Page 11: About This Manual
The purpose of this manual The purpose of this installation manual is to provide the descriptions and procedures required to install the Kongsberg SBP 120 Sub-bottom profiler system units, and to perform the necessary cabling between the individual system units, and between the system and peripheral systems, sensors and devices.
Page 12: Sbp 120
The SBP 120 is used in combination with the EM 120/122, whilst the SBP 300 is used with the EM 302. This implies that the SBP 120 and the SBP 300 are interfaced to different receiver arrays and different preamplifier units.
Page 13: Purpose
SBP 120 2.1.2 Purpose The primary application of the SBP 120 is to do imaging of sediment layers and buried objects. Image quality is influenced by: • The spatial resolution of the system; its ability to distinguish objects separated in angle and/or range.
Page 14: Beam Stabilisation
2.1.6 Data logging and real-time processing The data produced by the SBP 120 are logged in the Topas raw format or in a SEG-Y format allowing post-processing by some seismic processing software.
Page 15: Transducer Arrays
• Remote Control Unit 2.2.2 Transducer arrays The SBP 120 transmit transducer has a physical width of 80 cm, a depth of 35 cm and a length depending on the requested beamwidth. The 3º, 6º, and 12º SBP 120 transmit arrays are 7.5, 3.8 and 1.9 meters long, respectively.
Page 16: System Drawing
Kongsberg SBP 120 2.3 System drawing Figure 1 System diagram 303562/C...
Page 17: Scope Of Supply
• Installation sketches to fit the specific vessel • Assistance during the installation • Testing • Training Assistance from Kongsberg Maritime AS must be ordered separately, and are charged according to the contract. 2.5 Supply conditions 2.5.1 Equipment responsibility Upon receipt of the equipment the system owner or installation shipyard automatically becomes fully responsible for the equipment, unless otherwise stated in the contract.
Page 18: Project Management
Before any installation work by Kongsberg Maritime AS can begin, all cables (at least those which are in any way connected with the system) must be run and connected to their respective terminations.
Page 19: Guarantee Period
SBP 120 Note Any damage incurred during the installation period, even with a Kongsberg Maritime AS representative present, is the installation shipyard’s responsibility unless it can be proven that the damage was due to production or material defects in the equipment delivered by Kongsberg Maritime AS, or irresponsibility by Kongsberg Maritime AS personnel.
Page 20: Installation Requirements
-15% to +20% of the nominal voltage (except under fault conditions). Kongsberg Maritime strongly recommends that the SBP 120 Operator Station and Beamformer Unit are powered through Uninterruptedly Power Supply (UPS). The UPS must be large enough to allow minimum 10 minutes operation. The system can then be switched off in a controlled manner in case of power failures.
Page 21: Wiring
SBP 120 2.6.5 Wiring All cables between the bridge, the various operation- and equipment rooms, must be supported and protected along their entire length using conduits or cable trays. Note that the cables must not be installed in the vicinity of high-power supplies and cables, antenna cables or other possible sources of interference.
Page 22: Technical Specifications
System performance , 3 degrees system on page 24 • Environmental specifications on page 24 Note Kongsberg Maritime is engaged in continuous developments of its products and reserves the right to alter specifications without prior notice. List of units and main sub-units • Operator Station –...
Page 23: Physical Specifications
Technical specifications Interfaces • Operator Station: – Network or serial line interfaces (with operator adjustable baud rate, parity, data length, and stop bit length) for: * Positions in either Simrad 90, NMEA 0183 GGA and GGK formats. * External clock in NMEA 0183 ZDA format. * Input of depth, bottom slope angles and sound velocity information from EM 120/122 in a native KM datagram format or depth in NMEA DPT format.
Page 24: Power Requirements
Kongsberg SBP 120 • approx. 170 kg Weight: Remote Control Unit – Physical dimensions • 300 mm Height: • 380 mm Width: • 155 mm Depth: • 8.2 kg Weight: Tx/Rx Junction Box – Physical dimensions • 440 mm Height: •...
Page 25: Restrictions For Use - Limitations
Technical specifications – < 300 W – 47 to 63 Hz • EM 120/122 Preamplifier Unit – 100 to 240 Vac – < 300 W – 47 to 63 Hz • TX Junction Box – Not applicable • Remote control Unit –...
Page 26: System Performance , 3 Degrees System
Kongsberg SBP 120 3.6 System performance , 3 degrees system • 2.5 to 6.5 kHz Frequency: • Number of beams per ping: – Tx: 1 – Rx: max. 11 • (along x across) Beamwidth, 4 kHz: – Tx: 3 x 35 degrees –...
Page 27: Transducer Arrays
The SBP 120 Tx array should normally be mounted in flush and in parallel with the EM 120/122 Tx array. Both arrays are normally mounted in parallel with the keel.
