PNI Extra 45 User Instruction

Instructiuni de utilizare / User instruction / Felhasználói utasítás
RO
Descriere:
• Cea mai mica antena CB de pe piata
• Poate fi montata atat pe autoturisme cat si pe autoutilitare sau microbuze.
• Datorita dimensiunilor sale reduse este foarte discreta si poate fi demontata si
depozitata in orice portbagaj.
• Are un design special anti-zgomot ce face ca aerul sa alunece in jurul spicului,
eliminand zgomotul produs de vant.
Instalare:
• Insurubati antena pe magnetul inclus in pachet apoi pozitionati-o pe cupola masinii.
• Conectati mufa PL259 din capatul cablului magnetului la mufa de antena din spatele
statiei.
• Daca este necesara calibrarea antenei, recomandam efectuarea ei de catre personal
specializat cu aparatura aferenta.
Note:
• Dati jos antena de pe masina cand o duceti la spalatorie pentru a evita defectarea
acesteia.
• Nu utilizati antena impreuna cu o statie cu putere de emisie mai mare de 50W,
pentru a evita defectarea permanenta a antenei.
Caracteristici tehnice:
Frecventa
SWR
Impedanta
Polaritate
Putere maxima suportata
Inaltime
Material
Baza magnetica
Cablu RG58
Conector
EN

Introduction:

• PNI Extra 45 CB antenna is the smallest CB antenna on the market
• It can be mounted on cars, vans or minibuses.
• Due to its small size, it is very discreet, can be disassembled and stored easily in any luggage compartment.
• It has a special anti-noise design that makes the air flow around the whip, eliminating thus the wind noise.

Installation:

• Screw the antenna onto the magnet included in the pack and then position it on the dome of the car.
• Plug the PL259 to the CB radio.
• If necessary, calibrate the antenna. This operation should be performed
• only by specialized personnel with related equipment.
Note:
• Put the antenna off the car when you take it to the car wash in order to avoid its damage.
• Do not use PNI Extra 45 antenna with a CB radio that has more then 50W transmission power in order to avoid permanent
damages to the antenna.

Technical specifications:

Frequency
Impedance
Polarity
Maximum power
Height
Material
Magnetic mount
RG58 cable
Connector
Antena CB PNI Extra 45 cu magnet inclus
26.965-27.405 MHz
<1.2:1
50 Ohmi
Verticala
50 W continuu
150W pt scurt timp
45 cm
(baza magnetica inclusa)
Fibra de sticla
122 x 60 mm
4 m
PL259
26.965-27.405 MHz
50 Ohm
Vertical
50 W continuously / 150W for short time
45 cm (magnetic mount included)
Fiberglass
122 x 60 mm
4 m
PL259
