Page 1 Explosion Protection Technical Information TI 33Q01J30-01E Yokogawa Electric Corporation TI 33Q01J30-01E 2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan ©Copyright May 2004 (YK) 37th Edition Nov. 2022 (YK)
Page 2: Introduction
Introduction This book describes explosion protection compliance of CENTUM 3000 and CENTUM VP (hereinafter CENTUM.) Some parts of this book will occupy the general explanation about explosion protections, but it mainly explains what explosion protection complied with CENTUM which is an integrated production control system, and what regulation it has. The product explanation after standard maintenance phase start is leave for safety.
Page 3: Safety Precautions
• If any protection or safety circuit is required for the system controlled by the product or for the product itself, prepare it separately. • Be sure to use the spare parts approved by YOKOGAWA when replacing parts or consumables.
Page 4  Symbols in this Book This book has the following symbols. WARNING Indicates precautions to avoid a danger that may lead to death or severe injury. CAUTION Indicates precautions to avoid a danger that may lead to minor or moderate injury or property damage. IMPORTANT Identifies important information required to understand the operations or functions.
Page 5  Cautions for Safely Applying the Device Power Supply Wiring  WARNING The connection of power cables and the selection of power cables must be done in accordance with this book and the Installation Guidance, and implement so as to comply with the standards and laws about explosion protection in the country or the area where the cables are laid. Ground Wiring ...
Page 6: Trademarks
Some drawings depicted in the user’s manual may be partially emphasized, simplified, or omitted for the convenience of description. Trademarks Trademark Acknowledgment  The names of corporations, organizations, products and logos herein are either registered trademarks or trademarks of Yokogawa Electric Corporation and their respective holders. TI 33Q01J30-01E Dec. 3, 2021-00...
Page 7: Table Of Contents
Toc-1 CENTUM Explosion Protection TI 33Q01J30-01E 37th Edition CONTENTS Introduction ......................i Safety Precautions ....................ii Trademarks ......................v Overview of Explosion Protection ............1-1 Primary Explosion Protection and Secondary Explosion Protection ..1-1 Explosion Protection Standards ..............1-2 1.3 Classification of Explosion Protection Equipment ........1-3 1.4 Symbols That Indicate Specifications of Explosion Protection ....1-8 CENTUM and Explosion Protection Instrumentation ......
Page 8 Toc-2 4.1.6 Intrinsic Safety Explosion Protection of KCs ........4-7 4.2 Intrinsic Safety Explosion Protection Instrumentation Using Barriers ..4-8 Appendix 1. CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” ..... App.1-1 Appendix 1.1 FM NI Control Drawing of FCU (for FIO System) and FIO Node Unit ..................App.1-1 Appendix 1.2 CSA NI Control Drawing for FIO Node Unit ........App.1-17 Appendix 1.3 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Control Drawing of FCU (for N-IO system), N-IO Node Unit, and FIO Node Unit ................App.1-29 Appendix 1.4...
Page 9: Overview Of Explosion Protection
1. Overview of Explosion Protection Overview of Explosion Protection This chapter provides the general explanation about explosion protection. Primary Explosion Protection and Secondary Explosion Protection In order to prevent explosions and its danger, plants must have an effective explosion protection. To prevent explosions of plant, as a comprehensive countermeasure, the following steps must be taken.
Page 10: Explosion Protection Standards
1. Overview of Explosion Protection Explosion Protection Standards  ATEX Directive In Europe, European Community (EC) directive 94/9/EG (March 23, 1994) was issued. This is a new directive about explosion protection in Europe. On all the EC countries, it puts an obligation to pay attention and assure the safety and health mainly for persons.
Page 11: Classification Of Explosion Protection Equipment
1. Overview of Explosion Protection 1.3 Classification of Explosion Protection Equipment Explosion protection equipment is classified as follows: • Classification by to explosion protection constructions: what kind of method is taken for explosion protection? • Classification by hazardous area and explosive gas: in what kind of environment are they used?  Classification by Explosion Protection Constructions Type of explosion protection constructions are listed in the following table.
Page 12 1. Overview of Explosion Protection  Definition and Comparison of Explosion Protection Construction  Flame-proof Enclosures (Type “d”) 1) Definition: “Flame-proof enclosures” is totally enclosed construction. When gas or vapor get into the enclosure and an explosion take place, the enclosure withstands the pressure of explosion and prevents the ignition of explosion fire to gas and vapor surrounding the enclosure.
Page 13 1. Overview of Explosion Protection  Oil Immersion (Type “o”) 1) Definition: “Oil immersion” is an explosion protection construction that a part of electric machine and apparatus, which may create sparks or arcs and may become an ignition source by unacceptable high temperature, is immersed in insulating oil, so as not to ignite to gas or vapor.
Page 14 1. Overview of Explosion Protection Type of Protection “n” or Non-Incendive  1) Definition: “Type of protection “n” or Non-Incendive” is the special explosion protection construction for Zone 2 or Division 2. It is applicable to electric equipments which is not capable of igniting potentially explosive atmospheres under normal operation.
Page 15 1. Overview of Explosion Protection  Classification of Explosive Gas Classification of Explosive gas (vapor) involves a division by explosion intensity and a division by explosion energy. Classifications in the technical standard, IEC, ATEX, and UKEX are listed in the following table. Table Classification of Explosive Gas Flame-proof enclosures Intrinsic safety Minimum ignition current ratio of the...
Page 16: Symbols That Indicate Specifications Of Explosion Protection
1. Overview of Explosion Protection 1.4 Symbols That Indicate Specifications of Explosion Protection Each country has its own symbols. The following is an example of symbols.  Europe (ATEX, IECEx, UKEX) EXA 15 ATEX 0017 X F010403.ai EXA: Notified body Year of issuance ATEX 0017: EC-type examination certificate with sequence number 0017 Specific conditions of use II 3(1) G Ex nA [ia Ga] IIC T4 Gc (1) (2) (3) (4) (5)
Page 17 1. Overview of Explosion Protection Temperature class: (Maximum surface temperature [°C]) Equipment Protection Levels (EPL) All other surface installations, Level of protection: Very high, Presence of duration of explosive atmosphere: Continuous presence, for Zone 0 All other surface installations, Level of protection: Very high, Presence of duration of explosive atmosphere: Continuous presence, for Zone 20 All other surface installations, Level of protection: High, Presence of duration of explosive atmosphere: Likely to occur for Zone 1 All other surface installations,...
Page 18: Centum And Explosion Protection Instrumentation
3.2.6 –: Non-compliant Note: Regarding the latest conformity standard, refer to the GS 33J01A10-01EN “Integrated Production Control System CENTUM VP System Overview”. The products which use sealed devices also comply with Type “nC”. For detail , refer to Chapter 3.
Page 19: Explosion Protection Construction That I/O Devices Of Centum Comply
2. CENTUM and Explosion Protection Instrumentation 2.2 Explosion Protection Construction that I/O Devices of CENTUM Comply As described in 2.1, countries define their own standards and rules regarding technical methods for explosion protection. With CENTUM, NI, Ex “ec”, Type “n”, and intrinsic safety explosion protection are adopted as explosion protection construction for the installation of FCS or node unit in hazardous areas.
Page 20: Overview Of Connecting Centum To The Devices Installed In A Hazardous Area
2. CENTUM and Explosion Protection Instrumentation 2.3 Overview of Connecting CENTUM to the Devices Installed in a Hazardous Area This section describes the overview of connecting CENTUM to the devices installed in a hazardous area by giving some examples.  Overview of Connecting Ex “ec”/Type “n” compliant FIO Module with Devices Ex “ec”/Type “n” compliant module can be connected to the intrinsic safety equipment installed in Zone 0, Zone 1 and Zone 2 using a barrier and explosion-proof wiring as shown in the following figures.
