Operation
Thermostat
The Thermostat Dial (see previous page) controls the heat output according to
the room temperature. This ensures that the column heater will not produce heat
unnecessarily when the room is already warm.
1. To set the temperature, turn the thermostat dial clockwise until the required
setting is reached. Alternatively to heat a cold room quickly, turn the thermostat
dial up fully.
2. When the room has reached the desired temperature, turn the thermostat
dial anti-clockwise until the thermostat just clicks off. The heater will now
automatically operate at this temperature.
3. The thermostat also has a frost protection setting marked '
in areas such as garages, or other cold indoor rooms, to prevent frost damage. If
the thermostat is set to its minimum setting '
maintain a temperature of approximately 5°C to help protect against frost.
Note – If the heater fails to turn ON when the thermostat is at a low setting, this may
be due to the room temperature being higher than the thermostat setting.
On/Off & Heat Switches (see previous page)
Selector switches located on the control panel provide a choice of heat output to
suit varying conditions and for economy of operation.
Available output options are as follows:
Model
OCR10BLK
OCR15BLK
OCR24BLK
*
On/Off Switches (Left)
O I
Off On (700W)
Off On (1000W)
Off On (1700W)
*
' This setting is useful
' the heater will cycle on and off to
Heat Switches (right)
I
700W
1000W
1700W
II
1000W
1500W
2400W
