Record Product Information
Before setting up and operating your new equipment, please locate the model
plate and record the information in the area provided to the right. The model
plate contains the unit's model and serial numbers. This information will
be necessary, should you seek technical support via our web site, Customer
Support Department, or with a local authorized service dealer.
Read and follow all safety rules and instructions in this manual before attempting to operate this machine.
Failure to comply with these instructions may result in personal injury - SAVE THESE INSTRUCTIONS.
Engine Exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm.
Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and
reproductive harm. Wash hands after handling. www.p65warnings.ca.gov
NOTE: This Operator's Manual covers several models. Features may vary by model. Not all features in this manual are applicable to all models and the model
depicted may differ from yours.
O
'
M
peratOr
s
Pro Z Series
500/700/900 Lapbar
Model Number
Serial Number
WARNING
WARNING
CALIFORNIA PROPOSITION 65
anual
Form No. 769-26265A
(September 30, 2022)
Advertisement
Table of Contents
Related Manuals for MTD Pro Z Series
Summary of Contents for MTD Pro Z Series
- Page 1 Safe Operation Practices • Set-Up • Operation • Product Care • Replacement Parts and Accessories • Warranty ’ peratOr anual Pro Z Series 500/700/900 Lapbar Record Product Information Model Number Before setting up and operating your new equipment, please locate the model plate and record the information in the area provided to the right.
-
Page 2: Safe Operation Practices
SAFE OPERATION PRACTICES WARNING This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. -
Page 3: Slope Operation
SAFE OPERATION PRACTICES 27. Do not attempt to mow unusually tall, dry grass (e.g., pasture) or piles of dry 4. Keep all movements on slopes slow and gradual. Do not make sudden changes in leaves. Dry grass or leaves may contact the engine exhaust and/or build up on the speed or direction. - Page 4 SAFE OPERATION PRACTICES CHILDREN OPERATOR PROTECTIVE SYSTEM (OPS) 1. Tragic accidents can occur if the operator is not alert to the presence of children. 1. This machine is equipped with an Operator Protective System (OPS), Children are often attracted to the machine and the mowing activity. They do not which includes: understand the dangers.
-
Page 5: Safe Handling Of Fuel
SAFE OPERATION PRACTICES 10. Failure to use the seat belt properly could result in serious injury or death if an • Extinguish all cigarettes, cigars, pipes, and other sources of ignition. accidental overturn occurs. In order for the ROPS to be effective, the seat belt •... -
Page 6: Spark Arrestor
SAFE OPERATION PRACTICES 12. Grass catcher components and the discharge cover are subject to wear and When required, models are equipped with low permeation fuel lines and fuel damage which could expose moving parts or allow objects to be thrown. For tanks for evaporative emission control. - Page 7 SAFE OPERATION PRACTICES Symbol Description WARNING - AVOID TIP-OVER/ROLL-OVER INJURY - Do not operate machine on a slope greater than 15° (26%). Do not mow up or down slopes, only mow across slopes that are less than 15° (26%). Use low speeds and avoid sudden turns on slopes. Stay at least 10 feet (3 meters) from drop-offs, ditches, embankments, or the edge of water.
-
Page 8: Contents Of Carton
SET-UP CONTENTS OF CARTON WARNING • Zero-Turn Mower (1) Do not tow the mower, even with the bypass valves engaged. Serious transmission damage will result from doing so. • Battery Installation Hardware (1) • Seat Tilt Knob Assembly & Hardware Pack (1) 5. -
Page 9: Operator's Seat
SET-UP ADJUSTING DRIVE CONTROL LEVERS To adjust the front-to-rear angle of the drive control levers: 1. Loosen the control lever knob (a) to unlock the drive control levers (Figure 6). The RH and LH drive control levers can be adjusted up or down and fore-and-aft for the comfort of the operator. -
Page 10: Seat Adjustment
SET-UP 4. Insert the wiring harness (a) into the bottom of the seat (Figure 9). 7. Remove the seat tilt knob assembly from the bag and install (Figure 12). Figure 12 Figure 9 NOTE: Be sure to orient the recliner plate (a) and install the plastic washer (b), NOTE: When the wiring harness (a) is connected, be sure to push the excess wire spring washer (c) and metal washer (d) (Figure 12). -
Page 11: Seat Suspension
SET-UP Seat Suspension This machine is equipped with an adjustable seat, which includes a retractable seat belt assembly and an Operator Presence Sensor (OPS). The OPS, in the form of a The mechanical suspension mechanism (500 and 700 series) incorporates weight/ switch, is integrated into the seat bottom and is connected to the machine electrical ride adjustment controls for operators in the 125 to 275 lb weight range. -
Page 12: Inflation Pressure
SET-UP Seat Air Ride 1. Using the lever on the back of the seat frame, lift up on the lever and tilt the seat forward locking it in place with the seat prop. Remove the bolts and hex nuts The air ride (900 series) can be adjusted up or down using the height adjustment from the manual bag. -
Page 13: Operation
OPERATION B. TRANSMISSION BYPASS LEVER WARNING Do not tow the mower, even with the bypass valves engaged. Serious transmission damage will result from doing so. The transmission bypass lever is located next to the LH console to the left of the operator’s seat. †... - Page 14 OPERATION NOTE: When the ignition key is out of the STOP position the hourglass symbol WARNING is illuminated/blinks to indicate it is recording the hours of mower operation, Never fill the fuel tank when the engine is running. If the engine is hot from regardless of whether the engine is started.