Page 21 2. CENTUM and Explosion Protection Instrumentation Zone0 Zone1 Zone2 Non-Hazardous Area FCS or node unit Safety Intrinsic Barrier (*2) safety device Safety Intrinsic Barrier (*2) safety device Safety Intrinsic Barrier safety (*2) device Type “n” Ex "ec" device F020305.ai Explosion-proof wiring that is defined in EN 60079-14 and the rules/standards of each country or region. Explosion-proof structure for hazardous area is required.
Page 22 2. CENTUM and Explosion Protection Instrumentation Overview of Connecting Non-Incendive Compliant FIO Module  NI-compliant module can be connected to the devices installed in Division 2. For the connection to an NI-compliant module, it is necessary to compare parameters between the device installed in a hazardous area and the device of CENTUM to evaluate whether connection is possible or not.
Page 23 2. CENTUM and Explosion Protection Instrumentation Overview of Connecting N-IO Components  Overview of Connecting A2BN3D adaptor base plate for ATEX, IECEx, and  UKEX A2BN3D Base plate for adaptor can be connected to the intrinsic safety devices installed in Zone 0, Zone 1, and Zone 2 using a barrier and explosion-proof wiring as shown in the following figures.
Page 24 2. CENTUM and Explosion Protection Instrumentation Zone0 Zone1 Zone2 Non-Hazardous Area A2BN3D Base plate for adaptor Safety Intrinsic (*2) Barrier safety device Safety Intrinsic Barrier (*2) safety device Safety Intrinsic Barrier safety (*2) device Type “n” Ex "ec" device F020312.ai Explosion-proof wiring that is defined in EN/IEC 60079-14 and the rules/standards of each country or region.
Page 25 2. CENTUM and Explosion Protection Instrumentation Overview of Connecting A2BN3D adaptor base plate for FM and CSA  A2BN3D base plate for adaptor can be connected to the devices installed in Division 2. For the connection to an NI-compliant module, it is necessary to compare parameters between the device installed in a hazardous area and the device of CENTUM to evaluate whether connection is possible or not.
Page 26 2. CENTUM and Explosion Protection Instrumentation  Overview of Connecting A2BN4D barrier base plate for ATEX, IECEx, and UKEX Intrinsic safety (hereinafter I.S.) barriers (*1) of MTL products from Eaton Electric Limited which can be mounted to the base plate (A2BN4D), comply with I. S. explosion protection standard (*2). I.
Page 27 2-10 2. CENTUM and Explosion Protection Instrumentation  Overview of Connecting A2BN4D barrier base plate for FM and CSA I.S. barriers of MTL products which can be mounted to the base plate (A2BN4D), comply with I.S. explosion protection standard. For connecting to the devices installed in Division 1 or Division 2, it is necessary to compare intrinsic safety parameters between the devices installed and A2BN4D to evaluate whether connection is possible or not.
Page 28 2-11 2. CENTUM and Explosion Protection Instrumentation  Overview of Connecting A2BN5D barrier base plate for ATEX, IECEx, and UKEX A2BN5D base plate for barrier can be connected to the I.S./Type “n” devices installed in the hazardous area with explosion-proof wiring and can be installed in Zone 2 by mounting in a keyed metal cabinet with protection rating of IP54 or higher as shown in the following figures.
Page 29 2-12 2. CENTUM and Explosion Protection Instrumentation  Overview of Connecting A2BN5D barrier base plate for FM and CSA A2BN5D base plate for barrier can be connected to the devices installed in Division 1 and Division 2. For connecting to the devices installed in Division 1 or Division 2, it is necessary to compare intrinsic safety parameters between the devices installed and A2BN5D to evaluate whether connection is possible or not.
Page 30: Explosion Protection Instrumentation In Zone 2/Division 2
App. 1.4 App. 1.5 App. 1.6 –: Non-compliant Note: Regarding the latest conformity standard, refer to the GS 33J01A10-01EN “Integrated Production Control System CENTUM VP System Overview”. Special Condition for Use  The A2BN4D base plate for barrier shall be used with I/O module (A2MMM843, A2MDV843) and MTL MTL4500 module series.
Page 31 3. Explosion Protection Instrumentation in Zone 2/Division 2 Precautions in Use  • To install a device in accordance with the standards above, the device needs to be accommodated in a keyed metal cabinet and installed. It is necessary to use a cabinet approved by CSA or local testing authorities for explosion-proof products.
Page 32 3. Explosion Protection Instrumentation in Zone 2/Division 2  CSA NI Approved Products and Their Configuration Example The figure below is an example of the configuration of CSA NI approved products which can be installed in hazardous areas. See the table “The List of CSA NI Compliant Products” in Appendix for details.
Page 33 3. Explosion Protection Instrumentation in Zone 2/Division 2 Signal Wiring  Cables other than power cables should be wired to conform to all wiring shall comply with Canadian Electrical Code Part I and Local Electrical Codes. The following is special considerations. •...
Page 34 3. Explosion Protection Instrumentation in Zone 2/Division 2 connection for the purpose of increasing capacity is not allowed. Mount ADV151, ADV161, AED5D, A1BD5D, AKB331 and AKB337 in the same cabinet. When ADV151 or ADV161 is mounted in a cabinet different from that for AED5D or A1BD5D, apply explosion-proof wiring defined in each country for AKB331 or AKB337.
Page 35 3. Explosion Protection Instrumentation in Zone 2/Division 2 Instruction on Voltage Input Mode Wiring The total current value of the channels must be within the rated current (limit) for DC power supply. But if the total current value exceeds the rated current, reduce the number of channels to be supplied at on time, and prepare the same DC power supply for each channel group.
Page 36 3. Explosion Protection Instrumentation in Zone 2/Division 2 WARNING For the warning of N-IO field enclosure, refer to Appendix 1.4 CSA NI/FM NI/IECEx Ex “ec” Control Drawing of N-IO field enclosure.  Parameters in Connecting with CSA NI Devices Energy transfer influences CSA NI properties. In order to maintain these properties, parameters must be displayed when CSA NI devices are connected.
Page 37 3. Explosion Protection Instrumentation in Zone 2/Division 2  Parameters of the Device which Gives Energy Voc: maximum open-circuit output voltage Maximum voltage that occurs at the open terminal (part) when the Non-Incendive (NI) circuit is open Isc: maximum short-circuit output current Maximum current which currents when the NI circuit is short and earth fault Ca: maximum allowable capacitance Maximum capacitance that can be connected to the NI circuit La: maximum allowable inductance...
Page 38 3. Explosion Protection Instrumentation in Zone 2/Division 2 How to Compare Parameters  It is necessary to compare both parameters of the CENTUM I/O module and the CSA NI device when they are connected. Comparing parameters between the device which gives energy and the device which receives energy are connected are the following two ways.
Page 39 We discuss the case where AAI141 of CENTUM I/O module, a power input module and EJA, a differential pressure transmitter of Yokogawa Electric Corporation are connected. EJA is connected to the circuit of AAI141 via a 100m cable, and installed in a hazardous area of Class I, Division 2.
Page 40 3-11 3. Explosion Protection Instrumentation in Zone 2/Division 2 Example of a Connection   Connecting ESB Bus Node Unit and a Device Installed in Division 2 <Hazardous area Division 2> <Non-hazardous area> FCU with a cabinet AEA4D Conduit wiring CSA NI equipment F030104.ai Figure Connecting ESB Bus Node Unit and a Device Installed in Division 2 • To connect with a field device, electrical parameters of each device should be met. •...
Page 41 3-12 3. Explosion Protection Instrumentation in Zone 2/Division 2  Installing Optical ESB Bus Node Unit in Division 2 (Wiring by Optical cable for Optical ESB Bus) <Hazardous area Division 2> <Non-hazardous Area> ANT401 ESB Bus Node Unit ANB10D/A2BE2D Cabinet Optical ESB Bus Node Unit ANB11D/A2BE2D Optical cable for Optical ESB Bus ANT502 AED5D CSA NI equipment AEP9D Conduit wiring AEP7D...
