READ AND SAVE THESE INSTRUCTIONS
Reveal
®
USER
SCC P/N
MANUAL
20-88455
REVEAL® SLIDE-IN, SELF-SERVICE, DRY (AMBIENT) MERCHANDISERS
> REAR SLIDING DOORS OR REAR PANEL
> CAUTION! DO NOT PUSH OR PULL ON GLASS END PANELS!
> ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!
Model NE4827DSSV With Rear Sliding Doors
Model NE4827DSSV With Rear Panel
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
REV E DATE: 10/18/2022
USER MANUALS\20-88455_REVEAL_USER MANUAL_NE(L)(H)DSSV_AMBIENT_SELF-SVC_SLIDE-IN_CASE
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Reveal NE4827DSSV
Summary of Contents for Reveal NE4827DSSV
- Page 1 > CAUTION! DO NOT PUSH OR PULL ON GLASS END PANELS! > ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION! Model NE4827DSSV With Rear Sliding Doors Model NE4827DSSV With Rear Panel Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com...
-
Page 2: Table Of Contents
WARNING …...…………………………………………………………………………..……………... WIRING DIAGRAM / SEALING COUNTER-MOUNTED UNITS …………………………………………. REVEAL® SLIDE-IN DRY (AMBIENT) SELF-SERVICE MODEL APPLICABILITY & DIMENSIONS.. INSTALLATION: TOE-KICK & REAR PANEL REMOVAL / REMOVING CASE FROM PALLET …... INSTALLATION, CONT’D: PREPARE CASE FOR COUNTER / REAR PANELS / MAGNETS / HANDLES ………………………………………………………………………………………….…... -
Page 3: Overview / Compliance / Lamp Replacement Precautions / Electrical Hazard
OVERVIEW / COMPLIANCE / LAMP REPLACEMENT PRECAUTIONS / ELECTRICAL HAZARD WARNING OVERVIEW ELECTRICAL HAZARD WARNING • • Cases should be installed and operated according Please read the electrical hazard warning in this to this operating manual’s instructions to insure document carefully as it can prevent injury or death. proper performance. -
Page 4: Wiring Diagram / Sealing Counter-Mounted Units
WIRING DIAGRAM / SEALING COUNTER-MOUNTED UNITS WIRING DIAGRAM SEALING COUNTER-MOUNTED UNITS • • Each case has its own wiring diagram folded and in a Proper sealing of base support to counter prevents packet. accumulation of dust, residue and liquids as well as •... -
Page 5: Reveal® Slide-In Dry (Ambient) Self-Service Model Applicability & Dimensions
REVEAL® SLIDE-IN DRY (AMBIENT) SELF-SERVICE MODEL APPLICABILITY & DIMENSIONS Upper Display Model Overall Height Case Depth x Length Height NE3613DSSV 13 5/8”UDH 32 7/8”OH 33”D x 35 3/4”L NE3620DSSV 20 3/8”UDH 39 5/8”OH 33”D x 35 3/4”L NE3627DSSV 27 7/8”UDH 47 1/8”OH... -
Page 6: Installation: Toe-Kick & Rear Panel Removal / Removing Case From Pallet
INSTALLATION: TOE-KICK & REAR PANEL REMOVAL / REMOVING CASE FROM PALLET 1. Remove Front Toe-Kick From Case • To prevent damage to case, remove front toe-kick from case before removing from pallet. • Place front toe-kick in secure location while removing case from pallet. Upper Rear Toe-Kick Panel... -
Page 7: Handles
7. Prepare Case For Counter: Side Handles Space For Countertop Handles On Side of Case (Typ.) Upper Model NE4827DSSV Slide-In Magnets Unit (Shown) May Not Exactly Reflect Every Feature or Option of Your Particular Case. Base Support Lower Magnets... -
Page 8: Installation, Cont'd: Bubble-Wrapped Glass (For Shelving)
INSTALLATION, CONT’D: BUBBLE-WRAPPED GLASS (FOR SHELVING) 8. Remove Bubble-Wrapped Glass Carefully Place Them On Shelves (For Shelving) From Case • Remove glass (for shelves) from its bubble-wrap. • Carefully remove bubble-wrapped glass shelving • Place glass pieces on shelves. pieces from case. •... -
Page 9: Installation, Cont'd: Shelving Assembly Components
INSTALLATION, CONT’D: SHELVING ASSEMBLY COMPONENTS 10. Shelving Assembly Components is installed so shelves can be disassembled (to clean or service). • Check that glass shelving is in proper position G. Rear shelf support rail before placing product in case H. Left and right glass shelf/cover assemblies (glass •... -
Page 10: Case