- Page 15 OPERATION S. TRANSPORT LOCK (NOT SHOWN) • OPERATION: The ROPS should always be in this position when operating unless the situations involved outlined in the TRANSPORT and TRANSPORT WITH BAGGER The transport lock is located on the left side of the descriptions arise.
-
Page 16: Safety Interlock System
OPERATION Manual Throttle/Choke or Throttle/Automatic EFI (Electronic Fuel 3. Never use gasoline containing more than 10% ethanol or methanol. Injection) Engines 4. Check the engine oil level as instructed in the Engine Operator’s Manual. WARNING 5. Check the transmission oil level. The transmission oil expansion reservoir is This machine is equipped with a safety interlock system designed for located beneath the operator’s seat. -
Page 17: Cold Weather Starting
OPERATION Practice Operation (Initial use) 6. Turn the ignition key clockwise to the START position and release it as soon as the engine starts; however, do not crank the engine continuously for more than 10 Operating a zero-turn mower is not like operating a conventional type riding mower. seconds at a time. - Page 18 OPERATION Forward Left Turn WARNING Always maintain a firm grip on the control levers. Do not release the control levers to slow or stop the mower; move levers to neutral position using your hands. 5. To drive the mower, firmly grasp the respective drive control levers with your right and left hands and continue with Driving the Mower Forward.
- Page 19 OPERATION 3. To slow the mower move the control levers forward to attain the desired speed, 2. To turn clockwise, move the left control lever forward while simultaneously or move the levers to the neutral position to stop the mower. moving the right control lever rearward (Figure 31).
-
Page 20: Driving On Slopes
OPERATION 4. If dismounting the mower, move the drive control levers fully outward in the 1. Use the deck lift pedal (a) to raise the deck to its highest position, place the clevis neutral position, engage the parking brake, move the throttle control lever (if pin (b) attached to the mower into the desired index hole on the deck height equipped) to the FAST position, turn the ignition switch to STOP and remove... - Page 21 OPERATION Mower Cutting Blades Medium-lift — These blades require less horsepower than the hi-lift, and they generally work well in wider leaf grasses and some mulch applications. The blades normally factory installed on a mower afford the best grass cutting performance on the majority of grasses and mowing conditions;...
-
Page 22: Product Care
PRODUCT CARE MAINTENANCE SCHEDULE Follow the Maintenance Schedule given below. This chart describes service guidelines only. WARNING Refer to the Engine Operator’s Manual for engine maintenance items listed in the Before cleaning, repairing, or inspecting, make certain the blade(s) and all table below. - Page 23 PRODUCT CARE OIL CHART Number of Oil Points Description Apply a few drops of SAE engine oil, grease or DAILY use a spray lubricant. Apply the oil to both sides Deck Suspension Pivots of pivot points. Wipe off any excess. Start engine Height Adjustment Turnbuckle Clevis Pin and operate mower briefly to ensure that oil spreads evenly.
-
Page 24: Storing The Mower
PRODUCT CARE Storing the Mower • Clean around the exhaust manifold, fuses, all wiring and harnesses, muffler pipe, muffler shield, engine intake screens and cooling fins, etc (Figure 34). • Allow the machine to cool in an open area before storing. •... -
Page 25: Battery Information
PRODUCT CARE 8. Replace the oil filter and refill the engine with new oil as instructed in the BATTERY STORAGE Engine Operator’s Manual. Refer to the Engine Operator’s Manual for information 1. When storing the mower for extended periods, disconnect the negative battery regarding the volume and weight of engine oil. - Page 26 PRODUCT CARE 1. Engage the transmission bypass valves by pulling the bypass lever (a) upward and 4. Replace the filter and drain plug (torque to 115-135 in-lbs) and fill the all the way back (Figure 39). transmission assembly to 1/8” up on the dipstick. 5.