Page 28: Installation Philosophy
Kongsberg SBP 120 Figure 2 Transducer installation principles 4.1.2 Installation philosophy The SBP 120 is an optional Sub-bottom profiler that can be delivered with the EM 120/122. Note Refer to the EM 120/122 Installation manual for more information about the multibeam echo sounder The transducer array must be located and installed depending on the vessel’s design.
Page 29: Installation Parameters
The installation parameters are listed in the tables below. We recommend that you complete these tables for documentation of your settings. Note Refer to the SBP 120 Operator manual for more information about the SBP 120 user interface Accuracy requirements for the installation is given in Alignment on page 75.
Page 30: Installation Steps
Prepare the transducer array installation arrangement. • The installation arrangement must be capable of accepting the two EM 120/122 transducer frames in addition to the one needed for the SBP 120 transmitter array. Mount the SBP 120 mounting frame. Mount the transducer elements into the frame.
Page 31: Locating The Transducer Array
4.3.2 Propeller noise The propulsion propeller is the dominant noise source on most vessel types. The noise is transmitted through the sea water, and may in extreme cases reduce the maximum range capability of the SBP 120. 303562/C...
Page 32: Noise From Protruding Objects On The Hull
Kongsberg SBP 120 Figure 3 Sketch of boundary layer underneath the vessel The transducer arrays should therefore be placed far away from the propeller, which means on the forward part of the hull. Positions outside the direct line of sight from the propeller are favourable.
Page 33: Recommended Location Of The Transducer Array On The Hull
Transducer arrays Figure 4 Recommended location of the transducer array on the hull Generally the possibility of getting air bubbles in front of the transducer array is the most important factor, and thus the recommended transducer array location is in the fore part of the hull, with a maximum distance from the bow equal to one third of the total water line length of the hull, see the figure.
Page 34: Installing The Steel Conduits
This is always the yard’s responsibility. For the principles, see Blister and conduits arrangements for the SBP 120 and the EM 120/122 systems (example) on page 39. The steel conduits must be designed to fit each individual vessel. They are not included with the system delivery.
Page 35: Casing
Close the top of the steel conduits with a seal. Kongsberg Maritime recommends the use of sealing from Roxtec AB in Sweden. This system is described in Cable gland assembly procedure on page 129. Mount cable protection between the hull and the cable outlet from the casing.
Page 36: Mounting Frames
Kongsberg SBP 120 4.6 Mounting frames The SBP 120 mounting frames are designed to house the individual transmit transducer elements. The elements are mounted next to each other to make up the arrays. The following mounting frames are available. These Tx frames are basically identical, but they differ in physical length.
Page 37: Cable Connection Unit (Ccu)
Two long cables, 20 meters each, transport the transducer signals to the Tx/Rx Junction Box. 4.7.1 Logistics and references Safety - Refer to the general safety procedures. Personnel - Trained mechanical workers and installation engineers from Kongsberg Maritime. Ship location - Dry dock Special tools - None References - None 4.7.2 Procedure...
Page 38: Transducer Elements
Personnel - Three installation engineers from Kongsberg Maritime Ship location - Dry dock Special tools - Battery drill (recommended) References - None Note Note that engineers from Kongsberg Maritime must be present to install the transducer elements. 4.8.2 Procedure Observe normal safety precautions for dockyard work. Caution...
Page 39 Transducer arrays See installation drawings, Casing with mounting frame, 3 degrees – arrangement drawings on page 89 When all transducers are mounted, mount the baffle. The baffle must be glued and bolted. Apply one layer of antifouling to the baffle and the transducer face. 303562/C...
Page 40: Installation Examples
This is a well proven way, when refitting a vessel with a SBP 120 system. Refer to Hatches for access to the steel conduits on page 39 for the principles.
Page 41: Blister And Conduits Arrangements For The Sbp 120 And The Em 120/122 Systems (Example)
Installation examples Figure 6 Blister and conduits arrangements for the SBP 120 and the EM 120/122 systems (example) Figure 7 Hatches for access to the steel conduits 303562/C...
Page 42: Logistics And References
• The blister must hold the three casings; one for the EM 120/122 Tx array, one for the SBP 120 Tx array and one for the Rx transducer array. • The blister will be water filled. To let the air escape, make a suitable hole in the rear end close to the vessel’s hull.
Page 43: Fairing
Installation examples 5.3 Fairing The transducer arrays may also be mounted directly under the vessel’s hull and then “streamlined” with fairing. This installation method has proven successful in former multibeam echo sounder installations. The required installation drawings must be made by the installation shipyard or by third-party ship designers.
