  • Page 1 IOLITE® TECHNICAL REFERENCE MANUAL IOLITE® V22-2...

  • Page 2: Table Of Contents

    IOLITE® TECHNICAL REFERENCE MANUAL Table of contents 1. About this document 1.1. Legend 1.2. Online versions 1.2.1. IOLITE® Technical Reference Manual 1.2.2. DewesoftX® User Manual 2. Getting started 2.1. Software installation 2.2. Connecting IOLITE® 2.2.1. DewesoftX® Settings IOLITE® 2.2.2. Channel Setup IOLITE® 2.3.
  • Page 3 IOLITE® TECHNICAL REFERENCE MANUAL 3.3.2. IOLITE-R8: Boxed Chassis 3.3.2.1. IOLITE-R8: Boxed Chassis: Renders 3.3.2.2. IOLITE-R8: Boxed Chassis: Dimensions 3.3.2.3. IOLITE-R8: Boxed Chassis: Connectors 3.3.2.3.1. IOLITE-R8: Boxed Chassis: Power in: Pinout 3.3.2.3.2. IOLITE-R8: Boxed Chassis: Sync: Pinout 3.3.2.3.3. IOLITE-R8: Boxed Chassis: BUS 1: IN: Pinout 3.3.2.3.4.
  • Page 4 IOLITE® TECHNICAL REFERENCE MANUAL 3.3.6.3.2. EtherNET - OUT (Data, Sync, PWR) 4. Module Overview 4.1. VOLTAGE MEASUREMENT 4.1.1. IOLITEi-8xLV / IOLITEi-8xLV-T2A2f 4.1.1.1. IOLITEi-8xLV: Specifications 4.1.1.2. IOLITEi-8xLV: Connectors 4.1.1.2.1. IOLITEi-8xLV: BNC Connector 4.1.1.2.1.1. IOLITEi-8xLV: BNC Connector: Pin out 4.1.1.2.1.2. IOLITEi-8xLV: BNC Connector: Wiring diagram 4.1.1.2.2.
  • Page 5 IOLITE® TECHNICAL REFERENCE MANUAL 4.3.2. IOLITEr-8xSTGS / IOLITEr-8xSTGS-D37 4.3.2.1. IOLITEr-8xSTGS: Specifications 4.3.2.1.1. IOLITEr-8xSTGS: Bridge Accuracy Specifications 4.3.2.2. IOLITEr-8xSTGS: Connectors 4.3.2.2.1. IOLITEr-8xSTGS: T2A9f Connectors 4.3.2.2.1.1. IOLITEr-8xSTGS: T2A9f Connector: Pinout 4.3.2.2.1.2. IOLITEr-8xSTGS: T2A9f Connector: Wiring diagram 4.3.2.2.2. IOLITEr-8xSTGS-D37: D-SUB37 Connectors 4.3.2.2.2.1. IOLITEr-8xSTGS-D37: D-SUB37 Connector: Pinout 4.3.2.2.2.2.
  • Page 6 IOLITE® TECHNICAL REFERENCE MANUAL 4.5. VIBRATION AND SOUND MEASUREMENT 4.5.1. IOLITEi-1xACC 4.5.1.1. IOLITEi-1xACC: Specifications 4.5.1.2. IOLITEi-1xACC: BNC Connector 4.5.1.2.1. IOLITEi-1xACC: BNC Connector: Pinout 4.5.1.2.2. IOLITEi-1xACC: BNC Connector: Wiring diagram 4.5.2. IOLITE-3xMEMS-ACC 4.5.2.1. IOLITE-3xMEMS-ACC: Specifications 4.6. ANALOG OUTPUT 4.6.1. IOLITE 16xAO 4.6.1.1.
  • Page 7 8.1. Safety symbols in the manual 8.2. General Safety Instructions 8.2.1. Environmental considerations 8.2.2. Product End-of-Life handling 8.2.3. System and components recycling 8.2.4. General safety and hazard warnings for all Dewesoft systems 9. Documentation version history IOLITE® V22-2 7 / 193...

  • Page 8: About This Document

    IOLITE® TECHNICAL REFERENCE MANUAL 1. About this document This is the Technical Reference Manual for IOLITE® Systems. IOLITE® is an industrial real time data acquisition hardware line that comes in many different form factors and can be equipped with a wide range of different amplifiers so that you can use it for virtually any measurement task.

  • Page 9: Online Versions

    1.2. Online versions 1.2.1. IOLITE® Technical Reference Manual The most recent version of this manual can be downloaded from our homepage: https://download.dewesoft.com/list/manuals-brochures/hardware-manuals In the Hardware Manuals section click the download link for the IOLITE® technical reference manual . 1.2.2. DewesoftX® User Manual The DewesoftX®...

  • Page 10: Getting Started

    IOLITE® TECHNICAL REFERENCE MANUAL 2. Getting started This chapter will help you to install the software, connect your IOLITE® system to the PC via EtherCAT® and will show you how to configure DewesoftX®. To follow these steps, you need the following items: your brand new Sirius system (included in the shipment) ●...

  • Page 11: Connecting Iolite

    IOLITE® TECHNICAL REFERENCE MANUAL 2.2. Connecting IOLITE® In this chapter, you can see the basic instructions for connecting IOLITE® devices. Advanced connections are described in the following chapters. IOLITE-R12 First connect the power supply cable (PS-120-L1B2f) to the PWR IN 2-pin LEMO 1B male connector. Then connect a standard ethernet cable to the IN connector of BUS 1 on IOLITE-GATE.
  • Page 12 IOLITE® TECHNICAL REFERENCE MANUAL IOLITEi - multichannel First connect the power supply cable (2x2 OMNIMATE SL 2.50 / BLF 2.50/180) to the PWR IN 2x2 TBLOCK connector. Then connect RJ-45 cable to the IN connector. Finally connect the other side (RJ45) to the LAN port of the PC.

  • Page 13: Dewesoftx® Settings Iolite

    IOLITE® TECHNICAL REFERENCE MANUAL Do not plug the powered network cable directly into the PC network port. It may damage the PC. 2.2.1. DewesoftX® Settings IOLITE® The connected device will show up in the DewesoftX® settings. Click on the Options button at the top right, and then on the Settings item in the pop-up to open the DewesoftX®...

  • Page 14: Channel Setup Iolite

    IOLITE® TECHNICAL REFERENCE MANUAL 2.2.2. Channel Setup IOLITE® In the channel setup you can see a preview of the connected devices on the left side. When you click on a connector in the image the corresponding channel in the Channel setup grid will automatically be selected.

  • Page 15: Simple Measurement

    IOLITE® TECHNICAL REFERENCE MANUAL 2.3. Simple Measurement This chapter describes measurement basics, how to configure IOLITE® and gives some details on the measurement setup. 2.3.1. Help - Manual Note that this document is just a quick start guide. For detailed information about DewesoftX® consult ❶...

  • Page 16: Analog Channel Setup

    IOLITE® TECHNICAL REFERENCE MANUAL 2.3.2. Analog channel setup In the analog channel setup screen you can see all channels of your connected IOLITE® systems. Per default only the first channel will be set to used. Unused channels will not show up in measure mode and can thus not be used for display, calculations or storing: thus, we will also set the other channels to ❶...

  • Page 17: Sample Rate

    IOLITE® TECHNICAL REFERENCE MANUAL 2.3.3. Sample rate One of the most important settings is the sample rate. The sample rate defines how many data points IOLITE® will transfer to DewesoftX®. A higher sample rate also means that more data needs to be transferred via EtherCAT®...

  • Page 18: Measurement Mode

    IOLITE® TECHNICAL REFERENCE MANUAL 2.3.4. Measurement Mode A click on Measure (at the right side of Ch. setup in Illustration below) will take you to the Recorder screen measure mode where you can already see live data. Hint When switching to Measure mode the data will not be stored automatically. Measure mode ❺...

  • Page 19: Analyse Mode

    IOLITE® TECHNICAL REFERENCE MANUAL 2.3.5. Analyse Mode When you have just stopped a measurement, DewesoftX® will automatically open the last recorded data file in Review mode, so that you can start the analysis right away. Analyse mode The Review mode is much like the measurement mode. You will see the same measurement displays, the channel-selector list and the properties of the currently selected widget.

  • Page 20: Advanced Configuration

    IOLITE® TECHNICAL REFERENCE MANUAL 2.4. Advanced configuration Note, that the Dewesoft launcher has already done the hardware setup for you – you can check this in ❶ ❷ the Settings dialogue. Click the Options button – and then click the Settings menu item Open settings dialogue The settings window will appear where all the currently connected devices will be seen.

  • Page 21: Firmware Upgrade

    ● the section Drivers. Copy the file into the Firmwares folder of your DewesoftX® installation (e.g. ● D:\DewesoftX\System\Firmwares). Connect the Dewesoft instrument to the PC and run DewesoftX®. ● Go to settings under the Update tab: ● Firmware update settings If the firmware package isn’t selected, select it by pressing the button and find the folder with the...

  • Page 22: Licensing

    IOLITE® TECHNICAL REFERENCE MANUAL 2.6. Licensing IOLITE or any other Dewesoft device already comes with an embedded DewesoftX® license. You can ❶ check the license details with all the available options in the Licensing tab by pressing the three ❻...

  • Page 23: Additional Instructions For Troubleshooting With Ethercat Devices

    TECHNICAL REFERENCE MANUAL 2.7.1. Additional instructions for troubleshooting with EtherCAT devices If the computer is still having trouble recognizing the Dewesoft EtherCAT devices, here are some additional steps: Check if there is an Ethercat DAQ Filter driver installed on your computer like shown on the ●...
  • Page 24 IOLITE® TECHNICAL REFERENCE MANUAL If the driver is already installed and the devices are still not recognized, the Speed & Duplex of the ● network card needs to be adjusted manually. Go to network connections ○ Right-click on the connection where the EtherCAT devices are connected ○...