-
Page 27: Side-To-Side Leveling
PRODUCT CARE Removing the Mower from Storage 3. Using a pair of needle-nose pliers or a magnet remove the filter. 1. Check the engine oil. 4. Replace the filter and drain plug (torque to 115-135 in-lbs) and fill through the expansion reservoir slowly until the “FULL COLD”... -
Page 28: Front-To-Back Leveling
PRODUCT CARE FRONT-TO-BACK LEVELING 1. Park the mower on a flat paved surface, engage the parking brake, shut off the engine, remove the key from the ignition switch and disconnect the spark plug wires. Using the deck lift pedal position the mowing deck into the 4” height of cut position (The 4”... - Page 29 PRODUCT CARE Servicing Electrical System Rear Tire Removal/Replacement FUSE 1. Remove the four lug nuts (a) to remove the tire (Figure 46). Always use the same capacity fuse for replacement. If you have a recurring problem with blown fuses, have the mower’s electrical system checked by your authorized service dealer.
- Page 30 PRODUCT CARE Replacing the PTO Belt 3. Using a 1/2” drive in the idler pulley bracket (a), turn the wrench towards the right of the mower and slide the PTO belt (b) off the PTO pulley (c) (Figure 48). 1. Remove the PTO belt (a) from the deck as instructed in the Deck Removal section then remove it from around the PTO clutch (Figure 51).
-
Page 31: Replacing The Blades
PRODUCT CARE 6. Route the new belt (Figure 53). Then reinstall the deck and PTO belt. 2. Carefully place the flat washer on the spindle shaft. Be sure that the splines at the base of the spindle shaft threads line up with the washer splines (Figure 56). Replacing the Blades WARNING Before cleaning, repairing, or inspecting, make certain the blade(s) and all... - Page 32 PRODUCT CARE 4. Test the blade’s balance using a blade balancer. Grind metal from the heavy side 8. Remove the hex flange bolt (a) and flat washer (b) securing the drive pulley (c) until it balances evenly. and center spindle pulley (d) to the spindle assembly (e) (Figure 59). NOTE: When replacing the blade, be sure to install the blade with the side marked ‘‘Bottom’’...
-
Page 33: Troubleshooting
PRODUCT CARE TROUBLESHOOTING WARNING Before cleaning, repairing, or inspecting, make certain the blade(s) and all moving parts have stopped. Turn off the engine, remove the key, disconnect the spark plug wire(s) and the negative battery cable to prevent unintended starting. Always wear safety glasses or safety goggles during operation and while performing an adjustment or repair to protect your eyes. -
Page 34: Replacement Parts And Accessories
REPLACEMENT PARTS AND ACCESSORIES REPLACEMENT PARTS ATTACHMENTS AND ACCESSORIES Part Number Description Part Number Description 954-05127 Deck Belt (54” Deck) 59A30060150 Triple Bagger 954-04319 Deck Belt (60/72” Decks) 59A30061150 54” Blower Kit 954-04327 PTO Belt (54” Deck) 59A30062150 60” Blower Kit 954-05128 PTO Belt (60”... - Page 35 NOTES...
- Page 36 NOTES...
- Page 37 NOTES...
- Page 38 CUB CADET LLC -- LIMITED WARRANTY The limited warranty set forth herein is given by Cub Cadet LLC with respect to a new Cub Cadet® product (hereinafter “Product”) purchased and used in the United States and/or Canada to the Initial Purchaser (as defined herein). This limited warranty does not cover Emission Control Systems and is not a Federal Emission Control Warranty Statement, as defined by U.S.
-
Page 39: Warranty & Service
LLC at P.O. Box 368023, Cleveland, Ohio 44136-0019, or call 1-877-282-8684, PARTS AS IDENTIFIED. NO OTHER EXPRESS WARRANTY OR GUARANTY, or log on to our Website at www.cubcadet.com. For Canada, contact MTD WHETHER WRITTEN OR ORAL, EXCEPT AS MENTIONED ABOVE, GIVEN... -
Page 40: Slope Gauge
SLOPE GAUGE...