Page 44: System Units
Kongsberg SBP 120 6 System units This chapter describes the installation of the SBP 120 Transceiver Unit in the equipment or operation room, and the Operator Station and the Beamformer Unit in the operation room. The Remote Control Junction Box installation is also described.
Page 45: Location
System units 6.1.1 Location The SBP 120 Transceiver Unit is normally installed in the vessel’s “sonar room” close to the Tx/Rx Junction Box. This room must be dry and free from excessive dust and vibration. Maximum humidity of 80% is recommended. Good ventilation for the equipment cooling must be provided.
Page 46: Procedures
Kongsberg SBP 120 Figure 8 SBP 120 Transceiver Unit mounting 6.1.4 Procedures Cabinet Mark the location of the holes for the first shock absorber on the bulkhead. Refer to Fixing holes for one shock absorber on page 45. The distance from the lower holes on the lower shock absorber to the lower holes on the upper shock absorber is shown in Transceiver unit –...
Page 47: Fixing Holes For One Shock Absorber
System units Drill 11 mm holes, eight (8) for each shock absorber. Caution Always check on the other side of the bulkhead before drilling holes ! Mount the main part of the Transceiver Unit cabinet. Four 8 mm bolts are used, one in each corner of the cabinet. The bolts and nuts are included with the delivery.
Page 48: Surface Preservation
Make appropriate cautions to avoid spilling paint on the cabinet 6.2 Tx/Rx Junction Box This chapter presents the general installation procedures for the SBP 120 Tx/Rx Junction Box. 6.2.1 Location The Tx/Rx Junction Box is normally installed in the vessel’s “sonar room” close to the Transceiver Unit.
Page 49: General Information
System units Kongsberg Maritime recommends that this room is chosen close enough to the transducer array so that you do not need to extend the cables between the Tx/Rx Junction Box and the Cable Connection Unit, which is located in the frame. These cables have a standard length of 26 meters.
Page 50: Surface Preservation
Kongsberg SBP 120 6.2.5 Surface preservation All exposed metal surfaces which are likely to corrode should be painted according to the appropriate preservation scheme. This includes welds, base frames and support brackets. Care must be exercised to ensure the cabinet is not splashed with paint.
Page 51: Procedures
System units 6.3.4 Procedures Cabinet Mark the location of the holes for the cabinet. The size and location of these holes are shown on the outline drawings. Drill the four 8.5 mm holes in the bulkhead. Caution Always check on the other side of the bulkhead before drilling holes! Mount the cabinet.
Page 52: Remote Control - Interconnection Diagram
Kongsberg SBP 120 Figure 11 Remote control - Interconnection diagram 303562/C...
Page 53: Operator Station And Beamformer Unit
System units 6.4 Operator station and beamformer unit This section describes the installation of the SBP 120 Operator Station in the operation room and the Beamformer Unit in the equipment or operation room. Note A separate Beamformer Unit is optional. The beamformer application may be run on the operator station.
Page 54: Cable Layout And Interconnections
• Cable gland assembly procedure on page 129 The standard cables used between the SBP 120 system units and between the units and their external devices are shown here. For larger installations where the SBP 120 is a subsystem, the cables will also be shown in the cable layout plan and interconnection diagram specific for the vessel into which the system is installed.
Page 55: System Cabling
• Number of cores • Recommended cable type • Minimum cable specifications The appropriate considerations must be taken to suit special requirements. Kongsberg Maritime accepts no responsibility for damage to the system or reduced operational performance if this is caused by improper cabling.
Page 56: Operator Station Cables
Kongsberg SBP 120 7.1.3 Operator Station cables The illustration and the list below specifies each cable used on the SBP 120 Operator Station. References are made to detailed cable drawings. Note that this information includes several cables that may not be in use on all installations Figure 12 SBP 120 Operator Station –...
Page 57 Cable layout and interconnections C7002 - Keyboard This is a standard keyboard cable. It is normally supplied with the keyboard. See Keyboard cable on page 112 C7003 - Mouse or pointing device This is a standard mouse cable. It is normally supplied with the keyboard. Note that different work station types allow for different mouse connections.
Page 58 Kongsberg SBP 120 The cable must be provided by the installation shipyard. C7018 - USB cable This is a standard USB2 cable for connecting external storage devices. There are four USB ports in the back of the Operator Station and two USB ports in front.
Page 59: Beamformer Unit Cables
Cable layout and interconnections 7.1.4 Beamformer Unit cables The illustration and the list below specifies each cable used on the SBP 120 Beamformer Unit. References are made to detailed cable drawings. Figure 13 SBP 120 Beamformer Unit – cable plan...
