uhlmann & zacher CX8936 Operating And Installation Instructions

Online module with bluetooth low energy
Hide thumbs Also See for CX8936:

Advertisement

Quick Links

CX8936
Online module with
®
Bluetooth
Low Energy
Operating and
installation instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX8936 and is the answer not in the manual?

Questions and answers

Summary of Contents for uhlmann & zacher CX8936

  • Page 1 CX8936 Online module with ® Bluetooth Low Energy Operating and installation instructions...
  • Page 2 CX8936 ABLE OF CONTENTS Legal Notice Operating and installation instructions (original language) CX8936 Online module with Bluetooth Low Energy ® Document number: 1519 Version: 1.2 Date: 13.02.2023 Manufacturer Uhlmann & Zacher GmbH Gutenbergstraße 2–4 97297 Waldbüttelbrunn Germany Tel.: +49 931 40672-0 Email: contact@UundZ.de...
  • Page 3: Table Of Contents

    CX8936 ABLE OF CONTENTS Table of contents About this document ................ 3 Warnings .................... 3 Symbols ....................3 Safety .................... 4 Proper use ..................4 Improper use ..................4 General safety information ..............4 Product description ................5 Functional description ................5 Layout and scope of delivery ..............
  • Page 4: About This Document

    Low Energy. They are part of the product and contain important ® information required for correct operation and maintenance. These operating and installation instructions apply for all versions of the CX8936 and are intended both for specialist personnel responsible for assembly and dis- assembly and for end customers.
  • Page 5: Safety

    CX8936 AFETY Safety Proper use The product is intended for use solely with Bluetooth ® -capable devices. It is de- termined for use in the system Clex public and can be operated with locking units from other systems by Uhlmann & Zacher.
  • Page 6: Product Description

    CX8936 RODUCT DESCRIPTION Product description Functional description The online module in Clex public system is the interface (2.4 GHz) between the Uhlmann & Zacher products and a third-party system. From the third-party system you can, for example, read transponder data or control Clex locking units via the online module.
  • Page 7: Versions

    CX8936 RODUCT DESCRIPTION Versions Configuration versions:  For RS485 and Clex public protocol (phg_crypt)  For RS485 and OSDP  For Wiegand/clock data Housing versions:  Housing in grey  Oval housing in white  Rectangular housing in white Technical data 3.4.1...
  • Page 8: Dimensions

    CX8936 RODUCT DESCRIPTION Dimensions Grey housing...
  • Page 9 CX8936 RODUCT DESCRIPTION White oval housing...
  • Page 10 CX8936 RODUCT DESCRIPTION White rectangular housing...
  • Page 11: Installation

    CX8936 NSTALLATION Installation General installation information  The valid national regulations for electronic installations (e.g. VDE regulations) must be observed.  The connecting cables must be available and laid.  Only operate the device at the correct operating voltage. ...
  • Page 12: Pin Assignment

    CX8936 NSTALLATION Pin assignment Contact number Pin assignment + power supply 5-24 VDC – power supply (ground) Input ground (together with pin 6/7/8 insulated against ground connection) (not used) Wiegand 0 Wiegand 1 6+7+8 Input (potential 5-24 V) (not used)
  • Page 13: Commissioning And Operation

    CX8936 OMMISSIONING AND OPERATION Commissioning and operation Connecting locking units To connect a locking unit with the online module, you have to perform the follow- ing steps: Bring the locking unit which you want to connect into the service mode by ...
  • Page 14: Configuring The Online Module

    CX8936 OMMISSIONING AND OPERATION Configuring the online module The configuration of the online mode normally takes place through the connected third-party system and the corresponding function of the respective protocols. Individual parameters of the online module can also be set directly via a BLE connection or bus commands in the service mode.
  • Page 15: Resetting The Configuration (Factory Reset)

    CX8936 OMMISSIONING AND OPERATION Resetting the configuration (factory reset) If you want to reset all the settings, proceed as follows: Use a screwdriver or a similar tool to turn the rotary switch (6) so that the arrow- head points to Position 9. Briefly press the button (7) to delete all the saved lock- ing units and parameters.
  • Page 16: Maintenance And Cleaning

    CX8936 AINTENANCE AND CLEANING Maintenance and cleaning Maintenance Since the device is not protected specially against dust, the product should be checked regularly for dust deposits. The frequency depends on the dust level at the operation site. Cleaning Clean the housing with a soft, lint-free and only slightly moistened cloth. When cleaning do not use corrosive liquids or liquids that decompose plastic such as benzine, turpentine, etc.
  • Page 17: Disassembly And Disposal

    CX8936 ISASSEMBLY AND DISPOSAL Disassembly and disposal Disassembly Disposal Do not dispose of the device with household waste, but at a municipal col-  lection point for special electrical waste in accordance with European Di- rective 2002/96/EC. Dispose of packaging as environmentally friendly recycling.
  • Page 18: Glossary

    CX8936 LOSSARY Glossary Term Meaning Bluetooth ® Low Energy German "Verband der Elektrotechnik" [Registered Asso- ciation of the Electrical, Electronic and Information Technology] phg_crypt Standard protocol of the company phg Peter Hengstler GmbH + Co. KG, Deißlingen in Germany...