  • Page 25: System Overview

    IOLITE® TECHNICAL REFERENCE MANUAL 3. System Overview IOLITE Data acquisition and real-time control front-end system for industrial applications. All-in-one solution for real-time control and feedback monitoring Voltage Strain / Stress Quarter Bridge Half Bridge Full Bridge Thermocouple Digital IO IEPE Charge Current LVDT...

  • Page 26: Main Features

    Each IOLITE system has two fully independent Ethercat bus systems that work in parallel. Primary Bus Primary bus is used for perfectly timed and synchronized data acquisition via Dewesoft X software. Secondary Bus The secondary bus can be used in two ways:...

  • Page 27: Input Slots And Amplifiers

    IOLITE chassis can be configured with up to 12 slots, each featuring high-quality input amplifiers. Currently, the following amplifiers are available: 6xSTG : universal analogue and strain gauge ● amplifiers. Compatible with Dewesoft smart IOLITE-R12 interface DSI adapters 8xSTGS: A dedicated module for strain ●...

  • Page 28: Redundant Power Supply

    IOLITE® TECHNICAL REFERENCE MANUAL 3.1.3. Redundant Power Supply Each IOLITE system is equipped with a redundant power supply completing the feature set for the ideal and reliable front-end system. If the primary power supply fails, the system will be powered by a secondary power supply without any interruption or system shutdown/restart.

  • Page 29: System Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 3.2. System specifications System IOLITE R12 IOLITE R8 IOLITE R8r Number of slots 12 Synchronization 2x SIRIUS® SYNC on L00B4f 2x SIRIUS® SYNC on L00B4f 2x SIRIUS® SYNC on L00B4f Sync Accuracy < 200 ns within same EtherCAT <...
  • Page 30 IOLITE® TECHNICAL REFERENCE MANUAL Hint For detailed explanation of IOLITE-R8 and IOLITE-R8r chassis shock and vibration specifications check this LINK IOLITE® V22-2 30 / 193...
  • Page 31 IOLITE® TECHNICAL REFERENCE MANUAL IOLITE Multi channel Interface IOLITE Single channel EtherCAT Data interface EtherCAT 100 Mbps Full Duplex bus speed Data Rate 100 Mbps Full Duplex bus speed < 200 ns within same EtherCAT chain < 200 ns within same EtherCAT chain <...

  • Page 32: Enclosure Overview

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3. Enclosure Overview IOLITE can be configured in the 19-inch cabinet compatible chassis (IOLITE-R12) or in more rugged Sirius-like compatible chassis (IOLITE-R8). 3.3.1. IOLITE-R12: Cabinet Mount Chassis Standard IOLITE chassis is compatible and can be mounted in any 19-inch rack cabinet. This is perfect for the test-bed installations.

  • Page 33: Iolite-R12: Cabinet Mount Chassis: Dimensions

    IOLITE® TECHNICAL REFERENCE MANUAL Cooling system on the Back panel of IOLITE-R12 3.3.1.2. IOLITE-R12: Cabinet Mount Chassis: Dimensions Technical Drawings of IOLITE-R12 IOLITE® V22-2 33 / 193...

  • Page 34: Iolite-Gate

    3.3.1.3. IOLITE-GATE The IOLITE-GATE module serves as a gateway between IOLITE measurement modules and either PC, other Dewesoft EtherCAT devices or 3rd party control masters. It includes dual EtherCAT bus, redundant power supply inputs and provides synchronization with Dewesoft USB devices.

  • Page 35: Iolite-Gate: Connectors

    Two 2-pin LEMO 1B connectors are used for redundant power supply (PWR IN). Synchronization with Dewesoft USB data acquisition devices or connection to clock master is on IOLITE-GATE enabled by connecting a synchronization cable to two SYNC inputs (4-pin LEMO 00).

  • Page 36: Iolite-Gate: Power In: Pinout

    Mating connector (for the cable): FGJ.1B.302.CLLD42Z 3.3.1.3.1.2. IOLITE-GATE: Sync: Pinout The sync connectors are required when you want to synchronize the data from IOLITE with Dewesoft USB devices for the same measurement. The signal that is transferred over sync cable makes sure that the measurement data of IOLITE and Dewesoft USB devices are perfectly synchronized to each other.

  • Page 37: Iolite-Gate: Rj45: Pinout

    The same connectors are used on Primary bus (BUS 1) for buffered data and on Secondary bus (BUS 2) for unbuffered data. Each RJ45 connector has two LEDs: GREEN LED indicates that IOLITE is connected to another device (Dewesoft EtherCAT device, PC or 3rd party control master). YELLOW LED is active only when the data transfer is active.

  • Page 38: Iolite-Gate: Connection Of Iolite-R12 Standalone Device To Pc

    Then connect a standard ethernet cable to the IN connector of BUS 1 on IOLITE-GATE. Finally, connect the other side of the ethernet cable to the LAN port of PC. Connection of IOLITE-R12 standalone device to PC List of required cables: Function Dewesoft order code Power supply PS-120-L1B2f (default) Ethercat CABLE-UTP-CAT.6-3m (default), CABLE-UTP-CAT.6-1m...

  • Page 39: Iolite-Gate: Connection Of Iolite-R12 And Dewe-43A Device

    L00B4m-L00B4m-0.2m) to the SYNC connector on IOLITE-GATE and the other side of cable to the SYNC connector on DEWE-43A. Connection of IOLITE-R12 and DEWE-43A device List of required cables: Function Dewesoft order code Power supply IOLITE-R12: PS-120-L1B2f (default) DEWE-43A: PS-60W-12V-5A-L1B2f (default) Ethernet RJ45-RJ45 CABLE-USBAmini-USBBS-1.8m (default),...

  • Page 40: Iolite-Gate: Connection Of Iolite-R12 Standalone Device To Iolite - Single Channel And Iolite - Multi Channel

    Use the RJ45 to RJ45 cable again to connect the data line to IOLITE - multi channel device. The IOLITE - multi channel device will need an additional Power supply. Connection of IOLITE-R12, IOLITE - single channel and IOLITE - multi channel Function Dewesoft order code Power supply IOLITE-R12: PS-120-L1B2f (default) IOLITE POWER-INJECTOR...

  • Page 41: Iolite-R8: Boxed Chassis

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.2. IOLITE-R8: Boxed Chassis In addition to a 19-inch rack cabinet compatible chassis, IOLITE is also available in standalone aluminium chassis compatible with Sirius data acquisition instruments. The chassis provides 8 slots for IOLITE input and output slices to be installed. IOLITE-R8 includes EtherCAT gateway and cooling system.
  • Page 42 IOLITE® TECHNICAL REFERENCE MANUAL IOLITE-R8 Back panel IOLITE® V22-2 42 / 193...

  • Page 43: Iolite-R8: Boxed Chassis: Dimensions

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.2.2. IOLITE-R8: Boxed Chassis: Dimensions Technical Drawings of IOLITE-R8 IOLITE® V22-2 43 / 193...

  • Page 44: Iolite-R8: Boxed Chassis: Connectors

    The IOLITE-R8 chassis also enables dual EtherCAT bus. There are two 8-pin LEMO 1B connectors on the back panel of IOLITE-R8 used for data transfer and synchronisation on the primary bus (BUS 1) for buffered data. The OUT connector on BUS 1 also enables power supply for external Dewesoft EtherCAT devices.

  • Page 45: Iolite-R8: Boxed Chassis: Sync: Pinout

    TECHNICAL REFERENCE MANUAL 3.3.2.3.2. IOLITE-R8: Boxed Chassis: Sync: Pinout The sync connectors are required when you want to synchronize the data from IOLITE with Dewesoft USB devices for the same measurement. The signal that is transferred over sync cable makes sure that the measurement data of IOLITE and Dewesoft USB devices are perfectly synchronized to each other.

  • Page 46: Iolite-R8: Boxed Chassis: Bus 1: In: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.2.3.3. IOLITE-R8: Boxed Chassis: BUS 1: IN: Pinout IN connector of primary EtherCAT bus (BUS 1) is a 8-pin LEMO 1B male connector. Name Description TX_P Transmission + TX_N Transmission - RX_P Reception + RX_N Reception - Power IN Power IN Ground...

  • Page 47: Iolite-R8: Boxed Chassis: Bus 1: Out: Pinout

    TECHNICAL REFERENCE MANUAL 3.3.2.3.4. IOLITE-R8: Boxed Chassis: BUS 1: OUT: Pinout The OUT connector of the primary EtherCAT bus (BUS 1) is a 8-pin LEMO 1B female connector. OUT connector enables power supply for external Dewesoft EtherCAT devices. Name Description...

  • Page 48: Iolite-R8: Boxed Chassis: Bus 2: Rj45: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.2.3.5. IOLITE-R8: Boxed Chassis: BUS 2: RJ45: Pinout IOLITE-R8 includes two RJ45 connectors on Secondary bus (BUS 2) for unbuffered data. Each RJ45 connector has two LEDs: GREEN LED indicates that IOLITE is connected to another device. YELLOW LED is active only when the data transfer is active.

  • Page 49: Iolite-R8: Boxed Chassis: Connection Of Iolite-R8 Standalone Device To Pc

    Finally, connect the other side of the L1T8f-RJ45-1M cable (RJ45 side) to the LAN port of the PC. Connection of IOLITE-R8 standalone device to PC List of required cables: Function Dewesoft order code Power supply PS-120-L1B2f (default) EtherCAT L1T8f-RJ45-1M (default), L1T8f-RJ45-3M, L1T8f-RJ45-5M IOLITE®...