13. Slide-In Units: Reattach Upper and Lower • Do not return upper rear panel to case. LED Light Switch Lower Rear Panel Upper Rear Panel Model NE4827DSSV Slide-In Units (Shown) May Not Exactly Reflect Every Feature or Option of Your Particular Case. Power Cord And Plug... -
Page 11: Installation, Cont'd: Optional Acrylic Security Cover
INSTALLATION, CONT’D: OPTIONAL ACRYLIC SECURITY COVER upper security cover stop. Lock at both ends of 15. Optional Acrylic Security Cover cover with locking mechanism. Note: Illustrations reflects Model NR4835RSS; it > Important! After locking in place, store keys in safe may not reflect every feature or option of your case. -
Page 12: Merchandisers
CASE DESIGN: FRONT VIEW OF SLIDE-IN, DRY (AMBIENT) SELF-SERVICE MERCHANDISERS 1. Front View Of Slide-In, Dry (Ambient) Self-Service Merchandisers • Model NE4827DSSV is illustrated below. • See next page for rear view. Model NE4827DSSV Slide-In Unit (Shown) May Not Exactly Reflect Every Feature or Option of Your Particular Case. -
Page 13: Merchandisers
CASE DESIGN, CONT’D: REAR VIEW OF SLIDE-IN, SELF-SERVICE UNITS 2. Rear View Of Slide-In, Self-Service Units Model NE4827DSSV Is Shown. • Slide-in unit with rear sliding doors is illustrated below. It May Not Exactly Reflect Every • Certain models may have rear panels. -
Page 14: Lights
CASE DESIGN, CONT’D: POWER CORD & PLUG / LED LIGHT SWITCH LOCATIONS / LED LIGHTS 3. Power Cord and Plug Model NE4827DSSV Slide-In Unit (Shown) • Power cord and plug (for LED lights) is at case May Not Exactly Reflect Every Feature or rear (shown below). -
Page 15: Case Design, Cont'd: Rear Sliding Doors Vs. Rear Panel / Door Operation
Individually lift each door up toward the top of the case; pivot the bottom of the door out. • Return doors to case in reverse order they were removed. Model NE4827DSSV (Shown) May Not Exactly Reflect Every Feature or Option of Your Particular Case. -
Page 16: Cleaning Schedule (To Be Performed By Store Personnel)
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) FREQUENCY INSTRUCTIONS Daily Glass Surfaces: Clean side glass and shelves with household or commercial glass cleaner. Daily Acrylic Surfaces (Sneeze Guard/Optional Acrylic Security Cover): • Clean: Use soft, clean cloth dipped in solution of warm water and small amount of mild, liquid soap. -
Page 17: Troubleshooting (To Be Performed By Store Personnel)
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) CONDITION TROUBLESHOOTING Case Lights Check that light switch is in the ON position. Not Working • See CASE DESIGN, CONT’D: POWER CORD & PLUG / LED LIGHT SWITCH LOCATIONS / LED LIGHTS section in manual for switch location (regardless of case design). -
Page 18: Troubleshooting (To Be Performed By Trained Service Providers Only)
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) CONDITION TROUBLESHOOTING Case Lights Are See TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) Not Working section in manual (previous sheet) for most common troubleshooting solutions. Check power. • If power is not supplied to the case, facility may have faulty power distribution. •... -
Page 19: Serial Label Information & Location
Serial labels contain electrical information as well as regulatory standards to which the case conforms. Blend MODEL NRS3648RXV-SAMPLE SERIAL NO. 12345X30DZ098765 888 E. Porter Rd - Muskegon, MI 49441 Reveal Harmony Grocerant Addenda Fusion Oasis Impulse SINGLE PHASE 1.84 AMPS... -
Page 20: Technical Service Contact Information & Warranty Information
STRUCTURAL CONCEPTS TECHNICAL SERVICE CONTACT INFORMATION & LIMITED WARRANTY YOU MUST HAVE THE FOLLOWING INFO AVAILABLE TECH SERVICE/WARRANTY CONTACT INFO: BEFORE CONTACTING STRUCTURAL CONCEPTS: 1 (800) 433-9490 / EXTENSION 1 SERIAL NO. / MODEL NO. / STORE NO. / STORE DAYS/HOURS AVAILABLE: MONDAY - FRIDAY (CLOSED HOLIDAYS) ADDRESS / DETAILS (PHOTOS, LEAK LOCATIONS,...
