Tews Technologies TPCE280 User Manual

Pci express x8, gen3 xmc carrier

Advertisement

Quick Links

The Embedded I/O Company
TPCE280
PCI Express x8, Gen3 XMC Carrier
Version 1.0
User Manual
Issue 1.0.3
January 2022
TEWS TECHNOLOGIES GmbH
Am Bahnhof 7
25469 Halstenbek, Germany
Phone: +49 (0) 4101 4058 0
Fax: +49 (0) 4101 4058 19
e-mail:
info@tews.com
www.tews.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPCE280 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tews Technologies TPCE280

  • Page 1 The Embedded I/O Company TPCE280 PCI Express x8, Gen3 XMC Carrier Version 1.0 User Manual Issue 1.0.3 January 2022 TEWS TECHNOLOGIES GmbH Am Bahnhof 7 25469 Halstenbek, Germany Phone: +49 (0) 4101 4058 0 Fax: +49 (0) 4101 4058 19 e-mail: info@tews.com...
  • Page 2 I/O, J16 I/O, JTAG connections to XMC module via 14-pin header TEWS TECHNOLOGIES GmbH is not liable for any TPCE280-20R damage arising out of the application or use of the device described herein.
  • Page 3 LEDs 1.0.2 Corrected the J15 pinout table to x8 pinout, was x4 September 2020 1.0.3 Order Options -2xR: removed the PCIe VGA power connector January 2022 adapter cable TPCE280 User Manual Issue 1.0.3 Page 3 of 20...
  • Page 4: Table Of Contents

    Table of Contents PRODUCT DESCRIPTION ................... 6 TECHNICAL SPECIFICATION ..................7 HANDLING AND OPERATING INSTRUCTIONS ............8 ESD Protection ..........................8 Installation of TPCE280-2xR ......................8 XMC INTERFACE ......................9 Power ............................... 9 4.1.1 VPWR Tolerance ........................9 4.1.2 Power Limits for XMC Modules ....................9 4.1.3...
  • Page 5 List of Figures FIGURE 1-1 : TPCE280 BLOCK DIAGRAM ..................... 6 FIGURE 5-1 : JTAG VOLTAGE ROTARY SELECTOR SWITCH LOCATION, MARKED RED (TOP VIEW OF TPCE280) ............................11 FIGURE 6-1 : ON-BOARD LED PLACEMENT ....................12 List of Tables TABLE 2-1 : TECHNICAL SPECIFICATION ..................... 7 TABLE 4-1 : CURRENT LIMITS FOR THE XMC MODULES ................
  • Page 6: Product Description

    XMC P16 Rear-I/O is implemented through two Samtec Firefly UCC8 and UEC5 connectors providing access to the P16 I/O lines. The TPCE280 provides a fan mounted under the XMC slot that helps cooling the system. This fan does not occupy a second PCIe slot as most other carrier solutions do.
  • Page 7: Technical Specification

    If FIT rates are not available, MIL-HDBK-217F and MIL-HDBK-217F Notice 2 formulas are used for FIT rate calculation. Humidity 5 – 95 % non-condensing Weight TPCE280: 98 g Table 2-1 : Technical Specification TPCE280 User Manual Issue 1.0.3 Page 7 of 20...
  • Page 8: Handling And Operating Instructions

    3 Handling and Operating Instructions ESD Protection The TPCE280 is sensitive to static electricity. Packing, unpacking and all other handling of the TPCE280 has to be done in an ESD/EOS protected Area. Installation of TPCE280-2xR For the TPCE280-2xR variants, it is imperative to always connect a PCI Express VGA power connector to the TPCE280, even if no XMC is mounted.
  • Page 9: Xmc Interface

     -12V (optional XMC voltage, available via order option) As the ±12V supplies are optional and VPWR can be 12V or 5V, it depends on the TPCE280 order option which supplies are available and what voltage level is provided as VPWR.
  • Page 10: Stable Power Supply

    If the XMC has a front panel, first remove the cover from the XMC front panel cut-out of the TPCE280. Install the XMC at an angle so that the XMC front panel pushes through the XMC front panel cut-out. Then rotate down to mate with the XMC connectors on the TPCE280.
  • Page 11: Jtag

