ROCWARE S172C Quick Start

S172C 1080P Ultra-Wide Field USB Camera Quick Start
1

Product Appearance

2

Packing List

3

Product Features

1080P Full HD Wide Angle
Support 1080P full HD, and can provide 1080P@30fps/25fps image coding
output. At the same time, it is compatible with 720P equal resolution
downwards, with wide field of view angle, and the maximum horizontal field
angle can be achieved 83°/84°(Support Auto Focus).
USB 2.0
Full-featured USB 2.0 interface, power supply, video and audio all in one.
Built-in Microphone
Built-in microphone array, it can pick up sound distance up to three meters,
unique noise suppression algorithm, make your voice perfect presentation.
Low-light
The application of 2D and 3D noise reduction algorithm greatly reduces the
image noise. Even under the condition of ultra-low illumination, it still keeps
the picture clean and clear, and the SNR of image is as high as 55dB.
Easy Installation
Standard damping bracket support, suitable for market 100% monitor, easy
installation, stable and reliable.
4

Safety Precautions

Careful Transportation
Transportation, custody and installation process to prevent heavy pressure,
violent vibration, immersion damage to the product.
Careful Installation
This product should be placed on the smooth desktop. The shell of the
product is an organic material and is strictly prohibited from contact with any
liquid, gas or solid material that may cause corrosion to the shell.
Do not Unauthorized Disassemble
This product has no parts which can be repaired by the user. The damage
caused by the user's own disassembly is not covered by warranty.
Electromagnetic fields at specific frequencies may affect image of machine.
5

Product Specifications

Camera
Sensor 1/2.7'', CMOS, Effective Pixel: 2.07M
Scanning Mode Progressive
Lens Mount M12
Lens 1 Focus: f=3.2mm, FOV: 83°
Focus: f=3.5mm, FOV: 84°
Lens 2
(Support Auto Focus)
Minimal Illumination 0.5 Lux @ (F2.0, AGC ON)
Shutter 1/30s ~ 1/10000s
Auto, Indoor, Outdoor, One Push,
White Balance
Manual, VAR
Camera bracket bracket with damper
Digital Noise
2D, 3D digital noise reduction
Reduction
Backlight
Support
Compensation
USB Features
Operate System Windows 7/8/10, Mac OS X, Linux, Android
Color / Compression MJPEG/YUY2/H.264
1080P@30fps/25fps, 720P@30fps/25fps,
Video Format 960x540P@30fps/25fps,
640x360P@30fps/25fps
