- Page 1 EG8040F5 Quick Start Issue Date 2019-09-10 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: Table Of Contents
EG8040F5 Quick Start Contents Contents 1 Placing the Device......................... 1 2 Connecting Cables.........................3 3 Indicator Description........................5 4 Technical Specifications.......................6 5 FAQs..............................7 Issue 02 (2019-09-10) Copyright © Huawei Technologies Co., Ltd. -
Page 4: Placing The Device
The figure below shows an ONT that is horizontally placed on a desk. NOTE The appearance shown in this document may be different from the actual appearance of the product. The actual product prevails. Issue 02 (2019-09-10) Copyright © Huawei Technologies Co., Ltd. - Page 5 Use a screwdriver to fasten the screws into the expansion bolts, reserving 5 mm ends out of the wall, and mount the ONT onto the screws. NOTE It is recommended that the screw be about 4 mm in diameter and longer than 20 mm. Issue 02 (2019-09-10) Copyright © Huawei Technologies Co., Ltd.
-
Page 6: Connecting Cables
The fiber connector connected to the optical port on the wall varies depending on actual conditions. l To ensure normal use of fibers, make sure that the fiber bending radius is larger than 30 mm. Issue 02 (2019-09-10) Copyright © Huawei Technologies Co., Ltd. - Page 7 (longer than 10s) to restore the device to the default settings and reset the device. NOTE Reset Huawei ONTs with caution. Otherwise, the ONTs may fail to access the Internet. If an ONT cannot access the Internet after a reset, contact your Internet service provider.
-
Page 8: Indicator Description
The optical power is lower than the receiver sensitivity. Internet Steady blue The Internet access service is normal. The system is not powered on or the Internet access service has not taken effect. Issue 02 (2019-09-10) Copyright © Huawei Technologies Co., Ltd. -
Page 9: Technical Specifications
System power supply: See the nameplate on the device. Ambient temperature: 0ºC to +40ºC Ambient humidity: 5%–95% (non-condensing) Dimensions (H x W x D): 145mm x 97mm x 32 mm Weight: About 140g Maximum system power consumption: 5 W Issue 02 (2019-09-10) Copyright © Huawei Technologies Co., Ltd. -
Page 10: Faqs
Use a network cable to connect a PC to the Huawei ONT. Set the IP address of the PC in the same subnet as the web address of the Huawei ONT. For example, if the web address of the Huawei ONT is 192.168.100.1 (for the web address of the Huawei ONT, see the product nameplate), set the IP address of the PC to 192.168.100.100. - Page 11 How do I restore the Huawei ONT to factory setting? Press Reset by using a needle-type object for longer than 10s to restore factory defaults and reset the Huawei ONT. If the indicator is off and then is lit, the system restarts successfully. NOTE Exercise caution when restoring factory settings.
- Page 12 Use another PC to check whether the network speed is normal. How can I download Huawei ONT firmware or ONT software? Huawei ONT is used with an OLT and NMS of a required version. If the versions are not the required ones, the ONT may not work.