  • Page 50: Iolite-R8: Boxed Chassis: Connection Of Iolite-R8 And Krypton® Device

    BUS 1 of IOLITE-R8 on one side and to IN connector of the KRYPTON device on the other side. Connection of IOLITE-R8 and KRYPTON® device List of required cables: Function Dewesoft order code Power supply PS-120-L1B2f (default) EtherCAT IOLITE to PC: L1T8f-RJ45-1M (default), L1T8f-RJ45-3M, L1T8f-RJ45-5M IOLITE to KRYPTON: L1T8m-L1T8f-02M, L1T8m-L1T8f-0.4M,...

  • Page 51: Iolite-R8: Boxed Chassis: Connection Of Iolite-R8 And Sirius® Device

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.2.6. IOLITE-R8: Boxed Chassis: Connection of IOLITE-R8 and Sirius® device Connect power supply cable Sirius (PS-120W-L1B2f). Then connect cable (CABLE-USBAmini-USBBS-1.8m) to the USB port on the back panel of the Sirius device. Finally connect the other side of the USB cable to the USB port on PC. Use power supply daisy chain cable (e.g.

  • Page 52: Iolite-R8: Boxed Chassis: Connection Of Iolite Multi And Single Channel Device

    IOLITE® TECHNICAL REFERENCE MANUAL List of required cables: Function Dewesoft order code Power supply Sirius: PS-120-L1B2f (default) Sirius to IOLITE: L1B2m-L1B2f-0.2m, L1B2m-L1B2f-0.4m, L1B2M-L1B2F-3m EtherCAT IOLITE to PC: L1T8f-RJ45-1M (default), L1T8f-RJ45-3M, L1T8f-RJ45-5M CABLE-USBAmini-USBBS-1.8m (default), CABLE-USBAmini-USBBS-1m Synchronization L00B4m-L00B4m-0.2m (default), L00B4m-L00B4m-0.5m, L00B4m-L00B4m-3m 3.3.2.7. IOLITE-R8: Boxed Chassis: Connection of IOLITE multi and single channel device Connect power supply cable to IOLITE-R8 (PS-120W-L1B2f).Then connect L1T8f-RJ45-1M cable (LEMO...
  • Page 53 IOLITE® TECHNICAL REFERENCE MANUAL Function Dewesoft order code Power supply IOLITE-R8: PS-120-L1B2f (default) IOLITE-multichannel: EtherNET IOLITE-R8 to IOLITE single channel: RJ-45 - RJ-45 IOLITE single channel to IOLITE multi channel: RJ-45 - RJ-45 IOLITE® V22-2 53 / 193...

  • Page 54: Iolite-R8R: Ruggedized Boxed Chassis

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.3. IOLITE-R8r: Ruggedized Boxed Chassis In addition to standard R8 chassis, IOLITE is also available in ruggedized version. The chassis provides 8 slots for IOLITE input and output slices to be installed. IOLITE-R8r includes EtherCAT gateway and has a passive cooling system. 3.3.3.1.

  • Page 55: Iolite-R8R: Ruggedized Boxed Chassis: Dimensions

    IOLITE® TECHNICAL REFERENCE MANUAL IOLITE-R8r Back panel 3.3.3.2. IOLITE-R8r: Ruggedized Boxed Chassis: Dimensions Technical Drawings of IOLITE-R8r IOLITE® V22-2 55 / 193...

  • Page 56: Iolite-R8R: Ruggedized Boxed Chassis: Connectors

    The IOLITE-R8r chassis also enables dual EtherCAT bus. There are two 8-pin LEMO 1T connectors on the back panel of IOLITE-R8r used for data transfer and synchronisation on the primary bus (BUS 1) for buffered data. The OUT connector on BUS 1 also enables power supply for external Dewesoft EtherCAT devices.

  • Page 57: Iolite-R8R: Ruggedized Boxed Chassis: Bus 1: In: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL Name Description Clock TRIG Trigger Ground Sync connector: pin-out (4-pin LEMO female) SYNC connector (on the device): XBG.00.304.CLL Mating connector (for the cable): FGG.00.304.CLAD27Z 3.3.3.3.3. IOLITE-R8r: Ruggedized Boxed Chassis: BUS 1: IN: Pinout IN connector of primary EtherCAT bus (BUS 1) is a 8-pin LEMO 1B male connector. Name Description TX_P...

  • Page 58: Iolite-R8R: Ruggedized Boxed Chassis: Bus 1: Out: Pinout

    TECHNICAL REFERENCE MANUAL 3.3.3.3.4. IOLITE-R8r: Ruggedized Boxed Chassis: BUS 1: OUT: Pinout The OUT connector of the primary EtherCAT bus (BUS 1) is a 8-pin LEMO 1T female connector. OUT connector enables power supply for external Dewesoft EtherCAT devices. Name Description...

  • Page 59: Iolite-R8R: Ruggedized Boxed Chassis: Bus 2: Rj45: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.3.3.5. IOLITE-R8r: Ruggedized Boxed Chassis: BUS 2: RJ45: Pinout IOLITE-R8r includes two RJ45 connectors on Secondary bus (BUS 2) for unbuffered data. Each RJ45 connector has two LEDs: GREEN LED indicates that IOLITE is connected to another device. YELLOW LED is active only when the data transfer is active.

  • Page 60: Iolite-R8R: Ruggedized Boxed Chassis: Connection Of Iolite-R8R Standalone Device To Pc

    Finally, connect the other side of the L1T8f-RJ45-1M cable (RJ45 side) to the LAN port of the PC. Connection of IOLITE-R8r standalone device to PC List of required cables: Function Dewesoft order code Power supply PS-120-L1B2f (default) EtherCAT L1T8f-RJ45-1M (default), L1T8f-RJ45-3M, L1T8f-RJ45-5M IOLITE®...

  • Page 61: Iolite-R8R: Ruggedized Boxed Chassis: Connection Of Iolite-R8R And Krypton® Device

    BUS 1 of IOLITE-R8r on one side and to IN connector of KRYPTON device on the other side. Connection of IOLITE-R8r and KRYPTON® device List of required cables: Function Dewesoft order code Power supply PS-120-L1B2f (default) EtherCAT IOLITE to PC: L1T8f-RJ45-1M (default), L1T8f-RJ45-3M, L1T8f-RJ45-5M IOLITE to KRYPTON: L1T8m-L1T8f-02M, L1T8m-L1T8f-0.4M,...

  • Page 62: Iolite-R8R: Ruggedized Boxed Chassis: Connection Of Iolite-R8R And Sirius® Device

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.3.6. IOLITE-R8r: Ruggedized Boxed Chassis: Connection of IOLITE-R8r and Sirius® device Connect power supply cable Sirius (PS-120W-L1B2f). Then connect cable (CABLE-USBAmini-USBBS-1.8m) to the USB port on the back panel of the Sirius device. Finally connect the other side of the USB cable to the USB port on PC. Use power supply daisy chain cable (e.g.

  • Page 63: Iolite-R8R: Ruggedized Boxed Chassis: Connection Of Iolite Multi And Single Channel Device

    IOLITE® TECHNICAL REFERENCE MANUAL List of required cables: Function Dewesoft order code Power supply Sirius: PS-120-L1B2f (default) Sirius to IOLITE: L1B2m-L1B2f-0.2m, L1B2m-L1B2f-0.4m, L1B2M-L1B2F-3m EtherCAT IOLITE to PC: L1T8f-RJ45-1M (default), L1T8f-RJ45-3M, L1T8f-RJ45-5M CABLE-USBAmini-USBBS-1.8m (default), CABLE-USBAmini-USBBS-1m Synchronization L00B4m-L00B4m-0.2m (default), L00B4m-L00B4m-0.5m, L00B4m-L00B4m-3m 3.3.3.7. IOLITE-R8r: Ruggedized Boxed Chassis: Connection of IOLITE multi and single channel device Connect power supply cable to IOLITE-R8r (PS-120W-L1B2f).Then connect L1T8f-RJ45-1M cable (LEMO...
  • Page 64 IOLITE® TECHNICAL REFERENCE MANUAL Connection of IOLITE-R8r and two different IOLITE devices Function Dewesoft order code Power supply IOLITE-R8r: PS-120-L1B2f (default) IOLITE-multichannel: EtherNET IOLITE-R8r to IOLITE single channel: RJ-45 - RJ-45 IOLITE single channel to IOLITE multi channel: RJ-45 - RJ-45 IOLITE®...

  • Page 65: Ioliter Slices: Mounting/Removing/Replacing From Rack Chassis

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.4. IOLITEr slices: Mounting/Removing/Replacing from Rack Chassis IOLITE rack slices (IOLITEr) can be mounted in all rack chassis versions: IOLITE-R12, IOLITE-R8 and IOLITE-R8r. Warning When mounting or removing IOLITEr slices TURN OFF the equipment! IOLITEr slice ARE NOT hot swappable.

  • Page 66: Ioliter Slices: Removing The Slice - Instructions

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.4.2. IOLITEr slices: Removing the slice - Instructions Turn off the device! Remove the IOLITEr slice. Unscrew two M2.5x5 TRX panhead screws. Important removing IOLITEr slice EtherCAT chain gets broken. IOLITEr slices right to the removed IOLITEr slice will not be detected.

  • Page 67: Iolite: Multi Channel Device

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.5. IOLITE: Multi channel device IOLITE multi-channel modules are fully compatible with the DIN rail mount. Chassis offers an easy clip-in mechanism for mounting to all standard industrial DIN rail mounts. IOLITE DAQ devices use RJ45 connectors which allow easy connection of modules with standard low-cost Ethernet/EtherCAT cables.

  • Page 68: Iolite - Multi Channel: Dimension

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.5.2. IOLITE - Multi channel: Dimension IOLITE® V22-2 68 / 193...

