ROCWARE RC15 Quick Start Manual

1
Product Appearance
2
Packing List
Name
Camera
Quick Start
3
Product Features
1080P Full HD Wide Angle
Support 1080P full HD, can provide 1080P@30fps/25fps image coding
output, and downward compatible with 720P equal resolution. Wide-angle
lens with wider field Angle.
USB 2.0
Full-featured USB 2.0 interface, power supply, video and audio all in one.
Built-in Microphone
Built-in microphone array with omnidirectional sound pickup, the unique
noise suppression algorithm makes your voice perfect presentation.
ROCWARE RC15 Quick Start Guide
Quantity
1
1
EPTZ
There is no need for mechanical transmission, which realizes more
accurate rotation, no noise, more reliable and durable pan-tilt function.
Low Illumination
The application of 2D and 3D noise reduction algorithm greatly reduces the
image noise. Even under the condition of ultra-low illumination, it keeps the
picture clean and clear, and the SNR of image is as high as 55dB.
Easy Installation
Standard damping bracket support, suitable for market 100% monitor, easy
installation, stable and reliable.
4
Product Specifications
Camera
Sensor
Scanning Mode
Lens Mount
Lens
Minimal Illumination
Shutter
White Balance
Camera bracket
Digital Noise
Reduction
Backlight
Compensation
Digital Zoom
USB Feature
Operate System
Color/Compression
Video Format
USB Communication
Protocol
EPTZ
Input/Output Interface
USB Interface
Physical Parameter
Input Voltage
Input Current
Operating
Temperature
Storage Temperature
Power Consumption
Dimension
Net Weight
The manual white balance, digital zoom, EPTZ and other functions can
only be realized by using an application with this function.
1/2.8'', CMOS, Effective Pixel: 2.07M
Progressive
M12
Focus: f=2.2mm
0.5 Lux @ (F2.2, AGC ON)
1/30s ~ 1/10000s
Auto, Manual
Standard Damping Rotary Support
2D&3D Digital Noise Reduction
Support
4x
Windows 7/8/10, Mac OS X, Linux, Android
MJPEG/YUY2/H.264
1080P@30fps/25fps, 720P@30fps/25fps,
960x540P@30fps/25fps,
640x360P@30fps/25fps
UVC 1.1
Support Panning and Zooming
1 x USB 2.0: Type A
5V (USB power supply)
0.27A
-10°C ~ 40°C
-40°C ~ 60°C
1.4W
118mm x 37.2mm x 30.8mm (without bracket)
0.1Kg
