (Order No. 7218)

    RS-232 Pass-Through: 15-Pin to RS-232 (Order No. 7218) Pin 1 Pin 9 15-position D-sub plug with locking posts (ground shield connected to backshell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Signal Ground Transmitted Data Transmit Clock Data Set Ready Data Carrier Detect Receive Clock Received Data...

  • Page 43: 44-Pin D-Sub To V.35: Leased Line Or V.25Bis (Order No. 7220)

    44-Pin D-Sub to V.35: Leased Line or V.25bis (Order No. 7220) Pin 1 Pin 16 Pin 31 44-position D-sub plug with screw locks (ground shield connected to backshell) Industry Interface Type: V.35 (V.10 and V.11) 300020-C Rev. 00 15 ft (4.57 m) Pin 15 Pin 30...
  • Page 44 Bay Networks Termination Signal VSD + VSD - VRT + VRT - VST + VST - VRD + VRD - Data Set Ready + Data Terminal Ready + Request to Send + Clear to Send + VTT + VTT - Frame Ground Data Carrier Detect + Signal Ground...

  • Page 45: 15-Pin D-Sub To Rs-232 (Order No. 7255)

    15-Pin D-Sub to RS-232 (Order No. 7255) Pin 1 Pin 9 15-position D-sub plug with locking posts (ground shield connected to backshell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Signal Ground Transmitted Data Transmitter Signal Element Timing (DTE Source) Transmitter Signal Element Timing (DCE Source) Request to Send...

  • Page 46: 15-Pin D-Sub To V.28 (Order No. 7256)

    15-Pin D-Sub to V.28 (Order No. 7256) Pin 1 Pin 9 15-position D-sub plug with locking posts (ground shield connected to backshell) Industry Interface Type: V.28 (V.10) Bay Networks Termination Signal Signal Ground Transmitted Data Transmitter Timing (DTE Source) Transmitter Signal Element Timing (DCE Source) Request to Send Clear to Send...

  • Page 47: 44-Pin D-Sub To Rs-232: Leased Line Or V.25Bis (Order No. 7826)

    44-Pin D-Sub to RS-232: Leased Line or V.25bis (Order No. 7826) Pin 1 Pin 16 Pin 31 44-position D-sub plug with screw locks (ground shield connected to backshell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Frame Ground Send Data + Receive Data + Request to Send + Clear to Send +...

  • Page 48: Pass-Through: 44-Pin To Rs-232 (Order No. 7833)

    RS-232 Pass-Through: 44-Pin to RS-232 (Order No. 7833) Pin 1 Pin 16 Pin 31 44-position D-sub plug with screw locks (ground shield connected to backshell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Receive Data + Send Data + Data Carrier Detect + RTS + Send Timing + Frame Ground...

  • Page 49: Pass-Through: 44-Pin To V.35 (Order No. 7834)

    V.35 Pass-Through: 44-Pin to V.35 (Order No. 7834) Pin 1 Pin 16 Pin 31 44-position D-sub plug with screw locks (ground shield connected to backshell) Industry Interface Type: V.35 (V.10 and V.11) 300020-C Rev. 00 15 ft (4.57 m) Pin 15 Pin 30 Pin 44 34-position V.35 plug with screw jack retainers...
  • Page 50 Bay Networks Termination Signal VSD + VSD - VRD + VRD - Request to Send + Data Carrier Detect + VTT + VTT - Frame Ground Signal Ground Internal Wire Connections Pin 4 > 5 Pin 32 > 34 > 40 Pin 31 >...

  • Page 51: 44-Pin D-Sub To V.28 (Order No. 7837)

    44-Pin D-Sub to V.28 (Order No. 7837) Pin 1 Pin 16 Pin 31 44-position D-sub plug with screw locks (ground shield connected to backshell) Industry Interface Type: V.28 (V.10) 300020-C Rev. 00 15 ft (4.57 m) Pin 1 Pin 15 Pin 30 Pin 14 Pin 44...
  • Page 52 Bay Networks Termination Signal Frame Ground Send Data + Receive Data + Request to Send + Clear to Send + Data Set Ready + Data Terminal Ready + Data Carrier Detect + Send Timing + Receive Timing + Transmitter Signal Element Timing + Signal Ground Internal Wire Connections...

