Tennsco Z-Line Installation Instructions

Congratulations on your purchase of Z-
Line Heavy Duty Boltless Rack from
Tennsco! Z-Line's interlocking keyhole
design not only makes installation fast
and easy but eliminates the need for
clips, gussets, sway braces or other
hardware commonly used in conventional
shelving. This allows completely free
access to your stored materials from all
sides of the unit.
Z-Line Boltless Rack is available in both
standard- and heavy-duty strengths, in a
variety of heights, widths and depths, to
fit virtually any storage application.
Adding an extra shelf is quick and easy.
And starter and adder units allow for
joining shelving units together.
SHELF LOAD CAPACITIES*
Unit Recommended
Width Deck Supports
48" 1
60" 1
72" 2
84" 3
96" 3
* Total weight capacity not to exceed 13,000 lbs. per unit (3,250 per post)
for SUR posts. Total weight capacity not to exceed 11,000 lbs. per unit
(5,500 lbs. per post) for ZTP posts.
Tennsco warrants goods purchased hereunder to be free of defects in materials and workmanship for a period of one (1) year from the date of shipment,
hereunder. This warranty shall not apply in the event goods are damaged as a result of misuse, abuse, neglect, accident, improper application, modification
or repair by persons not authorized by Seller, where goods are damaged during shipment, or where the date stamps on the goods have been defaced, modified
or removed. UNLESS CONSIDERED UNENFORCEABLE OR UNLAWFUL UNDER APPLICABLE LAW:
a. ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE HEREBY EXCLUDED:
b. BUYERS REMEDY, IF ANY, FOR ANY DEFECTIVE GOODS SHALL BE LIMITED TO A REFUND BY SELLER OR REPLACEMENT OF THE GOODS
AT SELLER'S OPTION, AND SHALL IN NO EVENT INCLUDE DAMAGES OF ANY KIND, WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE.
NO GOODS ACCEPTED FOR RETURN WITHOUT PRIOR APPROVAL. Seller shall have the right to inspect any goods claimed to be defective at Buyers place
of business or require Buyer to return the goods to Seller for inspection on Seller's premises. Transportation charges covering returned goods will be borne
by Seller only if such goods are proven to be defective, are covered by this warranty and are returned within the warranty period stated above.
ASSEMBLY INSTRUCTIONS & PARTS MANUAL #1940912
Z-Line Heavy Duty Boltless Rack
Installation Instructions
Tennsco Corp., Dickson, TN 37056-1888 • (615) 446-8000
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE!
Load Capacity,
With Deck Supports
2500 lbs.
2250 lbs.
2000 lbs.
1750 lbs.
1600 lbs.
TENNSCO CORP., P.O. BOX 1888, DICKSON, TN 37056-1888
(615) 446-8000 (800) 251-8184
GENERAL SAFETY INFORMATION
Some parts may have sharp edges. CARE must be
taken when handling the pieces to avoid injury. For
safety, wear a pair of work gloves when assembling or
performing any maintenance on shelving.
LIMITED WARRANTY
PK-1940912
