Corrective maintenance
·
Coin verifier replacement
·
Card reader replacement
·
·
Keyboard replacement
·
Cabinet & pedestal
·

CPU board lithium cell replacement

8.1

Lead battery replacement

For replacement of the on-board battery see
Replacing the battery
To replace the battery, follow the steps below:
1. Shut down the external power supply if any.
2. Lift out the battery from the pedestal. Be careful to not short-cut the contacts.
3. Unscrew the cable.
4. Connect the cable to the new battery. Make sure the red wire is connected to
the [+] pole
5. Place the new battery in the pedestal
6. reconnect the external power
8.2 CPU board lithium cell replacement
Warning:
Lithium batteries can be dangerous because they can explode if short-circuited.
Handle batteries according to local laws and regulations.
Removal
Carefully lift the battery holder tongue a little when you remove the battery cell.
Warning:
Avoid using conductive objects due to the risk of short circuiting the battery.
Issue 3 CWT Compact S4 Touch Installation & Maintenance Manual for CWT 1.0-0
77
78
81
75
Batteries
65
Page 75