  • Page 53: 50-Pin To V.35 (Order No. 7932)

    50-Pin to V.35 (Order No. 7932) Pin 1 Pin 26 50-position 0.8-mm plug (ground shield connected to internal shell) Industry Interface Type: V.35 (V.10 and V.11) 300020-C Rev. 00 15 ft (4.57 m) Pin 25 Pin 50 34-position V.35 plug with screw jack retainers (ground shield connected to backshell) CAB0070A...
  • Page 54 Bay Networks Termination Signal VSD + VSD - VRT + VRT - VST + VST - VRD + VRD - Data Set Ready + Data Terminal Ready + Request to Send + Clear to Send + VTT + VTT - Frame Ground Data Carrier Detect Signal Ground...

  • Page 55: 50-Pin To V.35: Raise Dtr (Order No. 7933)

    50-Pin to V.35: Raise DTR (Order No. 7933) Pin 1 Pin 26 50-position 0.8-mm plug (ground shield connected to internal shell) Industry Interface Type: V.35 (V.10 and V.11) 300020-C Rev. 00 15 ft (4.57 m) Pin 25 Pin 50 34-position V.35 plug with screw jack retainers (ground shield connected to backshell) CAB0071A...
  • Page 56 Bay Networks Termination Signal VSD + VSD - VRT + VRT - VST + VST - VRD + VRD - Data Set Ready + Data Terminal Ready + Request to Send + Clear to Send + VTT + VTT - Frame Ground Data Carrier Detect + Signal Ground...

  • Page 57: 50-Pin To Rs-232 (Order No. 7934)

    50-Pin to RS-232 (Order No. 7934) Pin 1 Pin 26 50-position 0.8-mm plug (ground shield connected to internal shell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Frame Ground Send Data + Receive Data + Request to Send + Clear to Send + Data Set Ready + Signal Ground Data Terminal Ready +...

  • Page 58: 50-Pin To Rs-232: Raise Dtr (Order No. 7935)

    50-Pin to RS-232: Raise DTR (Order No. 7935) Pin 1 Pin 26 50-position 0.8-mm plug (ground shield connected to internal shell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Frame Ground Send Data + Receive Data + Request to Send + Clear to Send + Data Set Ready + Data Terminal Ready +...

  • Page 59: 15-Pin To F Rs-232 Synchronous Pass-Through (Order No. 7941)

    15-Pin to F RS-232 Synchronous Pass-Through (Order No. 7941) Pin 1 Pin 9 15-position D-sub plug with locking posts (ground shield connected to backshell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Transmit Data Receive Data Request to Send Data Carrier Detect Transmit Clock Signal Ground Internal Wire Connections...

  • Page 60: 44-Pin To F Rs-232 Synchronous Pass-Through (Order No. 7943)

    44-Pin to F RS-232 Synchronous Pass-Through (Order No. 7943) Pin 1 Pin 16 Pin 31 44-position D-sub plug with screw locks (ground shield connected to backshell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Send Data + Receive Data + Request to Send + Data Carrier Detect + Send Timing +...

  • Page 61: 44-Pin To F V.35 Synchronous Pass-Through (Order No. 7944)

    44-Pin to F V.35 Synchronous Pass-Through (Order No. 7944) Pin 1 Pin 16 Pin 31 44-position D-sub plug with screw locks (ground shield connected to backshell) Industry Interface Type: V.35 (V.10 and V.11) Bay Networks Termination Signal VSD + VSD - VRD + VRD - Request to Send +...

  • Page 62: 50-Pin To F Rs-232 Synchronous Pass-Through (Order No. 7945)

    50-Pin to F RS-232 Synchronous Pass-Through (Order No. 7945) Pin 1 Pin 26 50-position 0.8-mm plug (ground shield connected to internal shell) Industry Interface Type: RS-232-C Bay Networks Termination Signal Send Data + Receive Data + Request to Send + Data Carrier Detect + Send Timing + Frame Ground...

  • Page 63: 50-Pin To F V.35 Synchronous Pass-Through (Order No. 7946)

    50-Pin to F V.35 Synchronous Pass-Through (Order No. 7946) Pin 1 Pin 26 50-position 0.8-mm plug (ground shield connected to internal shell) Industry Interface Type: V.35 (V.10 and V.11) Bay Networks Termination Signal VSD + VSD - VRD + VRD - Request to Send + Data Carrier Detect + VTT +...

