Disassembly Instructions
Remove cover 1, and remove cover 2 while keeping the touch panel cable connected.
Turn cover 2 90 degrees and place it. Then, remove the silicone mounts from the plate
and carefully pick up the PCB assembly and turn it 90 degrees.
Notice: Pay extra attention to not damage the other cables when picking up the PCB
assembly.
Silicone mount
Touch panel cable