Page 42: Fm Ni (Fm Nonincendive)
App. 1.1 App. 1.3 App. 1.3 App. 1.1 App. 1.4 App. 1.5 App. 1.6 –: Non-compliant Note: Regarding the latest conformity standard, refer to the GS 33J01A10-01EN “Integrated Production Control System CENTUM VP System Overview”. TI 33Q01J30-01E Dec. 3, 2021-00...
Page 43 3-14 3. Explosion Protection Instrumentation in Zone 2/Division 2  FM NI Approved Products and Their Configuration Example The figure below is an example of the configuration of FM NI approved products that can be installed in hazardous areas. See the table “The List of FM NI Compliant Products” in Appendix for details.
Page 44 Excluding N-IO field enclosure. Maintenance  • Devices must be installed by professionally trained personnel or ask Yokogawa’s service office. If devices are installed by person other than those above, FM NI approved products will be invalid. • Do not perform maintenance on running devices installed in a hazardous area in Class I, Division 2.
Page 45 3-16 3. Explosion Protection Instrumentation in Zone 2/Division 2 Power Supply Wiring  When field control unit (for Vnet/IP), node unit for FIO, power distribution unit and power supply module are installed in a hazardous area in Class I, Division 2, wire a power supply cable from a non-hazardous area by explosion-proof wiring (including metal conduit wiring).
Page 46 3-17 3. Explosion Protection Instrumentation in Zone 2/Division 2 Precaution  Please observe the following precautions while product is operating or under maintenance service. WARNING EXPOSURE TO SOME CHEMICALS MAY DEGRADE THE SEALING PROPERTIES OF MATERIALS USED IN THE FOLLOWING DEVICES; AFV10 and AFV30. WARNING EXPLOSION HAZARD.
Page 47 3-18 3. Explosion Protection Instrumentation in Zone 2/Division 2 Instruction on Contact Input Mode Wiring When the number of channels is limited because power supply exceeds its capacity, but parallel connection for the purpose of increasing capacity is not allowed. Mount ADV151, ADV161, AED5D, A1BD5D, AKB331 and AKB337 in the same cabinet.
Page 48 3-19 3. Explosion Protection Instrumentation in Zone 2/Division 2 Instruction on Voltage Input Mode Wiring The total current value of the channels must be within the rated current (limit) for DC power supply. But if the total current value exceeds the rated current, reduce the number of channels to be supplied at on time, and prepare the same DC power supply for each channel group.
Page 49 3-20 3. Explosion Protection Instrumentation in Zone 2/Division 2  Parameters in Connection with FM NI Devices Energy transfer influences FM NI properties. In order to maintain these properties, parameters must be displayed when FM NI devices are connected. To display parameters, FM NI devices are divided into the device that gives energy and the device that receives energy.
Page 50 3-21 3. Explosion Protection Instrumentation in Zone 2/Division 2 Example of a Connection   Connecting ESB Bus Node Unit and a Device Installed in Class I, Division 2 <Hazardous area Class I, Division 2> <Non-hazardous area> FCU with a cabinet AEA4D Conduit wiring CSA NI equipment F030116.ai Figure Connecting ESB Bus Node Unit and a Device Installed in Class I, Division 2 • To connect with a field device, electrical parameters of each device should be met. •...
Page 51 3-22 3. Explosion Protection Instrumentation in Zone 2/Division 2  Installing Optical ESB Bus Node Unit in Class I, Division 2 (Wiring by Optical cable for Optical ESB Bus) <Hazardous area Class I, Division 2> <Non-hazardous Area> ESB Bus Node Unit ANB10D/A2BE2D Cabinet ANT401 Optical ESB Bus Node Unit ANB11D/A2BE2D Optical cable for Optical ESB Bus ANT502 AED5D FM NI equipment AEP9D...
Page 52 3-23 3. Explosion Protection Instrumentation in Zone 2/Division 2  Installing a FCS or ESB Bus Node Unit in Class I, Division 2 <Hazardous area Class I, Division 2> <Non-hazardous Area> Cabinet L2-switch L2-switch AFV30D/A2BE1D AFV30D/A2BE1D L2-switch L2-switch ESB Bus Node Unit ANB10D/A2BE2D AEA4D FM NI equipment AEA4D Conduit wiring AEP7D 100 V AC Power supply Conduit wiring 220 V AC Power supply 24 V DC Power supply...
Page 53: Ex "Ec", Type "N
App. 2.4 – –: Non-compliant Note: Regarding the latest conformity standard, refer to the GS 33J01A10-01EN “Integrated Production Control System CENTUM VP System Overview”. The following products that use sealed devices also comply with ATEX Type “nC”. AFV30S, AFV30D, ANB10S, ANB10D, ANB11S, ANB11D, A1BD5D, A2FV50S, A2FV50D, A2ZN3D, A2BE1D, A2FU2, A2ZN70D, and A2ZN60D.
Page 54: Ecas-Ex Ex "Ec
(*1) –: Non-compliant Note: Regarding the latest conformity standard, refer to the GS 33J01A10-01EN “Integrated Production Control System CENTUM VP System Overview”. Note: Refer to descriptions for IECEx Ex “ec” on this document for installation and precautions for ECAS-Ex Ex “ec”.
Page 55: Ccc-Ex/Nepsi Type "N
N-IO field enclosure (A2NN70D, A2NN60D, A2CB60) comply with CCC-Ex/NEPSI Type “n”. Regarding the latest conformity standard, explosion-proof specifications and compliant products, refer to the GS 33J01A10-01EN “Integrated Production Control System CENTUM VP System Overview”. Refer to descriptions for IECEx Ex “ec” on this document for installation and precautions for installation and precautions for CCC-Ex/NEPSI Type “n”.
Page 56 3-27 3. Explosion Protection Instrumentation in Zone 2/Division 2 Ex “ec”/Type “n” Approved Products and Their Configuration  Example The figure below is an example of the configuration of Ex “ec”/Type “n” compliant products that can be installed in hazardous areas. See the table “The List of Ex “ec”/Type “n” Compliant Products”...
Page 57 Precautions  Refer to the latest edition of CENTUM VP Explosion Protection (IM 33K01J30-50E) for the installation and the precaution for Ex “ec”/Type “n” compliant devices. Refer to the latest edition of CENTUM VP Explosion Protection (IM 33K01J30-50E) for the installation, the precaution, and maintenance and repair for N-IO field enclosure.
Page 58 3-29 3. Explosion Protection Instrumentation in Zone 2/Division 2 Instruction on Contact Input Mode Wiring When the number of channels is limited because power supply exceeds its capacity, but parallel connection for the purpose of increasing capacity is not allowed. Mount ADV151, ADV161, AED5D, A1BD5D, AKB331 and AKB337 in the same cabinet.
Page 59 3-30 3. Explosion Protection Instrumentation in Zone 2/Division 2 Instruction on Voltage Input Mode Wiring The total current value of the channels must be within the rated current (limit) for DC power supply. But if the total current value exceeds the rated current, reduce the number of channels to be supplied at on time, and prepare the same DC power supply for each channel group.
Page 60 3-31 3. Explosion Protection Instrumentation in Zone 2/Division 2 Example of a Connection   Connecting ESB Bus Node Unit and a Device Installed in Zone 2 EN/IEC 61010 compliant <Hazardous area Zone 2> <Non-hazardous area> metal cabinet with a key AEA4D Safety Barrier Intrinsic safety Ex "ec"/Type “n” device device F030203.ai Explosion-proof wiring that is defined in EN/IEC 60079-14 and the rules/standards of each country or region.
Page 61 3-32 3. Explosion Protection Instrumentation in Zone 2/Division 2  Installing Optical ESB Bus Node Unit in Zone 2 (Wiring by Optical cable for Optical ESB Bus) <Hazardous area Zone 2> <Hazardous area> ESB Bus Node Unit ANB10D/A2BE2D Cabinet ANT401 Optical ESB Bus Node Unit ANB11D/A2BE2D Optical cable for Optical ESB Bus ANT502 AED5D Intrinsic safety Safety device Barrier...