Page 60: Transceiver Unit Cables
Kongsberg SBP 120 7.1.5 Transceiver Unit cables The illustration and the list below specifies each cable used on the SBP 120 Transceiver Unit. References are made to detailed cable drawings. Figure 14 SBP 120 Transceiver Unit – cable plan C7240 / C7241 - Ethernet The Transceiver Unit is equipped with two Ethernet interfaces to communicate with the Operator Station and the Beamformer Unit via a LAN Switch.
Page 61 Cable layout and interconnections C7245 - Serial line The Transceiver Unit is equipped with a serial line to connect to a motion sensor. The cable is connected to the Attitude plug on the Transceiver Unit. See Generic RS-232 Serial line on page 106 The cables must be provided by the installation shipyard.
Page 62: Transducer Cables
Kongsberg SBP 120 7.2 Transducer cables The following transducer cables are all supplied by Kongsberg Maritime with the SBP 120 system: Tx/Rx Junction Box to Cable Connection Unit Cable Connection Unit to transducers Tx/Rx Junction Box to EM 120/122 Preamplifier Unit...
Page 63: Transmit Array Cable Markings
See Transducer cabling with different numbers of Tx and Rx channels on page 70 for recommendations. The following cable information is available both in the SBP 120 installation and maintenance manuals. The cable markings are normally recorded in the installation manual first, and it is recommended to copy these records to the maintenance manual later.
Page 64 Kongsberg SBP 120 CCU<S/N> cable 1 and CCU<S/N> cable 2. These cables are molded into the CCU, and the two cables towards the Tx/Rx Junction Box are terminated with 25-pins male D-sub connectors. During installation, CCU<S/N> cable 1 of the most forward CCU is marked M1-1, while CCU<S/N>...
Page 65: Location Of The First Transducer Element / Module In Each Array (Example)
Cable layout and interconnections Figure 15 Location of the first transducer element / module in each array (example) 303562/C...
Page 66: Ccu1
Kongsberg SBP 120 CCU cable labelling Table 4 CCU1 CCU1 Serial number: Location of Tx elements Physical position Element serial Cable identification Cable C-number (Element) number: 1 (forward port) 2 (forward middle) 3 (forward stbd) 4 (port) 5 (middle) 6 (stbd)
Page 67 Cable layout and interconnections Table 5 CCU2 CCU2 Serial number: Location of Tx elements Physical position Element serial Cable identification Cable C-number (Element) number: 25 (port) 26 (middle) 27 (stbd) 303562/C...
Page 68 Kongsberg SBP 120 Table 6 CCU3 CCU3 Serial number: Location of Tx elements Physical position Element serial Cable identification (Element) number: 49 (port) 50 (middle) 51 (stbd) 303562/C...
Page 69 Cable layout and interconnections Table 7 CCU4 CCU4 Serial number: Location of Tx elements Physical position Element serial Cable identification Cable C-number (Element) number: 73 (port) 74 (middle) 75 (stbd) 303562/C...
Page 70: Sbp 120 Tx/Rx Junction Box Cables
Kongsberg SBP 120 7.2.2 SBP 120 Tx/Rx Junction Box cables The signal cabling between the Tx/Rx Junction Box and the Transceiver Unit is made with 8, 4 or 2 individual cables for system beamwidths of 3 degrees, 6 degrees and 12 degrees, respectively.
Page 71: Em 120/122 Preamplifier Unit Cables
Figure 16 Transceiver Unit sockets Figure 17 Tx/Rx Junction Box input and output sockets 7.2.3 EM 120/122 Preamplifier Unit cables The receive transducer hydrophone array used by the standard SBP 120 system is shared with the EM 120/122 Multibeam echo sounder. More information •...
Page 72: Transducer Cabling With Different Numbers Of Tx And Rx Channels
The number of these TRx channels in the transceiver unit is determined by the size of the SBP 120 transmitter array. If for instance a 6 degree SBP transmitter array is to be integrated with a 1 degree EM receiver array, there will be more low-frequency signals available from the EM preamplifier than the number of transmit/receive-channels present in the transceiver unit.
Page 73: Cable Specifications
Cable layout and interconnections entered into the SBP 120 operator software are the centre position of the port half of the EM receiver array (i.e. different from the lever arms entered in the EMs operator software for the same array) Follow the table below (alternative cabling between EM preamplifier unit and Tx/Rx junction box) and use the centre half of the EM receiver array.
Page 74: Basic Cabling Requirements
The cables specified may not meet the standards provided by the vessel’s classification society. Consult the applicable guidelines. Kongsberg Maritime as takes no responsibility for performance degradation or damage caused to system, vessel or personnel if the cables used during installation do not meet these specifications.
