Installation Guide
ROQSTAR
Gigabit Ethernet Switch
Part No.
Description
006-130-105
ROQSTAR Unmanaged 8 Port Gigabit Ethernet Switch M12
006-130-110
ROQSTAR Unmanaged 8 Port Gigabit Ethernet Switch M12 PoE
006-130-130
ROQSTAR Unmanaged 10 Port Gigabit Ethernet Switch M12
006-130-131
ROQSTAR Unmanaged 10 Port Gigabit Ethernet Switch M12 PoE
006-130-132
ROQSTAR Managed 10 Port Gigabit Ethernet Switch M12
006-130-133
ROQSTAR Managed 10 Port Gigabit Ethernet Switch M12 PoE
Installation Guide
ROQSTAR Gigabit Ethernet Switch
2022-08-24 EN
Page 1 of 20
Advertisement
Table of Contents
Related Manuals for TRONTEQ ROQSTAR
Summary of Contents for TRONTEQ ROQSTAR
- Page 1 Part No. Description 006-130-105 ROQSTAR Unmanaged 8 Port Gigabit Ethernet Switch M12 006-130-110 ROQSTAR Unmanaged 8 Port Gigabit Ethernet Switch M12 PoE 006-130-130 ROQSTAR Unmanaged 10 Port Gigabit Ethernet Switch M12 006-130-131 ROQSTAR Unmanaged 10 Port Gigabit Ethernet Switch M12 PoE...
- Page 2 © 2022 TRONTEQ GmbH All rights are reserved. The contents of this manual are protected by copyright. Their use is allowed as part of use of TRONTEQ GmbH products. Any other use which goes beyond in particular copying, reproduction, translation requires written consent of TRONTEQ GmbH.
-
Page 3: Table Of Contents
1.2. Warning information system......................4 1.3. Qualified Personnel........................5 1.4. Intended use..........................5 1.5. Liability Limitation......................... 5 1.6. Recycling............................. 5 2. ROQSTAR Gigabit Ethernet Switch....................6 2.1. Unmanaged Models........................7 2.2. Managed Models.......................... 8 2.3. Interfaces............................. 9 2.4. Interfaces PoE model......................... 10 3. -
Page 4: Safety Instructions
1.1. Information about this operation instructions This operating instruction describes the application of the ROQSTAR Ethernet Switches. It allows the safe and efficient handling of the product. The operating instruction is a part of the device and must be available for the users at any time. -
Page 5: Qualified Personnel
Intended use Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that TRONTEQ products operate safely and without any problems. The permissible ambient conditions must be complied with. The information in the relevant documentation must be observed. -
Page 6: Roqstar Gigabit Ethernet Switch
ROQSTAR PoE Power over Ethernet (PoE) makes it possible to provide power supply through data cable to the devices, that are connected to the Ethernet Switch. All ROQSTAR PoE devices have an integrated, isolated 24V power supply for PoE. ROQSTAR Gigabit Devices with Gigabit Ethernet ports allow a data rate of up to 1000 Mbps. -
Page 7: Unmanaged Models
PoE Voltage / Total Power Budget 53V / 62W 53V / 62W Boot time < 2s < 2s < 2s < 2s • • • • auto negotiation, auto polarity, auto crossing Installation Guide 2022-08-24 EN ROQSTAR Gigabit Ethernet Switch Page 7 of 20... -
Page 8: Managed Models
USB Interface for configuration and updates • • Configuration via User Web Interface QoS, VLAN, SNMP, LLDP, RSTP, DHCP • • sever/client, Port based DHCP, Port Mirroring, broadcast storm protection Installation Guide 2022-08-24 EN ROQSTAR Gigabit Ethernet Switch Page 8 of 20... -
Page 9: Interfaces