    5 JTAG There is one JTAG chain present on the TPCE280. This chain connects the 14-pin JTAG header with the XMC slot. There are no JTAG-capable devices onboard the TPCE280, so the XMC is the only “device” in this chain.
  • Page 12: Indicators

    6 Indicators LED Indicators The TPCE280 provides a couple of board-status LEDs as shown below. All LEDs are labeled on board for better recognition. Figure 6-1 : On-board LED Placement Color State Description 3.3V Power Supply is not OK +3.3V 3.3V Power Good...
  • Page 13: Pin Assignments

    4) WAKE# is connected to the PCIe edge card connector, so it is up to the mainboard to provide for this signal. If a different configuration is needed, please contact TEWS. 5) ROOT# is not supported; this pin is not connected on the TPCE280 by default. If a different configuration is needed, please contact TEWS.
  • Page 14: Xmc J16 I/O Connector

    Tx0- Tx1- TX0+ Tx1+ Tx2- Tx3- Tx2+ Tx3+ DIG_IO_00- DIG_IO_01- DIG_IO_00+ DIG_IO_01+ DIG_IO_02+ DIG_IO_03+ DIG_IO_02- DIG_IO_03- Rx3+ Rx2+ Rx3- Rx2- Rx1+ Rx0+ Rx1- Rx0- Table 7-2 : Pin Assignment X5 UEC5 TPCE280 User Manual Issue 1.0.3 Page 14 of 20...
  • Page 15: Table 7-3 : Pin Assignment X5 Ucc8

    Firefly Micro Flyover Connector Source & Order Info Samtec – UCC8-010-1-H-S-2-A X5 Pin Signal Name J16 Pin +3.3V PRESENTL SELECTL INTL RESETL n.c. +3.3V Table 7-3 : Pin Assignment X5 UCC8 TPCE280 User Manual Issue 1.0.3 Page 15 of 20...
  • Page 16: X6 - Firefly Micro Flyover Connector #2

    Tx4- Tx5- TX4+ Tx5+ Tx6- Tx7- Tx6+ Tx7+ DIG_IO_04- DIG_IO_05- DIG_IO_04+ DIG_IO_05+ DIG_IO_06+ DIG_IO_07+ DIG_IO_06- DIG_IO_07- Rx7+ Rx6+ Rx7- Rx6- Rx5+ Rx4+ Rx5- Rx4- Table 7-4 : Pin Assignment X6 UEC5 TPCE280 User Manual Issue 1.0.3 Page 16 of 20...
  • Page 17: Table 7-5 : Pin Assignment X6 Ucc8

    Firefly Micro Flyover Connector Source & Order Info Samtec – UCC8-010-1-H-S-2-A X6 Pin Signal Name J16 Pin +3.3V PRESENTL SELECTL INTL RESETL n.c. +3.3V Table 7-5 : Pin Assignment X6 UCC8 TPCE280 User Manual Issue 1.0.3 Page 17 of 20...
  • Page 18: Xmc J14 I/O Connector

    I/O 62 (I/O30-) I/O 61 (I/O30+) I/O 64 (I/O31-) I/O 63 (I/O31+) Table 7-6 : X4 - J14 I/O Pin Assignment All +/- pairs are routed differential, impedance controlled and equal-lengthed. TPCE280 User Manual Issue 1.0.3 Page 18 of 20...
  • Page 19: X8 - 14-Pin Jtag Header

    Molex 87832-142 (180°) Pin Assignment Description Connector View Description VREF HDR_EN# *) Table 7-7 : X5 – 14-pin JTAG Header Pin Assignment *) The JTAG cable has to connect this pin to GND TPCE280 User Manual Issue 1.0.3 Page 19 of 20...
  • Page 20: X3 - Pcie Vga Graphics Power Connector

    GND *) +12V Table 7-8 : X3 – 6-pin Auxilliary Power Connector *) The TPCE280 connects this pin to GND and does not do any power supply detection with this pin. TPCE280 User Manual Issue 1.0.3 Page 20 of 20...
