  • Page 1 Manual DLM-600 LINK Master...

  • Page 2: Table Of Contents

    Contents 1. Introduction 1.1. About the LINK Master 1.2. Box content 1.3. Keypad 1.3.1. Controller keypad 1.3.2. Gateway keypad 2. LINK Master 2.1. Installation 2.1.1. Mechanical installation 2.1.1.1. Positioning 2.1.1.2. Provisions 2.1.1.3. Phyisical installation 2.1.2. Electrical installation 2.1.2.1. Wiring instructions 2.1.3.
  • Page 3 2.4.2. Gateway 2.5. Safety Conditions 3. Pool light 3.1. Installation 3.1.1. Wiring instructions 3.2. Configuration 3.2.1. Lamp type selection 3.2.2. Pool light synchronisation 3.2.3. Manual pool light synchronization 3.3. Operation 3.3.1. LinkTouch 3.3.1.1. Control functions 3.3.1.2. Advanced control functions 3.3.2. App 3.3.3.
  • Page 4 6. Cover 6.1. Installation 6.1.1. DURACOVER Cover System wiring instructions 6.1.2. Multi-Brand Cover wiring instructions 6.1.3. Key Switch installation 6.2. Configuration 6.2.1. DURACOVER Cover System 6.2.1.1. Pairing 6.2.1.2. Calibrating 6.2.1.3. Configuration of the Dead Man Switch (DMS) 6.2.2. Multi-Brand Cover 6.2.2.1 Pairing 6.3.

  • Page 7: Introduction

    Cloud App and Portal for easy configuration and operation of the different devices. The LINK Master ensures efficient and safe operation of your pool. Be aware that the LINK Master is an exact and sensitive system that must always be handled with care. During installation, the regulations and provisions applicable for the...

  • Page 8: Box Content

    1.2. Box content Check that the following parts are supplied with the product. 1 x Cabinet 1 x Wall mounting plate 2 x Cabinet door triangle keys 1 x Quick guide 1 x Fixing set (screws, plugs) 1 x Antenna DLM-600...

  • Page 9: Keypad

    1.3. Keypad High level overview of the LINK Master and the two keypads that are inside. DLM 600...

  • Page 10: Controller Keypad

    Relay B function (→ 2.2.3.) 1.3.2. Gateway keypad On/Off button Cloud LED This led will be on if your This button will turn on/off the LINK Master has an internet gateway. connection. DuraLink LED Direct Wifi button This button will enable...

  • Page 11: Link Master

    The antenna needs to be attached on the top right of the LINK Master The LINK Master cabinet needs to be mounted vertically and permanently on a solid wall with sufficient bearing capacity. Respect a free space around the LINK Master cabinet for unobstructed airflow.

  • Page 12: Provisions

    The relative humidity at the location of installation must not exceed 90%, no condensation may occur. Direct heat or sun rays on the device must be avoided. The LINK Master is not suitable for outdoor installation. The DuraCloud App and LINK Touch need access to the LINK Master for configuration of certain settings and calibrations.

  • Page 13: Phyisical Installation

    2. Lift the Link Master up, and position in front of the hooks on the mounting plate. (best with 2 persons) 3. Lower the Link Master and let the hooks slide into the holes on the back of the cabinet. Make sure the Link Master is securely attached.

  • Page 14: Electrical Installation

    2.1.2. Electrical installation High level overview of the LINK Master and the parts that are inside. DLM-600 overview Antenna Transformer Gateway Controller Circuit breakers Terminal Blocks DLM-600 terminal blocks...

  • Page 15: Wiring Instructions

    2.1.2.1. Wiring instructions Before opening the housing, it is necessary to always de-energize the device electrically. The electrical connection as well as the work of adjustment and servicing should only be carried out by an qualified electrician! Check the sticker on the inside of the cabinet door for easy installation. Connect all the devices to the connection terminals at the bottom of the cabinet.

  • Page 16: Network Installation

    2.1.3. Network installation For the DuraCloud App to communicate with the LINK Master it needs to be connected to a ‘router’ device providing wireless (cloud) access. This access is essential to be able to fully configure your LINK Master (→ 2.2) The ‘router’...