Page 75 Cable layout and interconnections Radio Frequency interference All cables that are to be permanently installed within 9 m (30 ft) of any source of Radio Frequency (RF) interference such as a transmitter aerial system or radio transmitters, must, unless shielded by a metal deck or bulkhead, be adequately screened by sheathing, braiding or other suitable material.
Page 76 Kongsberg SBP 120 Where two cables are connected in series via a junction box or terminal block, the screens of both cables must be connected together but not grounded. Cable terminations Care must be taken to ensure that the correct terminations are used for all cable conductors, especially those that are to be connected to terminal blocks.
Page 77: Alignment
Mounting frames and structures on page 78 Figure 19 Reference points The SBP 120 is a precision instrument for sub-bottom investigation. To be able to produce data that are both detailed and correct, it is necessary to calibrate the survey vessel very well, and perhaps better than what may have been standard practice earlier.
Page 78: Summary
120/122 with sufficient accuracy for the SBP 120. Please see the EM 120/122 Installation manual for a further description. The only specific measurements for the SBP 120 is the location and orientation of the SBP 120 transmit transducer. This is described below.
Page 79: The Measurements
All distance measurements are to be done to an accuracy of 5 cm both horizontally and vertically. (2 cm for transducers or better) The procedures and requirements made by the manufacturers of the external sensors connected to the SBP 120 must also be taken into account. 8.2 The measurements 8.2.1 Objectives The measurements to be made after installation are: •...
Page 80: Mounting Frames And Structures
Kongsberg SBP 120 The actual measurement of the installation angles may be done by two different methods. • The most accurate method is to use land surveying techniques, establish a horizontal plane and do distance measurements to and in this plane •...
Page 81: System Tests
• Final installation checks on page 85 After the installation has been performed and before the SBP 120 system is brought into operation for the first time, a series of test procedures must be carried out to confirm a correct installation.
Page 82: Visual Inspection Of Units
After the physical installation has been carried out, all the system units must be visually checked to ensure that the SBP 120 units have been installed correctly. You must ensure that the units have been mounted in the correct locations, correctly orientated (e.g. the right way up) and are correctly secured.
Page 83: Electrical Checks
Check that the sonar room is equipped with the ventilation facilities required for continuous operation. Checked (date/sign):__________________________________ 9.2 Electrical checks This section of the manual contains the test procedures for the SBP 120 system’s power and signal interface cables. WARNING These checks must be completed before any power is switched onto the system.
Page 84: Operational Voltages
Kongsberg SBP 120 The check procedure will require two engineers equipped with two-way communication devices; one will require continuity test equipment, while the other will require a suitable shorting strap. Follow the check procedure below for each cable core Position yourselves one at each end of the cable to be checked. Good communications must be established between you and your assistant.
Page 85: Signal Transmission Check - Ringing
The test transducer element may be any unit that by using a signal generator transmits at the relevant frequency. The SBP 120 TX elements can be used for this purpose. We suggest that you mount all TX elements but one, use the last element for the signal check, and mount it when test is completed.
Page 86: Tx Elements To Hd8 Signal Path
Kongsberg SBP 120 The signal path to verify is shown in the following illustration: Figure 20 Tx elements to HD8 signal path For the complete interconnection diagram in A3 format, see A3 Drawings on page 140. 303562/C...
Page 87: Final Installation Checks
Check that the data from the motion sensor, the heading sensor and the positioning system are correctly read by the SBP 120 and that the values are reasonable before un-docing. The steps in this procedure may be incorporated in the “Harbour Acceptance Test” carried out as a final check to test both the installation and the main functions of the system.
Page 88: Drawings
• SBP 120 transceiver unit interconnection diagram in A3 Drawings on page 140 • SBP 120 wired cabinet subassembly, page 1 in A3 Drawings on page 140 • SBP 120 wired cabinet subassembly, page 2 in A3 Drawings on page 140 Cable details •...
Page 89 Drawings • Generic RS-232 Serial line on page 106 • SBP Remote synchronization and On/Off on page 107 • AC mains (IEC 60320) on page 108 • Ethernet with RJ45 plugs (screened) on page 109 • Ethernet BP-HVCI on page 110 •...
Page 90: Installation Drawings
Kongsberg SBP 120 10.1 Installation drawings 10.1.1 HWS – Hydrographic Work Station – outline dimensions 303562/C...
Page 91: Casing With Mounting Frame, 3 Degrees - Arrangement Drawings
Drawings 10.1.2 Casing with mounting frame, 3 degrees – arrangement drawings Figure 21 Casing with mounting frame, 3 degrees – arrangement drawing 1 303562/C...
Page 92: Casing With Mounting Frame, 3 Degrees - Arrangement Drawing 2
Kongsberg SBP 120 Figure 22 Casing with mounting frame, 3 degrees – arrangement drawing 2 303562/C...