Page 62 3-33 3. Explosion Protection Instrumentation in Zone 2/Division 2  Installing a FCS or ESB Bus Node Unit in Zone 2 <Hazardous Area Zone 2> <Non-hazardous Area> Cabinet Optical Cable L2-switch L2-switch AFV30D/A2BE1D AFV30D/A2BE1D L2-switch L2-switch ESB Bus Node Unit ANB11D/A2BE1D AEA4D AEA4D Intrinsic safety Safety device Barrier Ex "ec"/Type “n” AEP7D device 24 V DC Power supply...
Page 63: Intrinsic Safety Explosion Protection Instrumentation
4. Intrinsic Safety Explosion Protection Instrumentation Intrinsic Safety Explosion Protection Instrumentation Intrinsic safety explosion protection is an electric circuit and a construction, which made so as not to ignite to gas by controlling the energy of electric circuit, if sparks, arc, and heat occur at the time of normal operating and an accident (short-circuit, earth fault, burnout). Intrinsic safety explosion protection equipments include intrinsic safety equipments and equipments related with intrinsic safety. Intrinsic safety equipments are able to be used in hazardous area. Equipments related with intrinsic safety are set up in non-hazardous area, and is connected with intrinsic safety equipment. In CENTUM, intrinsic safety explosion protection instrumentation can be done by building Zener barrier or insulating barrier into it. TI 33Q01J30-01E June 30, 2017-00...
Page 64: Intrinsic Safety Explosion Protection Instrumentation Using Barrier Base Plates
[Complied standard] EN IEC 60079-0:2018 EN 60079-11:2012 EN IEC 60079-7:2015 + A1:2018 Note: Regarding the latest conformity standard, refer to the GS 33J01A10-01EN “Integrated Production Control System CENTUM VP System Overview”. Wiring of Intrinsic Safety Explosion Protection  An intrinsic safety circuit must be isolated from non-intrinsic safety circuit. Wiring should be prepared in accordance with EN 60079-14, or the standard of the country and the area in which it is set.
Page 65: Intrinsic Safety Explosion Protection Of Iec Standard
4. Intrinsic Safety Explosion Protection Instrumentation 4.1.2 Intrinsic Safety Explosion Protection of IEC Standard  A2BN5D base plate for barrier A2BN5D base plate for barrier can be connected to the I.S. equipment installed in the hazardous area with explosion-proof wiring and can be installed in Zone 2 by mounting in a keyed metal cabinet with protection rating of IP54 or higher as shown in the following figures.
Page 66: Intrinsic Safety Explosion Protection Of Fm Standard
4. Intrinsic Safety Explosion Protection Instrumentation 4.1.3 Intrinsic Safety Explosion Protection of FM Standard  A2BN5D base plate for barrier A2BN5D base plate for barrier can be connected to the I.S. equipment installed in the hazardous area with explosion-proof wiring and can be installed in Division 2 by mounting in a keyed metal cabinet approved by approval authorities.
Page 67: Intrinsic Safety Explosion Protection Of Csa Standard
4. Intrinsic Safety Explosion Protection Instrumentation 4.1.4 Intrinsic Safety Explosion Protection of CSA Standard  A2BN5D base plate for barrier A2BN5D base plate for barrier can be connected to the I.S. equipment installed in the hazardous area with explosion-proof wiring and can be installed in Division 2 by mounting in a keyed metal cabinet approved by approval authorities.
Page 68: Intrinsic Safety Explosion Protection Of Eac Ex
I. S. equipment installed in the hazardous area with explosion proof wiring.  Explosion-proof specifications and Complied standard Regarding the latest conformity standard, explosion-proof specifications and compliant products, refer to the GS 33J01A10-01EN “Integrated Production Control System CENTUM VP System Overview”. Wiring of Intrinsic Safety Explosion Protection ...
Page 69: Intrinsic Safety Explosion Protection Of Kcs
I. S. equipment installed in the hazardous area with explosion proof wiring.  Explosion-proof specifications and Complied standard Regarding the latest conformity standard, explosion-proof specifications and compliant products, refer to the GS 33J01A10-01EN “Integrated Production Control System CENTUM VP System Overview”. Wiring of Intrinsic Safety Explosion Protection ...
Page 70: Intrinsic Safety Explosion Protection Instrumentation Using Barriers
4. Intrinsic Safety Explosion Protection Instrumentation Intrinsic Safety Explosion Protection Instrumentation Using Barriers  Category of Barriers Classified roughly, barriers includes Zener barriers and insulating barriers (intrinsic safety barriers). Select the best one as your system, with the knowledge of their future. (1) Feature of Zener barriers Zener barrier has a simple construction which consists of just Zener Diode and resistance.
Page 71 4. Intrinsic Safety Explosion Protection Instrumentation (5) Failure rate The construction of Zener barriers is simple, because they carry out the function for security just with Zener Diode and resistance. On the other hand, insulating barriers consist of various parts, because they have the function of insulation and energy restriction. Therefore, the failure rate of insulating barriers is generally higher than that of Zener barriers.
Page 72 4-10 4. Intrinsic Safety Explosion Protection Instrumentation Wiring of Intrinsic Safety Explosion Protection  An intrinsic safety circuit must be isolated from non-intrinsic safety circuit. Wiring should be prepared in accordance with IEC 60079-14, NEC (National Electrical Code : NFPA-70), or the standard of the country and the area in which it is set. The wiring in cabinet should keep the distance to non-intrinsic safety circuit.
Page 73 4-11 4. Intrinsic Safety Explosion Protection Instrumentation Intrinsic safety circuit should consist of barriers to meet these conditions of permissible voltage, current, and electricity, and should be wired so that inductance and capacitance of its wiring doesn’t exceed its permissible value. Device that receives energy Device that gives energy (The load device)
Page 74 4-12 4. Intrinsic Safety Explosion Protection Instrumentation  Considerations for Zener Barriers in Use Check the specifications of barrier, before you use it.  Considerations for Input Channel of Current Note that the current value may have errors in a combination of FIO and Zener barrier. In the system illustrated in the following figure, when the input module applies electric power to the transmitter, the input current value may have errors.
Page 75 4-13 4. Intrinsic Safety Explosion Protection Instrumentation Considerations for Current Output Module  The current output module adjusts voltage so that it generates an appropriate value of current, and outputs it. The output module checks if the value of output current and that of actual current are the same.
Page 76 4-14 4. Intrinsic Safety Explosion Protection Instrumentation  Example of Connection at the Barrier in Use (Connection Using Marshalling Panel) <Hazardous area> <Non-hazardous area> Marshaling panel AEA4D AEA4D AED5D AED5D KS cable Grounding for explosion protection F040105.ai Figure Example of Connection at the Barrier in Use (Connection Using Marshaling Panel) • The barrier should be connected with field equipment in accordance with the electric parameter of each equipment.
Page 77: Appendix 1. Csa Ni/Fm Ni/Iecex Ex "Ec"/Ecas-Ex Ex "Ec
App.1-1 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Appendix 1. CSA NI/FM NI/IECEx Ex “ec”/ ECAS-EX Ex “ec” Appendix 1.1 FM NI Control Drawing of FCU (for FIO System) and FIO Node Unit TI 33Q01J30-01E Dec. 3, 2021-00...
Page 78 App.1-2 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 2021-04-28 Page Revision Date 1−6, 11−15 Revised pages ■ Applicable standards: FM 3600:2018 FM 3611:2018 FM 3810:2018 (Note 1) ANSI/UL 121201 Ed.
Page 79 App.1-3 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □□ ANT10U- 0 to 60 °C Unit □□ ANT10U- −20 to 70 °C □...
Page 80 App.1-4 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □ AAI143- 0 to 60 °C □ AAI143- −20 to 70 °C □...
Page 81 App.1-5 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □ ALR111-SE 0 to 60 °C ALR121-SE0 0 to 60 °C...
Page 82 App.1-6 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □□□ YCB301-C □□□ Bus cable YCB141-M −20 to 70 °C YCB138 □□...