  • Page 17: Dmx Controller Installation

    For more information about how to use the DMX commands please refer to (→ 3.3.5.) DLM-600 DMX connection 2.1.5. RS485 controller installation A controller with RS485 connection can be connected to the LINK Master in the following way. Connect the RS485 controller wires to the connection terminal blocks 29 and 30 on the DLM-600 For more information about how to use the RS485 commands please refer to (→...

  • Page 18: Configuration

    2.2. Configuration 2.2.1. System start-up For the initial start-up the LINK Master Controller and Gateway keypads will be used be- cause the DuraCloud App and LINK Touch are not yet paired with the LINK Master. Also be aware that the last step in the initial start-up of the Gateway is to search for any software updates.
  • Page 19 Ensure the smart phone or tablet you are using is connected to the same network as the LINK Master. Open the DuraCloud App on your ‘smart’ device. Open the menu on the top left Navigate to “Claim Ownership” Select the Gateway keypad button “Owner” to obtain authorised access.

  • Page 20: Configure Other Devices

    2.2.3. Configure other devices Before continuing with the pairing of the LINK Touch (→ 2.2.6.) it is important that all installed devices are correctly paired with the LINK Master. Pool lights (→ 3.2.) Heat pump (→ 4.2.) Filter pump (→ 5.2.) 2.2.4.

  • Page 21: Configure Input C As Level Sensor

    The filing control system which is connected to the LINK Master will be activated 2.2.6. LINK Touch pairing To operate the LINK Master using the LINK Touch remote control, a connection needs to be establish first, by pairing the two devices.
  • Page 22 Touch the screen once to put the LINK SETTINGS Touch in pairing mode. Pair start The LINK Touch will now start the pairing with the LINK Master When the pairing is successfully completed, the LINK Touch display will show “Paired”...

  • Page 23: Configuring Smart Rules

    2.2.7. Configuring smart rules Smart rules are pre-programmed to automate processes of specific pool devices con- nected with the LINK Master. The only manual options remaining are to select, activate and to deactivate the ‘Smart Rules’. Manual selections for ‘Smart Rules’ between two devices.
  • Page 24 To make sure the temperature displayed on the LINK Touch and app is a good representation of the pool temperature, the filter pump can be automatically set to run regularly for a short time by the LINK Master. - Enabled...

  • Page 25: Scheduler

    High mode: → All devices are running at full power. Normal mode: → Everyday use, the LINK Master ensures the pool stays as clean and warm as possible with the least amount of energy consumed. Eco mode: → All devices are running at a bare minimum to keep the pool clean and warm.

  • Page 26: Schedules Overview

    1. Open the DuraCloud App and navigate to the relevant pool. 2. Click the clock icon ‘ ’ in the top right of the DuraCloud App screen. 3. This page will show all the ‘Duratech schedules’ and ‘Custom schedules’ 2.2.8.1.2. Create schedules To create a ‘Custom schedule’:...

  • Page 27: Schedule Detail

    2.2.8.1.3. Schedule detail Viewing the schedule details can be done by selecting the schedule in the overview. After opening the schedule, it can be deleted or activated. To activate the schedule, click the ‘Run’ icon in the top right of the DuraCloud App screen.

  • Page 28: Schedule Events

    2.2.8.2. Schedule events Every schedule consists of multiple events. These events can be set for filter pump, heat pump and pool lights. These events can be created, updated, and deleted via the Dura- Cloud App. 2.2.8.2.1. Creating events When creating a schedule there is the option to add events to these schedules using the ‘+’...

  • Page 29: Deleting Events

    When creating a schedule there is the option to delete events, to do this hold the event and you get the option to delete the event. 2.2.8.2. Duratech Schedules These are our different duratech schedules: - High - Normal - on/off...
  • Page 30 - High → Everything running at full power - Normal → Everyday use, the controller keeps the pool as clean and warm as possible with the least amount of energy. NORMAL ON/OFF...
  • Page 31 NORMAL MULTI-BRAND INVERTER NORMAL INVERTER...
  • Page 32 - Eco → Everything is running at a bare minimal to keep the pool clean and warm. No automatic systems are allowed to work outside the scheduled times. ECO ON/OFF ECO MULTI-BRAND INVERTER...
  • Page 33 ECO INVERTER - Off → Everything is off...

