- Page 1 CYBERBOARD 用户使用手册 CYBERBOARD User Manual 感谢选购 Thank you for your purchase m.angrymiao.com...
-
Page 2: Table Of Contents
目录 Catalog 产品说明 Manual - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 安装流程... -
Page 3: 产品说明 Manual
产品说明 Manual... - Page 4 产品说明 Manual 表格 1 产品型号 CYBERBOARD 键盘 Product CYBERBOARD 重量 2.5（±0.1）kg，不含轴与键帽 Weight 2.5（±0.1）kg (excluding switches or keycaps) 人机角度 10° Typing Angle 10° incline LED 数量 5*40 动态点阵，200 颗灯珠 LED quantities 5*40 lamps, 200 Leds 赛博灰、工业黄、紫雾、虚白、雨林 配色方案 Cyber Grey, Industrial Yellow, Purple Haze, Vapor White, Jungle Green Color choices 定位板固定方式...
- Page 5 产品说明 Manual 表格 1 双模：无线蓝牙 5.0、有线（支持 C to C、蓝牙 5.0 只支持 Windows8.0 以上） 连接方式 Bluetooth 5.0 and USB switchable，tap the bottom switch to switch mode Connections (supports C to C,Bluetooth 5.0 only availble on Windows 8.0+) CapsLock 提示灯 提示灯位于数字 6 与 7 之间 Capslock hint The indicator light is located between the numbers 6 and 7 Fn+F12，显示电量...
- Page 6 产品说明 Manual 3mm M2 × 3.5mm+2mm M2 x 5mm M3 x M3 六角螺丝刀 x 1 M2 六角螺丝刀 x 1 M3 Hexagon Screwdriver x M2 Hexagon Screwdriver x...
-
Page 7: 安装流程 Installation
安装流程 Installation... - Page 8 安装流程 Installation 1. 卸下后盖的螺丝 1. Remove the screws of the back...
- Page 9 安装流程 Installation 2. 注意：打开方向，避免扯坏排线 2. Note: please make sure open from the bottom to avoid damaging the cables 排线 排线 FPC Cable...
- Page 10 安装流程 Installation 3. 分别移除排线、RF 线连接，并拧开螺丝 3. Remove the FPC cables and RF cables, and loosen the screws S 排线底座 FPC Connector RF 线插座 RF Connector...
- Page 11 安装流程 Installation 4. 取出 PCB 板等组件 4. Take out the PCB sets...
- Page 12 安装流程 Installation 5. 移除 PCB 板上的螺丝（3mm M2） 5. Remove the screws (3mm M2) on the PCB...
- Page 13 安装流程 Installation 6. 取下 PCB 板 6. Remove the PCB...
- Page 14 安装流程 Installation 7. 安装卫星轴至 PCB 板 7. Install the stabilizers in the PCB...
- Page 15 安装流程 Installation 8. 将 PCB、硅胶减震垫以及定位板按顺序组装好。 注意：区分硅胶垫以及定位板的正反面，正面有 logo 8. Assemble the PCB, silicone mute mount and plate in order Note: please make sure to put on the front side (with logo) of the silicone mute mount and the plate PCB 硅胶垫 silicone mute mount 硅胶垫...
- Page 16 安装流程 Installation 9. 安装轴体 注意：勿暴力安装，以防定位板变形，压坏主板;注意将轴体的轴脚引直，避免歪脚 9. Install the switches Note: Please install it carefully to prevent deforming the plate or crushing the PCB...
- Page 17 安装流程 Installation 10. 将 PCB 安装到上盖，锁好螺丝并连接好排线 注意：排线正反面 10. Install the PCB to the upper cover, lock the screws and connect the cables Note: Please make sure you connect to the right side.
- Page 18 安装流程 Installation 11. 合上后盖 注意：盒盖方向，避免扯坏排线 11. Close the back cover Note: Closing the the back cover in the wrong direction could damage the cables...
- Page 19 安装流程 Installation 12. 锁上后盖的螺丝，完成组装 12. Lock the screws from the back cover and complete the installation...
-
Page 20: 快捷键示意 Shortcut Keys
快捷键示意 Shortcut keys... - Page 21 快捷键示意 Shortcut keys 1. 多媒体组合键 1. Media Keys 表格 1 静音 Fn+F1 Mutes system sound 减小音量 Fn+F2 Lowers system volume 增大音量 Fn+F3 Increases system volume 上一首 Fn+F4 Back to previous song 下一首 Fn+F5 Goes to next song 播放/暂停 Fn+F6 Play/Pause 长按...