  • Page 69: Iolite - Multi Channel: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.5.3. IOLITE - Multi channel: Connectors 3.3.5.3.1. IOLITE - Multi channel: PWR IN Name Description PWR+ PWR- PWR+ PWR- Power in connector: pin-out (4-pin male) Connector (on the device): SCDN-THR 3.81/04/90G 3.2SN BK BX Mating Connectors (for the cable): BCF 3.81/02/180 SN BK BX IOLITE®...

  • Page 70: Ethernet In

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.5.3.2. EtherNET in Connector used on the device is a standard Ethernet connector (RJ45). Standard ethernet cable with standard connector can be used to connect IOLITE - Multi channel to PC. Name Description TX_P Transmission + TX_N Transmission - RX_P...

  • Page 71: Iolite: Single Channel Device

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.6. IOLITE: Single channel device IOLITE single-channel modules are small and can be placed next to your measurement points. They offer screw holes for easy mounting with screws or any other method. Multiple IOLITE modules can be daisy-chained together with a single cost-effective Ethernet/EtherCAT cable with RJ45 connectors.

  • Page 72: Iolite - Single Channel: Dimensions

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.6.2. IOLITE - Single channel: Dimensions 3.3.6.3. IOLITE - Single channel: Connectors 3.3.6.3.1. EtherNET - IN (Data, Sync, PWR) Connector used on the device is a standard Ethernet connector (RJ45). Standard ethernet cable with standard connector can be used to connect IOLITE-Single channel with a Name Description TX_P...

  • Page 73: Ethernet - Out (Data, Sync, Pwr)

    IOLITE® TECHNICAL REFERENCE MANUAL 3.3.6.3.2. EtherNET - OUT (Data, Sync, PWR) Connector used on the device is a standard Ethernet connector (RJ45). Standard ethernet cable with standard connector can be used to connect IOLITE-Single channel with a Name Description TX_P Transmission + TX_N Transmission -...

  • Page 74: Module Overview

    IOLITE® TECHNICAL REFERENCE MANUAL 4. Module Overview Multichannel modules that comes as slices for the rack system or as a single device: 6xSTG 8xSTGS¹ 8xLV 16xLV¹ 8xLA 8xTH 8xTH-HS¹ Connectors DSUB-9 Terminal block, BNC, Terminal Terminal BNC, Terminal MINI TC MINI TC DSUB-37 block...
  • Page 75 IOLITE® TECHNICAL REFERENCE MANUAL 8xRTD 8xRTD-HS¹ 32xDI² 32xDO² 8xDI-4xDO² 4xCNT 16xAO Connectors L0B6f, L0B6f, Terminal Terminal Terminal block block Terminal block Terminal block Terminal block L1B7f block Channels per module 8x digital in, 4x digital out Data rate / channel 100 S/s, upgradable 100 S/s...
  • Page 76 IOLITE® TECHNICAL REFERENCE MANUAL Overview for single channel devices 1xACC 1xSTG 4xDI 4xDO 1xAO Input / Output Input: Voltage, IEPE Input: Voltage, Strain Input: Digital Output: Digital Output: Voltage types Number of channels per module Connector BNC DSUB15HD male DSUB15HD female Data rate per 40 kS/s 40 kS/s...

  • Page 77: Voltage Measurement

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1. VOLTAGE MEASUREMENT IOLITE product family includes two types of low voltage (LV) modules: 8-ch fully isolated module and 16-ch module. Below is the list of LV products: IOLITEir-8xLV (rack version), IOLITEi-8xLV (standalone version) ● IOLITEir-8xLV-10V (rack version), IOLITEi-8xLV-10V (standalone version) ●...

  • Page 78: Iolitei-8Xlv: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.1.1. IOLITEi-8xLV: Specifications Analog input IOLITEi-8xLV Input type Isolated voltage Number of channels 8 ADC Type 24-bit oversampled SAR Sampling Rates Simultaneous 20k, 10k, 5k, 2k, 1k, 500, 200, 100 S/s (software-selectable) Voltage Range ±100 V ±10 V Accuracy ±0.03 % of reading ±50 mV ±0.03 % of reading ±5 mV...

  • Page 79: Iolitei-8Xlv: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.1.2. IOLITEi-8xLV: Connectors IOLITEi 8xLV is available with BNC and terminal block connectors. 4.1.1.2.1. IOLITEi-8xLV: BNC Connector IOLITE LV module has 8 BNC connectors for analog input. IOLITEir-8xLV front IOLITE® V22-2 79 / 193...

  • Page 80: Iolitei-8Xlv: Bnc Connector: Pin Out

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.1.2.1.1. IOLITEi-8xLV: BNC Connector: Pin out Name Description Analog input Analog input - LV connector: pin-out (BNC) 4.1.1.2.1.2. IOLITEi-8xLV: BNC Connector: Wiring diagram Voltage IOLITE® V22-2 80 / 193...

  • Page 81: Iolitei-8Xlv-T2A2F: T2A2F Connector

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.1.2.2. IOLITEi-8xLV-T2A2f: T2A2f Connector IOLITEi-8xLV-T2A2f and IOLITEi-8xLV-10V-T2A2f modules have 8 Omnimate terminal block connectors for analog input. IOLITEir-8xLV-T2A2f front IOLITE® V22-2 81 / 193...

  • Page 82: Iolitei-8Xlv-T2A2F: T2A2F Connector: Pin Out

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.1.2.2.1. IOLITEi-8xLV-T2A2f: T2A2f Connector: Pin out Name Description Analog input + Analog input - LV connector: pin-out (TBLOCK male) Connector (on the device): OMNIMATE Signal SL 2.50/02/180G 3.2SN BK BX Mating connector (for the cable): OMNIMATE Signal BLF 2.50/02/180 4.1.1.2.2.2.

  • Page 83: Iolitei-8Xlv-10V / Iolitei-8Xlv-10V-T2A2F

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.2. IOLITEi-8xLV-10V / IOLITEi-8xLV-10V-T2A2f IOLITEi 8xLV-10V is the 8-channel module with channel-to-channel isolation and comes with either BNC (IOLITEi-8xLV-10V) or terminal block connectors (IOLITEi-8xLV-10V-T2A2f) and a maximum range of 10 V. 4.1.2.1. IOLITEi-8xLV: Specifications Analog input IOLITEi-8xLV-10V Input type Isolated voltage Number of channels 8...

  • Page 84: Iolitei-8Xlv-10V: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.2.2. IOLITEi-8xLV-10V: Connectors IOLITEi 8xLV-10V is available with BNC and terminal block connectors. 4.1.2.2.1. IOLITEi-8xLV-10V: BNC Connector IOLITEi-8xLV-10V module has 8 BNC connectors for analog input. IOLITEir-8xLV-10V front IOLITE® V22-2 84 / 193...

  • Page 85: Iolitei-8Xlv-10V: Bnc Connector: Pin Out

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.2.2.1.1. IOLITEi-8xLV-10V: BNC Connector: Pin out Name Description Analog input Analog input - LV connector: pin-out (BNC) 4.1.2.2.1.2. IOLITEi-8xLV-10V: BNC Connector: Wiring diagram Voltage IOLITE® V22-2 85 / 193...

  • Page 86: Iolitei-8Xlv-10V-T2A2F: T2A2F Connector

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.2.2.2. IOLITEi-8xLV-10V-T2A2f: T2A2f Connector IOLITEi-8xLV-T2A2f and IOLITEi-8xLV-10V-T2A2f modules have 8 Omnimate terminal block connectors for analog input. IOLITEir-8xLV-10V-T2A2f front IOLITE® V22-2 86 / 193...

  • Page 87: Iolitei-8Xlv-10V-T2A2F: T2A2F Connector: Pin Out

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.2.2.2.1. IOLITEi-8xLV-10V-T2A2f: T2A2f Connector: Pin out Name Description Analog input + Analog input - LV connector: pin-out (TBLOCK male) Connector (on the device): OMNIMATE Signal SL 2.50/02/180G 3.2SN BK BX Mating connector (for the cable): OMNIMATE Signal BLF 2.50/02/180 4.1.2.2.2.2.

  • Page 88: Ioliter-16Xlv

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.3. IOLITEr-16xLV IOLITEr-16xLV modules have terminal block connectors for analog input. 16-channel low voltage module comes with channel-to-ground isolation and a range of 200 V. IOLITEr-16xLV module IOLITE® V22-2 88 / 193...

  • Page 89: Ioliter-16Xlv: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.3.1. IOLITEr-16xLV: Specifications Analog input IOLITEr-16xLV Input type Voltage Number of channels 16 ADC Type 24-bit oversampled sigma-delta Sampling Rates Simultaneous 20k, 10k, 5k, 2k, 1k, 500, 200, 100 S/s (software-selectable) Voltage Range ±200 V ±10 V Accuracy ±0.03 % of reading ±40 mV ±0.03 % of reading ±2 mV Typ.

  • Page 90: Ioliter-16Xlv: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.3.2. IOLITEr-16xLV: Connectors IOLITEr-16xLV modules have four 9-pin terminal block connectors (T2A9f) with 2.50 mm pitch for voltage input. 8 pins on a 9-pin connector bank are used for digital inputs and pin 9 for common GND. Additionally, there is a 2-pin terminal block connector with a 2.50 mm pitch for PWR OUT function.

  • Page 91: Ioliter-16Xlv: T2A2F Power Out Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.3.2.1. IOLITEr-16xLV: T2A2f Power OUT Connector: Pinout Name Description +PWR OUT output supply -PWR OUT Non-isolated GND LV connector: pin-out (TBLOCK male) Connector (on the device): OMNIMATE Signal SL 2.50/02/90G Mating connector (for the cable): OMNIMATE Signal BLF 2.50/02/180 Caution PWR OUT pins are intended to supply external loads.