  • Page 34: Operation

    2.3. Operation When the configuration has been completed the LINK Master is ready for daily use. The LINK Master will standard and therefore in most cases be running in the automatic mode. • Automatic mode (→ 2.3.3.) Additional operation modes & informations are available and explained in the following chapters.

  • Page 35: Gateway Keypad

    2.3.1.2. Gateway keypad On/Off button Cloud LED This led will be on if your This button will turn on/off the LINK Master has an internet gateway. connection. DuraLink LED Direct Wifi button This button will enable This led will blink if it receives an access point on your a wireless DuraLink message.

  • Page 36: Discovery/Pairing Mode

    2.3.2. Discovery/Pairing mode The Pairing/Discovery mode is used to connect House of DURATECH devices with the LINK Master. The LINK Master will be able to pair with all devices part of the DuraLink connected product range. Enabling pairing/discovery mode: This mode is enabled by pressing the Duralink button on the LINK Master controller key- pad.

  • Page 37: Automatic Mode

    2.3.3. Automatic mode By default the LINK Master is in Automatic mode. In this mode the LINK Master will follow the schedule which is behind the selected Pool mode. (→ 2.2.8.) Returning to Automatic mode • From Automatic mode with user override the LINK Master can go to Automatic mode by pressing the MANUAL button on the keypad.
  • Page 38 It is recommended that only trained professionals operate this feature. The LINK Master will continue to run in the automatic mode with user override until this mode is disabled by pressing the “manual” button on...
  • Page 39 All other devices will continue to work as set. Using Filling in The automatic mode with user override. • Filling is only available when Relay B is configured as Filling output (→ 2.2.3.), if filling is activated without the correct configuration of Relay B, the led will blink 3 times fast. •...

  • Page 40: Cleaning Mode

    This can be done as often as necessary. When you are done with the cleaning of your pool, you can disable the Cleaning mode by pressing the button “Cleaning” on the Keypad. The LINK Master will return to automatic mode and will resume normal operation.

  • Page 41: Direct Wifi

    LINK Master) Connect to this Wifi network using the password: duralink When you open the DuraCloud App and it cannot find a LINK Master in your network, then it will guide you through the process of setting up Direct Wifi.

  • Page 42: Updating

    The LINK Master controller can be updated in two ways. • The first is an automated process whereby the firmware of the LINK Master and all the devices will be updated when the gateway receives a new firmware image from the cloud, containing all the firmware of the connected devices.

  • Page 43: Safety Conditions

    2.5. Safety Conditions The LINK Master is fitted with several safety features. They can be split in two main cate- gories. - External - Differential switch 30mA - Circuit Breakers - Internal - Current measurement on all 12V & 24V outputs of the controller...

  • Page 44: Pool Light

    DuraVision offers four types of pool lights (model codes are listed) which can be con- nected to the LINK Master. Each type has their own functionality, with the PLC being fully compatible with all features available on the LINK Master.

  • Page 45: Installation

    The pool lights are not allowed to exceed 450VA and the current 37.5A 3.1.1. Wiring instructions There are two ways to wire the pool lights. Whereby the ‘Star’ connection is the preferred one over the ‘Daisy Chain’ layout, for the best optimal performance with the LINK Master. Pool Pool...

  • Page 46: Configuration

    3.2. Configuration The connected pool lights will automatically be selected by the LINK Master. However we highly recommend verifying the settings and when needed adjusting to the specific model pool light in the DuraCloud App. (→ 3.2.1.) 3.2.1. Lamp type selection Please follow the below sequence: Open the DuraCloud App and ensure it has the owner role for the relevant pool.

