PNI ML75 CB antenna, without accessories
Description:
CB radio antenna suitable for both cars and trucks, compatible with any CB
radio. Very easy to install.
Installation:
•
Fix the antenna on a threaded magnetic base (eg PNI 145/PL) or connect
it to a support with a connecting cable (eg PNI T941, PNI T601).
•
Connect the PL259 plug to a CB radio (plug not included).
•
Test the SWR in an open area using a reflectometer. In some cases it may
be necessary to raise or shorten the wire to get an optimal SWR value.
For maximum performance it is recommended that this procedure, called
calibration, be performed by authorized personnel with special equipment.
Technical specifications:
Frequency
SWR
Impedance
Max. supported power
Length
Material
Tilt angle
Connector
User manual
26 – 28 MHz
≤ 1.2:1
50 Ohm
40 W continuous
300 W for a short time
850 mm
Stainless steel
0 - 90°
UHF PL
1