Page 83 For current controlled circuits, Imax of the nonincendive field wiring apparatus is not required and need not be aligned with parameter Isc or It of CENTUM or other associated nonincendive field wiring apparatus. Use only the following batteries specified by Yokogawa Electric Corporation for the CPU modules: CP461: S9548FA, CP471: S9548FA WARNING –...
Page 84 App.1-8 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision Bus1 Bus2 Non-Hazardous Area Class Ⅰ,Division 2 Cabinet Cabinet L2SW for Bus1 L2SW for Bus2 SWITCH HUB...
Page 85 App.1-9 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision TI 33Q01J30-01E Dec. 3, 2021-00...
Page 86 App.1-10 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision TI 33Q01J30-01E Dec. 3, 2021-00...
Page 87 App.1-11 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision TI 33Q01J30-01E Dec. 3, 2021-00...
Page 88 App.1-12 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision Nonincendive Field Wiring Parameter (Equipment supplying energy) (*1) Model Remark (mA) (μF) (mH) AFV30D — — —...
Page 89 App.1-13 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision Nonincendive Field Wiring Parameter (Equipment supplying energy) (Continued) (*1) Model Remark (mA) (μF) (mH) Redundant — —...
Page 90 App.1-14 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision Nonincendive Field Wiring Parameter (Equipment receiving energy) (*1) Vmax Imax Model Remark (mA) (μF) (μH) AFV30D —...
Page 91 App.1-15 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision Nonincendive Field Wiring Parameter (Equipment receiving energy) (Continued) (*1) Vmax Imax Model Remark (mA) (μF) (μH) Redundant 0.001...
Page 92 App.1-16 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP FIO Model Control drawing Title NFM020-A13 Page Revision Cable Parameter Model Remark (μH/m) (pF/m) YCB301 — — (*1) YCB141 0.25 AKB331 AKB335 AKB336 — —...
Page 93: Appendix 1.2 Csa Ni Control Drawing For Fio Node Unit
App.1-17 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Appendix 1.2 CSA NI Control Drawing for FIO Node Unit  Applicable standards: CAN/CSA-C22.2 No. 0-10 C22.2 No. 213-17 CAN/CSA-C22.2 No.61010-1-12 + Amd1-18 (Note 1) CAN/CSA-C22.2 No.61010-2-030:18 (Note 1) CAN/CSA-C22.2 No.61010-2-201:18 (Note 1) Note 1: Instead of CAN/CSA-C22.2 No. 61010-1-12 + Amd1-18, CAN/CSA-C22.2 No. 61010-2- 030:18 and CAN/CSA-C22.2 No.
Page 94 App.1-18 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” (Continued) Classifications Model Ambient Temperature (*1) A2BE2D-S100 0 to 60 °C Base Plate −20 to 70 °C A2BE2D-S130 □ 0 to 60 °C ANT10U- □ −20 to 70 °C ANT10U- Unit □...
Page 95 App.1-19 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” (Continued) Classifications Model Ambient Temperature (*1) □ 0 to 60 °C AAI141- □ −20 to 70 °C AAI141- AAV141-SE0 0 to 60 °C −20 to 70 °C AAV141-SE3 AAB141-HE0 0 to 60 °C −20 to 70 °C AAB141-HE3 □...
Page 96 App.1-20 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” (Continued) Classifications Model Ambient Temperature (*1) □ ADV151- 0 to 60 °C □ ADV151- □ ADV151- −20 to 70 °C □ ADV151- ADV551-PE0 0 to 60 °C ADV551-PF0 I/O module ADV551-PE3 −20 to 70 °C ADV551-PF3...
Page 97 App.1-21 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” (Continued) Classifications Model Ambient Temperature (*1) AEA3D-0E AEA3D-0F AEA4D-0E AEA4D-0F AET4D-0E AET4D-0F AER4D-0E AER4D-0F AED5D-0E AED5D-0F −20 to 70 °C AEF9D-0E AEF9D-0F Terminal board A1BA4D-0E A1BA4D-0F A1BR4D-0E A1BR4D-0F A1BT4D-0E A1BT4D-0F A1BD5D-0E A1BD5D-0F 0 to 50 °C...
Page 98 App.1-22 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” (Continued) Classifications Model Ambient Temperature (*1) YCB138 □□□ −20 to 70 °C YCB141-M Bus cable □□□ YCB301-C □□ KS1- □□ KS2- □□ KS8- □□□ −20 to 70 °C Signal cable AKB331-M □□□...
Page 99 Information of Installation Guidance), and IM (User’s Manuals) should be referred to and the instructions described in the documents should be observed. CENTUM VP IS SUITABLE FOR USE IN ZONE 2, GROUP IIC; CLASS 1, DIVISION 2, GROUPS A, B, C, and D; OR NON-HAZARDOUS LOCATIONS ONLY.
Page 100 App.1-24 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Bus1 Bus2 Non-Hazardous Area Class Ⅰ,Division 2 Cabinet Cabinet L2SW for Bus1 L2SW for Bus2 SWITCH HUB SWITCH HUB EB402 EC401 ANR11D AFV10D EB511 ANR10D SB401+T Branch ANB10D EB501 EB401 AEA4D AEA4D Fieldbus...
Page 101 App.1-25 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” TI 33Q01J30-01E Dec. 3, 2021-00...
Page 102 App.1-26 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” TI 33Q01J30-01E Dec. 3, 2021-00...
Page 103 App.1-27 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Nonincendive Field Wiring Parameter (Equipment supplying energy) (*1) Model Remark (μF) (mA) (mH) Redundant 27.6 54.0 0.12 AAI141 2-wire transmitter input Single 27.6 27.0 0.19 AAI135 Redundant 31.0 31.0 0.25 15.4 2-wire transmitter input ~style2...
Page 104 App.1-28 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Nonincendive Field Wiring Parameter (Equipment receiving energy) (*1) Vmax Imax Model Remark (μF) (μH) (mA) Redundant 20.0 60.0 4200 pF AAI141 4-wire transmitter input Single 12.0 30.0 3100 pF Redundant 31.0 8600 pF AAI135...
Page 105: Appendix 1.3
App.1-29 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Appendix 1.3 CSA NI/FM NI/IECEx Ex “ec”/ECAS- EX Ex “ec” Control Drawing of FCU (for N-IO system), N-IO Node Unit, and FIO Node Unit Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 2021-04-28 Page Revision Date 1−4, 12−16, 23, 24...
Page 106 App.1-30 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □□ □ A2BN3D- 0 to 60 °C □□ □ A2BN3D- □...
Page 107 App.1-31 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □ A2SMX801-S10 0 to 60 °C □ A2SMX801-S11 □ A2SMX801-S12 −40 to 70 °C (*5, *7) □...
Page 108 App.1-32 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision (Continued) Classifications Model Ambient Temperature (*1) A2BM4-100 0 to 60 °C A2BM4-110 Terminal board A2BM4-120 −40 to 70 °C (*6) A2BM4-130 □□...
Page 109 App.1-33 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision TI 33Q01J30-01E Dec. 3, 2021-00...
Page 110 App.1-34 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision TI 33Q01J30-01E Dec. 3, 2021-00...
Page 111 App.1-35 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision Hazardous (Classified) Location Non-hazardous Class I, Division 2, Groups A, B, C, D, T4 Location Base plate for Adaptor...
Page 112 App.1-36 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision TI 33Q01J30-01E Dec. 3, 2021-00...
Page 113 App.1-37 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision Hazardous (Classified) Location Non-hazardous Class I, Division 2, Groups A, B, C, D, T4 Location Base plate for Adaptor...
Page 114 App.1-38 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision Nonincendive field wiring parameters (Output parameters) Model Function Remark (mA) (μF) (mH) A2MMM843 Analog Input 2-wire Redundant...