  • Page 47: Pool Light Synchronisation

    3.2.2. Pool light synchronisation This synchronisation option is not used for ON/OFF pool lights and PLC controlled pool lights Synchronization is only required for the toggle pool lights, to ensure that all pool lights are running the same color scene. This process of synchronising the scenes generally takes 45 seconds to complete.

  • Page 48: Operation

    3.3. Operation 3.3.1. LinkTouch The LINK Touch can be used to control the pool lights wirelessly, the LINK Touch provides the following functions: Turning pool lights On/Off Dimming of the pool lights (PLC pool lights only) Changing the color (only for RGB pool lights) Changing color scenes (predefined by DuraVision) Changing CCT (Correlated Color Temperature) for RGB and TW pool lights...

  • Page 49: Control Functions

    3.3.1.1. Control functions Corelated Colour temperature (CCT): Slide to the right to adjust the pool light from “warm white” to “cool white” ON/OFF Lights: Press to switch all Lights ON/OFF Colour wheel: Slide to change colour of Pool Lights (only DLT10-RGB) Colour program: Press for next colour program.

  • Page 50: Advanced Control Functions

    3.3.1.2. Advanced control functions Activate the settings menu, then use right arrow key to select the desired setting and the left arrow key to exit the setting. Activate the settings menu, then use right arrow key to select the desired setting Touch the display for 3 seconds to activate the settings menu.

  • Page 51: App

    3.3.2. App 3.3.3. DMX controller operation When using a DMX controller for operating the pool light, the functionalities of the LINK Touch or the DuraCloud App will no longer be active. 3.3.4. RS485 command set Function Command Remark Example Avail- Available able in PLC...
  • Page 52 Color temperature PTxyz x = ten thousand; y = thou- PT035 = Set white color sand; z = hundred temperature to 3500K (in steps of 500K)

  • Page 53: Updating

    3.4. Updating Currently the DuraVision pool lights do not support remote updating. 3.5. Safety conditions Do not use DC voltages with the pool lights Ensure the voltage meets the required 12VAC (10-14 VAC)

  • Page 54: Heat Pump

    4. Heat pump 4.1. Installation The LINK Master is equipped with ‘smart’ functions for the DURAHEAT heat pump. These ‘smart’ functions will only work with heat pumps part of the DuraLink connected range of products. • DURAHEAT heat pumps •...

  • Page 55: Multi-Brand Heat Pump With Link Dongle

    4.1.3. Multi-brand heat pump without LINK dongle Multi-brand heat pumps are not supported. They need to be installed and operated as a stand-alone device. Therefor the designated connection terminal blocks on the LINK Master cannot be used for the electrical connection.

  • Page 56: Configuration

    Heatpump will start up, and after 1 – 2 min. the temperatures should appear on the LINK Touch and DuraCloud App. Only one ‘DURAHEAT’ heat pump can be connected with the LINK Master at a time. For a new ‘DURAHEAT’ heat pump to be connected, the pairing process needs to be execut- ed again.

  • Page 57: Operation

    4.3. Operation 4.3.1. LINK Touch The LINK Touch can be used to control the ‘DURAHEAT’ heat pump wirelessly, the LINK Touch supports the following functions for controlling the ‘DURAHEAT’ heat pump: Turning the ‘DURAHEAT’ heat pump ON/OFF Changing the pool water setpoint temperature Displaying the actual pool water temperature Error feedback (‘DURAHEAT’...

  • Page 58: Updating For 'Duraheat' Heat Pump

    4.4 Updating for ‘DURAHEAT’ heat pump Multi-brand heat pumps with the LINK Dongle will be recognized as a ‘DURAHEAT’ heat pump and the LINK Dongle is updated in a similar way as the ‘DURAHEAT’ heat pumps. The gateway will automatically update the ‘DuraHeat’ heatpumps when connected to the internet and when a new firmware version is available.

  • Page 59: Safety Conditions

    4.5. Safety conditions Please refer to the ‘DURAHEAT’ heat pump manual for specific safety conditions. For the LINK Master, do not exceed the ‘DURAHEAT’ power supply values mentioned in the installation chapter. (→ 4.1.)