  • Page 92: Ioliter-16Xlv: T2A9F Connector: Wiring Diagram

    IOLITE® TECHNICAL REFERENCE MANUAL 4.1.3.2.3. IOLITEr-16xLV: T2A9f Connector: Wiring diagram Voltage IOLITE® V22-2 92 / 193...

  • Page 93: Current Measurement

    IOLITE® TECHNICAL REFERENCE MANUAL 4.2. CURRENT MEASUREMENT IOLITE includes an 8-channel isolated module dedicated for current measurement: IOLITEir-8xLA (rack version), IOLITEi-8xLA (standalone version) ● IOLITEir-8xLA-T2A2f (rack version), IOLITEi-8xLA-T2A2f (standalone version) ● 4.2.1. IOLITEi-8xLA / IOLITEi-8xLA-T2A2f The IOLITEi-8xLA is a multi channel low current measurement module. It is a perfect device for data acquisition in control applications requiring an input current range of ±20 mA.

  • Page 94: Iolitei-8Xla: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.2.1.1. IOLITEi-8xLA: Specifications Analog input IOLITEi-8xLA Input type Isolated current Number of channels 8 ADC Type 24-bit oversampled SAR Sampling Rates Simultaneous 20k, 10k, 5k, 2k, 1k, 500, 200, 100 S/s (software-selectable) Current Range ±20 mA ±2 mA Accuracy ±0.05 % of reading ±10 µA ±0.05 % of reading ±2 µA...

  • Page 95: Iolitei-8Xla: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.2.1.2. IOLITEi-8xLA: Connectors IOLITEi 8xLA is available with BNC and terminal block connectors. 4.2.1.2.1. IOLITEi-8xLA: BNC Connector IOLITE-8xLA Front 4.2.1.2.1.1. IOLITEi-8xLA: BNC Connector: Pinout Name Description Analog input + Analog input - LV connector: pin-out (BNC) IOLITE®...

  • Page 96: Iolitei-8Xla: Bnc Connector: Wiring Diagram

    IOLITE® TECHNICAL REFERENCE MANUAL 4.2.1.2.1.2. IOLITEi-8xLA: BNC Connector: Wiring diagram Current 4.2.1.2.2. IOLITEi-8xLA-T2A2f: T2A2f Connector IOLITE-8xLA-T2A2f front IOLITE® V22-2 96 / 193...

  • Page 97: Iolitei-8Xla-T2A2F: T2A2F Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.2.1.2.2.1. IOLITEi-8xLA-T2A2f: T2A2f Connector: Pinout Name Description Analog input + Analog input - LA connector: pin-out (TBLOCK male) Connector (on the device): OMNIMATE Signal SL 2.50/02/180G 3.2SN BK BX Mating connector (for the cable): OMNIMATE Signal BLF 2.50/02/180 4.2.1.2.2.2.

  • Page 98: Strain And Stress Measurement

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3. STRAIN AND STRESS MEASUREMENT IOLITE product family offers 6-channel and single channel universal module and 8-channel strain gauge. Both types of modules can be used in various bridge configurations. List of universal and strain gauge modules: IOLITEr-6xSTG (rack version), IOLITE-6xSTG (standalone version) ●...

  • Page 99: Iolite 6Xstg: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.1.1. IOLITE 6xSTG: Specifications Analog inputs Input type Voltage Full / half / quarter bridge strain Current Potentiometer Resistance Number of channels 6 ADC Type 24-bit SAR with anti-aliasing filter Sampling Rate Simultaneous 20 kS/s per channel (software-selectable) Analog inputs - Voltage Voltage Ranges ±50 V ±10 V...

  • Page 100: Iolite-6Xstg: D-Sub9 Connector

    IOLITE® TECHNICAL REFERENCE MANUAL Predefined Levels 0, 2, 4, 8, 16, 44 mA Accuracy ±0.1 % ±2 μA (<10 mA), ±0.5 % ±5 μA (>10 mA) Bridge measurement Bridge Connection Types full bridge strain, ½ bridge strain, ¼ bridge strain (3-wire) Ranges 2…1000 mV/V free programmable Internal Bridge Completion ½...

  • Page 101: Iolite-6Xstg: D-Sub9 Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.1.2.1. IOLITE-6xSTG: D-SUB9 Connector: Pinout Name Description Exc+ Excitation+ Input+ Sns- Sense- Ground ¼ Bridge / Shunt Sns+ Sense+ Input- Exc- Excitation- IOLITE-6xSTG connector: pin-out (DSUB-9 female) TEDS TEDS 4.3.1.2.2. IOLITE-6xSTG: D-SUB9 Connector: Wiring diagram Voltage Single ended Differential Use only when sensor Output (+) and Output (-)
  • Page 102 IOLITE® TECHNICAL REFERENCE MANUAL Potentiometer IOLITE® V22-2 102 / 193...
  • Page 103 IOLITE® TECHNICAL REFERENCE MANUAL Bridge Full bridge Half bridge Quarter bridge IOLITE® V22-2 103 / 193...
  • Page 104 IOLITE® TECHNICAL REFERENCE MANUAL Current External direct shunt External loop powered shunt Internal shunt IOLITE® V22-2 104 / 193...
  • Page 105 IOLITE® TECHNICAL REFERENCE MANUAL Resistance IOLITE® V22-2 105 / 193...

  • Page 106: Ioliter-8Xstgs / Ioliter-8Xstgs-D37

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.2. IOLITEr-8xSTGS / IOLITEr-8xSTGS-D37 IOLITE-8xSTGS is an 8-channel module dedicated for strain measurement supporting inputs for Full, Half and Quarter bridge configuration. STGS module is available with terminal block input connectors and optionally with D-SUB37 input connectors. IOLITEr-8xSTGS (left) and IOLITEr-8xSTGS-D37 (right) module IOLITE®...

  • Page 107: Ioliter-8Xstgs: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.2.1. IOLITEr-8xSTGS: Specifications IOLITEr-8xSTGS Analog inputs Input type Full / half / quarter bridge strain (3-wire), Potentiometer Number of channels 8 ADC Type 24-bit oversampled sigma-delta with anti-aliasing filter Sampling Rate Simultaneous 20 kS/s per channel (software-selectable) Voltage Ranges ±1 V ±100 mV...

  • Page 108: Ioliter-8Xstgs: Bridge Accuracy Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL Shunt Resistor Accuracy 0.05 %; TCR: 10 ppm/K (others on request) Input Short, Sensor Offset Adjust Software-selectable Additional Specifications Input connectors Terminal block, DSUB-37 TEDS support Available for Terminal block Power supply 9 - 48 V DC Power Consumption Typ.

  • Page 109: Ioliter-8Xstgs: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.2.2. IOLITEr-8xSTGS: Connectors 4.3.2.2.1. IOLITEr-8xSTGS: T2A9f Connectors IOLITEr-8xSTGS Front IOLITE® V22-2 109 / 193...

  • Page 110: Ioliter-8Xstgs: T2A9F Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.2.2.1.1. IOLITEr-8xSTGS: T2A9f Connector: Pinout Name Description IN + Input+ IN - Input- SNS + Sense+ SNS - Sense- EXC + Excitation+ EXC - Excitation- Ground ¼ Bridge / Shunt TEDS TEDS Analog in connector: pin-out (terminal block male) AI connector (on the device): OMNIMATE Signal SL 2.50/09/90G Mating connector (for the cable): OMNIMATE Signal BLF 2.50/09/180 IOLITE®...

  • Page 111: Ioliter-8Xstgs: T2A9F Connector: Wiring Diagram

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.2.2.1.2. IOLITEr-8xSTGS: T2A9f Connector: Wiring diagram Bridge Full bridge (6-wire) Full bridge (4-wire) Half bridge (5-wire) Half bridge (3-wire) IOLITE® V22-2 111 / 193...
  • Page 112 IOLITE® TECHNICAL REFERENCE MANUAL Quarter bridge Potentiometer IOLITE® V22-2 112 / 193...

  • Page 113: Ioliter-8Xstgs-D37: D-Sub37 Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.2.2.2. IOLITEr-8xSTGS-D37: D-SUB37 Connectors IOLITEr-8xSTGS-D37 Front IOLITE® V22-2 113 / 193...

  • Page 114: Ioliter-8Xstgs-D37: D-Sub37 Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.2.2.2.1. IOLITEr-8xSTGS-D37: D-SUB37 Connector: Pinout Warning PWR OUT pins are intended to supply external loads. Do not connect the external power supply to the PWR OUT pins! It can damage the equipment. There is no protection on the module. Current limit of the IOLITE system is 16 A! Incorrect connection can damage the equipment or cause data loss.

  • Page 115: Ioliter-8Xstgs-D37: D-Sub37 Connector: Wiring Diagram

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.2.2.2.2. IOLITEr-8xSTGS-D37: D-SUB37 Connector: Wiring diagram Bridge Full bridge (6-wire) Full bridge (4-wire) Half bridge (5-wire) Half bridge (3-wire) IOLITE® V22-2 115 / 193...
  • Page 116 IOLITE® TECHNICAL REFERENCE MANUAL Quarter bridge Potentiometer IOLITE® V22-2 116 / 193...

  • Page 117: Iolitei-1Xstg

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.3. IOLITEi-1xSTG IOLITEi-1xSTG is a single channel strain gauge amplifier with internal quarter, half and full-bridge configurations. Low noise voltage and current source excitation are available with freely settable levels. Input ranges span from 50V to 100mV. Data transferred over the EtherCAT to a PC running powerful and easy to use.
  • Page 118 IOLITE® TECHNICAL REFERENCE MANUAL Input Coupling DC, AC 1 Hz Range ≥ 10 V; 1 MΩ between IN+ and IN- Input Impedance Range < 10 V: 20 MΩ Range ≥ 10 V; 200 V Overvoltage Protection Range < 10 V: 50 V Isolation 125 Vrms channel to ground isolation TEDS support Standard + DSI adapters Analog input - Current...

