StreamLight BANDIT Manual

SPECIFICATIONS

LED Radiation (RG-2) -
Do not stare into beam. May be harmful to eyes.

SPECIFICATIONS
Runtime: 3.25 hrs (Flash)

Use of light in "strobe" mode maycause seizure in persons with photosensitive epilepsy.

GENERAL OPERATION

You must charge the battery before using the Bandit to disable the Packaged "Try Me Mode" functionality.
Once the light is charged, the light will function as described below in Light Function.

Light Function
The Bandit^® features an on/off switch and two brightness levels, Low/High and Off. Each press of the button within 1.5 seconds will step to the next level or off. Wait more than two seconds between button presses and the next press will turn the light off. Press and hold the on/off button down for three (3) seconds to access strobe mode. Press and hold the button again for three seconds to go back to normal low/high/off operation.

Charging the Streamlight Lithium Polymer Battery
To charge the lithium polymer battery slide your finger nail under the rubber USB cover on the bottom of the light. Peel it back to expose the Micro USB connector.
Using the supplied cord, plug the Micro USB connector into the mating socket on the light. Be sure to align the connector in the correct orientation to the socket. Then, plug the standard USB connector into a USB port on your computer or other USB accessible port.

warning
NOTE: The lights case is ultrasonically sealed closed and the battery is not replaceable.

Charge Indication LED
Light features charge indicator LEDs in the button:

LED Red: Charging
LED Green: Fully Charged

Charge Time
The light has a digital control circuit that prevents overcharge. The battery fully recharges in approximately 2.5 hours, depending on your USB power connection.

warning
NOTE: The 2.5 hour charge time assumes 1000 mA output of a typical AC/USB charger. (Most computer
SB power ports range from 100 to 500 mA.)

Run Time Note
There is "no end of run time notification." The light will simply turn off when the battery power is fully depleted.

Streamlight's Warranty

Streamlight warrants its Bandit^® "Non-replaceable 450ma lithium polymer battery rated at 300-400 discharges" will be free from manufacturing defects under normal use for 24 months after purchase. During the warranty period, at its sole discretion,
Streamlight will repair or replace any defective part or product.
THIS IS THE ONLY WARRANTY, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARE EXPRESSLY DISCLAIMED EXCEPT WHERE SUCH LIMITATION IS PROHIBITED BY LAW.
You may have other specific legal rights which vary by jurisdiction.

Go to www.streamlight.com/support for a complete copy of the warranty, and information on product registration and the location of authorized service centers. Retain your receipt for proof of purchase.

Customer Service
STREAMLIGHT, INC.
30 Eagleville Road, Suite 100
Eagleville, PA U.S.A. 19403-3996
Phone: (800) 523-7488 Toll-Free
Fax: (800) 220-7007
www.streamlight.com
