Dimplex DHMH20C Instruction Manual page 6

Assembly
Castor and Feet Assembly
1. Assemble the castors.
2. Fix the castors into the base of the feet.
3. Fix the feet into the base of the unit, by removing the screws on the base and
screwing back in through the holes of the feet.
Wall Installation
1. To install the unit on a wall, please ensure to remove the feet and castors. Ensure
there is 30cm of space between each side of the unit in the intended mount
location.
2. Mark two dots on the wall and use the plastic plaque to ensure the distance
between the holes meets the requirements as per below (13.5cm).
3. Drill two holes in the wall with a distance of 135mm from each other, and ensure
the diameter of each hole is 6mm, and the depth is 30mm.
6