  • Page 119: Iolitei-1Xstg: D-Sub9 Connector

    IOLITE® TECHNICAL REFERENCE MANUAL 4.3.3.2. IOLITEi-1xSTG: D-SUB9 Connector IOLITEi-1xSTG module has a standard D-SUB9 female connectors for voltage or strain measurement. 4.3.3.2.1. IOLITEi-1xSTG: D-SUB9 Connector: Pinout Name Description Exc+ Excitation+ Input+ Sns- Sense- Ground ¼ Bridge / Shunt Sns+ Sense+ Input- Exc- Excitation-...
  • Page 120 IOLITE® TECHNICAL REFERENCE MANUAL Potentiometer IOLITE® V22-2 120 / 193...
  • Page 121 IOLITE® TECHNICAL REFERENCE MANUAL Bridge Full bridge Half bridge Quarter bridge IOLITE® V22-2 121 / 193...
  • Page 122 IOLITE® TECHNICAL REFERENCE MANUAL Current External direct shunt External loop powered shunt Internal shunt IOLITE® V22-2 122 / 193...

  • Page 123: Temperature Measurement

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4. TEMPERATURE MEASUREMENT IOLITE includes modules specially designed for temperature measurements. Supported are most common temperature sensor such as thermocouples and resistance temperature detectors (RTD). List of temperature modules: IOLITEir-8xTH (rack version), IOLITEi-8xTH (standalone version) ● IOLITEir-8xTH-HS (rack version) ●...

  • Page 124: Iolitei-8Xth: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.1.1. IOLITEi-8xTH: Specifications Inputs Input type Isolated universal thermocouple and voltage Number of channels 8 ADC Type 24-bit delta-sigma Sampling Rate Simultaneous 100 S/s Voltage Ranges ±1 V ±100 mV Input Accuracy ±0.02 % of reading ±100 μV ±0.02 % of reading ±10 μV Typical Noise floor @ 10/100 S/sec -114 dB / -105 dB -109 dB / -100 dB...

  • Page 125: Iolitei-8Xth: Miniature Thermocouple Connector

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.1.2. IOLITEi-8xTH: Miniature Thermocouple Connector IOLITEi-8xTH module has 8 miniature thermocouple-connectors for temperature measurement. IOLITEir-8xTH front 4.4.1.2.1. IOLITEi-8xTH: Miniature Thermocouple Connector: Pinout Name Description Input+ Input- TH connector: pin-out (Mini TC female) IOLITE® V22-2 125 / 193...

  • Page 126: Iolitei-8Xth: Miniature Thermocouple Connector: Wiring Diagram

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.1.2.2. IOLITEi-8xTH: Miniature Thermocouple Connector: Wiring diagram Voltage Temperature T-type thermocouple S-type, R-type thermocouple IOLITE® V22-2 126 / 193...
  • Page 127 IOLITE® TECHNICAL REFERENCE MANUAL N-type thermocouple K-type thermocouple J-type thermocouple E-type thermocouple B-type thermocouple C-type thermocouple IOLITE® V22-2 127 / 193...

  • Page 128: Iolitei-8Xth-Hs

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.2. IOLITEi-8xTH-HS IOLITE TH-HS modules are isolated DAQ devices for temperature measurements using thermocouples. Isolated thermocouple modules can acquire data from any kind of thermocouple (K, J, T, R, S, N, E, C, B). It offers sensor break detection in software as well as using LED indicators. IOLITE TH-HS is a perfect choice for thermal shock measurements with sampling rate up to 10 kS/s.

  • Page 129: Iolitei-8Xth-Hs: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.2.1. IOLITEi-8xTH-HS: Specifications Inputs Input type Isolated universal thermocouple and voltage Number of channels 8 ADC Type 24-bit delta-sigma Sampling Rate Simultaneous 10, 20, 40, 50, 80, 100, 200, 500, 1k, 2k, 5k, 10k S/sec Voltage Ranges ±1 V ±100 mV Input Accuracy ±0.02 % of reading ±50 μV...

  • Page 130: Iolitei-8Xth-Hs: Miniature Thermocouple Connector

    IOLITE® TECHNICAL REFERENCE MANUAL Hint The higher sample rate is unlocked with a device license key as it is shown on the image below. This upgrade raises the maximum possible sample rate of the IOLITEi-8xTH-HS from 100 S/s to 10 kS/s. 4.4.2.2.

  • Page 131: Iolitei-8Xth-Hs: Miniature Thermocouple Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.2.2.1. IOLITEi-8xTH-HS: Miniature Thermocouple Connector: Pinout Name Description Input+ Input- TH-HS connector: pin-out (Mini TC female) 4.4.2.2.2. TH-HS: Miniature Thermocouple Connector: Wiring diagram Voltage Temperature T-type thermocouple S-type, R-type thermocouple IOLITE® V22-2 131 / 193...
  • Page 132 IOLITE® TECHNICAL REFERENCE MANUAL N-type thermocouple K-type thermocouple J-type thermocouple E-type thermocouple B-type thermocouple C-type thermocouple IOLITE® V22-2 132 / 193...

  • Page 133: Iolitei-8Xrtd / Iolitei-8Xrtd-T2A4F

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.3. IOLITEi-8xRTD / IOLITEi-8xRTD-T2A4f IOLITE RTD module is used for measurements with universal platinum thermometer probes, thermistors, as well as for resistance and voltage measurements. IOLITEi-8xRTD module has 8 isolated measurement channels and it comes with LEMO 0B 6-pin connectors (IOLITEi-8xRTD) or with 4-pin terminal block connectors (IOLITEi-8xRTD-T2A4f).

  • Page 134: Iolitei-8Xrtd: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.3.1. IOLITEi-8xRTD: Specifications Analog inputs Input types Voltage, Resistance or Universal PTxxx inputs Number of channels ADC Type 24-bit delta-sigma Sampling Rate Simultaneous 100 S/s Voltage Ranges ±1 V ±100 mV Input Accuracy ±0.02 % of reading ±0.01 % of range ±10 μV Typical Noise floor @ 10/100 s/sec -117 dB / -107 dB -111 dB / -101 dB...

  • Page 135: Iolitei-8Xrtd: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.3.2. IOLITEi-8xRTD: Connectors IOLITEi 8xRTD is offered with LEMO 0B 6-pin connectors (IOLITEi-8xRTD) or with 4-pin terminal block connectors (IOLITEi-8xRTD-T2A4f). 4.4.3.2.1. IOLITEi-8xRTD: LEMO L0B6f Connector IOLITEi-8xRTD module has eight 6-pin LEMO 0B female connectors. IOLITEir-8xRTD front IOLITE®...

  • Page 136: Iolitei-8Xrtd: Lemo L0B6F Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.3.2.1.1. IOLITEi-8xRTD: LEMO L0B6f Connector: Pinout Name Description Input+ Input- Do not connect Exc+ Excitation+ Exc- Excitation- IOLITEi-8xRTD connector: pin-out (6-pin LEMO female) Do not connect RTD connector (on the device): EEA.0B.306.CLN Mating connector (for the cable): FGA.0B.306.CLAD22Z 4.4.3.2.1.2.
  • Page 137 IOLITE® TECHNICAL REFERENCE MANUAL Resistance 3-wire 4-wire Temperature 3-wire 4-wire IOLITE® V22-2 137 / 193...

  • Page 138: Iolitei-8Xrtd-T2A4F: Terminal Block Connector

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.3.2.2. IOLITEi-8xRTD-T2A4f: Terminal block connector IOLITEi-8xRTD-T2A4f module has 8 terminal block Weidmueller SL 2.50-04 (T2A4f) female connectors. IOLITEi-8xRTD-T2A4f front IOLITE® V22-2 138 / 193...

  • Page 139: Iolitei-8Xrtd-T2A4F: Terminal Block Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.3.2.2.1. IOLITEi-8xRTD-T2A4f: Terminal block connector: Pinout Name Description Input- Input+ Exc- Excitation- Exc+ Excitation+ RTD connector: pin-out (TBLOCK male) 4.4.3.2.2.2. IOLITEi-8xRTD-T2A4f: T2A4f Connector: Wiring diagram Voltage IOLITE® V22-2 139 / 193...
  • Page 140 IOLITE® TECHNICAL REFERENCE MANUAL Resistance 3-wire 4-wire Temperature 3-wire 4-wire IOLITE® V22-2 140 / 193...

  • Page 141: Iolitei-8Xrtd-Hs / Iolitei-8Xrtd-Hs-T2A4F

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.4. IOLITEi-8xRTD-HS / IOLITEi-8xRTD-HS-T2A4f IOLITE RTD-HS module is used for measurements with universal platinum thermometer probes, thermistors, as well as for resistance and voltage measurements. It is a perfect choice for thermal shock measurements with sampling rate up to 10 kS/s. IOLITEi-8xRTD-HS module has 8 isolated measurement channels and it comes with LEMO 0B 6-pin connectors (IOLITEi-8xRTD-HS) or with 4-pin terminal block connectors (IOLITEi-8xRTD-HS-T2A4f).

  • Page 142: Iolitei-8Xrtd-Hs: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.4.1. IOLITEi-8xRTD-HS: Specifications Analog inputs IOLITEi-8xRTD-HS Input types Voltage, Resistance or Universal PTxxx inputs Number of channels 8 ADC Type 24-bit delta-sigma Sampling Rate Simultaneous 10k, 5k, 2k, 1k, 500, 200 100, 80, 50, 40, 20, 10 S/sec Voltage Ranges ±1 V ±100 mV...