- Page 22 快捷键示意 Shortcut keys 2. LED控制组合键 2. LED Control 表格 1 LED 模式切换 Fn+F12 Switch the LED effects 开熄屏 Fn+F10 On/off LED display Fn+方向键↑ 增加亮度 Fn+Up arrow↑ Increase brightness Fn+方向键↓ 降低亮度 Fn+Down arrow↑ Decrease brightness...
- Page 23 快捷键示意 Shortcut keys 3. 蓝牙连接 3. Bluetooth connection 表格 1 蓝牙模式下切换设备 1，长按 5 秒直到 LED 图标 闪烁，配对成功 Fn+1 后停止闪烁，LED 恢复之前的显示模式 Switch to device 1 in Bluetooth mode, press and hold for 5 seconds until the LED icon starts blinking. The icon will stop flashing if the device paired successfully, and the panel will resumes its previous display 蓝牙模式下切换设备...
- Page 24 快捷键示意 Shortcut keys 3. 蓝牙连接 3. Bluetooth connection 表格 1 按 Fn+1/2/3 可在不同设备间切换，图标提示 5 秒后，LED 恢复之前的显示模式 设备切换 Press Fn+1/2/3 to switch between different connected devices. 5 seconds after Switching the device the icon appears, and the panel will resumes its previous display 待机...
-
Page 25: 灯效配置 How To Edit Lighting Effects
灯效配置 How to edit lighting effects... - Page 26 3. Download the Angry Miao loader (windows program) from diy.angrymiao.com. And keep the CYBERBOARD connected to th computer via USB. 4. 双击打开怒喵加载器，选择下载的 PROFILE.json 文件导入（可以直接使用他人分享的配置文件）。 4. Double-click to open the Angry Miao loader, select your config file and import (you can directly use the config file shared by others). 5. 等待生效即可。...
-
Page 27: 防伪须知 Anti-Counterfeiting Notice
防伪须知 Anti-counterfeiting... - Page 28 请注意，您从官方渠道购买的 CYBERBOARD 产品，都可以通过输入产品背盖处的防伪码，在 https://verify.angrymiao.com 进行防伪注册。每个防伪码都是唯一的，且仅可以验证对应的一件商品。 Please note that all the CYBERBOARD products that you purchased from official channels can be registered at https://verify.angrymiao.com by entering the security code on the back of the product. Each anti-counterfeiting code is unique and can only verify the corresponding item.
-
Page 29: 售后服务After-Sales Service
售后服务 After-sales service... - Page 30 售后服务 售后服务 After-sales service 3NtMY&sITMs sMYvQcM 售后服务细则 售后服务细则j 以下售后条款适用于中国大d地区用户 a换货注U事e 我们每件产品都是经过w格品控以保障质量l如遇质量问题pfffi损坏请立即联系我们l在收货之日起7日内可以申请退货l )-天内可以申请换货nx人定制产品除外o。j 以t情况u在退换货服务内kj )'超过规定退换货时效j *'非产品质量问题的人z损坏j 3'产品原始包装已被拆除l影响~次销售j 保I注U事e 当你购买的产品出现非人z损坏故障时l我们提供相应维修服务l请您提供相应购买凭证并在保修期限内联系我们m保修期限 自签收之日起开始计算l对应产品保修期限如tkj cybMYUIt 我们提供主机)年保修服务l如涉及更换配件或耗材需要付费。 Cybermat 以下T况C在保I范O内： )' 因用户使用u当p保管u妥善导致的损坏j *' 无法提供相应的购买凭证j 3' 未经授权私自维修过的产品j ,' 因u可抗拒因素n如雷电p地震p火灾等o造成的损坏...
- Page 31 After-sales service 免责声明 Disclaimer 1. 非官方渠道购买的相关产品，我方不提供售后且不承担由此产生的交易风险 1. For related products purchased through NON offical channels, we do not provide corresponding after-sales service and do not bear the transaction risk arising there from 2. 我方保留对本售后服务细则的最终解释权及修订权 2. All rights reserved by Angry Miao...
- Page 32 售后服务 After-sales service Return & Refund Policy The following terms apply to regions outside of mainland China. Our policy lasts 72 hours. If the time is due, unfortunately we can't offer you a refund or exchange. There are certain situations we can't offer you a refund or exchange. •...