Page 115 App.1-39 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision Nonincendive field wiring parameters (Input parameters) Model Function Vmax Imax Remark (mA) (μF) (μH) A2MMM843 Analog Input...
Page 116 Modules can be mounted also on an FM-approved Base Plates A2BN4D or A2BN5D. In such case, installation must be in accordance also with the control drawing of these Base Plates. CENTUM VP IS SUITABLE FOR USE IN CLASS 1, DIVISION 2, GROUPS A, B, C, and D OR NONHAZARDOUS LOCATIONS ONLY.
Page 117 App.1-41 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision (Canada) ■ Applicable standards: CAN/CSA-C22.2 No. 0-10 C22.2 No. 213-17 CAN/CSA-C22.2 No.61010-1-12 + Amd1-18 CAN/CSA-C22.2 No.61010-2-030:18 CAN/CSA-C22.2 No.61010-2-201:18 The models which conform to these standards are listed in the following tables of the ambient temperature ranges.
Page 118 App.1-42 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision (Continued) Classifications Model Ambient Temperature (*1) A2PW503-S0100 0 to 60 °C A2PW503-S0110 A2PW503-S0120 −40 to 70 °C...
Page 119 App.1-43 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □ A2SMX801-S10 0 to 60 °C □ A2SMX801-S11 □ A2SMX801-S12 −40 to 70 °C (*5, *7) □...
Page 120 App.1-44 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision (Continued) Classifications Model Ambient Temperature (*1) A2BM4-100 0 to 60 °C A2BM4-110 Terminal board A2BM4-120 −40 to 70 °C (*6) A2BM4-130 □□...
Page 121 App.1-45 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision Hazardous Location Non-hazardous Zone 2, Group IIC, T4 Location Class I, Division 2, Groups A, B, C, D, T4...
Page 122 App.1-46 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision TI 33Q01J30-01E Dec. 3, 2021-00...
Page 123 App.1-47 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision Hazardous Location Non-hazardous Zone 2, Group IIC, T4 Location Class I, Division 2, Groups A, B, C, D, T4...
Page 124 App.1-48 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision TI 33Q01J30-01E Dec. 3, 2021-00...
Page 125 App.1-49 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision TI 33Q01J30-01E Dec. 3, 2021-00...
Page 126 App.1-50 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision Non-incendive field wiring parameters (Output parameter) Model Function Remark (mA) (μF) (mH) A2MMM843 Analog Input 2-wire Redundant...
Page 127 App.1-51 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision Non-incendive field wiring parameters (Input parameters) Model Function Vmax Imax Remark (mA) (μF) (μH) A2MMM843 Redundant Analog Input...
Page 128 Base Plates. CENTUM VP IS SUITABLE FOR USE IN ZONE 2, GROUP IIC; CLASS 1, DIVISION 2, GROUPS A, B, C, and D; OR NON-HAZARDOUS LOCATIONS ONLY.
Page 129 App.1-53 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Control drawing Title NIE008-A101 Page Revision 10. WARNING – EXPLOSION HAZARD – SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION 2.
Page 130 App.1-54 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Instructions (IECEx) Title NIE008-A102 2021-04-28 Page Revision Date 1–6 Revised pages ■ Applicable standards: IEC 60079-0 Ed. 7.0 (2017) IEC 60079-7 Ed. 5.1 (2017) IEC 60079-15 Ed.
Page 131 App.1-55 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Instructions (IECEx) Title NIE008-A102 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □ □□ 0 to 60 °C A2NN30D-440 □ □□ A2NN30D-440 □...
Page 132 App.1-56 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Instructions (IECEx) Title NIE008-A102 Page Revision (Continued) Classifications Model Ambient Temperature (*1) SB401-E0 0 to 60 °C SB401-E1 SB401-E3 −20 to 70 °C □...
Page 133 App.1-57 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Instructions (IECEx) Title NIE008-A102 Page Revision (Continued) Classifications Model Ambient Temperature (*1) A2MMM843-SS1100 0 to 60 °C A2MMM843-SS1110 A2MMM843-SS1120 −40 to 70 °C (*2, *7)
Page 134 App.1-58 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO Model Instructions (IECEx) Title NIE008-A102 Page Revision (Continued) Classifications Model Ambient Temperature (*1) Terminal block ATF9S-00 −20 to 70 °C □ AEF9D-0 −20 to 70 °C A2BM4-100 0 to 60 °C...
Page 135 IEC 60079-19. ・ Repairs of the equipment shall be carried out only by trained, experienced, skilled, knowledgeable and/or supervised personnel, or by the service engineers recognized by YOKOGAWA. Otherwise, the type of protection may be invalidated.
Page 136: Appendix 1.4
App.1-60 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Appendix 1.4 CSA NI/FM NI/IECEx Ex “ec” Control Drawing of N-IO field enclosure  Applicable Standards / Applicable Models [CSA NI] <Applicable Standards> C22.2 No.213-17 CAN/CSA-C22.2 No.61010-1-12 CAN/CSA-C22.2 No. 61010-2-030-12 CAN/CSA-IEC 61010-2-201:14 <Marking> A2NN70D, A2CB60: CL I, DIV 2, GP ABCD, T4, Type 4X A2NN60D: CL I, DIV 2, GP ABCD, T4 <Applicable Models>...
Page 137 App.1-61 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” [IECEx] <Applicable Standards> IEC 60079-0 Ed. 7.0 (2017) IEC 60079-7 Ed. 5.1 (2017) IEC 60079-15 Ed. 5.0 (2017) <Marking> IECEx FMG 20.0021X Ex ec nC IIC T4 Gc (A2NN70D, A2NN60D) Ex ec IIC T4 Gc (A2CB60) Note: When A2CB60 and A2NN60D are provided as separate products, the Ex marking external to the enclosure shows the marking of...
Page 138 App.1-62 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO field enclosure Model Control drawing (US) Title NFM036-A101 2020-04-10 Page Revision Date 2, 4 Revised pages Control Drawing (US) TI 33Q01J30-01E Dec. 3, 2021-00...
Page 139 App.1-63 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO field enclosure Model Control drawing (US) Title NFM036-A101 Page Revision Specific condition of use: - A2NN60D shall be installed in A2CB60. - Since Ta is not marked on the equipment, the control drawing NFM036-A101 shall be referred to for the ambient temperature range.
Page 140 App.1-64 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO field enclosure Model Control drawing (Canada) Title NFM036-A101 Page Revision Control Drawing (Canada) TI 33Q01J30-01E Dec. 3, 2021-00...
Page 141 App.1-65 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Yokogawa Electric Corporation CENTUM VP N-IO field enclosure Model Control drawing (Canada) Title NFM036-A101 Page Revision Specific condition of use: - A2NN60D shall be installed in A2CB60. - Since Ta is not marked on the equipment, the control drawing NFM036-A101 shall be referred to for the ambient temperature range.
Page 142 D. Harada NFM036-A102 2020-04-10 Page Revision Date − Revised pages Instructions (IECEx) App.1-66 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Following items shall be included in instructions: – Applicable standards (together with the year of issue) listed in Chapter 1; –...
Page 143 Repairs of the equipment shall be carried out only by trained, experienced, skilled, knowledgeable and/or supervised personnel, or by the service engineers recognized by YOKOGAWA. Otherwise, the type of protection may be invalidated. • Modifications shall not be made to the equipment which are operated in hazardous areas.
Page 144: Appendix 1.5 Csa Ni/Fm Ni Control Drawing Of A2Bn4D
App.1-68 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Appendix 1.5 CSA NI/FM NI Control Drawing of A2BN4D  Applicable Standards / Applicable Models [CSA NI] <Applicable Standards> Class I, Division 2, Groups A, B, C, and D, T4; Non Sparking for Class I, Zone 2, Ex nA IIC T4 Gc hazardous (classified) locations with an ambient temperature rating of -20 °C to +60 °C.