  • Page 64: Configuring Ppp Services

    Configuring PPP Services The following sections are amendments to Configuring PPP Services. Replace the existing sections “Setting the Maximum Receive Unit (MRU)” and “Enabling RFC 1661 Compliance for Dial Circuits” with the sections that follow. Note that all the upgrade options listed in “Setting the Maximum Receive Unit (MRU)”...

  • Page 65: Using Site Manager

    Using Site Manager For leased lines, MRU is negotiated automatically, so there is no need to manually set this parameter. To set the MRU for dial lines, complete the following tasks: You do this 1. In the Configuration Manager window, choose Protocols.

  • Page 66: Disabling Rfc 1661 Compliance

    Disabling RFC 1661 Compliance RFC 1661 compliance is enabled by default for dial lines. For leased lines, you must disable compliance so that the MRU size can be negotiated correctly. To disable RFC 1661 compliance, complete the following tasks: You do this 1.

  • Page 67: Ppp Line Parameters

    PPP Line Parameters Replace the existing descriptions for MRU Size and RFC1661 Compliance with the parameter descriptions that follow. Parameter: MRU Size (bytes) Path: Protocols > PPP > Interfaces > Lines Default: 1590 (leased lines) Options: 1 to 4600 Function: Sets the maximum receive unit (MRU) size, in bytes, for the line. Instructions: The router determines the MRU size based on the value of the RFC1661 Compliance parameter and whether the connection is a leased line or a dial line.
  • Page 68 BayRS Version 13.10 Document Change Notice Parameter: RFC1661 Compliance Path: Protocols > PPP > Interfaces > Lines Default: Enable Options: Enable Disable Function: Enables RFC 1661 compliance for a PPP dial circuit. RFC 1661 defines the standards for PPP operation.

  • Page 69: Configuring Data Encryption Services

    Configuring Data Encryption Services The following sections are amendments to Configuring Data Encryption Services. Replace the existing section, “Configuring Encryption with Dial Backup” with the following section, “Using Encryption with Dial Services.” Using Encryption with Dial Services You can configure WEP to work with dial-on-demand, dial backup, and bandwidth-on-demand services.

  • Page 70: Configuring Frame Relay Services

    Configuring Frame Relay Services The following section is an amendment to Configuring Frame Relay Services. Calculating the MTU Size for Frame Relay Connections If your Bay Networks router communicates across a frame relay line, you need to make an adjustment when you configure the maximum transmission unit (MTU). You set the MTU value by configuring the MTU parameter.

  • Page 71: Using Technician Interface Software

    Using Technician Interface Software The following sections are amendments to Using Technician Interface Software. Monitoring EIA Signals You can monitor Electronic Industries Association (EIA) signals on the serial ports of Bay Networks AN request to send (RTS), clear to send (CTS), data send ready (DSR), data terminal ready (DTR), and data carrier detect (DCD) signals on any serial port including RS-232-C, RS-422, and V.35 interfaces.

  • Page 72: Configuring And Managing Routers With Site Manager

    Syslog configuration parameters Overview of the Syslog Service You can use the BayRS Syslog messaging service to capture and process router event messages on any UNIX-based network management platform. The Syslog component of the router software supports this functionality by communicating with a counterpart software component named syslogd on your management workstation.

  • Page 73: Figure 7. Syslog And Syslogd Operations

    • Receives syslog messages • Identifies message sources • Determines message priorities • Logs, displays, prints, and/or forwards messages Figure 7. 300020-C Rev. 00 Syslog software: • Polls slot logs • Retrieves event messages • Filters retrieved messages • Maps retrieved...
  • Page 74 Remote Hosts and Filters Through the Syslog service, you use a management workstation (typically, a remote UNIX host) to monitor event messages generated by the software entities on each router in your network. You configure entity filters on each router to capture and forward to that host only messages that you specify.