2.3. Interfaces Description Description mounting holes port LEDs model label Gigabit Ethernet ports status LED ground connection power port USB port model name Installation Guide 2022-08-24 EN ROQSTAR Gigabit Ethernet Switch Page 9 of 20... -
Page 10: Interfaces Poe Model
2.4. Interfaces PoE model Description Description mounting holes port LEDs model label Gigabit PoE ports status LED Gigabit Ethernet ports power port ground connection model name USB port Installation Guide 2022-08-24 EN ROQSTAR Gigabit Ethernet Switch Page 10 of 20... -
Page 11: Installation
► Connect and fasten all cables Recommended torque: ► ground bolt M6: min. 1Nm / max. 3Nm ► M12 cables: min. 0.6Nm / max. 0.8Nm ► protection caps: 0.6Nm Installation Guide 2022-08-24 EN ROQSTAR Gigabit Ethernet Switch Page 11 of 20... -
Page 12: Power Port
3.2. Power Port The ROQSTAR device provides two redundant power ports. For Ethernet Switch function apply power supply to V1 or V2. For PoE function the power supply must be applied to V1. The power supply for PoE function is V1 only... -
Page 13: Startup Unmanaged Model
Startup Unmanaged Model An unmanaged ROQSTAR model starting immediate to operate after a valid supply voltage is being applied. 4.1. PoE Operation Unmanaged Model All combinations of PoE Classes according total power budget are supported. In case the total power budget is reached, no other PD devices will be supplied. -
Page 14: Leds
PoE supply is inactive, peripheral device is not powered orange PoE supply is active, peripheral device is powered orange flashing PoE port is blocked, peripheral device is not powered orange all ports flashing Internal PoE error Installation Guide 2022-08-24 EN ROQSTAR Gigabit Ethernet Switch Page 14 of 20... -
Page 15: Technical Data
Dimension Ethernet Port ↔ Ethernet Port Ethernet Ports (PoE) ↔ Power Port ± 2250 Ethernet Ports ↔ Chassis (ground) ± 2250 Chassis (ground) ↔ Power Port ± 850 Installation Guide 2022-08-24 EN ROQSTAR Gigabit Ethernet Switch Page 15 of 20... -
Page 16: Data Transfer
Dimensions (H x B x T, ± 0.5 mm) 121 x 175 x 52 Mass standard type, net Mass PoE type, net Protection Class IP54 Mounting 4x 4.8mm (Diameter) Installation Guide 2022-08-24 EN ROQSTAR Gigabit Ethernet Switch Page 16 of 20... -
Page 17: Environmental
► EN61000-4-3 ► EN61000-4-4 ► EN61000-4-5 ► EN61000-4-6 ► Specific applications: ► EN50155 ► EN50121-4 ► EN61131-2 ► UNECE (E1) R10 ► UNECE (E1) R118 ► ITxPT Label Installation Guide 2022-08-24 EN ROQSTAR Gigabit Ethernet Switch Page 17 of 20... -
Page 18: Wiring Diagrams
8.2. Power cable ITxPT Accessories 006-000-009, -010, -011 M12 a-coded, female wiring TE 8-968970-1 female 8.3. USB Adaptor Accessory 006-000-007 M12 a-coded, male wiring USB2.0 type A, female Installation Guide 2022-08-24 EN ROQSTAR Gigabit Ethernet Switch Page 18 of 20... -
Page 19: Order Numbers
Order no. Description 006-130-105 ROQSTAR Unmanaged 8 Port Gigabit Ethernet Switch M12 006-130-110 ROQSTAR Unmanaged 8 Port Gigabit Ethernet Switch M12 PoE 006-130-130 ROQSTAR Unmanaged 10 Port Gigabit Ethernet Switch M12 006-130-131 ROQSTAR Unmanaged 10 Port Gigabit Ethernet Switch M12 PoE... -
Page 20: 10. Contact
Please contact our sales team at sales@tronteq.com for further inquiries and questions regarding our products. 10.2. Technical support Please contact our support team at support@tronteq.com if you have any technical questions or if you need technical training. TRONTEQ GmbH HOELZLESTR. 3...