Page 145 Class I, Zone 2 wiring methods specified in the National Electric Code (ANSI/NFPA 70) for the US or Canadian Electrical Code (C22.1) for Canada. Rev.1: October 24, 2017 Doc. No.: NFM035-A100 P.1 Yokogawa Electric Corporation TI 33Q01J30-01E Dec. 3, 2021-00...
Page 146 Installations in Canada must comply with the Canadian Electrical Code. Note 9 Warning: Equipment must be powered down before connecting or disconnecting when mounted in Division 2 or Zone 2. Rev.1: October 24, 2017 Doc. No.: NFM035-A100 P.2 Yokogawa Electric Corporation TI 33Q01J30-01E Dec. 3, 2021-00...
Page 147: Appendix 1.6 Csa Ni/Fm Ni Control Drawing Of A2Bn5D
App.1-71 Appendix 1 CSA NI/FM NI/IECEx Ex “ec”/ECAS-EX Ex “ec” Appendix 1.6 CSA NI/FM NI Control Drawing of A2BN5D  Applicable Standards / Applicable Models [CSA NI] <Applicable Standards> Class I, Division 2, Groups A, B, C, and D, Temperature Class T4; Non-Sparking Class I Zone 2, Group IIC, Temperature Class T4; hazardous locations.
Page 148 Wiring methods must be in accordance with the National Electrical Code for installations in the United States, the Canadian Electrical Code for installations in Canada, or other local codes, as applicable. Rev. Doc. No.: IFM050-A100 P.1 Drawing: M. Ootsubo Approved: D. Harada Yokogawa Electric Corporation TI 33Q01J30-01E Dec. 3, 2021-00...
Page 149 WARNING - Do not remove or replace fuse when energized. AVERTISSEMENT - Ne pas retirer ni re mplacer de fusible sous tension Rev. Doc. No.: IFM050-A100 P.2 Drawing: M. Ootsubo Approved: D. Harada Yokogawa Electric Corporation TI 33Q01J30-01E Dec. 3, 2021-00...
Page 150: Appendix 2. Atex Ex "Ec"/Atex Type "N" / Ukex Ex "Ec" / Ukex Type "N
App.2-1 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Appendix 2.1 ATEX Ex “ec” / UKEX Ex “ec” Instruction of FCU (for FIO system) and FIO Node Unit TI 33Q01J30-01E...
Page 151 App.2-2 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP FIO Model Instructions Title NKE043-A13 2021-05-14 Page Revision Date 1–8 Revised pages ■ Applicable standards: EN IEC 60079-0:2018 EN IEC 60079-7:2015 + A1:2018...
Page 152 App.2-3 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP FIO Model Instructions Title NKE043-A13 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □ 0 to 60 °C ANB10S- □...
Page 153 App.2-4 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP FIO Model Instructions Title NKE043-A13 Page Revision (Continued) Classifications Model Ambient Temperature (*1) SB401-E0 0 to 60 °C SB401-E1 SB401-E3 −20 to 70 °C...
Page 154 App.2-5 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP FIO Model Instructions Title NKE043-A13 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □ 0 to 60 °C AAI141- □...
Page 155 App.2-6 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP FIO Model Instructions Title NKE043-A13 Page Revision (Continued) Classifications Model Ambient Temperature (*1) AAT145-SE0 0 to 60 °C AAT145-SE3 −20 to 70 °C...
Page 156 App.2-7 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP FIO Model Instructions Title NKE043-A13 Page Revision (Continued) Classifications Model Ambient Temperature (*1) □ ATA4S- □ ATA4D- □ ATI3S- □...
Page 157 App.2-8 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP FIO Model Instructions Title NKE043-A13 Page Revision (Continued) Classifications Model Ambient Temperature (*1) YCB138 Bus cable −20 to 70 °C □□□...
Page 158 EN 60079-19. ・ Repairs of the equipment shall be carried out only by trained, experienced, skilled, knowledgeable and/or supervised personnel, or by the service engineers authorized by YOKOGAWA. Otherwise, the type of protection may be invalidated.
Page 159: Appendix 2.2 Atex Ex "Ec" / Ukex Ex "Ec" Instruction Of Fcu (For N-Io System) And N-Io Node Unit
Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Appendix 2.2 ATEX Ex “ec” / UKEX Ex “ec” Instruction of FCU (for N-IO system) and N-IO Node Unit Yokogawa Electric Corporation CENTUM VP N-IO Instructions NKE051-A31 2021-12-17 1, 3, 6 EN IEC 60079-0:2018...
Page 160 App.2-11 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP N-IO Instructions NKE051-A31 Note: Suffix codes relevant to each equipment are specified in the spaces of Option codes are omitted from the models shown below..
Page 161 App.2-12 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP N-IO Instructions NKE051-A31 (Continued) Classifications Model Ambient Temperature (*1) A2BN3D- 0 to 60 °C A2BN3D- A2BN3D- 012 A2BN3D- 013 A2BN3D- 112 40 to 70 °C (*6)
Page 162 App.2-13 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP N-IO Instructions NKE051-A31 (Continued) Classifications Model Ambient Temperature (*1) A2MMM843-SS1100 0 to 60 °C A2MMM843-SS1110 A2MMM843-SS1120 40 to 70 °C (*5, *6)
Page 163 App.2-14 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP N-IO Instructions NKE051-A31 (Continued) Classifications Model Ambient Temperature (*1) A2SAM105-H100 0 to 60 °C A2SAM105-H110 A2SAM105-H120 40 to 70 °C (*3, *5)
Page 164 App.2-15 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Yokogawa Electric Corporation CENTUM VP N-IO Instructions NKE051-A31 (Continued) Classifications Model Ambient Temperature (*1) A2BM4-100 0 to 60 °C A2BM4-110 Terminal board A2BM4-120 40 to 70 °C (*7) A2BM4-130 -10 to 60 °C...
Page 165 Repairs of the equipment shall be carried out only by trained, expe rienced, skilled, knowledgeable and/or supervised personnel, or by the service engineers authorized by YOKOGAWA. Otherwise, the type of protection may be invalidated. Modifications shall not be made to the equipment which is operated in hazardous areas.
Page 166: Atex Ex "Ec" / Ukex Ex "Ec" Instruction Of N-Io Field Enclosure
App.2-17 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Appendix 2.3 ATEX Ex “ec” / UKEX Ex “ec” Instruction of N-IO field enclosure Yokogawa Electric Corporation CENTUM VP N-IO field enclosure Model Instructions Title NKE0055-A011 2021-06-18 Page...
Page 167 Repairs of the equipment shall be carried out only by trained, experienced, skilled, knowledgeable and/or supervised personnel, or by the service engineers authorized by YOKOGAWA. Otherwise, the type of protection may be invalidated. Modifications shall not be made to the equipment which is operated in hazardous areas.
Page 168: Appendix 2.4 Atex Type "N"/ Ukex Type "N" Information Of A2Bn4D
App.2-19 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Appendix 2.4 ATEX Type “n”/ UKEX Type “n” Information of A2BN4D Applicable Standards  EN IEC 60079-0:2018 EN 60079-15:2010 Markings  II 3 G Ex nA IIC T4 Gc X Applicable Models ...
Page 169: Appendix 2.5 Atex Ex "Ec"/ Ukex Ex "Ec" Information Of A2Bn5D
App.2-20 Appendix 2. ATEX Ex “ec”/ATEX Type “n” / UKEX Ex “ec” / UKEX Type “n” Appendix 2.5 ATEX Ex “ec”/ UKEX Ex “ec” Information of A2BN5D Applicable Standards  EN IEC 60079-0:2018 EN IEC 60079-7:2015 + A1:2018 EN 60079-11:2012 Markings  FIDI 21 ATEX 0071X CML 22UKEX2105X II 3 (1) G Ex ec [ia Ga] IIC T4 Gc...
