Dimplex OFRB7 Operating And Maintenance Instructions

Oil-free Radiator
OFRB7

IMPORTANT INSTRUCTIONS

When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electric shock,
and injury to persons, including the following:
1. Read all instructions before using this heater.
2. Extreme caution is necessary when any heater is used
by or near children or invalids and whenever the unit is
left operating and unattended.
3. Always unplug the heater when not in use.
4. The heater must not be located immediately below an
electrical socket-outlet.
5. Do not operate any unit with a damaged cord or plug, or
if the heater has malfunctioned, or if the heater has been
dropped or damaged in any manner. Return heater to
authorized service facility for examination, electrical or
mechanical adjustment or repair.
6. Do not use outdoors.
7. The heater is not intended for use in bathrooms, laundry
areas and similar indoor locations. Never locate heater
where it may fall into a bathtub or other water container.
8. Do not run the cord under carpeting. Do not cover cord
with throw rugs, runners or the like. Arrange cord away
from traffic area and where it will not be tripped over.
9. To disconnect the unit, turn the controls off, then remove
the plug from the outlet.
10. Do not insert or allow foreign objects to enter any venti-
lation or exhaust opening as this may cause an electric
shock or fire, or damage to the heater.
11. To prevent a possible fire, do not block air intake or ex-
haust in any manner. Do not use on soft surfaces, like a
bed, where openings may become blocked.
12. All electrical heaters have hot and arcing or sparking
parts inside. Do not use in areas where gasoline, paint,
or flammable liquids are used or stored or where the unit
will be exposed to flammable vapours.
13. Do not modify the heater. Use it only as described in
this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock or injury to
persons.
14. Always plug heaters directly into a wall outlet/receptacle.
Never use with an extension cord or relocatable power
tap (outlet/power strip).
15. Always use properly grounded, fused and polarized
outlets.
16. Disconnect all power supply before performing any
cleaning, maintenance or relocation of the unit.
17. When transporting or storing the unit and cord, keep in a
dry place, free from excessive vibration and store so as
to avoid damage.
WARNING: IN ORDER TO AVOID OVERHEATING,
DO NOT COVER THE HEATER. THE MEANING OF
FIGURE IN MARKING IS "DO NOT COVER".

SAVE THESE INSTRUCTIONS

Operation
Figure 1
CAUTION: Ensure that the unit is placed on a firm,
level surface and not located directly below a convience
electrical outlet before operation.
A. On/Off Switch
The On/Off switch supplies power to all unit functions. There
is a light which indicates when the appliance is on.
B. Thermostat
To adjust the temperature to your individual requirements,
turn the thermostat control clockwise all the way to turn
on the heater. When the room has reached the desired
temperature, turn the thermostat knob counter clockwise until
you hear a click. Leave in this position to maintain the room
temperature at this setting.
For additional heat, turn clockwise until you hear the click
again and the heater will turn on.
!
NOTE: Should the heater fail to come on when the thermo-
stat is at a low setting, this may be due to the room temperature
being higher than the thermostat setting.
Maintenance

W ARNING: Disconnect power before attempting any
maintenance or cleaning to reduce the risk of fire, electric
shock or damage to persons.
The appliance contains no moving parts, therefore little
maintenance is required beyond vacuum cleaning. It is
however essential that the heater is not operated with an
accumulation of dust or dirt on the heater, as this can cause
a build up of heat and eventual damage. For this reason
the heater must be inspected regularly, depending upon
conditions and at least at yearly intervals.
A. On/Off Switch
B. Thermostat
7212870100R02