  • Page 75: Figure 8. Router Event Message Filtering For One Host

    Each event message contains the name of the entity that originated (logged) that message. For a complete list of BayRS entity names and their corresponding internal entity numbers, refer to the BayRS documentation CD, or access the event message database at: http://support.baynetworks.com/library/tpubs/events...
  • Page 76 You can configure an individual entity filter to do one of the following: • Capture from one entity all messages that fall within the numbered range of events you specify. • Capture from all entities event messages logged with the severity levels that you specify.
  • Page 77 If you configure an event number range of 0 to 255, Syslog ignores the range as a filtering parameter and instead captures messages that match the criteria of the filter’s message severity mask. Filtering by Event Severity Level Each event message generated by the router software has one of the following severity levels: • Fault •...
  • Page 78 Filtering by Slot Number The router stores event messages in the log buffer associated with each slot. You can create an entity filter that captures only event messages logged on the slots you specify. To define a range of slot numbers for an entity filter, you specify values for the following •...

  • Page 79: Figure 9. Syslog Message Encapsulation

    [IP header] [UDP header] "{<priority code>} {Syslog message}" "<[Facility] | [Level]>" Figure 9. Syslog Message Encapsulation The following paragraphs describe the purpose of each field in a Syslog packet shown in Figure IP Header -- Syslog adds to any event message that matches all filtering criteria the destination IP address for a specific remote host.

  • Page 80: Figure 10. Syslog Message Composition

    Facility Codes The facility code identifies a standard UNIX system facility that receives a message from an internal or external software entity. The “Local <0-7>” UNIX system facilities receive event messages (in Syslog format) from routers in the network. The following table relates UNIX system facility names to their respective facility codes on a workstation.
  • Page 81 UNIX System Error Codes You determine how the severity levels of Bay Networks router event messages map to error levels on your UNIX workstation, based on the requirements of the network management application you use. For instructions on how to map router event messages to UNIX system error level codes, see “Mapping Router Message Severity Levels to UNIX System Error Levels”...
  • Page 82 Configuring syslog.conf UNIX workstations have a syslog.conf file in which you define destinations for event messages received by the local syslogd software module. For syslogd to properly dispatch router event messages to a file, display, printer, or another remote host, you must edit the contents of the /etc/syslog.conf file.
  • Page 83 Example: Messages dispatched to console display: local7.debug [TAB] local7.info [TAB] local7.notice [TAB] local7.err [TAB] local7.crit [TAB] local7.alert [TAB] local7.emerg [TAB] local7.debug;local7.info;local;local7.notice; local7.err;local7.crit;local7.alert;local7.emerg Messages dispatched to a file: local7.info [TAB] local7.debug [TAB] local7.warning [TAB] Messages dispatched to a host: local7.notice [TAB] Messages dispatched to a printer: local7.trace [TAB] The example shows that you press the [Tab] key to access the path designation for...

