ADDER ADDERView Secure AVS-4128 Quick Start

NIAP protection profile
This product is certified to the NIAP protection profile PSD version 4.0 certification for peripheral
sharing devices.
Security Vulnerability
• Web form: https://www.adder.com/en/support/contact-support
• Email: compliance@adder.com
• Tel: +44 (0)333 2079766
Notes and warnings
• Note: Holographic anti-tampering labels protect the product's enclosure, providing a clear visual
indication if it has been opened or compromised.
• WARNING: For security reasons, this product does not support wireless keyboards. It is
recommended not to connect a microphone of headset to the audio output port.
• WARNING: If the unit's enclosure appears disrupted or if all of the indicators are flashing
continuously, remove the product from service immediately and contact Technical Support.
• Maximum allowable ambient temperature: 40
Dimensions
• 444 (W) x 155 (D) x 44 (H) mm, weight 2.6 kg
Supplied power adapter
• Input: 120 to 240VAC, 50 to 60Hz, autoswitching.
• Output: 12VDC, 2.5A maximum.
www.adder.com
© 2023 Adder Technology Limited • All trademarks are acknowledged.
Part No. MAN-QS-000038_V1.3
C.
O
ADDERView
Welcome
This quick start guide covers some of the key points of the ADDERView Secure model: AVS-4128
The ADDERView Secure 8-port High Security Flexi-Switch allows you to work simultaneously on two
computers, view the extended screens of all computers. You can connect two displays and up to eight
computers to the Flexi-Switch unit. Select which computer to present on each display or duplicate the
output of any computer by presenting it on both displays simultaneously.
Keyboard/ Audio Hold
mouse button button
Toggles Allows you to listen Press a button to connect
association to audio from one the console peripherals to
between computer while the corresponding computer.
computers. working with An indicator will illuminate
another.
Do not connect this product to computing devices that:
• are TEMPEST computers,
• include telecommunication equipment,
• include frame grabber video cards,
• include special audio processing cards.
Secure
™
8-Port High Security Flexi-Switch
Quick Start
Computer channel Display screen
buttons
Provides status
information related to
the current operations.
on the selected button.