Page 170: Appendix 3. Iecex Ex "Ec"/ Iecex Type "N" Of A2Bn4D / A2Bn5D
App.3-1 Appendix 3. IECEx Ex “ec”/ IECEx Type “n” of A2BN4D / A2BN5D Appendix 3. IECEx Ex “ec”/ IECEx Type “n” of A2BN4D / A2BN5D Appendix 3.1 IECEx Type “n” Information of A2BN4D Applicable Standard  IEC 60079-0:2011 IEC 60079-15:2010  Markings IECEx BAS 15.0097X Ex nA IIC T4 Gc Applicable Models ...
Page 171 App.3-2 Appendix 3. IECEx Ex “ec”/ IECEx Type “n” of A2BN4D / A2BN5D  Specific conditions of use All the devices must be installed in the hazardous area in accordance with the marking shown on each device. When the equipment consists of several devices, ensure that the equipment consists only of the devices which can be used in the same hazardous environment.
Page 172: Appendix 3.2 Iecex Ex "Ec"/ Intrinsic Safety/Ecas-Ex Ex "Ec" Information Of A2Bn5D
App.3-3 Appendix 3. IECEx Ex “ec”/ IECEx Type “n” of A2BN4D / A2BN5D Appendix 3.2 IECEx Ex “ec”/ Intrinsic Safety/ ECAS-Ex Ex “ec” Information of A2BN5D Applicable Standard  IEC 60079-0 Ed. 7.0 (2017) IEC 60079-7 Ed. 5.1 (2017) IEC 60079-11 Ed.6.0 (2011)  Markings IECEx EXA 15.0003X Ex ec [ia Ga] IIC T4 Gc Applicable Models...
Page 173 App.3-4 Appendix 3. IECEx Ex “ec”/ IECEx Type “n” of A2BN4D / A2BN5D  Specific conditions of use All the devices must be installed in the hazardous area in accordance with the marking shown on each device. When the equipment consists of several devices, ensure that the equipment consists only of the devices which can be used in the same hazardous environment.
Page 174: Revision Information
Revision Information  Title: Explosion Protection  Manual No.: TI 33Q01J30-01E March 2004/1st Edition Newly published Apr. 2007/2nd Edition Explosion Protection Standards Revised description of Type “n” standard number in “Table Explosion Protection Standards” Explosion Protection Standards that CENTUM has Acquired Non-Icendive of “Table Explosion Protection Standards that CENTUM Complies” is changed to CSA Non-Icendive.
Page 175 Apr. 2010/4th Edition CENTUM and Explosion Protection Instrumentation Explosion Protection Standards that CENTUM has Acquired Revised description of “Table Explosion Protection Standards that CENTUM Complies” Overview of Connecting CENTUM to the Devices Installed in a Hazardous Area Added “Overview of Connecting a Module with Built-in Barrier (Compliant with CENELEC Standard)” Added “Overview of Connecting a Module with Built-in Barrier (Compliant with FM Standard)”...
Page 176 Intrinsic Safety Explosion Protection Instrumentation Local Node is changed into ESB Bus Node Unit Remote Node is changed into ER Bus Node Unit Example of a Connection Revised to *1 and Remarks Appendix 1.1 Lists of CSA NI Compliant Product and CSA NI Parameters The List of CSA NI Compliant Products Table The List of CSA NI Compliant Products [ANB10S-1, ANB10S-4, ANB10D-1, ANB10D-4, ANB11S-1, ANB11S-4, ANB11D-1, ANB11D-4, ANT10U-1,...
Page 177 Symbols That Indicate Specifications of Explosion Protection Europe, Australia, IEC [Revised descripteve texts] Explosion Protection Standards that CENTUM has Acquired Table Explosion Protection Standards that CENTUM Complies [Revised “Conformed standard number”] Explosion Protection Construction that I/O Devices of CENTUM Comply [Revised descriptive text and figure] Overview of Connecting CENTUM to the Devices Installed in a Hazardous Area [Revised descriptive texts and figures]...
Page 178 Appendix 1.2 Lists of FM NI Compliant Products and FM NI Parameters Table The List of FM NI Compliant Products [Revised Type names] Table FIO Parameters (The Source Devices) [Revised Module name] Table FIO Parameters (The Load Devices) [Revised Module name] Appendix 2.
Page 179 Appendix 1.2 Lists of FM NI Compliant Products and FM NI Parameters Table The List of FM NI Compliant Products [AW810D, VI461, and PW441/442/444 are added] Table FIO Parameters (The Source Devices) [AW810D and VI461 are added] Table FIO Parameters (The Load Devices) [AW810D, VI461, and PW441/442/444 are added] Appendix 2.
Page 180 Instruction on Contact Input Mode Wiring [A1BD5D is added] Instruction on Voltage Input Mode Wiring [A1BD5D is added] Appendix 1.1 Lists of CSA NI Compliant Products and CSA NI Parameters Table The List of CSA NI Compliant Products <for FIO> [A1BD5D, A1BA4D, A1BR4D, an A1BT4D are added] Table FIO Parameters (The Load Devices) [A1BD5D is added]...
Page 181 viii Overview of Connecting CENTUM to the Devices Installed in a Hazardous Area Figure Connection of a Type “n” Compliant Module (1) [Explosion-proof wiring is changed] Figure Connection of a Type “n” Compliant Module (2) [Explosion-proof wiring is changed] Figure Connection of an NI Compliant Module (1) [Explosion-proof wiring is changed] Figure Connection of an NI Compliant Module (2) [Explosion-proof wiring is changed]...
Page 182 [N-IO related information is added] Parameters of FM NI Compliant Equipments [“ FIO” and “ N-IO” are added] Appendix 2. FM NI/CSA NI Control Drawing for CENTUM VP N-IO [New addition] Appendix 3. FM NI/CSA NI Control Drawing for A2BN5D [New addition] Appendix 4.
Page 183 [Deleted A2ZN3D] [Added A2MDV843] [Correction of errors]  N-IO [Added A2MDV843 for descriptive texts] [Correction of errors] Appendix 2. FM NI/CSA NI Control Drawing for CENTUM VP N-IO [Replacement Control Drawing] Appendix 5.1 Table The List of ATEX Type “n” Compliant Products...
Page 184 Appendix1.2 Lists of FM NI Compliant Products and FM NI Parameters [A2SAM105, A2SAM505, A2SAT105, A2SMX802 were added] Appendix2. FM NI/CSA NI Control Drawing for CENTUM VP N-IO [A2SAM105, A2SAM505, A2SAT105, A2SMX802 were added] Appendix5.1 The Lists of ATEX Type"n" Compliant Product [A2SAM105, A2SAM505, A2SAT105, A2SMX802, A2EXR001 were added] Appendix5.2 The List of IECEx Type"n"...
Page 185 AKB331 were revised.]  N-IO [Table of Cable Parameter was added.] Appendix 2. FM NI/CSA NI Control Drawing for CENTUM VP N-IO [Control Drawing(NIE008) was replaced to new revision.] Appendix 5.1 Table The List of ATEX Type "n" Compliant Products [A2BM4 was added.] Appendix 5.2 Table The List of IECEx Type "n"...
Page 186 Appendix 1.2 Table The List of FM NI Compliant Products [N-IO field enclosure was revised.] Appendix 2. FM NI/CSA NI Control Drawing for CENTUM VP N-IO [Control Drawing(NIE008) was replaced to new revision.] Appendix 5.1 Table The List of ATEX Type "n" Compliant Products [N-IO field enclosure was added.]...
Page 187 4.1.1 Intrinsic Safety Explosion Protection of ATEX Standard [Explosion-proof Specifications and Complied Standard was revised.] 4.1.2 Intrinsic Safety Explosion Protection of IEC Standard [Explosion-proof Specifications and Complied Standard was revised.] 4.1.5 Intrinsic Safety Explosion Protection of EAC Ex [Added section] 4.1.6 Intrinsic Safety Explosion Protection of KCs [Added section] Appendix 2.2 Configuration was changed.
Page 188 Written by Yokogawa Electric Corporation Published by Yokogawa Electric Corporation 2-9-32 Nakacho, Musashino-shi, Tokyo 180-8750, JAPAN...