Page 93: Tx Mounting Frame - Outline Dimensions
Drawings 10.1.3 TX mounting frame – outline dimensions Figure 23 TX mounting frame – outline dimensions, drawing 1 303562/C...
Page 94 Kongsberg SBP 120 Figure 24 TX mounting frame – outline dimensions, drawing 2 303562/C...
Page 95: Casing, Tx Mounting Frame, 3 Degrees - Outline Dimensions
Drawings 10.1.4 Casing, TX mounting frame, 3 degrees – outline dimensions Figure 25 Casing, TX mounting frame, 3 degrees – drawing 1 303562/C...
Page 96 Kongsberg SBP 120 Figure 26 Casing, TX mounting frame, 3 degrees – drawing 2 303562/C...
Page 97: Cover Frame, Casing, 3 Degrees - Outline Dimensions
Drawings 10.1.5 Cover frame, casing, 3 degrees – outline dimensions Figure 27 Cover frame, casing, 3 degrees 303562/C...
Page 98: Cable Connection Unit - Outline Dimensions
Kongsberg SBP 120 10.1.6 Cable connection unit – outline dimensions Figure 28 Cover frame, casing, 3 degrees 303562/C...
Page 99: Transceiver Unit - Outline Dimensions
Drawings 10.1.7 Transceiver unit – outline dimensions Figure 29 Transceiver unit – outline dimensions, drawing 1 303562/C...
Page 100 Kongsberg SBP 120 Figure 30 Transceiver unit – outline dimensions, drawing 2 303562/C...
Page 101: Transceiver Unit - Illustration
Drawings 10.1.8 Transceiver unit – illustration Figure 31 Transceiver unit – illustration 303562/C...
Page 102: Transceiver Unit - Wired Rack
Kongsberg SBP 120 10.1.9 Transceiver unit – wired rack Figure 32 Transceiver unit – wired rack 303562/C...
Page 103: Remote Control - Outline Dimensions
Drawings 10.1.10 Remote control – outline dimensions Figure 33 Remote control – outline dimensions 303562/C...
Page 104: Tx/Rx Junction Box - Outline Dimensions
Kongsberg SBP 120 10.1.11 Tx/Rx junction box – outline dimensions Figure 34 Tx/Rx junction box – outline dimensions 303562/C...
Page 105: Tx/Rx Routing - Assembly Drawing
Drawings 10.1.12 Tx/Rx routing – assembly drawing Figure 35 Tx/Rx routing – assembly drawing 303562/C...
Page 106: Cable Details
Kongsberg SBP 120 10.2 Cable details • RS-232 with 25–pin D-sub (DCE) on page 105 • Generic RS-232 Serial line on page 106 • SBP Remote synchronization and On/Off on page 107 • AC mains (IEC 60320) on page 108 •...
Page 107: With 25-Pin D-Sub (Dce)
Drawings 10.2.1 RS-232 with 25–pin D-sub (DCE) This cable described the pin configuration for an RS-232 interface. The Data Circuit terminating Equipment (DCE) end is shown. Shield Received data (Rx) 25-pin D-sub connector Transmitted data (Tx) Original and complete RS-232 signal definition shown.
Page 108: Generic Rs-232 Serial Line
Kongsberg SBP 120 10.2.2 Generic RS-232 Serial line This cable comprises a multi purpose serial line. It provides interface with any peripheral unit. One end of the cable connects to the local unit with a 9-pin D-connector, (DTE) while the other connects to the peripheral as described in the peripheral unit’s...
Page 109: Sbp Remote Synchronization And On/Off
Drawings 10.2.3 SBP Remote synchronization and On/Off This cable connects the Transceiver Unit to a remote On/Off switch located in a Junction Box. The same connection allows trigger output and remote control (synchronization). Cable specifications • Conductors: 5 x 2 x 0.5 mm² •...
Page 110: Ac Mains (Iec 60320)
Kongsberg SBP 120 10.2.4 AC mains (IEC 60320) This is a commercial 230 Vac power cable for mains power. One end is fitted with an IEC plug, the other with a standard European mains plug. This is a standard cable type supplied in different lengths.
Page 111: Ethernet With Rj45 Plugs (Screened)
Drawings 10.2.5 Ethernet with RJ45 plugs (screened) This cable contains the Ethernet connection. RJ45 plugs are used to terminate the cable. Note that these plugs must be screened to comply to EC rules. Pin 8 Pin 1 End view of RJ45 plug Pin 8 View Pin 1...
Page 112: Ethernet Bp-Hvci
Kongsberg SBP 120 10.2.6 Ethernet BP-HVCI 303562/C...