  • Page 60: Filter Pump

    Ensure the advised cable sections are adhered to when connecting the DURAFLOW Variable Speed filter pump. The designated connection terminal blocks need to be used to connect the DURAFLOW Variable Speed filter pump to the LINK Master. Ensure the screws are firmly tightened! DLM-600 filter pump wiring...

  • Page 61: Multi-Brand Single Speed Filter Pump Wiring Instructions

    Speed filter pump. The designated connection terminal blocks need to be used to connect the Multi-Brand Single Speed filter pump to the LINK Master. Ensure the screws are firmly tightened! DLM-600 filter pump wiring 5.1.3. Multi-Brand Variable Speed filter pump wiring instructions Ensure the advised cable sections are adhered to when connecting the Multi-Brand Vari- able Speed filter pump.
  • Page 62 DLM-600 filter pump wiring with boost cable...

  • Page 63: Configuration

    5.2.1. Pairing the DURAFLOW Variable Speed filter pump For the ‘DURAFLOW’ Variable Speed filter pump to work correct it needs to be paired with the LINK Master. Be aware that the LINK Touch and DuraCloud App require that the ‘DURAFLOW’ Variable Speed filter pump is paired first.

  • Page 64: Multi-Brand Single Speed Filter Pump

    5.2.2. Multi-Brand Single Speed filter pump The Multi-Brand Single Speed filter pump does not require a dedicated pairing with the LINK Master. (For installation see 5.1.2.) However, the use of a Multi-Brand Single Speed filter pump does require the filter pump mode to be correctly configured in the DuraCloud App.

  • Page 65: Operation

    The filter pump is the core device for a swimming pool set up. It provides the water flow needed for most of the other devices to make them work. Therefor the filter pump’s operation is fully managed by the LINK Master, however there are settings that can be changed to optimize your filter pump.

  • Page 66: Multi-Brand Single Speed Filter Pump

    Skimmer Function - This function increases the speed of the filter pump periodically, making sure that the dirt floating on the water surface of the pool gets pushed to the skimmer in an efficient and fast way. The Skimmer Function duration and -interval can be adjusted in the DuraCloud App.

  • Page 67: Updating

    5.4. Updating The gateway will automatically update the ‘DURAFLOW’ inverter filter pump when con- nected to the internet and when a new firmware version is available.