  • Page 84: Figure 11. Bcc Configuration Hierarchy For Syslog Services

    Starting Syslog on the Router The following steps describe how to configure Syslog on a router: Using the console attached to the router, or using a telnet connection to the router, log on to the Technician Interface. Start the BCC and enter configuration mode. Configure the Syslog global entity.
  • Page 85 * To list all system commands, type ? * To exit the BCC, type exit bcc> If you need more information about how to log on to a Bay Networks router, see Using Technician Interface Software. To enter BCC configuration mode, enter: config bcc>...
  • Page 86 Identifying a UNIX Host to Receive Router Syslog Messages You must define which remote hosts you want to receive Syslog (event) messages from the router. To define a host, navigate to the log-host address <IP_address> IP_address For example, to point the Syslog service to the remote host at IP address 192.168.3.4, enter: syslog box#...
  • Page 87 You can configure up to 10 filters per remote host, without changing configuration context. For each new filter, reenter the legal value for the required entity parameter. To see a list of entity names you can use, enter the following command: log-host/192.168.3.7# Legal values: atm_dxi...
  • Page 88 To define by message number the events you want Syslog to capture and forward to a remote host, configure values for the event-lower-bound and event-upper-bound parameters. Navigate to the appropriate entity filter and enter: event-lower-bound <event_number> event-upper-bound <event_number> event_number range of events you want Syslog to capture. Example: syslog box#...
  • Page 89 Example: filter/192.168.3.4/telnet-sessions# Note: To specify multiple severity levels (other than “all”) concurrently, you must enclose these values within braces {...} on the command line, and you must insert a space after each value except the last one preceding the closing brace.
  • Page 90 Saving a Syslog Configuration You can save your configuration as a bootable (binary) file on an NVFS volume by entering: save config <vol> : <filename> You can also save the configuration as an ASCII text file, which you can import into the active router configuration.
  • Page 91 Stopping or Restarting Syslog Messaging to All Hosts You can stop Syslog messaging to all remote hosts by disabling Syslog services. Navigate to the disable Example: syslog box# disable syslog# To confirm the change, check the current value of the state parameter by entering: state syslog# state disabled...
  • Page 92 To restart Syslog messaging, navigate to the appropriate enter: enable Example: syslog box# log-host 192.168.3.4 syslog# log-host/192.168.3.4# To confirm the change, check the current value of the state parameter by entering: log-host/192.168.3.4# state enabled Disabling or Reenabling a Filter You can stop an entity filter from capturing event messages for its associated remote host.
  • Page 93 Document Change Notice To confirm the change, check the current value of the filter state parameter by entering: state filter/192.168.125.3/telnet-sessions# state enabled Deleting an Entity Filter from a Configured Host To delete an entity filter from a configured host, navigate to the appropriate filter context and enter: delete...
  • Page 94 BayRS Version 13.10 Document Change Notice Deleting a Configured Host and its Filters To delete a specific entry from the Syslog configuration, navigate to the log-host appropriate context and enter: log-host delete Example: delete log-host/192.168.3.4# syslog# Notice that the BCC prompt returns to the configuration context.
  • Page 95 Customizing Syslog Operation Many Syslog service parameters already have suitable default values. Depending on your specific requirements, you may want to customize settings associated with the following tasks: • Mapping router event message severity levels to remote host (UNIX) system error levels •...
  • Page 96 Example: filter/192.168.3.4/telnet-sessions# filter/192.168.3.4/telnet-sessions# filter/192.168.3.4/telnet-sessions# filter/192.168.3.4/telnet-sessions# filter/192.168.3.4/telnet-sessions# Defining the Maximum Number of Remote Hosts You can accept the default maximum number of remote hosts configurable on a device (5), or you can navigate to the router’s maximum-hosts <maximum_hosts> Example: syslog box# maximum-hosts 3 syslog# Defining the Time Between Polling Cycles...
  • Page 97 Example: syslog box# log-host/192.168.3.4 syslog# log-host/192.168.3.4# Legal values for the log-facility parameter are local0 through local7. Enabling Sequential Syslog Messaging Message time-sequencing allows Syslog to capture and forward router event messages in chronological order. Disabling this feature causes Syslog messages to be forwarded according to the polled sequence of slots.
  • Page 98 show syslog base show syslog base This command has no optional filters (flags). The output of State Maximum Active Hosts Poll Iteration Timer Operational State # Active Seq. Hosts # Active Non-seq. Hosts The number of hosts receiving Syslog messages on a # Messages Sent show syslog log-host show syslog log-host...
  • Page 99 The output of the information: Host IP Address Configured State Operational State Time Sequencing UDP Port Facility Code # Messages Sent show syslog filter show syslog filter the router. This command supports the following command filters (flags) and filter arguments: -log-host <IP_address>...
  • Page 100 The output of the information: Host IP Address Filter Name Entity Name Configured State Operational State Syslog Parameter Descriptions This section describes parameters for the following BCC configurable objects: • syslog • log-host • filter Table 2. Syslog Parameters (box or stack > syslog) Parameter Function log-poll-timer...
  • Page 101 Table 3. Parameters of log-host (box or stack > syslog > log-host) Parameter Function address REQUIRED -- Specifies the IP address of this remote host. time-sequence Enables or disables time-sequencing and forwarding of Syslog messages. Enabling this feature allows Syslog messages from different slots (router-wide) to be interleaved and forwarded sequentially.
  • Page 102 Table 4. Parameters of filter (box or stack > syslog > log-host > filter) Parameter Function severity-mask Specifies the severity levels of router event messages -- warning, information, trace, fault, and debug -- that Syslog will capture and forward to this filter's host. Syslog uses this severity mask only if you specify the wildcard event number range (0 to 255) as values for the event-lower-bound and event-upper-bound parameters.

  • Page 103: Upgrading Routers To Bayrs Version 13.Xx

    PROMs for BayRS Version 13.10. Upgrade the PROMs if the features that you need depend on a PROM version more recent than the version now in your router.