Page 113: Ethernet Bp-Msp6Xl
Drawings 10.2.7 Ethernet BP-MSP6XL 303562/C...
Page 114: Keyboard Cable
Kongsberg SBP 120 10.2.8 Keyboard cable This is a standard keyboard cable. In most cases, the cable is physically connected to the keyboard. It is terminated in a plug suited to fit the computer. Several keyboard types are available for different languages and hardware platforms.
Page 115: Mouse Cable
Drawings 10.2.9 Mouse cable This is a standard mouse (or other pointing device) cable. It is physically connected to the mouse, and terminated in a plug suited to fit the computer. Several mouse and pointing device types are available with two or three buttons, and with or without a scroll wheel.
Page 116: Parallel Printer
Kongsberg SBP 120 10.2.10 Parallel printer This is a standard “Centronics” parallel printer cable. It is provided ready-made with printers, and also obtainable from commercial retailers. Termination is made with 25–pin “D-sub” connector in one end, parallel port connector in the other end (IEEE 1284–A)
Page 117: Dvi-I Display
Drawings 10.2.11 DVI–I Display This cable is a standard DVI-I cable. It is normally provided with the colour display. For more information about the DVI signals, see http://en.wikipedia.org. Signal Signal TMDS Data 2- (Digital red - (Link 1)) Ground (Return for pin 14 and analog sync) TMDS Data 2+ (Digital red + (Link 1)) Hot plug detect TMDS Data 2/4 shield...
Page 118: K-Sync To Sbp Interface
Kongsberg SBP 120 10.2.12 K-Sync to SBP interface This connection allows synchronisation of the Kongsberg Maritime Sub-bottom profiler systems. The cable is not included with the delivery, and must be provided by the installation shipyard. 303562/C...
Page 119 Drawings Table 11 K-Sync interface to SBP K-SYNC Junction box Terminal block Pin. no Signal / Type Pin no. Trig out+→ / TTL (External trigger) ←Ground ←CTS (RTT/blanking) ←Trig in+ / TTL ←Ground Cable specifications • Conductors: 5 x 2 x 0.5 mm² •...
Page 120: Equipment Handling
A.1 Transportation Unless otherwise stated in the accompanying documentation, electronic, electro-mechanical and mechanical units supplied by Kongsberg Maritime can be transported using all methods approved for delicate equipment; (by road, rail, air or sea). The units are to be transported in accordance with general or specific instructions for the appropriate unit(s), using pallets, transport cases, or carton boxes as appropriate.
Page 121: Storage Prior To Installation Or Use
Appendix A Equipment handling Ensure that all available lifting lugs are used. Ensure the unit remains under control during the operation to avoid damage to the unit, equipment or personnel. Heavy units may be transported using a forklift truck. Special attention must then be paid to the position of the unit’s centre of gravity.
Page 122: Inspection
If any units are damaged, prepare an inspection report stating the condition of the unit and actions taken. Describe the damage and collect photographic evidence if possible. Send the inspection report to Kongsberg Maritime as soon as possible. If the units are not damaged, check the humidity absorbing material. If required, dry or replace the bags, then re-pack the unit(s) according to the packing instructions.
Page 123: Unpacking Electronic And Electromechanical Units
Appendix A Equipment handling Check the carton before opening it to ensure it shows no signs of dropping, immersion in water or other mishandling. If the carton shows signs of such damage, refer to the paragraph covering Inspection on receipt. Place the carton on a stable work bench or on the floor with the top of the carton uppermost.
Page 124: Unpacking Transducers
Kongsberg SBP 120 A.5.4 Unpacking transducers Transducers may be supplied mounted to a hull unit (if any), or packed separately. Crates are normally identified by the order number and the serial number. The transducer face must be protected by a rigid, padded cover (e.g. a wooden box lined with foam rubber) all the time it is exposed to the risk of physical damage.
Page 125: Cleaning Cabinets
The mediums to be used will normally be defined in the unit’s maintenance manual. A.7.3 Cables Wipe clean all exposed cables, and check for damage. If a cable shows signs of wear or ageing, contact Kongsberg Maritime for advice. 303562/C...
Page 126: Internal Batteries
Kongsberg SBP 120 A.7.4 Internal batteries If the unit contains batteries, these may discharge slowly during storage. If the unit is to be stored for an extended period, disconnect or remove all internal batteries. A suitable piece of insulating material can be placed between the battery and the electrical contacts to prevent electrical discharge.
Page 127: Circuit Board Handling And Packaging
Appendix A Equipment handling Must not be transported or stored in temperatures below -5 degrees Celsius. Other units can normally be stored in temperatures between -30° C and +70° C, refer to the system’s technical specifications for details. Unless otherwise specified, transducers must not be stored in temperatures below -20° C and above +60°...
