Summary of Contents for Satel CSP ROP-110/EU
- Page 1 Conventional manual call point ROP-110/EU Firmware version 1.00 rop-110_en 01/23 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 IMPORTANT The device should be installed by qualified personnel. Prior to installation, please read carefully this manual in order to avoid mistakes that can lead to malfunction or even damage to the equipment. Disconnect power before making any electrical connections. Changes, modifications or repairs not authorized by the manufacturer shall void your rights under the warranty.
- Page 3 This manual applies to the ROP-110/EU conventional manual call point for indoor use. The ROP-110 call point is used to manually trigger an alarm when a fire is discovered. The call point is designed to work with the CSP-104, CSP-108, CSP-204 and CSP-208 fire alarm control panels.
-
Page 4: Installation
1. Place the mounting box against the wall and mark the location of the mounting holes (Fig. 2). The mounting box is sold separately. SATEL offers the ROP-BT and ROP-BS surface mounting boxes. Instead the SATEL surface mounting boxes, you can use a flush-mounted box (Fig. - Page 5 SATEL ROP-110...
- Page 6 ROP-110 SATEL...
- Page 7 SATEL ROP-110 4. ROP-FLAP You can install the ROP-FLAP on the call point (Fig. 13). It is a transparent protective cover that prevents unintentional activation of the call point. The flap is sold separately.
-
Page 8: Maintenance
ROP-110 SATEL 5. Maintenance The fire alarm system elements require regular maintenance. The periodic checks of the ROP-110 manual call point should be carried out at least every 6 months. In spaces where working conditions are difficult (e.g. dust, aggressive environment that may cause corrosion, etc.), the periodic checks should be carried out more often. - Page 9 The ROP-110/EU manual call point has been granted the Certificate of Admittance No 4832/2023 by the CNBOP-PIB in Józefów. The Certificate of Admittance can be downloaded from the www.satel.pl website. SATEL Sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND 1438 1438-CPR-0878...
