After removing fuse panel cover, find a fuse that powers on when engine
- 1
is turned on (ex. cigarette lighter socket, audio, etc) and another fuse that
remains powered on after the engine is turned off (ex. hazard light, interior
light). Connect the ACC+ cable to a fuse that powers on after engine
start (Front camera hardwiring cable (3p)) and BATT+ cable to a fuse that
remains powered on after engine is turned off (Front camera hardwiring
cable (3p) + DMS camera hardwiring cable (2p)).
Front camera hardwiring cable (3p)
Connect the GND cable to metal ground bolt (Front camera hardwiring
- 2
cable (3p) + DMS camera hardwiring cable (2p)).
Connect the power cable to the DC in terminal of the front and DMS
cameras. BlackVue will power up and start recording. Video files are stored
on the microSD card.
Note
y When you run the dashcam for the first time the firmware is automatically loaded
onto the microSD card. After the firmware has been loaded onto the microSD card
you can customize settings using BlackVue Viewer on a computer.
y To record in parking mode while the engine is off, connect the Hardwiring
Power Cable (included in the box) or install a Power Magic Battery Pack (sold
separately). A Hardwiring Power cable uses the automotive battery to power
your dashcam when the engine is off. A low voltage power cut-off function and a
parking mode timer to protect the automotive battery from discharge is installed
in the device. Settings can be changed in the BlackVue App or Viewer.
DMS camera hardwiring cable (2p)