Page 128: Returning A Circuit Board
Kongsberg SBP 120 Unpacking on board the vessel When you are working on board a vessel, an “approved conductive service mat” is often far away. As you still need to unpack circuit boards, make sure that you do it in the instrument room, or at another location where you have a steel deck. Keep far away from the bridge or any other rooms with wall-to-wall carpets! If possible, bring a wristband and ground yourself.
Page 129 Appendix A Equipment handling The service personnel involved must wear a wristband in direct contact with the skin, connected to the service mat. Printed circuit boards must be placed on the conductive service mat during installation, maintenance etc. If, for any reason, it is necessary to move the circuit board from the conductive service mat, it must be placed in an approved antistatic transportation container (e.g.
Page 130: Bgeneral Safety Rules
Kongsberg SBP 120 Appendix B — General safety rules The Kongsberg SBP 120 operates on 230 Vac 50/60 Hz. WARNING This voltage is lethal! The following safety precautions must be followed at all times during installation and maintenance work • Always switch off all power before installation or maintenance. Use the main circuit breaker, and label the breaker with a warning sign that informs others that maintenance or installation work is being carried out on the system.
Page 131: Ccable Gland Assembly Procedure
Note There are many different types of cable glands on the market. This procedure describes the types used (now and previously) as standard in the units manufactured by Kongsberg Maritime. The cable glands are not supplied with the system. Even though the cabinets from Kongsberg Maritime may be prepared for specific types, the installation shipyard will be responsible for selecting types and installing them.
Page 132: General Procedure
Kongsberg SBP 120 C.1 General procedure Ensure that all the cables to be connected are completely isolated from any power sources. • That is, switch off and remove the supply fuses from any units or systems into which the cables are already connected.
Page 133: Securing And Terminating The Cables
Appendix C Cable gland assembly procedure C.2 Securing and terminating the cables Refer to the wiring diagram and ensure that there is 5 to 10 cm slack cable inside the cabinet. Prepare and connect the cable cores to the appropriate terminals within the cabinet. Secure the cable within the cabinet using cable clips.
Page 134: Multidiameter Modules
If you need help finding a proper solution that fits into your design or structure, do not hesitate to contact Kongsberg Maritime for guidance. After the frame has been mounted, the cables can be pulled through, and in most cases the opening will be large enough even to accept the plugs on the cables.
Page 135: Multidiameter Modules (Example)
Appendix C Cable gland assembly procedure Figure 36 Multidiameter modules (example) Figure 37 Multidiameter sealing system - Basic steps in the assembly 303562/C...
Page 136 Kongsberg SBP 120 Once the cables are through, each cable is secured with a square module, which is adjusted to fit the cable’s outer diameter. When the required number of modules are installed, the assembly is tightened with a compression unit.
Page 137: Multidiameter Sealing System - The Finished Assembly
Appendix C Cable gland assembly procedure Figure 38 Multidiameter sealing system - The finished assembly 303562/C...
Page 138: Standard Type
Kongsberg SBP 120 C.4 Standard type Ensure that all the cables to be connected, are completely isolated from any power sources. • Switch off and remove the supply fuses from any units or systems into which the cables are already connected.
Page 139 Appendix C Cable gland assembly procedure Take care not to damage the screening, carefully remove the outer insulation from the required cable length. Leave 12 mm of the screen exposed from the insulation, cut off the remainder. Take care not to damage the screening, slide the compression nut (smallest diameter first) over the cable and onto the intact insulation.
Page 140: Additional Type 1 (842-093878)
Kongsberg SBP 120 C.5 Additional type 1 (842-093878) Mount the body, and tighten it with the nuts on each side of the cabinet wall. Slide the metal washers, the rubber gasket and the compression nut onto the cable in the order indicated in the figure. See Additional type 1 on page 138...
Page 141: Additional Type 2 (541-093642)
Appendix C Cable gland assembly procedure C.6 Additional type 2 (541-093642) Mount the body, and tighten it with the nuts on each side of the cabinet wall. Slide the metal washers, the rubber gasket and the compression nut onto the cable in the order indicated in the figure.
Page 142: D A3 Drawings
Appendix D — A3 Drawings Dwg.no. Drawing title 215354 Interconnection diagram, cable layout, complete system 215367 Interconnection diagram, transceiver unit 861-215406 Wired cabinet subassembly TRU SBP 120, sheet 1 of 2 861-215406 Wired cabinet subassembly TRU SBP 120, sheet 2 of 2 303562/C...
Page 147 Appendix D A3 Drawings 303562/C...

Kongsberg SBP 120 Installation Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Kongsberg SBP 120

Summary of Contents for Kongsberg SBP 120

Table of Contents
