switching
cost-effective
S
mall and medium businesses (SMBs) are faced with different challenges to larger
enterprises. When it comes to networking equipment, you are looking for:
• Minimal time for set-up
• Plug-and-play capability
• Opportunities to improve employee productivity
• Potential for gaining competitive advantage
• Ability to save money
Nortel Networks BayStack* 325 Switches are designed to address the needs of small and
medium customers. The switches help save money by allowing devices to be connected at
either 10 Mbps or 100 Mbps without needing newer switches to accommodate different
speeds. In addition, the switches provide small and medium businesses with the comfort of
knowing that their investment is protected with free new feature upgrades for the life of the
switches. Easy Web-based management features will save customers significant time in
setting up the switches. Also, the switches' ease of use features require minimal technical
expertise to configure them.
BayStack 325 Switches are standalone 10/100 Mbps Layer 2 Ethernet switches featuring
easy configuration, high-speed uplinks, and Web-based management from your Web
browser. The BayStack 325 Switches have been architected to be Layer 3 and DiffServ
capable via a software upgrade in the future.

Product Brief

Nortel Networks
BayStack 325 Switches
• Cost-effective desktop switching
for small and medium enterprises
and branch offices
• Easy to use
• Uplink connectivity for server or
backbone connections
• Easy Web-based management
• 1U high compact design with low
power consumption

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BayStack 325-24G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nortel BayStack 325-24G

Summary of Contents for Nortel BayStack 325-24G

  • Page 1: Product Brief

    • Potential for gaining competitive advantage • Ability to save money Nortel Networks BayStack* 325 Switches are designed to address the needs of small and medium customers. The switches help save money by allowing devices to be connected at either 10 Mbps or 100 Mbps without needing newer switches to accommodate different speeds.

  • Page 2: Features And Benefits

    • Easy set-up The BayStack 325 Switches are available in two standalone, compact 1 rack-unit (1U) size models—the BayStack 325-24T Switch (Figure 1) and the BayStack 325-24G Switch (Figure 2). The BayStack 325-24T Switch has 24 10BASE-T/100BASE-TX auto-sensing ports. The BayStack 325-24G Switch has 24 10BASE-T/100BASE-TX auto-sensing ports plus 2 10/100/1000BASE-T ports for uplink connectivity to servers or backbone switches.

  • Page 3: Multi-Link Trunking

    Multi-Link Trunking (MLT) enables grouping of links between a BayStack 325 Switch and another switch or a server to provide greater bandwidth with active redundant links (Figure 4). The BayStack 325 Switches support up to six MLTs per switch with up to four ports per MLT. VLAN support Up to 32 port-based VLANs can be established on a BayStack 325 Switch, to extend the broadcast domain and segment network traffic for higher network efficiency.

  • Page 4: Network Management

    For example, if messages from a specific segment are crucial to the network, the switch port connected to that segment can be set to a higher priority level. Up to four queues can be set on a BayStack 325 Switch with IEEE 802.1p.

  • Page 5: Advanced Management Features

    Protocol (SNMPv3), MAC-address based security, and RADIUS authentication. SSHv2 supports strong authentication and encrypted communications. It allows you to log into the switch from an SSH client and perform a secure Telnet session using CLI commands. This feature is ideal for security-conscious customers such as federal governments.
  • Page 6 Why take a chance on a vendor that only understands part of the equation? Let us show you how the BayStack 325 Switches, along with other Nortel Networks products, can increase your profitability, streamline your business operations, increase productivity, and help you...

  • Page 7: Technical Specifications

    Width: 43.82 cm (17.25 in) Depth: 22.91 cm (9.02 in) Performance Switch fabric bandwidth Frame forwarding rate BayStack 325-24T BayStack 325-24G Switched 10 Mbps forwarding rate Switched 100 Mbps forwarding rate Switched 1000 Mbps forwarding rate Memory Address database size...

  • Page 8: Electromagnetic Immunity

    Research Triangle Park, NC 27709 USA Networks, Wireline Networks, Enterprise Networks, and Optical Networks. As a global company, Nortel Networks does business in more than 150 countries. More information about Nortel Networks can be found on the Web at: In Canada: Nortel Networks www.nortelnetworks.com...