  • Page 143: Iolitei-8Xrtd-Hs: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.4.2. IOLITEi-8xRTD-HS: Connectors IOLITEi 8xRTD is offered with LEMO 0B 6-pin connectors (IOLITEi-8xRTD-HS) or with 4-pin terminal block connectors (IOLITEi-8xRTD-HS-T2A4f). 4.4.4.2.1. IOLITEi-8xRTD-HS: LEMO L0B6f Connector IOLITEi-8xRTD-HS module has eight 6-pin LEMO 0B female connectors. IOLITEir-8xRTD-HS front IOLITE®...

  • Page 144: Iolitei-8Xrtd-Hs: Lemo L0B6F Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.4.2.1.1. IOLITEi-8xRTD-HS: LEMO L0B6f Connector: Pinout Name Description Input+ Input- Do not connect Exc+ Excitation+ Exc- Excitation- IOLITEi-8xRTD-HS connector: pin-out (6-pin LEMO female) Do not connect RTD connector (on the device): EEA.0B.306.CLN Mating connector (for the cable): FGA.0B.306.CLAD22Z 4.4.4.2.1.2.
  • Page 145 IOLITE® TECHNICAL REFERENCE MANUAL Resistance 3-wire 4-wire Temperature 3-wire 4-wire IOLITE® V22-2 145 / 193...

  • Page 146: Iolitei-8Xrtd-Hs-T2A4F: Terminal Block Connector

    IOLITE® TECHNICAL REFERENCE MANUAL 4.4.4.2.2. IOLITEi-8xRTD-HS-T2A4f: Terminal block connector IOLITEi-8xRTD-T2A4f module has 8 terminal block Weidmueller SL 2.50-04 (T2A4f) female connectors. 4.4.4.2.2.1. IOLITEi-8xRTD-HS-T2A4f: Terminal block connector: Pinout Name Description Input- Input+ Exc- Excitation- Exc+ Excitation+ RTD connector: pin-out (TBLOCK male) 4.4.4.2.2.2.
  • Page 147 IOLITE® TECHNICAL REFERENCE MANUAL Resistance 3-wire 4-wire Temperature 3-wire 4-wire IOLITE® V22-2 147 / 193...

  • Page 148: Vibration And Sound Measurement

    IOLITE® TECHNICAL REFERENCE MANUAL 4.5. VIBRATION AND SOUND MEASUREMENT IOLITE product family includes solutions for vibration and sound measurement with single channel IOLITEi-1xACC module and IOLITE-3xMEMS-ACC - sensing device with integrated triaxial MEMS sensor. 4.5.1. IOLITEi-1xACC IOLITEi-1xACC is a single channel signal conditioner for IEPE sensors with high-precision isolated front end and EtherCAT bus on the back side.

  • Page 149: Iolitei-1Xacc: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.5.1.1. IOLITEi-1xACC: Specifications Analog inputs Input types Voltage, IEPE Number of channels 1 Input connector BNC ADC Type 24-bit SAR with anti-aliasing filter Sampling Rate 40 kS/s Voltage Ranges ±10 V ±5 V ±1 V ±200 mV Typ.

  • Page 150: Iolitei-1Xacc: Bnc Connector

    IOLITE® TECHNICAL REFERENCE MANUAL 4.5.1.2. IOLITEi-1xACC: BNC Connector 4.5.1.2.1. IOLITEi-1xACC: BNC Connector: Pinout Name Description Input + Ground ACC connector: pin-out (BNC) 4.5.1.2.2. IOLITEi-1xACC: BNC Connector: Wiring diagram Voltage IOLITE® V22-2 150 / 193...
  • Page 151 IOLITE® TECHNICAL REFERENCE MANUAL IEPE IOLITE® V22-2 151 / 193...

  • Page 152: Iolite-3Xmems-Acc

    Windows PC, or alternatively to any controller running EtherCAT master on any platform. Scaling is automatic in DEWESoft software, therefore the data in g or m/s2 is readily available to the user. MEMS sensor internal temperature is also available as a data channel in DEWESoft software under System monitor channels.

  • Page 153: Iolite-3Xmems-Acc: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.5.2.1. IOLITE-3xMEMS-ACC: Specifications MEMS Accelerometer 3xMEMS-ACC-8g 3xMEMS-ACC-40g Min. Typ. Max. Min. Typ. Max. Measurement ranges +-2 g +-8 g +-10 g +-40 g -3 dB bandwidth 1000 Hz 1000 Hz Sample rate 4 kHz 4 kHz Dynamic range 96 dB 96 dB...

  • Page 154: Analog Output

    IOLITE® TECHNICAL REFERENCE MANUAL 4.6. ANALOG OUTPUT The IOLITE AO module comes in the following options: IOLITEr-16xAO (rack version), IOLITE-16xAO (standalone version) ● IOLITE-1xAO (standalone version) ● 4.6.1. IOLITE 16xAO IOLITE-16xAO is a 16-channel analog voltage output module with terminal block input connectors. 16xAO can output voltage in the range of and is a perfect tool for signal conditioning.

  • Page 155: Iolite-16Xao: Specifications

    Typ. 4.3 W, Max. 7.2 W Weight 210 g Slice Dimensions 128.4 x 115.4 x 30.1 mm 1) Only asynchronous mode is supported in Dewesoft, function generator is not supported 2) Only DC output voltage, function generator not supported IOLITE® V22-2 155 / 193...

  • Page 156: Iolite 16Xao: Terminal Block Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.6.1.2. IOLITE 16xAO: Terminal block Connectors IOLITE-16xAO Front 4.6.1.2.1. IOLITE-16xAO: T2A2f Power Connector: Pinout Name Description +PWR OUT output supply -PWR OUT Non-isolated GND LV connector: pin-out (TBLOCK male) Connector (on the device): OMNIMATE Signal SL 2.50/02/90G Mating connector (for the cable): OMNIMATE Signal BLF 2.50/02/180 Caution PWR OUT pins are intended to supply external loads.

  • Page 157: Iolite-16Xao: T2A9F Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.6.1.2.2. IOLITE-16xAO: T2A9f connector: Pinout Name Description AO 1 Analog out 1 iGND Ground AO 2 Analog out 2 iGND Ground AO 3 Analog out 3 iGND Ground AO 4 Analog out 4 AO connector: pin-out (TBLOCK male) iGND Ground iGND...

  • Page 158: Iolite-1Xao: Specifications

    IP rating IP20 Physical Dimensions 93 x 67 x 28 mm Weight 130 g 1) Only asynchronous mode is supported in Dewesoft, function generator is not supported 2) Only DC output voltage, function generator not supported IOLITE® V22-2 158 / 193...

  • Page 159: Iolite-1Xao Bnc Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.6.2.2. IOLITE-1xAO BNC Connector: Pinout Name Description Out+ Output + Out- Output - AO connector: pin-out (BNC) IOLITE® V22-2 159 / 193...

  • Page 160: Digital And Counter Measurement

    IOLITEi-4xDO offers a software option for PWM output. Hint Find out more about Watchdog feature in Watchdog User Manual: https://download.dewesoft.com/list/manuals-brochures/software-manuals In the Software Manuals section click the download link of the Watchdog User Manual entry. IOLITE® V22-2 160 / 193...

  • Page 161: Ioliter-32Xdi

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.1. IOLITEr-32xDI IOLITE 32xDI module has 32 digital inputs. Module comes in rack version and offers input range of 48 V with an isolated common GND in groups of 8 channels. IOLITEr-32xDI module IOLITE® V22-2 161 / 193...

  • Page 162: Ioliter-32Xdi: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.1.1. IOLITEr-32xDI: Specifications Digital Input Isolated Input Channels 32 Input low level -1 V ~ +1 V Input high level -48 V ~ -3 V, +3 V ~ +48 V Input high current @ 5 V UIN < 1 mA Input high current @ 30 V UIN <...

  • Page 163: Ioliter-32Xdi: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.1.2. IOLITEr-32xDI: Connectors IOLITEr-32xDI modules have 9-pin terminal block connectors with 2.50 mm pitch for digital input. 8 pins on a 9-pin connector bank are used for digital inputs and pin 9 for common GND. Additionally, there is a 2-pin terminal block connector with a 2.50 mm pitch for PWR OUT function. IOLITEr-32xDI front IOLITE®...

  • Page 164: Ioliter-32Xdi: Power Out: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.1.2.1. IOLITEr-32xDI: Power Out: Pinout Name Description +PWR OUT output supply -PWR OUT Non-isolated GND Power out connector: pin-out (terminal block male) PWR OUT connector (on the device): OMNIMATE Signal SL 2.50/02/90G Mating connector (for the cable): OMNIMATE Signal BLF 2.50/02/180 Caution PWR OUT pins are intended to supply external loads.

  • Page 165: Ioliter-32Xdi: Isolation Concept

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.1.3. IOLITEr-32xDI: Isolation concept Diagram below is showing the bank-to-bank isolation concept for digital inputs in groups of 8 channels. IOLITEr-32xDI isolation conpet IOLITE® V22-2 165 / 193...

  • Page 166: Ioliter-32Xdo

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.2. IOLITEr-32xDO IOLITE 32xDO module has 32 digital outputs. Module comes in rack version and offers watchdog function and solid state relay compatibility with maximum 0.5 A sink current and 50 V switching voltage. Module includes isolation of common GND in groups of 8 channels. IOLITEr-32xDO module 4.7.2.1.

  • Page 167: Ioliter-32Xdo: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.2.2. IOLITEr-32xDO: Connectors IOLITEr-32xDO modules have 9-pin terminal block connectors with 2.50 mm pitch for digital output. 8 pins on a 9-pin connector bank are used for digital outputs and pin 9 for common GND. Additionally, there is a 2-pin terminal block connector with a 2.50 mm pitch for PWR OUT function. IOLITEr-32xDO front IOLITE®...

