- Page 1 Manual for 485 total solar radiation sensor JXBS-3001-ZFS Ver1.1...
-
Page 3: Chapter 1 Product Introduction
Chapter 1 Product Introduction 1.1 Product overview JXBS-3001-ZFS Total Solar Radiation Sensor (Transmitter) is a sensor that can measure total solar radiation with a spectral range of 0.3-3μm. If the sensing surface is facing downwards, it can measure reflected radiation, and a light-shielding ring can also measure scattering radiation. - Page 4 PLC can be programmed through the modbus protocol specified later to cooperate with the sensor. use simultaneously USB to 485 can be connected to the computer, use the sensor configuration tool provided by our company to configure and test.
- Page 5 (See Appendix). In theory, one bus can connect more than 16 485 sensors If you need to connect more 485 sensors, you can use a 485 repeater to expand Charge more 485 devices, connect the other end to the PLC with 485...
- Page 6 一站式物联网供应平...
-
Page 7: Chapter 2 Hardware Connection
1 set （Optional） 1 serving Warranty card/certificate Wide voltage power input is 12-24V. Note when wiring the 485 signal line The two wires A/B cannot be reversed, and the addresses of multiple set devices on the bus cannot be conflicted... - Page 8 Thread color Description power supply brown Power is positive （12-24V DC） black Power negative 485-A Communication Yellow (gray) color 485-B blue Note: Please be careful not to connect the wrong wiring sequence, the wrong wiring will cause the equipment to burn.
-
Page 9: Chapter 3 Configuration Software Installation And Use
2.3 Product size and installation instructions (1) Ensure that the mounting bracket is parallel to the ground; (2) Use M6 screws and nuts to fix the sensor on the cross arm through the 2 mounting holes on the sensor; (3) Please avoid disassembling the sensor during installation. - Page 10 3.1 Connect the sensor to the computer After the sensor is correctly connected to the computer via USB to 485 and supplied with power, you can see the correct COM port ("My Computer—Properties" —Device Manager — Port” to view the COM port).
- Page 11 3.1, and then click to automatically obtain the current baud rate and address to automatically detect all devices and baud rates on the current 485 bus . please Note that you need to ensure that there is only one sensor on the...
- Page 12 一站式物联网供应平 Then click to connect the device to get the sensor data information in real time. If your device is a gas concentration sensor, please specify the sensor type Select "gas concentration sensor", formaldehyde sensor select "formaldehyde transmitter", analog transmitter select "analog transmitter module", atmospheric pressure sensor select "Atmospheric pressure sensor", illuminance sensor selects...
- Page 13 then "automatically obtain the current baud rate and address" to find the address And the baud rate has been changed to the address and baud rate you need. If you need to use modbus command to modify baud rate and address, you can refer to the appendix "How to use modbus command to modify baud rate and address"...
-
Page 14: Chapter 4 Communication Protocol
一站式物联网供应平 Chapter 4 Communication Protocol 4.1 Basic communication parameters parameter content 8-bit binary coding 8-bit Data bit Parity bit Stop bit 1-bit CRC lengthy cyclic code Wrong calibration 2400bps/4800bps/9600bps can be set ,the factory Baud rate default is 9600bps 4.1 Data frame format definition Adopt Modbus-RTU communication protocol, the format is as follows: Initial structure ≥... - Page 15 Interrogation frame Check Register High bit Regist code low start of proof Address code address code length Features 1 byte 1 byte 2 byte 2 byte 1 byte Reply frame address Features Valid First to the Code byte number distrit According to Second Code...
- Page 16 一站式物联网供应平 0x00 0x00 0x01 0x03 0x84 0x0A 0x00 0x01 Response frame (for example, the total solar radiation value is 71 W/m2) addr Returns the Check Check functio Data number of code code n code area code valid bytes high 0x00 0x01 0x03 0x02...
-
Page 18: Chapter 5 Appendix
"Revision of temperature and humidity deviation of 485 sensor": Describes how to confirm and adjust temperature and humidity deviation when you feel that there is a deviation in temperature and humidity. - Page 19 How to calculate CRC16 and an example C language program. "How to use USB to 485 auxiliary debugging when reading sensor communication has problems": describes how to use auxiliary tools to solve and troubleshoot when there are communication problems. "How to use and set the product alarm function": Describes the Optional product alarm function, how to use it, how to wire and other issues.
- Page 20 一站式物联网供应平...