  • Page 68: Safety Conditions

    5.5. Safety conditions Please refer to the ‘DURAFLOW’ Variable Speed filter pump manual for specific safety conditions. Please refer to the Multi-Brand filter pump manual for specific safety conditions.
  • Page 69 This way, the user can intervene immediately in case of any problems. The LINK Master operation for Multi-brand covers is supported. Please be aware that configuration of the LINK Master is a manual process and needs to be carefully followed for the Multi-brand cover to work correctly.
  • Page 70 Relay A and B terminals on the LINK Master. When a Key-switch is used it needs to be connected to the LINK Master, this signal will be received and passed on by the LINK Master over the Relay A and B to the stand alone Multi-Brand controller.
  • Page 71 Both the DURACOVER Cover System and the Multi-Brand cover can also be operated with a key Switch. The designated connection terminal blocks need to be used to connect the Key Switch to the LINK Master. • The lead wires of the key-switch must be connected to...
  • Page 72 6.2.1.1. Pairing The DURACOVER Cover System does not require a dedicated pairing with the LINK Mas- ter. It is already part of the LINK Touch pairing sequence with the LINK Master. 6.2.1.2. Calibrating Calibration of a DURACOVER Cover System is required to have the cover moving to the open and close position correctly.
  • Page 73 6.2.1.3. Configuration of the Dead Man Switch (DMS) One essential configuration is the setting of the Dead Man Switch (DMS). This is a safety feature to prevent dangerous and harmful situations when using the cover. Preventive measure. Always ensure there is a visual contact with the pool when operating the cover.
  • Page 74 Multi-brand covers, using their own stand-alone cover controller can be controlled via relays A and B on the LINK Master. In this case the two relays A and B of the LINK Master will drive the stand-alone cover controller and simulate a key contact (left/right rotation of the motor) For further calibration of the Multi-Brand cover and its positioning please refer to the man- ual of this specific device.
  • Page 75 6.3. Operation 6.3.1. DURACOVER Cover System The full control for the DURACOVER Cover system is integrated in the LINK Master. 6.3.1.1. Controller keypad The LINK Master Controller keypad button ‘Cover’ can be used to operate the DURA- COVER Cover System.
  • Page 76 6.3.1.2. LINK Touch The Open and Close cover buttons on the LINK Touch can be used to operate the DURA- COVER Cover System. The touching of the ‘Cover Open’ symbol on the LINK Touch screen will open the cover. The touching of the ‘Cover Close’ symbol on the LINK Touch screen will close the cover. Pool cover OPEN: Press or hold to open the pool cover depending on your DMS configuration.
  • Page 77 When the DeadManSwitch (DMS) is enabled the ‘Cover Open’ or ‘Cover Close’ symbol on the LINK Touch screen must be kept touched to activate the function. When the DeadManSwitch (DMS) is disabled the ‘Cover Open’ or ‘Cover Close’ symbol on the LINK Touch be released after touching. The opening and closing functions will work until the calibrated end positions of the cover.
  • Page 78 6.3.1.3. DURACloud App The Open and Close cover buttons on the DuraCloud App can be used to operate the DURACOVER Cover System. The touching of the ‘Cover Open’ symbol on the DuraCloud App will open the cover. The touching of the ‘Cover Close’ symbol on the DuraCloud App will close the cover. In case the cover is already open and the user presses the “Open”...
  • Page 79 6.3.1.4. Key Switch The Open and Close cover positions on the Key Switch can be used to operate the DURACOVER Cover System. Turning the key to the ‘Cover Open’ position on the Key Switch will open the cover. Turning the key to the ‘Cover Close’ position on the Key Switch will close the cover. When the DeadManSwitch (DMS) is enabled the key must be kept turned into the ‘Cover Open’...
  • Page 80 6.3.2. Multi-brand Cover 6.3.2.1. Controller keypad The LINK Master Controller keypad buttons ‘Relay A’ and ‘Relay B’ can be used to oper- ate the Multi-brand Cover. By pressing the ‘Relay A’ button you will open your Multi-brand cover. By pressing the ‘Relay B’ button you will close your Multi-brand cover 6.3.2.2.
  • Page 81 6.3.2.3. DURACloud App The Open and Close cover buttons on the DuraCloud App can be used to operate the Multi-Brand cover. The touching of the ‘Cover Open’ symbol on the DuraCloud App will open the cover. The touching of the ‘Cover Close’ symbol on the DuraCloud App will close the cover. When the Multi-Brand cover is opening or closing, the feedback of the actual position will not be pictured as a live animation in the DuraCloud App.
  • Page 82 6.4. Updating The LINK Master Gateway is updated automatically after House of DURATECH releases a new firmware version. The DURACOVER Cover System functions are part of the LINK Master updates and distributed to the LINK Touch.
  • Page 83 6.5. Safety conditions Please refer to the ‘DURACOVER’ Cover system for specific safety conditions. When selecting the spot for fitting the key switch, make sure there will be an unobstructed line-of-sight with the pool when using the key switch. This way, the user can intervene immediately in case of any problems.
  • Page 84 DuraCloud App will also be accessible through our web portal The DuraCloud App is available from the Google Play store and the Apple App Store by searching “DuraCloud”, you can also find a redirect on our website (https://duratech.be). 7.2. Configuration When starting the DuraCloud App it needs to be connected to a selected pool to start the configuration.
  • Page 85 DuraCloud app and -portal. 7.3.3. Remote support By using the DuraCloud platform, remote support can be provided for the LINK Master and the House of Duratech connected devices. If any issues occur please first ready the related chapter for the initial problem solving of the connected device.
  • Page 86 Propulsion Systems bvba Dooren 72 1785 Merchtem, Belgium Tel +32 2 461 02 53 Fax +32 2 706 59 60 www.duratech.be info@propulsionsystems.be We reserve the rights to change all or part of the contents of this document without prior notice...