  • Page 168: Ioliter-32Xdo: Power Out: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.2.2.1. IOLITEr-32xDO: Power Out: Pinout Name Description +PWR OUT output supply -PWR OUT Non-isolated GND Power out connector: pin-out (terminal block male) PWR OUT connector (on the device): OMNIMATE Signal SL 2.50/02/90G Mating connector (for the cable): OMNIMATE Signal BLF 2.50/02/180 Caution PWR OUT pins are intended to supply external loads.

  • Page 169: Iolite-8Xdi-4Xdo

    IOLITE® TECHNICAL REFERENCE MANUAL Important The common pin is not shared through all the 32 channels, but by groups of 8 channels. Isolation concept is shown in case of 32xDI Hint Check how to use DO as a switch on this LINK 4.7.3.

  • Page 170: Ioliter-8Xdi-4Xdo: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.3.1. IOLITEr-8xDI-4xDO: Specifications Digital Input Isolated Input Channels 8 Input low level -1 V ~ +1 V Input high level -48 V ~ -3 V, +3 V ~ +48 V Input high current @ 5 V UIN < 1 mA Input high current @ 30 V UIN <...

  • Page 171: Ioliter-8Xdi-4Xdo: Power Out: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL IOLITEr-8xDI-4xDO front Hint Connection of digital input/output channel is explained in detail LINK 4.7.3.2.1. IOLITEr-8xDI-4xDO: Power Out: Pinout Name Description +PWR OUT output supply -PWR OUT Non-isolated GND Power out connector: pin-out (terminal block male) PWR OUT connector (on the device): OMNIMATE Signal SL 2.50/02/90G Mating connector (for the cable): OMNIMATE Signal BLF 2.50/02/180 IOLITE®...

  • Page 172: Ioliter-8Xdi-4Xdo: Power In: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL Caution PWR OUT pins are intended to supply external loads. Do not connect the external power supply to the PWR OUT pins! It can damage the equipment. Current limit of PWR OUT source is 2 A per module. Current limit of the IOLITE system is 16 A! 4.7.3.2.2.

  • Page 173: Ioliter-8Xdi-4Xdo: Digital Input: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.3.2.3. IOLITEr-8xDI-4xDO: Digital Input: Pinout Name Description Input voltage DI 1 Digital input 1 Input ground Input voltage DI 2 Digital input 2 Input ground Input voltage DI 3 Digital input 3 Input ground Input voltage DI 4 Digital input 4 Digital in connector: pin-out (terminal block male)

  • Page 174: Ioliter-8Xdi-4Xdo: Digital Output: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.3.2.5. IOLITEr-8xDI-4xDO: Digital Output: Pinout Name Description DO 1 Digital output 1 Output ground DO 2 Digital output 2 Output ground DO 3 Digital output 3 Output ground DO 4 Digital output 4 Output ground Digital out connector: pin-out (terminal block male) DO connector (on the device): OMNIMATE Signal SL 2.50/09/90G Mating connector (for the cable): OMNIMATE Signal BLF 2.50/09/180 4.7.4.

  • Page 175: Iolitei-4Xdi: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.4.1. IOLITEi-4xDI: Specifications Digital Input Input type Digital Number of channels 4 Connector DSBU15HD Male Compatibility TTL / CMOS Voltage Levels Input low level UIN < 1 V Input high level UIN > 2 V Input high current @ 5 V UIN 3 mA typ. Input high current @ 30 V UIN 6 mA typ.

  • Page 176: Iolitei-4Xdi Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.4.2. IOLITEi-4xDI Connector: Pinout IOLITEi-4xDI Name Description DI1 + Digital input CH1 + DI2 + Digital input CH2 + DI3 + Digital input CH3 + DI4 + Digital input CH4 + DSUB-15 HD male for IOLITEi-4xDI DI1 - Digital input CH1 - DI2 -...

  • Page 177: Iolitei-4Xdo: Specifications

    IOLITE® TECHNICAL REFERENCE MANUAL IOLITEi-4xDO module 4.7.5.1. IOLITEi-4xDO: Specifications Digital Output Output type Digital Number of channels 4 Connector DSUB15HD Female Maximum update rate depends on EtherCAT master cycle time Output type open collector with active internal pullup to 5 V Sink max 50 V, 2 A (resistive load, unprotected) Source 5 V, max.

  • Page 178: Iolitei-4Xdo Connector: Pinout

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.5.2. IOLITEi-4xDO Connector: Pinout IOLITEi-4xDO Name Description Digital output CH1 Digital output CH2 Digital output CH3 Digital output CH4 Vext + External voltage DSUB-15 HD female for IOLITEi-4xDO GNDi Isolated ground GNDi Isolated ground GNDi Isolated ground GNDi Isolated ground +5V/300mA...

  • Page 179: Iolite-4Xcnt

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.6. IOLITE-4xCNT IOLITE CNT has 4 channels, each capable of 3x digital inputs, 1x event counter, encoder, period, pulse-width, duty-cycle, and precise frequency and angle measurement using patented SUPERCOUNTER® technology. IOLITEr-4xCNT Module 4.7.6.1. IOLITE-4xCNT: Specifications Counter Number of channels 4 Timebase 100 MHz Time base accuracy Typical: 5 ppm, Max: 20 ppm...

  • Page 180: Iolite-4Xcnt: Lemo L1B7F Connector

    IOLITE® TECHNICAL REFERENCE MANUAL 4.7.6.2. IOLITE-4xCNT: LEMO L1B7f Connector IOLITE-4xCNT module has four 7-pin LEMO connectors for digital, counter and encoder inputs. IOLITE-4xCNT Front 4.7.6.2.1. CNT: LEMO L1B7f Connector: Pinout Name Description IN0/A Digital input 0/A IN1/B Digital input 1/B IN2/Z Digital input 2/Z Ground...

  • Page 181: Ecat Accessories

    IOLITE® TECHNICAL REFERENCE MANUAL 5. ECAT Accessories 5.1. IOLITE Power injector IOLITE Power Injector is a passive PoE power injector. It merges a 12-48V DC power source and the EtherCAT communication into a single CAT6 cable. The IOLITE single channel devices need the IOLITE Power injector as the first device in the chain.

  • Page 182: Iolite Power Injector: Connector

    IOLITE® TECHNICAL REFERENCE MANUAL 5.1.2. IOLITE Power Injector: Connector 5.1.2.1. IOLITE Power Injector: 2 mm Jack Pinout Name Description Supply Ground For the power supply an unregulated DC voltage between 12 V and 48 V is required. Power in connector: pin-out (2 mm DC jack, male) Connector (on the device): 2 mm DC power jack - PJ-067A 5.1.2.2.

  • Page 183: Iolite Repeater

    IOLITE® TECHNICAL REFERENCE MANUAL 5.2. IOLITE Repeater Daisy-chains and increases the distance for signal, synchronization and power between IOLITEi single channel instruments. Suggested length of the cable is up to 50 m. 5.2.1. General specifications General specifications of the IOLITE Repeater device Digital interface EtherCAT EtherCAT connector...

  • Page 184: Connectors

    IOLITE® TECHNICAL REFERENCE MANUAL 5.2.2. Connectors Connector used on the device is a standard ethernet connector (RJ45). Standard ethernet cable with standard connector can be used to connect IOLITE-RPT with a device. 5.2.2.1. EtherNET - IN Name Description TX_P Transmission + TX_N Transmission - RX_P...

  • Page 185: Accessories

    Optional Accessories and Sensors (e.g. DSI®-adapters, Battery Packs, Current Clamps, etc.) can be found in a separate document, which is available for download from our homepage: https://download.dewesoft.com/download-file/accessories-and-sensors-technical-reference-manual.pdf In the HW Manuals section click the download link for the Manual for DewesoftX® Accessories and Sensors .

  • Page 186: Warranty Information

    7.2. Support Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties regarding the system. For any support please contact your local distributor first or Dewesoft directly.

  • Page 187: Copyright

    When used in text representing the company, product or technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ® sign is not used in the visual representation of the triangle logo.

  • Page 188: Safety Instructions

    Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the product. Dewesoft d.o.o. assumes no liability for the customer’s failure to comply with these requirements.

  • Page 189: System And Components Recycling

    This symbol indicates that this system complies with the European Union’s requirements according to Directive 2002/96/EC on waste electrical and electronic equipment (WEEE). Please find further information about recycling on the Dewesoft web site www.dewesoft.com Restriction of Hazardous Substances This product has been classified as Monitoring and Control equipment and is outside the scope of the...
  • Page 190 REMOVE POWER and do not use the product until the safe operation can be verified by service-trained personnel. If necessary, return the product to the Dewesoft sales and service office for service and repair to ensure that safety features are maintained.
  • Page 191 IOLITE® TECHNICAL REFERENCE MANUAL Please contact a professional if you have doubts about the method of operation, safety or the ● connection of the system. Please be careful with the product. Shocks, hits and dropping it from already- lower level may ●...

  • Page 192: Documentation Version History

    IOLITE® TECHNICAL REFERENCE MANUAL 9. Documentation version history Date Version [dd.mm.yyyy] Notes 1.0.0 10.11.2019 Initial version ● V20-1 14.07.2020 Added devices: ● LV modules (IOLITEi-8xLV, IOLITEi-8xLV-10V, ○ IOLITEi-8xLV-TBLOCK, IOLITEi-8xLV-10V-TBLOCK) DIO module (IOLITEi-8xDI-4xDO) ○ RTD module (IOLITEi-8xRTD-T2A4f) ○ CNT module (IOLITE-4xCNT) ○...
  • Page 193 IOLITE® TECHNICAL REFERENCE MANUAL Added products ● IOLITEir-8xRTD-HS, IOLITEir-8xRTD-HS-T2A4f ○ IOLITE® V22-2 193 / 193...

Table of Contents
